Omega Altise ODE10 Manuel utilisateur

ODE10

10 Litre Dehumidifier

Instruction

Manual

omega altise

Important Safety Instructions

1. Read all instructions.

2. Disconnect the power plug before dismantling, assembling or before cleaning.

3. Avoid touching mobile parts of the unit.

4. Make sure the unit is on a dry and even surface.

5. Never insert fingers, pencils or any other objects though the guards whenever

the power plug is connected, especially while running.

6. The appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervised or instruction concerning

use of the appliance by a responsible person for their safely.

7. Young children or infirm persons should be supervised to ensure that they do not

play with the appliance.

8. Do not use the appliance for any other purpose than its intended use.

9. The unit must not be used if the guards are not fastened according to

instructions.

10. When the power cord is damaged, it must be replaced by the manufacturer or its

service agent or a similarly qualified person in order to avoid a hazard.

11. Do not use your appliance with an extension cord unless it has been checked

and tested by a qualified electrician or electrical supplier.

12. Return to Hagemeyer or authorised service agent.

13. Leave the unit to stand for one hour before connecting to the mains supply after

transport or when it has been tilted (e.g. during cleaning).

Read all instructions before using this unit. Keep them for future reference.

omega altise

Specifications

Model no. ODE10

Power supply 230-240V~, 50Hz

Test condition DB 30oC, RH 80%

Dehumidification capacity 10 L/day

Power consumption 260 W

Air volume (max.) 70m3/h

Compressor Reciprocating

Refrigerant R134a

Working range 5 ~ 32oC

Water tank 3.6 L

Size (w x d x h) 342 x 245 x 492 mm

N.W. 11.5 kg

omega altise

How a Dehumidifier works

This product is a dehumidifier. It controls relative humidity by passing the air through

the unit, forcing the excess moisture to condensate over the cooling elements.

Contact with this cold surface causes the moisture in the air to condense. This

condensed water then drains safely into the water tank. The dried air then passes

through the condenser where it is slightly warmed and re-enters the room at a

slightly elevated temperature.

Where to position the unit

Excess moisture will travel throughout your home, in the same way that cooking

smells waft to every room in the house. For this reason, the dehumidifier should be

positioned, so that it can draw this moist air towards it from all over the home.

Alternatively, if you have a serious problem in one area you can begin by positioning

the dehumidifier close to this area and later moving it to a more central point.

When positioning the dehumidifier, ensure that it is placed on a level surface and

that there is a minimum of 10 cm (4") of space on either side of the unit to allow for

efficient airflow.

This dehumidifier is fitted with castors for extra mobility, if you move the unit, it

should first be switched off and the water tank emptied.

We do not recommend the use of an extension lead, so please try to ensure that the

unit is sufficiently close to a fixed mains socket. If it is necessary to use an extension

lead, please ensure the diameter of the wires of the cable are at least 1mm2.

When the dehumidifier is in operation, outside doors and windows should be closed

when necessary for most efficient use.

omega altise

Parts List

Front

1. Control panel

2. Air inlet

3. Filter (inside the unit

4. Water tank

5. Castor

6. Handle for water tank

7. Handle for the unit

Rear

8. Air outlet

9. Hole for continuous drainage

10. Power cable

Control Panel

11. Water full indicator

12. Operation indicator

13. On/off humidistat controller

omega altise

Operating Instructions

1. Plug the unit into a correct mains socket.

2. To turn the unit on turn the humidistat control

clockwise.

3. The humidistat (humidity controller) also

controls the required humidity level. The

intensity of humidity extraction is increased

clockwise

4. For continuous working, set the humidistat to

position 'MAX'.

5. To turn off the unit turn the humidistat to OFF position.

Drainage

Whenever the water tank is full, or the water tank is not positioned properly, the

compressor will stop and the water full indicator will turn red.

To remove the water tank, use the handle to pull the tank out squarely from the unit.

After empting, replace the water tank. The tank will need to be properly positioned in

order for the 'water full' sign to cancel and your dehumidifier will start operating.

omega altise

Continuous Drainage

When the dehumidifier is operated at very high humidity levels, the water tank will

require more frequent drainage. In this situation, it may be more convenient to set

the unit up for continuous drainage with the following procedures:

1. Pull out the stopper from the

drain hole A at the rear of the

machine ( see FIG. 1) and

connect the drain hole A with a

water tube of inner diameter 12

mm. (FIG.2)

* Please note, the water tube is

not supplied with the unit.

2. Pull out the water tank. Use the

stopper taken from Hole A to

stick into drain Hole B (FIG. 3).

3. Ensure the water will always

drain away freely and the tube

will remain in right place. Note!

In very cold weather conditions,

precautions should be taken to

prevent the water tube from

freezing.

4. Put the water tank back to its

position (FIG. 4).

Hole A

omega altise

Care and Maintenance

lways disconnect the cord from the electrical outlet when cleaning the unit.

LEANING THE BODY e the unit clean.

LEANING THE AIR FILTER

2. m cleaner or tap the filter

3. irty, use warm water

4. ry before

5. r to sunlight.

torage

you do not use the unit for an extended period of time, please turn the unit off,

1. Use a soft cloth to wip

2. Do not use volatile chemicals, gasoline,

detergents, chemically treated cloths or

other cleansing solutions as they could

possibly damage the unit.

1. Remove the water tank and extract the

filter holder

Use a vacuu

lightly for easy cleaning.

If the filter is particularly d

with a small amount of detergent.

Make sure the filter is completely d

placing into position.

Do not expose the filte

unplug and tidy power cord, completely empty the water tank and wipe it clean.

Cover the unit and store where it will not receive direct sunlight.

omega altise

Trouble Shooting

The unit does not operate:

• Is the unit plugged in?

• Is the house electricity on?

• Is the room temperature below 5oC or above 32oC? If so,

then it is out of the working range of the unit.

• Ensure the humidistat (or ON/OFF switch) is turned on.

• Check the water tank is positioned properly in the unit and

it is not full.

• Make sure the air inlet and outlet are not obstructed.

The unit seems to do nothing:

• Is the filter dusty, contaminated?

• Is the air intake or outlet blocked up?

• Is the room humidity already quite low?

The unit seems to do little:

• Are too many windows or doors open?

• Is there something in the room producing lots of humidity?

The unit is too noisy:

• Check whether the unit is sitting on a level surface.

The unit is leaking:

• If you are not using continuous drainage, make sure the

rubber plug (at the bottom of the unit) is in its position.

CAUTION! Do not immerse the unit in water or allow water to drip into

the interior of the unit housing as this could create a fire or electric

shock hazard.

WARNING! Do not attempt to repair the unit yourself. Doing so could

void the warranty and cause damage or personal injury.

Omega Altise products are distributed in Australia by MEA,

(A Division of Hagemeyer Brands Australia Pty Ltd)

ABN 28 001 375 686

Locked Bag 4013, Kingsgrove NSW 2208

Phone: 1300 739 033

Fax: 1800 838 899

Email: [email protected]

Web: meaappliances.com.au
