Page 1
Revision #1.12
February 8, 2022
Some of the safety and usage measures you may wish to consider include:
-snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to sweep
the snow off the roof(s).
-if the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
-in high or gusty wind conditions it is advisable to keep the structure securely grounded.
-have a regular maintenance plan to ensure screws, doors, windows and parts are tight.
Customer agrees to hold Outdoor Living Today Partnership and any Authorized Dealers
free of any liability for improper installation, maintenance and repair.
Thank you for purchasing
an 8x12 SunShed Greenhouse
Buidling from Outdoor Living
Today. Please take the time to
identify all the parts prior to
assembly.
Safety Points and Other Considerations
Our products are built for use based on
proper installation and normal residential
use, on level ground. Please follow the
instruction manual when building your
shed and retain the manual for future
maintenance purposes.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer
Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our
commitment to you to courier replacement parts, free of charge, within 10 business days of
this notification. Replacement parts will not be provided free of charge after the 30 day grace
period.
Stock Code: SSGS812-Metal
8x12 SunShed Greenhouse
Building with Metal Roof
Assembly Manual
What to do before my Shed arrives?
Become familiar with this assembly manual and determine if you can•
complete the project yourself or will require a professional contractor.
Clear the construcon area and ensure a clear pathway for delivery when•
the freight company arrives. Remove all debris: roots, grass, rocks, etc.
Excavate the site. Contact your local ulies company to ensure there are•
no gas or electric lines buried in the area before digging.
Decide on the type of foundaon you will be using:•
Concrete slab, or
46 inches of crushed gravel with paver stones or 4x4 stringers.
You can find the footprint for your shed on Page 3 of your Assembly Manual.
If doing the assembly yourself, have all the necessary tools ready to go and in•
working condion. A list of required tools can be found aer the parts list.
One helper is recommended to assist in construcng your shed.•
It generally takes two people over two days to assemble a shed. If you’re
hiring a contractor, their rate should be in line with that duraon of work.
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 2
Foundation Types for 8x12 Garden Shed
Concrete Slab Foundation:
- Slab must be at least the same size as assembled floor frame (136 1/2” x 96”) or larger.
- 6” Deep foundation.
- 1.7 Cubic Yards of concrete required.
- A concrete slab will have the longest durability out of your foundation options.
Once level, a concrete slab is the easiest surface to build on.
Gravel with 4x4 Pressure Treated Stringers:
- Excavate at least 6” deep, and 6” wider than floor frame on each side.
- 2.1 Cubic Yards of gravel required, approximately 19 wheelbarrows.
- 7 - 4x4 Pressure Treated Stringers 8’ long required.
- Evenly spaced, with one at each end of floor frame.
Saves money on materials, easy to level and work with.
Gravel with Patio Paver Stones:
- Excavate at least 6” deep, and 6” wider than floor frame on each side.
- 2.1 Cubic Yards of gravel required, approximately 19 wheelbarrows.
- 25 patio pavers (8” x 8” or larger).
- Center patio paver stones underneath floor runners and underneath seams in floor joists.
Patio paver stones are widely available from most landscape stores.
96”
136 1/2”
6” Deep
108”
148 1/2”
7 - 4”x4”x96”
25 Patio Stones
Floor FrameConcrete Foundation Completed Foundation
18 5/8”
Gravel Foundation Gravel Foundation with treated stringers Completed Foundation
Gravel Foundation Gravel Foundation with Patio Pavers Completed Foundation
96”
136 1/2”
108”
148 1/2”
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 3
Thank you for purchasing our 8x12 SunShed Greenhouse Building.
Please take the time to identify all the parts prior to assembly.
