OCZ ZT550W Manuel utilisateur

1 x OCZ ZT Series Power Supply

1 x AC Power Cord

1 x Modular Cables Pack

1 x Screw Pack

1 x User Manual

80 PLUS is an innovative, electric utility-funded incentive program to

integrate more energy-efficient power supplies into desktop computers

and servers.

Meaning of 80 PLUS

The efficiency of a computer power supply is the amount of energy it

supplies, divided by how much energy is input. The remaining energy is

converted into heat. For instance, a power supply operating at 60%

efficiency, supplying 300 watts to a computer would draw 500 watts,

and give off 200 watts of heat. An 80% efficient supply would draw 375

watts to produce the same 300 watts, giving off 75 watts of heat.

Eﬃciency Level Cerﬁcaon Chart

CONTENTS

80 PLUS CERTIFICATE

80 PLUS Test Type

Fracon of Rated Load 20% 50% 100% 20% 50% 100%

80 PLUS 80% 80% 80%

80 PLUS Bronze 82% 85% 82% 81% 85% 81%

80 PLUS Silver 85% 88% 85% 85% 89% 85%

80 PLUS Gold 87% 90% 87% 88% 92% 88%

80 PLUS Planum 90% 94% 91%

115V Internal Non-Redundant 230V Internal Redundant

Not deﬁned

OCZ ZT Series 80 PLUS Bronze Cerﬁed

Model OCZ-ZT550W, OCZ-ZT650W, OCZ-ZT750W

BRONZE

· 550W/650W/750W continuous output rated at a demanding 45°C ambient

temperature

· Built with premium low ESR 105°C electrolytic capacitors

· Single +12V rail for efficient power distribution in your system

· Compliant with ATX12V v2.2 standard for worry-free compatibility

· 140mm temperature and load-controlled double ball-bearing fan for whisper

quiet operation

· 80 PLUS Bronze certified, 85% efficiency in real world operating environments

· ErP compliant for low power usage in standby

· Active Power Factor Correction (PFC) to effectively regulate input voltage

· Heavy-duty protection circuitry, (over-voltage, over-current, under-voltage, and

short circuit) for protecting your valuable components

· Backed with OCZ’s 5-year “PowerSwap” warranty

· Safety Approvals: UL, CUL, CE, CB, FCC Class B, TÜV, CCC, C-tick, BSMI and GOST

· Dimensions: 5.9"(W) x 3.4"(H) X 6.9"(L); 150mm(W) x 86mm(H) x 175mm(L)

· MTBF: 100,000 Hours

FEATURES

· There are dangerous high voltages inside the power supply.

· DO NOT open the cover of the power supply case.

· Warranty is void if the cover is removed.

· Under no circumstances should the power supply cover be opened. Please keep

the power supply away from humidity and operate it in the proper environment.

· The PSU is suggested to face downwards to help the CPU dispel the heat.

WARNING! SAFETY NOTICE

1. Make sure that your system is turned off and unplugged. Disconnect the AC

power cord from your old power supply.

2. Open your computer case, please refer to the direction in your case manual.

3. Disconnect all power connectors from the devices.

4. Remove the old power supply and replace the new one into your computer case.

5. Connect power connectors to your motherboard and peripheral devices.

A. Connect the 20+4-pin Main Power Connector to your motherboard

as needed.

B. Connect the 4+4-pin +12V Power Connector to your motherboard

as needed.

C. Connect the Peripheral 4PIN Power Connector to devices. SATA

connectors are for devices with Serial ATA interface.

D. Connect the Y type Floppy Drive Power Adapter to the floppy as

needed.

E. Connect the PCI-E + 12V Power Connector(s) to the PCI-E graphics

card(s). Please consult your graphics manual for details if needed.

6. Close your computer case, connect the power cord to the power supply unit,

and then set the “I/O” switch of the power supply unit to “I” position.

