Ocean Reef SAV III Basic Manuel utilisateur

SAV III Basic

OWNER’S MANUAL

SAV III Basic rel. 1.0

SAV III Basic - OWNER’S MANUAL

1 - INTRODUCTION

2 - GENERAL WARNINGS / OWNER’S RESPONSIBILITIES

3 - FEATURES

4 - GLOSSARY

5 - ASSEMBLY

6 - TROUBLESHOOTING

7 - MAINTENANCE, CLEANING AND STORAGE

8 - SPARE PARTS

9 - WARRANTY

TABLE OF CONTENTS

SAV III Basic rel. 1.0 3

#UNDERWATERNATURALLY

For more than 70 years, OCEAN REEF has been involved in the underwater

diving industry. We have contributed much to this industry, from ns and

snorkels to the most modern systems of underwater communication. Through

the spirit of intrepid pioneers, brilliant inventors, passionate divers, and dynamic

entrepreneurs, OCEAN REEF has been able to turn dreams into reality in the

underwater world.

1 - INTRODUCTION

The Manufacturer has carefully worded and edited this owner’s manual.

However, in no event the Manufacturer will be responsible for any damage

caused by the incorrect interpretation of its content, nor due to any misprints

and/or incompleteness in the text.

The Manufacturer will not accept liabilities for any damage caused by:

• Insufcient, incorrect and improper maintenance, failing to comply with the

manual’s recommendations

• Absence of periodic tests and checks

• Incorrect and improper use

• Failing to comply with guidelines included in the owner’s manual

• Alterations and/or modications of the SAV III Basic

If any of the above were to occur, considering these actions are potentially

dangerous to the health and life of the users, the manufacturer is released of

any responsibility and the warranty is void.

The Manufacturer is an ISO 9001:2015 certied company (https://diving.

oceanreefgroup.com/support/#ISO_CC).

If you lose this manual or if you should require more copies, you can

download it at diving.oceanreefgroup.com/support/ or contact the

Manufacturer: Mestel Safety SRL, Via Arvigo 2, 16010 Sant’Olcese

(GE), IT. Phone: +39 0107082011. E-mail: infoitaly@oceanreefgroup.

com. Website: diving.oceanreefgroup.com

SAV III Basic rel. 1.0

A WARNING indicates a procedure or situation that, if not avoided, could result in

serious injury or death to the user.

A CAUTION indicates any situation or technique that could cause damage to the

product, and could subsequently result in injury to the user.

A NOTE is used to emphasize important points, tips, and reminders.

WARNINGS, CAUTIONS AND NOTES

Pay special attention to information provided in warnings, cautions, and notes that is

accompanied by these symbols:

2 - GENERAL WARNINGS / OWNER’S RESPONSIBILITIES

While this is a product of high quality, the user is not exempt from problems

connected with the incorrect use of the product or failure to follow the rules of

safe diving.

If the instructions provided in the manual are unclear or difcult to understand, please contact

OCEAN REEF at infoitaly@oceanreefgroup.com before using the equipment or attempting any

repairs.

IMPORTANT

The content of this manual is based upon the latest information available at the time of print.

OCEAN REEF reserves the right to modify any products, processes and manufacturing techniques

at any time. It is the technicians’ responsibility to acquire the latest information and parts from

OCEAN REEF for service and repairs to be performed.

Carefully read this instruction manual before use, and keep it for future reference.

This instruction manual does not replace a diving course.

DO NOT USE the SAV III Basic if any part is broken.

DO NOT DIVE YOUR OCEAN REEF IDM IF SAV IS LEAKING WATER OR AIR. TROUBLE

SHOOT THE SAV IF THERE IS SIGN OF WATER OR AIR LEAKAGE.

DO NOT OVERTIGHTEN OR OVER OPEN THE SAV – THIS CAN CAUSE THE VALVE

CAP OR SCREW/RING TO BECOME STUCK OR DIFFICULT TO OPERATE. As with all

valves operated while SCUBA diving, tightening, and opening should be done gently

and never with force. Saline, water, and other residues can affect operating the SAV.

