User Manual

WR-282CD

Please read this user manual carefully before using the receiver.

1. Standby button

2. Volume/Home

Rotate to adjust the volume

level/Press the knob to return

Home (main menu).

3. Preset

Long press to add to favourite

list. Press it briefly to recall the

preset list.

4. Infrared remote sensor

5. 3.5 mm earphone jack

6. Left

Left cursor/Press to return to

previous menu.

7. Dial/Select

Rotate to browse the

menu/Return to the station

list/Press to confirm a selection.

8. Right

Right cursor/Press to return to

the station list/View radio info

9. 2.4” color display

10. Speaker

11. Line out Jack

12. Aux-In Jack

13. DC IN Socket

14. Telescopic antenna

Location of Controls

Remote Control

1. : Mute

2. : Standby button

3. 0-9: Favorite station key / input letters and

numbers for WiFi Encryption code

4. : Preset the current playing station to

Favorite

5. : Recall the favorite list

6. ▲: Cursor up

7. t: Cursor left / back to previous menu

8. u: Cursor right

9. ▼: Cursor down

10. OK: confirm button

11. : Alarm button

12. : Sleep Timer

13. Vol+: Volume up

14. Vol-: Volume down

15. : Main Menu

16. Mode: Switch between the modes of radio

17. EQ: Equalizer

18. : Previous station on the list/previous

track on UPnP

19. : Play/pause for internet radio

20. : Next station on the list/next track on

UPnP

21. Local: Access the local station list (Local

area set up in Configuration)

22. Info: View the detailed info of the radio channel

or the music info under UPnP.

23. Dimmer: Dim down the backlight of display

Key“0”―― 0,‘DEL’

Key“1”―― ‘1’->‘@’->‘ ’（space）->‘！’-> “ (double quotes)

->‘#’->‘$’->‘%’->‘&’-> ’（single quotes）->‘（’

->‘）’->‘*’->‘+’->‘，’->‘-’->‘.’->‘/’->‘:’->‘;’->‘<’->‘=’->‘>’->‘?’->‘[’->‘\’->‘]’->‘^’-

>‘_’->‘`’->‘{’->‘|’->‘}’->‘~’

Key “2”―― 2,A,B,C,a,b,c

Key“3”―― 3,D,E,F,d,e,f

Key“4”―― 4,G,H,I,g,h,i

Key“5”―― 5,J,K,L,j,k,l

Key“6”―― 6,M,N,O,m,n,o

Key“7”―― 7,P,Q,R,S,p,q,r,s

Key“8”―― 8,T,U,V,t,u,v

Key“9”―― 9,W,X,Y,Z,w,x,y,z

Remark: press ’►’ to move to next character and press ’OK’ button to confirm.

You can also press▲▼ to change the character /number, then press the right key to confirm

the entry.

After you finish the entry, press the select button to confirm.

Remote control character list

Getting started

Connect the mains adaptor to the radio unit, one end to the DC IN on the radio and the other

end to the AC mains wall socket.

Caution: Use only the mains adaptor supplied with the radio. Connecting a power

supply with a different rating will cause permanent damage to the radio and may be

hazardous.

The display on the front of the radio will light up and show:

Then you can select your prefer language on the radio.

It will ask you if you want to Enable the <Check Network when Power on>, it is suggested to

choose <Yes>. Then the radio will always check the available WiFi network automatically.

Welcome

• English

Deutsch

Français

< 2/7 8

01:44

Connecting to your WiFi network

The screen below will appear. You can choose <Yes> to proceed to search for the available

WiFi network. If your router has the WPS function, you can select <Yes(WPS)> to proceed.

It will then start scanning the network. After the search is done, it will display a list of the

available router.

Choose your router from the list, enter the WEP(Wired Equivalent Privacy) or WPA(Wi-Fi

Protected Access) code. If your network is not configured to be with the WEP or a WPA code,

the unit will connect to the router automatically.

Note: The encryption code would have been set up by the person who set up and

configured your network.

Please follow the steps below to enter the encryption code of your router using the buttons on

the radio:

- Rotate the <Dial/Select> knob to browse the character

- Press the right button to skip to the next entry

- After you finish with the entries, press the <Dial/Select> knob to confirm. Do NOT press the

right button again.

To use the remote control entering the password, please refer to the “Remote control

character list” to learn how to select the characters. Press the “►” button for the next entry,

press “◄” button to delete the character or to amend it. When the last character is entered,

press the <OK> button this time.

Do NOT press the “►” button.

The radio will start connecting to the network.

After the router is connected successfully, it will display the main menu as follow:

You can now start enjoying the internet radio.

01:01

Would you like to

configure Network now?

Yes(WPS) NOYes

01:44

Linksys

Homeaudio

Demo

MOVE INPUT:OK

Enter

Password

1/1

16:23

08:58

Internet Radio

Choose <Internet Radio> from the menu, you can see several listed options.

