Olympia OC 800 Manuel utilisateur
IP-Kamera OC 800
Quick Start Guide
...easy to operate with ProHomeIPC
Do you need detailed descriptions on
how to use the app and operate the
camera?
Visit us at www.olympia-vertrieb.de
Or scan this QR code.
Contents
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Intended Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
General Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connecting the Camera . . . . . . . . . . . . . . . . . . . . . . . . . 12
1. Connecting the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . 14
2. Connecting the Camera - Network Cable . . . . . . . . . . . 14
3. Installing the ProHomeIPC App . . . . . . . . . . . . . . . . . . . 15
4. Establishing a Connection. . . . . . . . . . . . . . . . . . . . . . . . 16
5. Last Step Prior to Assembly . . . . . . . . . . . . . . . . . . . . . . 18
6. Determining the Installation Location. . . . . . . . . . . . . . 18
7. Installing the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8. Aligning the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4IP-KAMERA OC 800
BEFORE YOU START
Before You Start
Read the operating manual thoroughly and observe all
the information contained when using the IP camera.
Keep the operating manual in a safe place for future
reference.
Pay attention to this symbol. Texts which are highlighted
by this symbol provide helpful information on handling
the IP camera.
Detailed Operating Instructions . . . . . . . . . . . . . . . . . . . . . . 21
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Guarantee and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Information on Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Information on Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Legal Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5
IP-KAMERA OC 800
SAFETY INSTRUCTIONS
Safety Instructions
The following warnings indicate potentially dangerous situa-
tions which could lead to serious injuries or even fatal injuries
if the information is ignored.
WARNING! Risk of fatal injury from electric shock! NEVER
use the device if you suspect damage to the power cable
or power plug or there are visible signs of damage to the
power cable or power plug.
WARNING! Risk of suocation! Children can swallow
small parts, packaging and protective foils. Keep the
device and packaging out of reach of children.
NEVER complete any repairs to the device yourself.
Never open the device because it contains no compo-
nents which you may service yourself. In the event of a
fault, contact our Service Department.
The following warnings indicate potentially dangerous situa-
tions which could lead to minor or slight injuries if the informa-
tion is ignored.
6IP-KAMERA OC 800
SAFETY INSTRUCTIONS
CAUTION! This device can be used by children from the
age of 8and persons with restricted physical, sensory or
mental capabilities or a lack of experience and knowl-
edge as long as they are supervised or have been in-
structed with regard to safe use of the device and are
aware of the potential risks involved with its use. Chil-
dren must never play with the device. Cleaning and user
maintenance may not be completed by children without
any supervision.
The following warnings indicate potentially dangerous situa-
tions which could lead to property damage if the information is
ignored.
IMPORTANT! Do not use the camera in prohibited areas! Prohib-
ited areas could include public buildings or spaces, for exam-
ple. Please observe local laws and regulations!
IMPORTANT! Risk of property damage through environmental
inuences! Prevent environmental inuences such as exposure
to smoke, dust, vibration, chemicals, moisture, heat and direct
sunlight.
7
IP-KAMERA OC 800
SAFETY INSTRUCTIONS
IMPORTANT! Only use original accessories. Only connect acces-
sories approved by the manufacturer to the camera and only
us the power adapter supplied.
IMPORTANT! Repairs to this device may only be completed by
properly qualied service personnel.
Intended Use
The IP camera (subsequently referred to as camera) is de-
signed to perform video surveillance (CCTV) by day and night.
The camera is exclusively designed for use indoors and out-
doors within the scope of the permissible ambient conditions.
When installing and selecting the area of application of the
camera, pay attention to the personal rights of third-parties
and that the respective, applicable local laws and regulations
are not violated.
A condition for complying with the intended use is that the
equipment is installed correctly and the information in the
8IP-KAMERA OC 800
SAFETY INSTRUCTIONS
manual is observed and maintained. Any other use is consid-
ered unintended use.
The camera is not suitable for use in potentially explosive
areas.
Monitoring of third-parties is not permitted without having
obtained the respective, explicit authorisation and could have
legal consequences.
Unauthorised modications or reconstructions are not permit-
ted.
9
IP-KAMERA OC 800
GENERAL OVERVIEW
General Overview
This section provides information on the package contents of
the camera, the system requirements to operate it with the
ProHomeIPC app and contains a summary of the functions and
operating elements available on the camera.
Package Contents
Please check the contents of the package carefully. If anything
is missing or has been damaged during transport, DO NOT put
the camera into operation!
IP Camera OC 800 1
Power adapter 1
Holder 1
Network cable 1 x Cat.5e (RJ45)
Antenna 1
Hex key 1
Operating manual 1
10 IP-KAMERA OC 800
GENERAL OVERVIEW
Camera
8
4
5
6
7
1
2
3
1Brightness sensor
2Infrared LED
3Lens
4WLAN receiving antenna