Follow maintenance instructions properly to avoid issues.

It is essential that the diver using this product is properly trained and equipped and

fully understand these instructions before attempting to use the SAV. Testing the use

on surface and in conned water is strongly recommended.

Do not modify or alter the product in any way.

SAV III Basic rel. 1.0 5

#UNDERWATERNATURALLY

In order to maintain the warranty, service and routine maintenance of the products

must be performed by the end user as indicated by OCEAN REEF and described in

chapter 8 MAINTENANCE, CLEANING AND STORAGE.

For details, contact an authorized OCEAN REEF dealer at: https://diving.

oceanreefgroup.com/shop-dealers/

OCEAN REEF refuses all responsibility for damages caused by non-compliance with

the instructions contained in this manual. These instructions do not extend the warranty

or the responsibilities stated by OCEAN REEF terms of sales and delivery.

Before using the SAV III Basic the user must ensure that the product has been properly

inspected and maintained. (see Chapter 8 Maintenance, Cleaning and Storage).

Dust and any debris in the area of the SAV can cause malfunction in the product

or even compromise its correct use. In order to avoid this, before use, make sure

that the SAV is perfectly clean.

While the SAV provides the diver the ability of breathing ambient air on surface, it does

not change or eliminate the potential hazards of diving. As a further component of the

diver’s equipment, it should be operated according to this manual and included in

one’s conguration only when fully understood and condent use achieved.

While our SAVs feature a valve to avoid water to rush in the mask when submerged,

this is intended in vertical position and normal diving trim position. According to the

position of the valve, leaking can be more serious. For this reason, the valve should not

be forgotten open, upon submerging as instructed in this manual.

Check the COMMUNICATION port plug: it should be in place, screwed into it’s tting

if you have not installed a communication unit microphone/PTT assembly. IF you have

opened and closed this port plug, make sure youu have placed the at gaskeet that

should be on the inside perimeter - back in place.

Verifying quick connection hoses before the dive is imperative. Attach and detach

hoses from male connections multiple times (before and after pressurizing) to ensure

the connection system operates smoothly. Make sure, once nally connected, that the

coupling is secure by pulling on the female part of the hose, without unlocking the

quick connections. The hoses must remain assembled on the male part rmly. Always

make sure you do not get dirt, sand or other material in the hose mechanism.

SAV III Basic rel. 1.0

3 - FEATURES

The Surface Air Valve / SAV III / SAV III basic allows the diver to breathe ambient air while

at the surface conserving the diver’s gas supply.

To use, simply open the valve while on the surface or outside of the water to breathe

ambient air, and close it when ready to dive.

Keep in mind cold water diving might require specic procedures.

• Easy to grab, sturdy design.

• Large air vents

• Easy to assemble on the mask

*The Surface Air Valve III Basic is retro compatible with all prior OCEANREEF IDM

models that do not have a Professional or Neptune III SAV installed and an available

OCTOPUS/SAV port. The Neptune III SAV III is permanently installed on the IDM/FFM.

Scan the QR code and

watch the video tutorial

Code OR025030

SAVIII Basic

4 - GLOSSARY

(PART B)

BASE OF THE SAV

(PART A)

TOP OF THE SAV

SAV III Basic rel. 1.0 7

#UNDERWATERNATURALLY

1 - Unscrew the OCTOPUS/SAV plug

from the port on the right side of the

mask (facing away from you).

5 - ASSEMBLY

2 - Make sure the at gasket is

located on the internal perimeter

of the port. Check integrity of the

gasket and ensure absence of

debris and dirt.

3 - Insert the SAV III Basic or SAV

in the OCTOPUS/SAV port aligning

the threads.

SAV III Basic rel. 1.0

4 - Holding the base of the SAV (part

B) as seen in the picture, screw in

the body of the SAV, very rmly, by

tightening clockwise.

