Publication issued by:

Olivetti S.p.A.

Telecom Italia Group

Via Jervis, 77 - 10015 Ivrea (TO)

This manualdescribes the NETTUN@7000int’l and provides information of a

general nature necessaryfor using the cash register for the first time.

For more detailed information on how to use the cash register functions, the User

Manual can be downloaded from the Olivetti site (www.olivetti.com) that contains

detailed information.

The manufacturer reserves the right to carry out modifications to the product

described in this manual at any time without any notice.

The quality requirements of this product are attested

through display of marking on the product.

Your attention is drawn to the following actions which could compromise the

conformity attested to above and also product characteristics:

•incorrect power supply;

•incorrect installation, incorrect or improper use or use not in compliance with

the warnings provided in the User’s Manual furnished with the product;

•replacement of original components or accessories with others of a type not

approved by the manufacturer, or performed by unauthorised personnel

User Safety

Connect the machine to a nearby and readily accessible current outlet.

Access the print unit area only to replace accessories. Do not use the machine

above or close to sources of heat (e.g. radiators) or very close to water (e.g.

swimming-pools or showers).

To effectively disconnect the appliance, remove the plug of the power cord from the

current outlet. To clean the machine, disconnect it from the current outlet, use a

damp cloth. Do NOT not use corrosive liquids.

Warning: This unit belongs to class A.

In a domestic environment it may cause radio interference. If necessary, the user

must take appropriate measures.

iii

CONTENTS

INSTALLING THE CASH REGISTER .......................................... 1

PACKAGE CONTENTS ....................................................................................... 1

INSTALLATION....................................................................................................2

CONNECTING THE CASH REGISTER TO THE POWER SUPPLY................... 2

POWERING ON THE CASH REGISTER .............................................................4

INSERTING PAPER .............................................................................................5

SAFETY PRECAUTIONS AND GENERAL STANDARDS OF USE ................... 5

LOADING THE PAPER ROLL ............................................................................6

PRINTER WARNINGS .......................................................................................8

CALIBRATING THE PAPER SENSOR...............................................................8

REGULATING THE NEAR END-OF-PAPER SENSOR ................................... 10

THE PRINTING UNIT ....................................................................................... 10

THE CUSTOMER DISPLAY............................................................................... 11

INSERTING THE ELECTRONIC JOURNAL...................................................... 12

INSERTING THE SD CARD OF THE ELECTRONIC JOURNAL ..................... 12

INITIALISING THE ELECTRONIC JOURNAL .................................................. 12

REMOVING THE ELECTRONIC JOURNAL .................................................... 13

CONNECTING THE DRAWER (OPTIONAL) ..................................................... 13

CONNECTING EXTERNAL PERIPHERALS ..................................................... 14

CONNECTING AN EXTERNAL PRINTER (OPTIONAL)................................. 14

CONNECTING A BARCODE READER (OPTIONAL) ...................................... 14

CASH REGISTER MAIN COMPONENTS.................................. 15

USING THE TOUCH SCREEN ........................................................................... 16

HOW TO INSERT THE CHIPCARD ................................................................... 17

TECHNICAL SPECIFICATIONS............................................... 18

CASEMENT...................................................................................................... 18

CUSTOMER DISPLAY ..................................................................................... 18

ELECTRICAL CONNECTIONS PROVIDED..................................................... 18

EXTERNAL PERIPHERALS CONNECTABLE ................................................. 18

INTEGRATED THERMAL PRINTER ................................................................ 19

POWER UNIT................................................................................................... 19

ELECTRICAL SPECIFICATIONS.....................................................................19

POWER DATA.................................................................................................. 19

ENVIRONMENTAL SPECIFICATIONS ............................................................ 19

DIMENSIONS AND WEIGHT ........................................................................... 19

ENGLISH

INSTALLING THE CASH REGISTER

PACKAGE CONTENTS

The cash register is supplied in a single package containing the following

components:

•Cash register

•External power unit with power cord

•Manual providing operating instructions

•Roll of thermal paper, 80 mm, provided with initial supply

•Electronic journal

•Drawer fixing kit

•Adapter for paper rolls of 57.5 / 60 mm.

Note: The electronic journal is loaded on the cash register.

ENGLISH

INSTALLATION

The steps to install the cash register are as follows:

- Connect the cash register to an electricity supply

- Powering on the cash register

- Insert the paper roll

- Connect the drawer (not indispensable for general use)

- Connect the external peripherals (not indispensable for general use).

WARNING: For the cash register to be operational, the paper roll and electronic

journal must be inserted correctly.

CONNECTING THE CASH REGISTER TO THE POWER SUPPLY

Connect the external power unit first to the cash register (A) and then to the 220V

mains supply (B).