7. You are now ready to start your computer.

POWER SUPPLY INSTALLATION

SPECIFICATION

OCZ-ZT650WOCZ-ZT550W OCZ-ZT750W

Max. Output +3.3V 24A 24A

+5V 30A 30A

+12V 54A 62A

-12V 0.5A 0.5A

+5Vsb 3A 4A

+3.3& +5V comb 170W 170W

Total Power 650W

24A

45A

0.5A

140W

550W 750W

PF Correcon

Fan Type

Operang Temp.

Operang Humidity

Protecon Features

Safety Approvals

EMC

Hazardous Materials

AC Input Range

Frequency

Input Current

Model

ATX12V /EPS12V

175 x 150 x 86 mm

80 PLUS Bronze

Intel Speciﬁcaons

Dimensions (LxWxH)

Eﬃciency

Acve, 0.99PF Typical

Double Ball Bearing

0~45°C, 100 % Connuous Power @ 45°

5% ~ 85% RH

OCP/ OPP / OVP / UVP/ SCP

TUV / UL / CB / CE / FCC/CCC/C-Tick/BSMI/GOST

Triple AC + Dual DC EMC Filtering stage

WEEE / ROHS

100 ~ 240 Vac

50 / 60 Hz

10 - 5A 12 - 6A8 - 4A

CONNECTORS

CONNECTOR

TYPE (20+4) P MAINBOARD 4+4P (8P) CPU+12V

[detachable]

6+2P (8P) PCI-EXPRESS

[detachable]

SATA Peripheral FDD

DESCRIPTION

Modular cable, 12V rail

supplied For new

generations of

ATX/EEB/CEB

server/workstation MB.

Modular cable, 12V rail

supplied.

- In Combined Mode -

8 pin configuration

supports multi-CPU

server/workstation

systems and some single

extreme CPU system.

- In Split Mod -

4 pin configuration

supports certain single

CPU systems. Some multi-

CPU workstation/server

system might also need

Modular cable/ socket,

12V rail supplied.

- In Combined Mode -

8 pin configuration

supports latest extreme

graphic cards, which

require 8 pin PCI

connector.

- In Split Mode -

6 pin configuration

supports most

performance PCI-E graphic

cards, which require 6 pin

PCI-E connector.

Modular cable/

socket, for SATA /

SAS drives.

Modular cable/ socket, for

IDE / SCSI / SAS drives or

some AGP graphic cards

w/ traditional 4P power

socket.

Adaptor cable/ socket, for

floppy drive or certain

add-on card.

QUANTITY

CONNECTOR

TYPE

DESCRIPTION

QUANTITY

12 [ 650 W model ]

2 [ 550 W model ]

4 [ 750 W model ]

6 [ 550 W model ]

9 [ 650 W model ]

9 [ 750 W model ]

1 [ 650 W model ]

1 [ 550 W model ]

2 [ 750 W model ]

MODULAR CABLES

MODEL / DESCRIPTION [550W]

5 PIN to 3 X SATA Connector

Modular Cable

Modular cable for SATA /

SAS drives like ODD & HDD.

2 PCS

5 PIN to 3 X Peripheral

Connector

Modular Cable

Modular cable for IDE / SCSI /

SAS drives and peripheral

8 PIN to 1 X 6+2P (8P)

PCI-E Connector

Modular Cable

Modular cable for 1 or 2

performance PCI

Express graphic cards, which

needs 6P or 8P

PCI-E connector.

24 PIN to 20+4 Pin ATX

8 PIN to 4+4 Pin CPU

Modular cable for CPU.

2 PCS

[750W]

3 PCS

2 PCS

[650W]

3 PCS

2 PCS

2 PCS 4 PCS

1 PC 1 PC

1 PC 2 PCS1 PC

1 PC

2 PCS

TROUBLESHOOTING/WARRANTY AND RMA

If you experience any problems with your new power supply, please check these simple

trouble-shooting steps or consult the retailer where the product was purchased.

Caution: Working on electrical devices can be life-threatening. If you are not familiar with

the steps taken please consult a professional. If your power supply has developed traces

of smoke, broken cables, or was exposed to liquids it should not under any

circumstances be brought back into operation.

If you installed a new power supply and the system will no longer start, please check

the following steps:

1. Make sure the AC input is plugged in correctly and the wall outlet distributes power.

[ Try another device in the electrical outlet to verify it is working properly.]