5 - Now practice opening and closing the top (part A) of the SAV to ensure proper

operation of the product. Part A should be closed and opened by operating

only on the part itself and not the valve body (B). Opening the valve is achieved

turning part A counter-clockwise, closing = clockwise. Part A should not be

overtightened nor cranked open to avoid getting stuck.

OPENING THE VALVE

PART A COUNTER-CLOCKWISE

CLOSING THE VALVE

PART A CLOCKWISE

SAV III Basic rel. 1.0 9

#UNDERWATERNATURALLY

6 - WITH YOUR SCUBA SETUP CONNECTED AND OPEN (FULL)

CYLINDER donn the mask as instructed in Neptune III Series Products

manual, with part A SAV screw open. Once the mask is donned properly

test breathing from the SAV. You will notice you are breathing ambient

air and not gas from cylinder. Close the SAV screw (part A). Proper

sealing of the mask on the face and proper closing of the SAV will result

in you now breathing gas from cylinder.

NOTE! Before each dive make sure part B (SAV Body) is tightened

properly on the OCTOPUS/SAV mask port, if not fully tightened working

on part A (Top) can cause the body (B) to open resulting in water leaking

that could cause serious injury and may even lead to fatal accident.

Leaking SAV:

Any leaking should be easily spotted while operating the pre-dive checks before

descent. In case the leaking is noticed once the dive has started (bubbles seen

from the valve, or you feel water seeping in from the SAV side):

1. Ensure the SAV is closed while upright. If not, close the SAV and verify

you don’t have leaks. Exhaling/clearing the mask as per training skills will

dump all water and you will be able to identify if the SAV is still leaking.

2. If the SAV is closed, but it is still leaking ABORT THE DIVE. When on the

boat/on land, ensure the SAV is clean, doesn’t have any debris or other

deposit that prevent it from closing properly. If you have a SAV III basic

make sure the body of the valve is properly screwed in the port and

make sure that the gasket in the port is in place. If you own a Neptune

III with installed SAV III, make sure there is no debris or deposit that

prevents the ring to close, make sure the cap is not unscrewed.

If these steps of troubleshooting don’t result in a perfectly working SAV – contact

a Service Center or our Customer Service. DO NOT DIVE.

6 - TROUBLESHOOTING

A A

SAV OPEN

BREATHING AMBIENT AIR

SAV CLOSE

BREATHING GAS FROM CYLINDER

SAV III Basic rel. 1.0

Table 2: Periodic maintenance program

7.1 MAINTENANCE AND CLEANING

Cleaning frequency must ensure to the user a good protection and the right functionality. When

using any disinfectant, be sure to follow the manufacturer’s instructions for use. Follow this with

a thorough rinse in fresh water, and allow the equipment to dry completely before use. Since

some chemicals can damage surfaces, they should be tested prior to use for each individual item

or surface. After disinfecting, one must take care not to contaminate the equipment, such as by

handling it when storing. Therefore, dry, pack and store any sanitized equipment in a disinfected bag

or container using washed/sanitized hands. For an efcient cleaning of any part of the equipment,

soaking in clean warm water (around 40°C/100F°)

adding a colorless not perfumed hand washing liquid soap is suggested. Afterwards, rinse deeply

under fresh water to remove any soap residual and allow the perfect drying in a

safe and clean environment.

7 - MAINTENANCE, CLEANING AND STORAGE

TYPE OF

ACTION FIRST USE

BEFORE

EACH

USE

AFTER A

DIVE

GENERAL

FUNCTION

CHECK X X

GENERAL

AND VISUAL

INSPECTION X X

CLEANING /

RINSING X

For optimum longevity of the SAV and

the proper functioning of its parts, we

recommend rinsing thoroughly with fresh

water after every use.

As this product cannot be dove on its

own, for proper instruction, refer to the

Neptune III Series Products user manual

and follow chapter 15’s information.

