Odot ODOT-S1E1V2.0 Manuel utilisateur

http:// www.odotautomation.com 1/ 29 TEL: +86-0816-2538289

Protocol Converter

ODOT-S1E1V2.0

User Manual

V2.00

2020.03.16

http:// www.odotautomation.com 2/ 29 TEL: +86-0816-2538289

ODOT Series ODOT-S1E1V2.0

ODOT Automation System Co., Ltd.

2022-03

http:// www.odotautomation.com 3/ 29 TEL: +86-0816-2538289

Version information

The following changes have been made to the document:

Date

version number

revise content

author

2020-07-20

V1.00

release version

CCL

2021-11-17

V1.01

firmware upgrading

CCL

2022-03-20

V2.00

hardware upgrading

CCL

Ownership rights information

Without the permission of the copyright owner，all or part of this document shall

not be republished as a paper or electronic document.

Disclaimer

This document is only intended to assist the reader in using the products, and the

company shall not be responsible for any loss or error caused by the use of the

information in this document. The product and text described in this document are

under constant development and refinement. ODOT Automation System Co., Ltd. has

the right to modify this document without notifying users.

Software download

Please log on the official website: www.odotautomation.com and click on the

corresponding product page to download.


http:// www.odotautomation.com 4/ 29 TEL: +86-0816-2538289
Catalogue


Product Overview ...................................................5
1 Product Functions ................................................5
2 Functional Characteristics..........................................5
3 Technical parameters..............................................6
Hardware description ................................................7
1 Product appearance ...............................................7
2 Indicator LED description..........................................8
3 Terminal definition ...............................................9
4 Reset switch ....................................................9
5 External terminal resistance .......................................11
6 Installation dimension............................................12
Typical application .................................................12
1 Transparent transmission with protocol data ..........................12
1.1 TCP_SERVER pattern ........................................13
1.2 TCP_CLIENT pattern ........................................15
1.3 UDP_CONNECT pattern: .....................................17
2 None protocol data transmission....................................20
2.1 TCP_SERVER pattern ........................................20
2.2 TCP_CLIENT pattern ........................................22
2.3 UDP_CONNECT pattern......................................23
Supplement .......................................................25
Brief introduction of serial port network topology .........................25
RS232 .......................................................25
RS422 .......................................................26
RS485 .......................................................28



http:// www.odotautomation.com 5/ 29 TEL: +86-0816-2538289

1. Product Overview

1.1 Product Functions

The protocol converter is a converter developed by Sichuan Odot Automation System

Co., LTD between RS232/485/422 and TCP/UDP. It can easily connect serial port

devices to Ethernet and realize network upgrade of serial port devices.

The protocol converter supports the function of "data transparent transmission"，

which can be set as a client or a server. This function can easily realize the data

communication between PLC, server and other Ethernet devices and the underlying

serial port devices.

1.2 Functional Characteristics

◆ 9-36V wide voltage input, anti-reverse connection protection.DC-DC isolation

power supply, 3000V isolation voltage.

◆ 2KV network port isolation protection, 10M/100Mbps rate adaptive, automatic

MDI/MDIX reversal.

◆ Support TCP server pure transparent transmission, support 10 clients access.

◆ Support TCP client pure transparent transmission, support to connect 1 server.

◆ Support UDP pure transparent transmission.

◆ Support with and without protocol transparent transmission, protocol transparent

transmission supports MODBUS RTU/ASCII.

◆ Support for WEB browser configuration parameters.

◆ It has three interfaces of RS485, RS422 and RS232.

◆ Serial port baud rate support 1200 ~ 115200bps

◆ Support DHCP, more convenient to use.

◆ Support one-key reset function to restore factory Settings.

◆ 35mm standard DIN-rail installation.

◆ EMC meets EN 55022:2010 & EN55024:2010 international standards.

http:// www.odotautomation.com 6/ 29 TEL: +86-0816-2538289

1.3 Technical parameters

The technical parameters of this product are shown in Table 3.1. Please use this

product within the parameters of this product to obtain better performance.

Table 3.1 Technical parameters

ODOT-S1E1

Environmental parameters

Working temperature

-20~70℃

Storage temperature

-55~125℃

Operating humidity

5%~95% (No condensation)

The power supply parameters

Number of power

ports

Input voltage

9-36V（DC）

Power consumption

700mW

Ethernet parameters

Working mode

TCP server，TCP client，UDP

Number of Ethernet

ports

Network protocol

TCP，UDP，HTTP

Number of TCP

connections

TCP server pure transparent transmission，supports 10 clients

accesses.

TCP client pure transparent transmission, support to connect

1 server.

Serial port parameters

Quantity of serial port

Serial communication

mode

RTU mode and ASCII mode are optional.

Serial terminal

resistance

120 Ω external resistance

Supported Baud rate

2400-115200bps

Supported validation

mode

None, odd check, even check

Number of slave

stations supported

31(RS485)

http:// www.odotautomation.com 7/ 29 TEL: +86-0816-2538289

2. Hardware description

2.1 Product appearance

http:// www.odotautomation.com 8/ 29 TEL: +86-0816-2538289

2.2 Indicator LED description

The converter has 5 LED status indicators, of which symbol definition and status

description are shown in "Table 2.1".

Table 2.1 Description of LED indicators

Symbol

Definition

State

Instruction

PWR

Power LED

Power supply is connected

OFF

Power supply is not connected

STA

Converter status LED

Flash

The converter is running

properly

OFF

The converter is not running

properly

Not used

OFF

Not used

DAT

Serial port transceiver

indicator

Flash

The serial port is sending and

receiving data

OFF

No data is being sent or

received through the serial port

Not used

OFF

Not used

OFF

Not used

http:// www.odotautomation.com 9/ 29 TEL: +86-0816-2538289

2.3 Terminal definition

The equipment connection adopts 10Pin 3.81mm distance unplugging terminal. The

RS485 interface terminal is defined as follows.

ODOT-S1E1 Terminal definition

2.4 Reset switch

The paper clip can be used to click the reset button, and all the indicators blink once

to indicate a successful reset. Gateway reset successfully, the technical parameters of

the gateway are as follows:

serial

numbe

Terminal

RS485

RS422

RS232

RS232 receive

RS232

transmission

SGND

RS232 grounding

TB-

RS485 B-

RS422 send negative

TA+

RS485 A+

RS422 send positive

R-

RS422 receive negative

R+

RS422 receive positive

SGND

RS485

grounding

RS422 grounding

http:// www.odotautomation.com 10 / 29 TEL: +86-0816-2538289

Device Info

Device name

S1E1

Firmware version

V1.452

Device ID

Network Configuration

Device IP

192.168.1.254

Device Port

502

Web access port

Operating mode

TCP server（default）, TCP client, UDP

mode, UDP multicast

Subnet mask

255.255.255.0

Gateway

192.168.1.1

Destination IP/DNS

192.168.1.2

Destination port

1024

IP mode

Static (default), dynamic

Serial Port Configuration

Baud rate

1200-115200, default；115200

Data bit

5, 6, 7, 8; default: 8

Parity bit

None, odd check, even check;

default: None

Stop bit

1,2; default:1

Flow Control

None

Advance Level

None data restart

Disabled (default), Enabled

None data restart time

5-1270ms, default:300

Disconnection and

reconnection time

1-255 Second, default: 12

Multiple Host Settings

Conversion Protocol

Modbus TCP to RTU(default), None

Timeout time for

command response

32-8000ms, default:192

Multiple host setting

Enabled (default), Disabled

RS485 Idle time

interval

5-255ms,20

Change the web login password

New password

Retype new password