2. Check that all connectors from the power supply are correctly plugged into the

motherboard.

3. Are the cables from the power switch of the computer case properly connected to

the motherboard?

4. Make sure there are no short circuits within the systems that could result from

defective hardware or misplaced connectors.

5. If you are not sure take all parts out of the housing and only leave the motherboard

inside together with the power supply. Disconnect all plugs, check them and then

connect them again to the respective sockets.

If you need further assistance please visit:

http://www.ocztechnology.com/support/ticket.html

5- Year Warranty

Your OCZ ZT Series PSU is covered by an industry-leading 5-Year Warranty. This

product is warranted to be free from defects in material and workmanship for a period

of five [5] years from the date of purchase. If any defects should occur during this

period, contact OCZ Technology for further assistance and to take advantage of your

warranty.

To place a Returned Merchandise Authorization [RMA] request, you may simply submit

a ticket through our website at: http://www.ocztechnology.com/support/ticket.html

1 x Netzteil der OCZ ZT-Serie

1 x AC-Stromkabel

1 x Packung modulare Kabel

1 x Packung Schrauben

1 x Gebrauchsanweisung

80 PLUS ist ein innovatives, von Elektrizitätsversorgungsunternehmen

bezahltes Anreizprogramm für die Integration energieeffizienterer

Netzteile in Desktopcomputern und Servern.

Bedeutung von 80 PLUS

Die Effizienz (oder der Wirkungsgrad) eines Computer-Netzteils ist die

Menge von Energie, die es liefert, geteilt durch die Menge von Energie,

die eingespeist wird. Die verbleibende Energie wird in Wärme umgewan-

delt. Ein Netzteil beispielsweise, das eine Effizienz von 60 % bringt und

300 Watt an den Computer liefert, verbraucht 500 Watt und gibt 200

Watt Wärme ab. Ein Netzteil mit einer Effizienz von 80 % verbraucht

375 Watt bei einer Produktion von 300 Watt Energie und 75 Watt

Wärme.

Eﬃzienzstufen-Zerﬁzierungstabelle

INHALTSVERZEICHNIS

80-PLUS-ZERTIFIKAT

80-PLUS-Tesyp

Bruchteil des Nennstroms

20% 50% 100% 20% 50% 100%

80 PLUS 80% 80% 80%

80 PLUS Bronze 82% 85% 82% 81% 85% 81%

80 PLUS Silver 85% 88% 85% 85% 89% 85%

80 PLUS Gold 87% 90% 87% 88% 92% 88%

80 PLUS Planum 90% 94% 91%

115 V intern nicht redundant 230 V intern redundant

Nicht deﬁniert

OCZ ZT-Serie 80 PLUS Bronze zerﬁziert

Modell OCZ-ZT550W, OCZ-ZT650W, OCZ-ZT750W

BRONZE

• 550 W/650 W/750 W Dauerleistung bei einer anspruchsvollen Umgebung-

stemperatur von 45°C

• Gebaut mit 105°C-Low-ESR-Elektrolytkondensatoren der Premiumklasse

• Single + 12-V-Schiene für effiziente Stromverteilung in Ihrem System

• Konform mit dem Standard ATX 12 V 2.2 für sorgenfreie Kompatibilität

• Temperatur- und lastabhängiger, doppelt kugelgelagerter 140-mm-Lüfter für

flüsterleisen Betrieb

• 80 PLUS Bronze-zertifiziert, 85 % Effizienz in realen Betriebsumgebungen

• ErP-konform für geringen Energieverbrauch im Standby-Modus

• Aktives Leistungsfaktorkorrekturfilter (PFC) für effektive Regulierung der

Eingangsspannung

• Hochleistungs-Schutzfunktionen (Überspannung, Überstrom, Unterspannung und

Kurzschluss) zum Schutz Ihrer wertvollen Komponenten

• Abgesichert durch die 5 Jahre gültige „PowerSwap“-Garantie von OCZ

• Sicherheitszertifikate: UL, CUL, CE, CB, FCC Klasse B, TÜV, CCC, C-tick, BSMI und

GOST

• Abmessungen:

150 mm (B) x 86 mm (H) x 175 mm (L) [5,9" (W) x 3,4" (H) x 6,9" (L)]

• Mittlere störungsfreie Zeit: 100.000 Stunden

EIGENSCHAFTEN

• Innerhalb des Netzteils treten gefährlich hohe Spannungen auf.