7.2 STORAGE

Product should be stored in a ventilated environment preferably between -10°C (14°F)

and +50°C (122°F), avoiding the direct action of sunlight, pollution, dirt, etc.

For both storage and transportation the product can be kept assembled on mask.

WARNING: This product can expose you to chemicals including Butadiene

which is known to the State of California to cause cancer and birth defects or

other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Table des matières

Autres manuels Ocean Reef Instrument de plongée

Ocean Reef

Ocean Reef AQUARIST Manuel utilisateur

Ocean Reef

Ocean Reef GSM Cube3 Manuel utilisateur

Ocean Reef

Ocean Reef Visor Lights Manuel utilisateur

Ocean Reef

Ocean Reef Snorkie-talkie Manuel utilisateur

Ocean Reef

Ocean Reef Space Extender Manuel utilisateur

Ocean Reef

Ocean Reef Alpha Pro X-Divers Manuel utilisateur

Ocean Reef

Ocean Reef NEPTUNE III Manuel utilisateur

Ocean Reef

Ocean Reef NEPTUNE SPACE IRON MASK Manuel utilisateur

Ocean Reef

Ocean Reef NEPTUNE SPACE PREDATOR Manuel utilisateur

Ocean Reef

Ocean Reef Space Extender Manuel utilisateur

Ocean Reef

Ocean Reef OCTOPUS SYSTEM Manuel utilisateur

Ocean Reef

Ocean Reef APA ARIA Protection Adaptor Manuel utilisateur

Ocean Reef

Ocean Reef NEPTUNE SPACE Manuel utilisateur

Ocean Reef

Ocean Reef Neptune Space G-divers Manuel utilisateur

Ocean Reef

Ocean Reef Space Extender Manuel utilisateur

Ocean Reef

Ocean Reef SL35TX Manuel utilisateur

Ocean Reef

Ocean Reef GSM Mercury Manuel utilisateur

Ocean Reef

Ocean Reef Snorkie-talkie Manuel utilisateur

Ocean Reef

Ocean Reef OR030110 Manuel utilisateur

Ocean Reef

Ocean Reef neptune II Manuel utilisateur

Ocean Reef

Ocean Reef GSM Mercury Manuel de réparation

Ocean Reef

Ocean Reef Extender Kit Manuel utilisateur

Ocean Reef

Ocean Reef Snorkie-talkie Manuel utilisateur

Ocean Reef

Ocean Reef NEPTUNE SPACE PREDATOR Manuel utilisateur

Manuels Instrument de plongée populaires d'autres marques

Sherwood

Sherwood Amphos Manuel utilisateur

Zeagle

Zeagle N2ition Manuel utilisateur

Tusa

Tusa Q 1203 CE Mode d’emploi

Sherwood Scuba

Sherwood Scuba Insight Instructions de montage

SUBMERSIBLE SYSTEMS

SUBMERSIBLE SYSTEMS Spare Air 600 Manuel utilisateur

OCEANS

OCEANS S1 Supersonic Manuel utilisateur

heinrichs weikamp

heinrichs weikamp OSTC 2 Manuel utilisateur

Omer

Omer SP2 Manuel utilisateur

Scott

Scott PRO-PAK Manuel utilisateur

Apeks

Apeks BLACK SAPPHIRE Manuel utilisateur

Waterproof

Waterproof DRYSUIT Manuel utilisateur

Dräger

Dräger PAS AirPack 1 Manuel utilisateur

Dive Lab

Dive Lab KIRBY MORGAN KMB 18 Manuel utilisateur

Ratio Computers

Ratio Computers iDive Manuel utilisateur

Oceanic

Oceanic PROPLUS X Manuel utilisateur

CFA

CFA MSA G1 Manuel utilisateur

Genesis

Genesis Centauri Manuel utilisateur

TREND

TREND GAUGE/60 Manuel utilisateur
