Ocean Digital WR-03 Manuel utilisateur

WR-03

Internet Radio Adaptor with

DAB and Bluetooth

Please read this user manual carefully before using the receiver.

User Manual

(Additional powered speaker/active speaker is required to use this product)

Contents

Location of Controls .......................................1

Remote Control .............................................2

Remote control character list ..........................3

Getting started ..............................................5

Connecting to your WiFi network .....................6

Internet Radio ...............................................7

Spotify Connect .............................................9

Media Center ...............................................10

FM mode .....................................................12

DAB Mode ...................................................13

Information Center .......................................14

DLNA ..........................................................15

Bluetooth ....................................................15

Conﬁguration ..............................................16

Trouble Shooting .........................................24

Technical Speciﬁcation .................................27

Location of Controls

1. 2.8'' TFT color screen

2. Infrared remote sensor

3. 3.5mm antenna input socket

Two types of antenna are supplied with the radio. One is wire

type and the other is the rod antenna. Apply one of them to get

the best result on the reception of DAB and FM radio

4. 3.5 mm audio out socket

Connect external powered speakers with 3.5 mm plug or RCA

adaptor with 3.5mm plug

5. Optical Out

Digital optical output connection

6. DC IN socket

Connect with the power adaptor supplied in the package

7. Power ON/OFF switch

1 2

3 4 5 6 7

- 01 -

1. : Mute

2. : Standby button

3. 0-9: Favorite station key / input

letters and numbers for WiFi

Encryption code

4. : Preset the current playing station

to Favorite

5. : Recall the favorite list

6. ▲: Cursor up

7. t: Cursor left / back to previous

8. u: Cursor right

9. ▼: Cursor down

10. OK: confirm button

11. : Alarm button

12. : Sleep Timer

13. Vol+: Volume up

14. Vol-: Volume down

15. : Main Menu

16. Mode: Switch between the modes of

radio

17. EQ: Equalizer

18. : Previous station on the list /

previous track on UPnP

19. : Play/pause for internet radio

20. : Next station on the list/next track

on UPnP

21. Local: Access the local station list

(Local area set up in

Configuration)

22. Info: View the detailed info of the

radio channel or the music info

under UPnP.

23. Dimmer: Dim down the backlight of

display

Remote control

- 02 -

Remote control character list

Key“0”―― 0,‘DEL’

Key“1”―― ‘1’->‘@’->‘ ’（space）->‘！’-> “ (double quotes)

->‘#’->‘$’->‘%’->‘&’-> ’（single quotes）->‘（’

->‘）’->‘*’->‘+’->‘，’->‘-’->‘.’->‘/’->‘:’->‘;’->‘<’->‘=’-

>‘>’->‘?’-

>‘[’->‘\’->‘]’->‘^’->‘_’->‘`’->‘{’->‘|’->‘}’->‘~’

Key “2”―― 2,A,B,C,a,b,c

Key“3”―― 3,D,E,F,d,e,f

Key“4”―― 4,G,H,I,g,h,i

Key“5”―― 5,J,K,L,j,k,l

Key“6”―― 6,M,N,O,m,n,o

Key“7”―― 7,P,Q,R,S,p,q,r,s

Key“8”―― 8,T,U,V,t,u,v

Key“9”―― 9,W,X,Y,Z,w,x,y,z

To enter the password, press " ▲ " or " ▼ " button to select the

characters. Press the " ► " button for the next entry, press " ◄ "

button to delete the character or to amend it. When the last

character is entered, press the <OK > button this time.

Do NOT press the " ► " button.

The radio will start connecting to the network.

- 03 -

Please ensure the following is ready:

• You have a broadband internet connection.

• A wireless (Wi-Fi) broadband router is connected to the internet

successfully. The radio supports Wireless B, G and N

connection (Wireless N router can also be used with the setting

on B or G).

• You know the Wired Equivalent Privacy (WEP) or Wi-Fi

Protected Access (WPA) data encryption code/password. You

need to key in the correct code when the radio is connected to

the wireless router for network connection. If you do not know

the code/password, please contact the person /technician who

set up the router/network for you.