A. Floor Section
3 - 45 1/2” x 75” - Floor Joist Frames (Interior Joist Unattached)
3 - 45 1/2” x 21” - Floor Joist Frames (Interior Joists Attached)
6 - 1 1/2” x 3 1/2” x 71 7/8" - Floor Joists
3 - 45 3/8” x 74 7/8” - Floor Plywood
3 - 45 3/8” x 20 7/8” - Floor Plywood
10- 1 1/2” x 3 1/2” x 68 3/16” - Floor Runners
B. Wall Section
Main Wall Panels
4 - 45 1/2” x 75” - Solid Wall Panels
4 - 1 1/2" x 2 1/2" x 45 1/2" - Wall Plates
2 - 45 1/2” x 75” - Window Wall Panels
3 - 45 1/2” x 75” - Double Window Walls
1 - 12” x 73” - Narrow Wall Panel
1 - 31 1/2” x 72” - Dutch Door - 2pcs (42” and 30” high)
5 - 45 1/2” x 9” - Wall Extendors
2 - 47 1/2” x 9” - Angle Wall Extendors for Front & Back - L/R
3 - 3/4” x 3 1/2” x 60” - Horizontal Wall Extendor Brace
2 - 3/4” x 3 1/2” x 30” - Horizontal Wall Extendor Brace (front/back)
1 - 3/4” x 3 1/2” x 71 1/2” - Horizontal Wall Extendor Brace (side)
Door Jamb, Header & Door Stops
1 - 1 1/2” x 3” x 73” - Vertical Door Jamb
1 - 2” x 3” x 45 1/2” - Door Header
2 - 1/2” x 2 1/2” x 72” - Interior Vertical Door Stops
Gable Walls
2 - Front and Rear Gable Walls - Triangular shaped
(33 3/4 degrees on 1 side / 22 1/2 degrees on other)
Top Wall Plates
2 - 3/4” x 2 1/2” x 65 3/4” - Short Side - 22 1/2 degree cut on edge
2 - 1 1/2” x 2 1/2” x 65 3/4” - Tall Side - 33 3/4 degree cut on edge
2 - 3/4” x 2 1/2” x 73 3/4” - Front & Rear
(33 3/4 degrees on 1 end / 22 1/2 degrees on other)
C. Rafter Section
Rafters
9 - 1 1/2” x 3 1/2” x 77 3/4” - Long Roof Side Rafters (22 1/2 degrees)
9 - 1 1/2” x 3 1/2” x 37 3/4” - Short Roof Side Rafters (33 3/4 degrees)
Ridge Boards & Gussets
1 - 3/4” x 4 5/8” x 52 1/2” - Ridge Boards (long roof side)
1 - 3/4” x 4 5/8” x 84” - Ridge Boards (long roof side)
1 - 3/4” x 5 1/8” x 52 1/2” - Ridge Boards (short roof side)
1 - 3/4” x 5 1/8” x 84” - Ridge Boards (short roof side)
3 - 3/4” x 3 1/2” x 72 - Gussets (angle cut on both ends)
Soffits
2 - 1/2” x 3 1/2” x 68 1/4” - Short Roof Side
2 - 1/2” x 4 1/2” x 68 1/4” - Long Roof Side
D. Roof Section
Battens
2 -Bundles of Roof Battens (3/4” thick x 3 1/2”)
12 - 48 1/4” Outside
6 - 45 1/2” Middle
4 - 3/4” x 1 1/2” x 13 1/2” - Batten Spacers Short
4 - 3/4” x 1 1/2: x 13 3/4” - Batten Spacers Long
Metal Roof
4 - (39”w x 41”) - Metal Roof Panels Short
4 - (39”w x 43”) - Metal Roof Panels Long
3 - 60” long - Metal Ridge Caps
Polygal Sun Roof
4 - 3/4” x 1 1/2” x 34” - F&R Facia Nailing Strips
12 - 3/4” x 3/4” x 44 1/2” - Polygal Support Cleats
3 - 1/2” x 2 1/2” x 41 1/2” - Caps for Polygal
2 - 1/2” x 5 1/2” x 41 1/2” - Outside Caps for Polygal (w nailing strip)
2 - 1/2” x 3 1/2” x 41 1/2” - Caps for Polygal
6 - 20 1/4”w x 44” - Polygal Panels
E. Miscellaneous Section
Bottom Skirting
10 - 1/2” x 4 1/2” x 45 1/4” - Bottom Skirting
Corner & Wall Trim
2 - 1/2” x 2 1/2” x 75” - Filler Trim Short Wall Side
2 - 1/2” x 2 1/2” x 84” - Filler Trim Tall Wall Side
2 - 1/2” x 4 1/2” x 82” - Corner Trim Short Wall Side
2 - 1/2” x 4 1/2” x 87” - Corner Trim Tall Wall Side
3 - 1/2” x 2 1/2” x 87” - Front Door Trim & Rear Wall Seam Trim
4 - 1/2” x 2 1/2” x 88” - Tall Wall Vertical Trim
4 - 1/2” x 2 1/2” x 79” - Short Wall Vertical Trim
1 - 1/2” x 2 1/2” x 32” - Horizontal Door Trim (above Door)
