OKOndt GROUP Sonocon B Manuel utilisateur
Battery compartment door
А-SCAN MANIPULATION
RECTIFICATION CHOICE
Radio Frequency
Full wave
Positive halfwave
Negative halfwave
С
С
-3-
H,mm
H,us
Y,mm
- Full Screen
GATES MANIPULATION
GAIN MANIPULATION
N, dB
50%
80%
38dB 0dB
Gain step
variation
Reference
gain
С
С
ВВ
В
Gain adjustment
Add / remove some
number of dB
Put signal to the
reference level
(80% or 50%)
-4-
H,mm
С
MENU NAVIGATION AND
PARAMETERS ADJUSTMENT
С
INDICATION PANEL
Gain Probe
frequency
Sound
velocity Measurands
Probe
angle
Probe
zero
Indicators
panel
-5-
В
INDICATORS
N dB addition
to the current
gain:/- Not added / Added
Reference
gain mode:/- Off / On
AGC:/
- Inactive / Active
TCG:/
- Inactive / Active
DAC system:/- Inactive / Active
DGS system:/- Inactive / Active
AWS rating:/- Inactive / Active
Measurement
threshold:/- Edge / Peak
Measurement
mode:
1, 2 – gates 1 and 2;
C1, C2 – cursors 1 and 2.
/ / ...
/
Reference level:/Reference level for amplitude
measurement
in % of vertical scale
Probe type:/- Single element / Dual element
Rectification
mode:/// Radio Frequency / Full wave /
Positive half waves /
Negative half waves
Signal freeze
modes:/// - Off / Frozen / Frozen + Live signals /
Estimate mode
Zoom modes:/ /
- Off / Zooming gate 1 / Zooming gate 2
Direct
manipulation
modes:/// Off / A-Scan manipulation /
Gate 1 manipulation /
Gate 2 manipulation
Battery
indicator:... - Full / … / Almost empty
-6-
В
-
-
-
-
dBrdBr
+dB +dB
AGC AGC
TCGTCG
DAC DAC
DGS DGS
AWS AWS
11-2 2-C1
50% 80%
ASC G1 G2
MENU STRUCTURE
In UT software version there are 3 sets of main menu - up to your choice:
user chosen menus
user chosen menus
В
In Thickness Gauge+ software version there is only one menu type:
Т
-7-
«Gates choice for Flaw Alarm System»
QUICK ACCESS
TO MAIN PARAMETERS
UT-B 1. Measurement and alarm
«Choice of gate(s) and cursor(s)
for absolute or relative measurements»
«Choice of the gate(s) level
for the sound alarm»
«Time/distance measurement
threshold choice» «Measurement point marker»
В
Absolute by gate 1
Relative
between
gate 1 and
gate 2
Relative between gate 1 and cursor 2
-8-
ALARM
SOUND
OFF
ALARM
SOUND
ACCEPT.
ALARM
SOUND
RECORD
ALARM
SOUND
SEARCH
PEAK
EDGE
UT-B 2. Measurands choice
∆
∆
A
A
H
H
X
X
Y
Y
De
De
D
D
Se
Se
off
off
Maximum signal amplitude,
relative to the reference level
Gain, necessary to get
maximum signal to
the reference level
Distance to
the indication
along the beam
Distance to the
indication projection
to the scanning plane
Indication depth
Equivalent diameter
of the indication
Equivalent area of
the indication
AWS rating
-9-
QUICK ACCESS
TO MAIN PARAMETERS
В
Par. 1
Main
parameter
Par. 2Par. 3
Par. 4
«Switching measurement units»
«Switching color schemes»
«Interface language choice»
«Display brightness adjustment»
UT-B 3. Display options
Light Dark
-10-
QUICK ACCESS
TO MAIN PARAMETERS
В