• The radio can work via Wireless network connection (Wi-Fi

connection).

Precautions

• The radio should not be used in a high temperature or high

humidity environment over prolonged periods of time as this

may damage the unit.

• Keep the radio away from liquids as it may get damaged. Please

switch off the radio immediately if water or liquids is spilled into

the radio. Consult with the shop you bought this radio for any

question.

• Avoid using or storing the unit in dusty or sandy environment.

• Do not open and repair the radio by yourself.

• Use only the DC adaptor supplied with the radio.

Connecting a power supply with a different rating will cause

permanent damage to the radio and may be hazardous.

• Clean only with dry cloth

Before you start

- 04 -

Getting started

Connect the mains adaptor to the radio unit, one end to the DC IN

on the radio and the other end to the mains wall outlet.

Caution: Use only the mains adaptor supplied with the radio.

Connecting a power supply with a different rating will cause

permanent damage to the radio and may be hazardous.

The radio is an adaptor and does not have internal speaker.

Prepare a powered speaker which has the 3.5mm pin in plug in to

the 3.5mm line out jack on the radio.

The radio supports also the optical connection. If you have a

system comes with optical input, connect to the optical out on the

radio to listen.

Switch the radio on using the Power on/off switch at the rear side

of the radio. The display on the front of the radio will light up and

show:

Then you can select your prefer language on the radio.

It will ask you if you want to Enable the <Check Network when

Power on>, it is suggested to choose <Yes>. Then the radio will

always check the available WiFi network automatically.

- 05 -

• English

Deutsch

Español

Français

1/17

01:44

Welcome

Connecting to your WiFi network

The following screen will appear. You can choose <Yes> to

proceed to search for the available WiFi network. If your router

has the WPS function, you can select <Yes(WPS)> to proceed.

It will then start scanning the network. After the search is done, it

will display a list of the available Wiﬁ networks.

Choose your network from the list, enter the WEP(Wired

Equivalent Privacy) or WPA(Wi-Fi Protected Access) code. If

your network is not enabled with security code, the unit will

connect to the network automatically.

Note: The encryption code would have been set up by the

person who set up and conﬁgured your network.

Please refer to the “Remote Control character list” for you to

enter the passwords. Press the “►” button to go to the next entry,

press “◄” button to make correction, press OK when the last

character is entered.

The radio will start connecting to the network.

After the wiﬁ network is connected successfully, it will display the

main menu as follow:

You can now start enjoying the internet radio.

08:58

Internet Radio

- 06 -

01:44

Linksys

Homeaudio

Demo

01:01

Would you like to

configure Network now?

Yes(WPS) NOYes

Ent er

Password

1/1

16:23

Input: Ç È Å Move Æ OK

Internet Radio

Choose <Internet Radio> from the menu, you can see different

functions as below:

To start listening the radio stations worldwide, select <Radio

Station/Music>.

My Favorite

This is to show the list of your Favorite stations which have been

assigned to the presets.

To preset a station:

While you are playing the favorite station, simply hold and

press the key until the follow screen appear. Press OK to

conﬁrm. The playing station will be added to the preset list

automatically.

The presets will be stored in ascending order. You can store

up to 250 presets.

Note: Preset 1 to 5 are reserved for your own choice of the

dedicated radio channels. Scroll to choose the desired

number to save your favourite channel. To save more

channels after the ﬁrst ﬁve presets are occupied, press

and hold the preset button and it will assign to preset no.

6 onwards.

You can edit your favorite list anytime. Go to Internet radio>

My Favourite or press the on the remote, When it

displays the list of favorite stations then press the ► button.

The following options will display:

Delete – To delete the selected station

Shift up- To shift the selected station by one level up on the

ranking

Press OK to conﬁrm The symbol means the station has

already been added to the favourite lis

- 07 -

Delete

Shift Up

Shift Down

Rename

1/5

iRadio

Internet Radio

Shift down – To shift the selected station by one level down on

the ranking Rename – To rename the selected station

Play – press and play the selected station

Choose the radio station that you want to make with the above

changes. Then press the Right key, it will enter into the list

with the options listed above. Then choose your desire action.

