doesn’t need set, this machine of leaving factory restores
default 01 channel).
4. After receiving seat inserts computer, press scanning
gun’s control for one time to wake up scanning gun (after
wake-up, the scanning gun will have two continuous sounds
of “drop, drop”, at the same time the blue LED lamp lights)
to realize automatic matching, if need to re-match, need to
be finished within 15s of receiver’s LED lights, when
receiving seat LED light changing to flashing mode, can
implement scanning operation.
5. Scanning mode operation
A Ordinary mode scanning (default “ordinary mode”), the
mode is real-time upload mode. a, scanning barcode and
upload, if it is successful, the blue LED light will flicker
once, at the same time buzzer will give two continuous
sounds (two sounds are continuous when signal is good, and
there will be about 0.5 seconds interval between two sounds
when signal is bad); b, both LED and buzzer have no action
when scanning is not successful；c, if scanning is successful
but unload fails due to beyond receiving range or channel
setting is not correct, the buzzer will sound once, bule LED
lights flickers once, about after one second, the buzzer will
sound three times continuously, and at the same time bule
LED light will filcker three times to indicate.
B Collection scanning mode (scanning ‘collection mode
SET’ is this mode). Under this mode, the data will be stored
in barcode gun (the number is about 500-10000, more than
500 need to customize), when need to upload, scanning
‘data upload’ barcode under inventory mode of setting
barcode, all cache barcode will be uploaded computer one