• ÖFFNEN SIE KEINESFALLS die Abdeckung des Netzteilgehäuses.

• Die Garantie erlischt, wenn die Abdeckung entfernt wird.

• Die Abdeckung des Netzteils darf unter keinen Umständen geöffnet werden.

Halten Sie das Netzteil bitte fern von Feuchtigkeit und betreiben Sie es in einer

geeigneten Umgebung.

• Das Netzteil sollte nach unten zeigen, um dem CPU bei der Wärmeverteilung

behilflich zu sein.

WARNUNG! SICHERHEITSHINWEIS

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels OCZ Alimentation

OCZ

OCZ SXS Manuel utilisateur

OCZ

OCZ OCZ700SXS - MECHANICAL DRAWING Manuel utilisateur

OCZ

OCZ OCZ400SXS2 - MECHANICAL DRAWING Manuel utilisateur

OCZ

OCZ OCZ600SXS Manuel utilisateur

OCZ

OCZ OCZ700SXS2 - MECHANICAL DRAWING Manuel utilisateur

OCZ

OCZ OCZ-Z1000M - MECHANICAL DRAWING Manuel utilisateur

OCZ

OCZ PRO X STREAM Manuel utilisateur

OCZ

OCZ ZX850W Manuel utilisateur

OCZ

OCZ MOD X STREAM Manuel utilisateur

OCZ

OCZ OCZGXS850 Manuel utilisateur

OCZ

OCZ ZX series Manuel utilisateur

OCZ

OCZ OCZ600SXS2 - MECHANICAL DRAWING Manuel utilisateur

OCZ

OCZ OCZ500SXS Manuel utilisateur

OCZ

OCZ Z SERIES 850W Manuel utilisateur

OCZ

OCZ OCZ500SXS2 - MECHANICAL DRAWING Manuel utilisateur

OCZ

OCZ MOD X STREAM-PRO Manuel utilisateur

OCZ

OCZ ZX1250W Manuel utilisateur

OCZ

OCZ MODXSTREAM-PRO 500 - MECHANICAL DRAWING Manuel utilisateur

OCZ

OCZ Z SERIES 1000W Manuel utilisateur

OCZ

OCZ ZX1000W Manuel utilisateur

OCZ

OCZ STEALTH X STREAM 400W Manuel utilisateur

OCZ

OCZ Fatality FTY550W Manuel utilisateur

OCZ

OCZ OCZ850GXSSLI - MECHANICAL DRAWING Manuel utilisateur

OCZ

OCZ OCZ-ZS450W Manuel utilisateur

Manuels Alimentation populaires d'autres marques

Monacor

Monacor PS-12CCD Manuel utilisateur

VOLTIMA

VOLTIMA MagicBox 15 Manuel utilisateur

Agilent Technologies

Agilent Technologies 6032A Manuel utilisateur

Miller

Miller Auto Deltaweld 452 Manuel utilisateur

BCP

BCP PUOUBK Feuille d'instructions

HC 2210 Manuel utilisateur

Puls

Puls CT5.241 Manuel utilisateur

iseg

iseg ECH 238 Manuel utilisateur

Power

Power XXL A Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 6631B Manuel utilisateur

Renogy

Renogy PHOENIX 300 Manuel utilisateur

HP 6200B Manuel de service

Epson

Epson Stylus Scan 2500 Manuel d'utilisation

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manuel utilisateur

Puls

Puls MiniLine ML50.100 Manuel utilisateur

Puls

Puls AS-Interface SLA4.100 Manuel utilisateur

Kenwood

Kenwood PS-60 Manuel utilisateur

Elmdene

Elmdene G1380xN-y-s Series Manuel utilisateur