To recall a preset station:

Press the on the remote brieﬂy and choose your desire

station.

Radio Station / Music

Select this option, then you can select your desired radio station

by Category, Genre or Location., etc.

Local Radio

If you want to access quickly the radio station located in your

area, select this function and it will display the list of the stations

available in your area.

History

The radio will memorize the last listened 10 stations.

Service

Search Stations

You can ﬁnd your desire radio station by entering the name of

the radio.

Add New Radio Station

If you cannot ﬁnd your desire station from the Radio station

list and you have the URL address, you can input the link here

and add to your favorite list.

Note: The URL has to be an audio streaming URL in order

to play on the radio.

When the radio station is playing, the display will show a color

image transmitted from the radio station.

iRadio

.977 The 80s Channel

977

Music

Internet Radio

- 08 -

Table des matières

Autres manuels Ocean Digital Radio

Ocean Digital

Ocean Digital DK-821B Manuel utilisateur

Ocean Digital

Ocean Digital WR-828F Manuel utilisateur

Ocean Digital

Ocean Digital DBA-03R Manuel utilisateur

Ocean Digital

Ocean Digital WR-23D Manuel utilisateur

Ocean Digital

Ocean Digital WR-210CB Manuel utilisateur

Ocean Digital

Ocean Digital DK-23 Manuel utilisateur

Ocean Digital

Ocean Digital WR-210N Manuel utilisateur

Ocean Digital

Ocean Digital DB-332 Manuel utilisateur

Ocean Digital

Ocean Digital MA-80 Manuel utilisateur

Ocean Digital

Ocean Digital WR-80 Manuel utilisateur

Ocean Digital

Ocean Digital WR-336N Manuel utilisateur

Ocean Digital

Ocean Digital wr-282cd Manuel utilisateur

Ocean Digital

Ocean Digital WR-336N Manuel utilisateur

Ocean Digital

Ocean Digital WR-800D Manuel utilisateur

Ocean Digital

Ocean Digital WR-230SF Manuel utilisateur

Ocean Digital

Ocean Digital WR-880N Manuel utilisateur

Ocean Digital

Ocean Digital WR-390 Manuel utilisateur

Ocean Digital

Ocean Digital WR-23F Manuel utilisateur

Ocean Digital

Ocean Digital WR-336F Manuel utilisateur

Ocean Digital

Ocean Digital WR-238 Manuel utilisateur

Ocean Digital

Ocean Digital WR-210CB Manuel utilisateur

Ocean Digital

Ocean Digital WR-230S Manuel utilisateur

Ocean Digital

Ocean Digital DB-230B Manuel utilisateur

Ocean Digital

Ocean Digital WR-210CB Manuel utilisateur

Manuels Radio populaires d'autres marques

EisSound

EisSound KBSound iSelect Manuel utilisateur

Midland

Midland 1001LWX Manuel utilisateur

Konig

Konig HAV-SR41 Manuel utilisateur

Roberts

Roberts exprssion Manuel utilisateur

VDigi

VDigi DD3.0 Manuel utilisateur

Radio Shack

Radio Shack 21-1863 Manuel utilisateur

Roberts

Roberts Stream 207 Manuel utilisateur

Sony

Sony Walkman SRF-M97 Manuel utilisateur

Stanley

Stanley FatMax FMC770 Manuel utilisateur

auna

auna DAB-Radio 10026947 Manuel utilisateur

SOUNDMASTER

SOUNDMASTER UR190 Manuel utilisateur

HYT

HYT TC-320 Manuel utilisateur

auna multimedia

auna multimedia Yellowstone 10026851 Manuel utilisateur

B-Tech

B-Tech GMRS-V2 Manuel utilisateur

Weierwei

Weierwei VEV-V8 Manuel utilisateur

SOUNDMASTER

SOUNDMASTER DAB750 Manuel utilisateur

Telefunken

Telefunken TF-1505 Manuel utilisateur

Makita

Makita LXRM03 Manuel utilisateur