To start listening the radio stations worldwide, select <Radio Station/Music>.

My Favorite

This is to show the list of your Favorite stations which have been assigned to the presets.

To preset a station:

While you are playing the favorite station, long pressing the <Preset> button ( on

the remote) and the <Add to My Favorite> menu will display. Press the rotary knob to

confirm. The playing station will be added to the preset list automatically.

The presets will be stored in ascending order. You can store up to 250 presets.

Note: Presets 1 to 5 are reserved for your own choice of the dedicated radio

channels. The preset will be stored from no. 6 onwards, you can scroll to choose

no. 1-5 at your preference.

For DAB, you can store up to 100 presets.

For FM, you can store up to 20 presets.

You can edit your favorite list anytime. Go to Internet radio> My Favourite or press

the <Preset> button ( on the remote), When it displays the list of favorite stations

then press the right button. The following options will display:

Delete – To delete the selected station

Shift up- To shift the selected station by one level up on the ranking

Shift down – To shift the selected station by one level down on the ranking

Rename – To rename the selected station

Play – press and play the selected station

Choose the radio station that you want to make with the above changes. Then press

the Right key, it will enter into the list with the options listed above. Then choose your

desire action.

To recall a preset station:

Press the <Preset> button ( on the remote) briefly and choose your desire station

Radio Station / Music

Select this option, then you can select your desired radio station by Category, Genre or

Location., etc.

Press rotary knob to conﬁrm The symbol on the top row means

station is added to preset list

Delete

Shift Up

Shift Down

< 1/5 >

iRadio

Local Radio

If you want to access quickly the radio station located in your area, select this function and it

will display the list of the stations available in your area.

History

The radio will memorize the last listened 10 stations.

Service

Search Stations

You can find your desire radio station by entering the name of the radio.

Add New Radio Station

If you cannot find your desire station from the Radio station list and you have the URL

address, you can input the link here and add to your favorite list.

Note: The URL has to be an audio streaming URL in order to play on the radio.

When the radio station is playing, the display will show a color image transmitted from the

radio station.

iRadio

.977 The 80s Channel

977

Music

Internet Radio

Media Center

UPnP (Universal Plug and Play)

You can stream music from the Networked device which supports UPnP function to the radio to

play.

For instance, most of the latest computer laptop supports UPnP, and you can stream music

from Windows Media Player application on the computer and listen on your radio.

Please make sure your computer laptop is on the same Wi-Fi network as the Radio

before you start using this function

1. If your PC is running Microsoft Windows XP, then you can use Windows Media Player

11(WMP11) to act as your UPnP (Universal Plug and Play) media server. (For Windows 7 or

above, please download the correspond version of Windows Media Player). The latest

Windows Media Player may be downloaded from Microsoft’s website and install by

following the instructions detailed in its installation wizard.

2. Once installed, Windows Media Player will create a library from all the media files available

to it on your PC.

2.1 Windows XP / Windows Media 11

2.1.1 To add new media files to the library, select’ File > Add to Library…> Advanced

Options’, Click ‘Add’ and choose the files you wish to add and click’ OK’.

2.1.2 Now you need to connect your Internet radio to Windows Media Player 11 and

configure it to allow the radio to access your media library. In order to this, you

will need to do the following:

a. On the radio, go to the main menu and select <Media Centre> <UPnP>.

b. It will scan for all available UPnP servers. Note, this may take a few seconds

for the radio to complete its scan and before the scan has completed, the

radio will display ‘[Empty]’. The radio will continue to display ‘[Empty]’ if no

UPnP servers and found.

c. After a successful scan. Select your UPnP server, by rotating the dial if there

is more than one UPnP server, and then press SELECT.

2.1.3 Your PC will now prompt you that a device has attempted to connect to your UPnP

server. In order to allow the radio to have access to the media files, you will need

to click the ‘Library’ tab from Windows Media Player 11 and select the <Media

Sharing> item to open the ‘Media Sharing’ window.

Selecting ‘Media Sharing…’ for Windows Media Player11:

2.1.4 From the ‘Media Sharing’ windows, the radio will be listed as an unknown device.

Click on the unknown device listed, then click the ‘Allow’ button and then click

‘OK’. Allowing the Radio to Connect:

2.2 Windows 7 / Windows Media Player 12

2.2.1 If you are using WMP 12, simply go to <File> and choose <Open> to retrieve the

music files you would like to add to library.

2.2.2 Windows 7 or above requires the PC to be set as Home network and also with

the Homegroup enabled to allow devices to access/ play the media files on your

Windows Media Player. Please find the steps below:

I) Go to <Control Panel>, select <Network and Internet>

ii) Choose <HomeGroup>

iii) Set the network location

iv) Choose Home network