1 - 1/2” x 2 1/2” x 8 3/4” - Horizontal Narrow Wall Trim (above Wall)
2 -1/2” x 4 1/2 x 85 1/2” - Hor.Gable Trim (F & R) Angle cut 1 end
Facia Trim
2 - 3/4” x 3 1/2” x 78 3/4” - Angle Cut Front/Rear Facia Trim
2 - 3/4” x 3 1/2” x 38 1/4” - Angle Cut Front/Rear Facia Trim
4 - 3/4” x 3 1/2” x 71 1/2” - Side Facia
2 - Facia Detail Plates (Sides)
2 - Pentagon Detail Plates (Front and Back Facia)
2 - Triangular Corner Gable Trim Pieces (L/R) Found in Gable - see
step 76
Flower Boxes
5 - Flower Box Kits
Potting Shelves
3 - 45” - Long Potting Shelves
1 - 41” - Short Potting Shelf
4 - 1 1/2” x 2 1/2” x 38” - Potting Shelf Legs
Window Inserts
2 Reg. Window Inserts
6 Small Window Inserts
2 Reg. Window Trim Pkgs: 1 x 24 1/16” Top, 3 x 23” Side & Bottom
6 Narrow Window Trim Pkgs: 1 x 19 7/8” Top, 2 x 21 7/16” Sides,
1 x 18 3/4” Bottom
**Miscellaneous Pieces
1 pc - Spare Wall Siding
2 pcs - Spare Shingles- use to shim door, etc
Several pcs - Foam Enclosures for Metal Roof (37” )
Note: All Trim, Facia and Bottom Skirting pieces will be positioned rough face out when installed.
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 4
8x12 SUNSHED - METAL ROOF - HARDWARE SHEET
Safety Glasses Work Gloves
Safety Equipment Required (Not Provided)
Ladder
Screw Gun/Drill Tape Measure
Hammer Wood Clamp
Level
Tools Required (Not Provided)
1/8” Drill Bits
Caulking Gun
Utility Knife
2 1/2”
2”
1 1/4”
3/4”
2”
3/4”
Tee Hinge x4 Pull Handle
Ridge Board
Connector x 2
Silver
Square Drive Bit
Hardware Kit (Provided)
Black Drop
Latch
Silver Barrel Bolt
Silicon Caulking (2)
1 1/2” Finishing
Pliers
300 pcs
174 pcs
26 pcs
541 pcs
23 pcs
16 pcs
550 pcs
1 pcs
Black Headed
Black Headed
Double Rafter
Bracket x 2
(2 @22°)
(2 @33°)
Single Rafter
Bracket x 4
(3 @22°)
(3 @33°)
x 36
1/4”x 2”
Metal Roof Screw
1”
Silver
55 pcs
Metal Roof
Hangar x4
x 1
1/4” Nut Driver
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 5
Regular Maintenance & Tips to prolong the life of your shed.
Before/During Assembly:
1.) Paint each face and edge of your plywood floor with a latex exterior paint.
2.) Caulk wall seams if gaps appear.
3.) Caulk around window framing.
4.) Caulk perimeter between floor plywood and bottom wall plate.
5.) Caulk channels in lap siding at the top of your door above the trim, just a drop in each channel.
6.) Caulk edge of door threshold (if applicable).
7.) Optional: Install a Sill Gasket between floor runners and foundation.
8.) Optional: Install an 8” strip of roofing paper below Cedar Ridge Caps for Cedar Roof Sheds.
Routine Maintenance:
- Routinely check all fasteners are tight (ex. Door Hinges, Nails)
- Brush off dirt from walls.
- Brush off snow from roof regularly.
- Routinely remove needles and leaves from roof.
Painting/Staining
- Your cedar shed, if left untreated, will weather to a silvery grey colour.
- Painting or staining your structure is highly recommended and will prolong the life of your shed.
- You do not need to wait to paint or stain your shed, the wood in your kit has been dried and can be
—stained or painted immediately.
- Consult your local paint store for the best paint or stain for cedar.
- Optional: stain the inside of your shed. (Note: this will remove the fresh cedar smell.)
