Omega OTMF450X Manuel utilisateur
Instruction Manual
Fridge Freezer
Top Mount 415L
OTMF450X
2
Thank you for purchasing an Omega appliance
Tailored for the modern aesthetic and lifestyle of busy people, your new Omega Appliance will make a
welcome addition to the family.
Omega caters to style-savvy customers who look for balance between stunning form and clever function.
This means a combination of sleek, chic, sophisticated design yet effortless functionality.
And we source from the best. The best craftsmanship. The best innovation. From the best international
design-houses.
All brought together under an appliance that stands for design-led balance.
Please take the time to read through the following instruction manual to familiarise yourself with the
installation, operation requirements and maintenance to ensure optimum performance.
Further Information
For important information about your Omega Appliance such as warranty registration, manuals, features,
and specifications please visit omegaappliances.com.au (if you are in Australia) and
omegaappliances.co.nz (if you are in New Zealand) or contact our Customer Care team on the below email
or phone numbers.
Registering Your Warranty
For peace of mind you can register your warranty at omegaappliances.com.au. Further information on the
Warranty can be found at the end of this manual.
Contact Us
Our customer service team is here to help you with any question or concern.
Both teams are on call Monday to Friday 8.30am to 5.00pm and of course you can always send an email at
your convenience.
Australia Contact Details
Monday to Friday 8.30am – 5.00pm
Email: [email protected]om.au
Phone: 1300 739 033
New Zealand Contact Details
Monday to Friday 8.30am – 5.00pm
Email: [email protected]
Phone: 09 415 6000
To stay up to date and find simple and easy recipes, follow us on our socials:
facebook.com/omegaappliances
instagram.com/omegaappliances_aus
3
READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING THE
AP
P
LIAN
CE.
It is important that you retain these instructions, proof of purchase as well as other important documents about
this product for future reference.
The manufacturer will not be responsible for any damage to property or to persons caused by incorrect
installation or improper use of the appliance.
Due to continual product development, Omega reserves the right to alter specifications and appearances without
notice.
Contents
Important Safety Warnings.............................................................................................................................................. 4
Installation Instruction……………………………………………………………………………………………………………………………………………….6
Operation Installation……………………………………………………………………………………………………………………………………………… 13
Care and Maintenance……………………………………………………………………………………………………………………………………………..15
Trouble Shooting………………………………………………………………………………………………………………………………………………………17
New Zealand Product Warranty Statements of Standard Warranty Conditions………………………………………………………18
Disposal Information
•Most of the packaging materials are recyclable. Please dispose of these materials through your local recycling
depot or by placing them into appropriate collection containers.
•If you wish to discard this product, please contact your local authorities and ask for the correct method of
disposal.
4
Important Safety Warnings
Read the safety precautions and assembly instruction section of this booklet carefully before removing the contents of
this carton.
1. This appliance is not to be use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
2. The appliance must be disconnected from the source of electrical supply before attempting the installation of
accessory.
3. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
4. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than
those recommended by the manufacturer.
5. WARNING: Do not damage the refrigerant circuit.
6. WARNING: Do not use electrical appliances inside the food storage compartments of the appliance.
7. When disposing of this appliance, please do so according to local regulations as it contains flammable gas and
refrigerant.
8. Do not store explosive substances such as aerosol cans with flammable propellant in this appliance. Do not
modify this appliance.
9. This appliance is intended to be used in household and similar applications such as:
-Staff kitchen areas in shops, offices and other working environment.
-Farm house.
-By clients in hotels, motels and other residential type environments.
-Bed and breakfast type environments.
-Areas for communal use in blocks of flats or in launderettes.
10. WARNING: When positioning the appliance, ensure the supply cord is not trapped or damage.
11. WARNING: Power plug must be accessible after installation.
12. WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
13. If the supply cord is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or a
similarly qualified person in order to avoid a hazard.
14. Follow the installation requirements in this manual. Avoid prolonged exposure to direct sunlight.
15. Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
16. Do not place hot items on plastic areas of appliance. Do not refreeze food once defrosted. Store pre‐packed
frozen food in accordance to the manufactures instructions. Take care when freezing liquids as sealed
containers can explode under pressure.
17. The refrigerant R600a contained within the refrigerant circuit of the appliance is a natural gas with a high level of
environmental compatibility, which is nevertheless flammable.
18. During transportation, installation and servicing of the appliance ensure that none of the components of the
refrigerant circuit are damaged.
19. Avoid open flames and sources of ignition.
WARNING
: Risk of fire / flammable materials
5
Warnings for Disposal
•Refrigerant and cyclopentane foaming material used for the refrigerator are flammable. Therefore when the
refrigerator is scraped, it shall be kept away from any fire source and be recovered by a special recovering
company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the
environment or any other harm.
•When the refrigerator is scraped, disassemble the doors, and remove gasket of door and shelves, put the doors
and shelves in a proper place, so as to prevent trapping hazard.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household wastes. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the return and collection systems or
contact the retailer where the product was purchased. They can take this product for environmental safe recycling.
6
Installation Instruction
Unpacking the appliance
•Before use, remove all packing materials, including bottom cushions, foam pads and tapes inside of the
refrigerator; tear off the protective film on the doors and the refrigerator body.
•Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or watery places to prevent
rust or reduction of insulating effect.
•Do not spray or wash the refrigerator; do not put the refrigerator in moist places easy to be splashed with
water so as not to affect the electrical insulation properties of the refrigerator.
•The refrigerator is placed in a well-ventilated indoor place; the ground shall be flat, and sturdy.
Electrical and product Details
Rated Voltage/Frequency 220~240V/50Hz
Rated Defrost Power 190 W
Rated Current 1.3 A
Refrigerant R600a (56g)
Insulation Blow Gas Cyclopentane
Product Dimensions WxDxH 705x680x1780mm
Net Weight 68Kg
Location
When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase
the electrical consumption. Extreme cold ambient temperatures may also cause the unit not to perform properly. This
unit is not designed for use in a garage or outdoor installation. Do not drape the unit with any covering.
When installing the unit, ensure that 5cm of free space is left at both sides, 10cm at the rear and 10cm at the top of the
unit. This will allow cold air to circulate around the refrigerator and improve the efficiency of the cooling process.
7
Product Overview
8
Installation Instruction
Door Reversibility
Before reversing the door, please be prepared below tools and material: straight screwdriver, cross
screwdriver, spanner and the components included in the poly bag:
1. Close upper door, take out the screw from the top hinge covers by cross screwdriver. Take off hinge cover,
disconnect the terminal, then unscrew top hinge and take off upper door.
2. Please upwarp and take off plastic cover and wire sleeve by straight screwdriver. Please be careful of the
wire inside. Then move wire with connector to another side and install wire sleeve to another side and fix
cover back.
3. Unscrew from the middle hinge by cross screwdriver, then take off the lower door.
9
Installation Instruction
4. Laying down the refrigerator, take out the adjusting feet as below, then unscrew the lower hinge by cross
screwdriver.
5. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it.
6. Refit the bracket fitting the bottom hinge pin. Replace both adjustable feet. Transfer the lower door to the
property position.
7. Make the middle hinge reverse the direction180 degrees, then transfer it to the left property position. Make
the middle hinge pin in the upper hole of the lower door, then tight the screws.
10
Installation Instruction
8. Unscrew right middle stopper with metal block from bottom of upper door. And then install left middle stopper
and metal block in left side of bottom of upper door.
9. Install the upper door, fix the upper door hinge onto the cabinet and connect the wire.
10. Take left hinge cover from accessories bag and install it with top hinge. Then install hole cover at right side.