1. 2. 3.
4. 5. 6.
7.
Sill Gasket
Floor Joists
Floor Runner
Foundation
8.
Floor Plywood
Wall Panel
Small gap between
bevel siding and
window trim
Dab of caulking
Strip of roofing paper over
apex of roof panels
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 6
A. Floor Section
Plywood Floor
Large (3)
Floor Joist
Frames
Large (3)
Floor Runners (10)
Plywood Floor
Small (3)
Exploded view of all parts necessary to
complete Floor Section. Identify all parts
prior to starting. Note: Floor Footprint is
96” wide x 136 1/2” deep.
Concrete Pad
(optional foundation method)
Floor Joist
Frames
Small (3)
1. Lay out a Large Floor Joist Frame and 2Floor Joists as illustrated above. Position Joists
equally in Floor Joist Frame. Position Joists flush with framing.
Flush with
framing
2. Use a Small Floor Joist Frame as a template to determine joist position. When correctly
positioned, attach each Joist with 4 - 2 1/2” screws (2 per end). You can find the Square Drive Bit
for the screws in with the Hardware Kit Bag.
You can find the
Square Drive Bit
for the screws in
with the Hardware
Kit Bag.
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 7
7. Attach Floor Runners to completed floor
frame. There are 2 floor runners per
136 1/2” side and 5 completed runners in
total. Use 6 - 2 1/2” screws per Runner.
96”
5. Complete all large and small frame attachments.
Screw each completed section together with 8 - 2 1/2”
screws.
6. When completed, your floor footprint
should be 96” wide x 136 1/2” deep.
136 1/2”
8. Make sure Runners are flush with
outside of framing, not overhanging.
3. Lay out completed Floor Joist Frames as
illustrated. There are 3 larger and 3 smaller
Frame Sections. The Footprint for the floor when
attached together will be 96” wide x 136 1/2”
deep.
4. Attach each large and small floor joist
frame together with 6 - 2 1/2” screws per
section.
Front of Shed
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 8
Note: The floor will be flipped over and floor runners will sit
on your foundation. It is important to note that having a
level foundation is critical. Choosing a foundation will vary
between regions. Typical foundations can be concrete
pads or patio stones positioned underneath the floor
runners.
10. With Floor Runners attached, carefully flip the
floor over and place on your foundation. Caution: you
will need 2 people to assist you. Be careful when
laying floor down not to bend or twist floor. When in
place, level floor completely.
Foundations
9. Complete all Floor Runners.
11. Position Plywood Floor pieces (6) on top of completed Floor Joists. The Plywood is cut
slightly smaller than floor framing and will sit slightly back from outside edge. Keep plywood seams
tight.
Hint: Use a chalk
line to mark location
of floor joists to
determine screw
placement.
Front
12. With Plywood positioned correctly on
floor framing, attach with 1 1/4” screws. Use
screws every 16”.
plywood
pushed together
at seams.
Concrete Slab
Foundation
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 9
B. Wall Section
Gable Walls (2)
Door
Header
Narrow Wall
Door Jamb
Window Wall
Panels (2) Reg. Window
Inserts (2)
Double Window
Wall Panels (3)
Small Window
Inserts (6)
Top Plates (2)
(short side)
Angled Wall
Extendors (2)
Wall Extendors (5)
Solid Walls (4)
Lay out Panels and
Pieces as illustrated
below.
Top Plates (2)
(tall side)
Important: If you prefer Polygal
Roof Panels on left side when
facing front, position wall panels as
illustrated above. Follow general
assembly directions but note
opposite orientations.
Left Side Polygal Roof
Panel Orientation
Front
Front
Exploded view of all parts necessary to
complete Wall Section. Identify all parts
prior to starting.
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 10
Table des matières
Autres manuels OLT Kit de serre
Manuels Kit de serre populaires d'autres marques
ACD PRESTIGE
ACD PRESTIGE MR3 H Manuel utilisateur
Vitavia
Vitavia VA0040-TRP Manuel utilisateur
VegTrug
VegTrug Nursery Manuel utilisateur
Riverstone Networks
Riverstone Networks Monticello 041315V Manuel utilisateur
STC
STC Easy Grow 6x12 Greenhouse Manuel utilisateur
CLIMA POD
CLIMA POD Spirit V7 Series Manuel utilisateur
