Oasser CW8 Manuel utilisateur
CW8
Pressure Washers
Model︓CW8
User Manual
Made in China
English
Warning Before Use
Product Parts
Technical Specification
Installation Steps
Operation Cautions
Maintenance
Troubleshooting
Contents
1
2
3
3
6
6
7
English
Warning Before Use
For your safety, please read this manual carefully before the initial use and follow the instructions.
This appliance is designed for household cleaning only. For example :
1.Clean cars, motorcycles, minivans, bicycles.
2.Clean patios, fences, paths, driveways, house facades, especially useful for blocked driveways.
3.Clean algae, moss on the roof, brick buildings.
4.Clean garden tools, furniture, barbecue utensils.
5.Clean the surroundings around farm animals.
※ Please wear protective equipment when using this kind of appliances. Better to wear protective clothing
and safety goggle to keep water and dirt from sputtering back.
※ To create a stable condition for the appliance can prevent from accidents and injuries. Please place the
appliance on a flat ground when using. Do not use the appliance in areas with any potential explosion risks.
※Never use this appliance against hazardous substances or spray the flammable liquid due to risk of
explosion.
※ Fort your safety, it is recommended to use leakage protector when operating (Max.30mAh).
※ Fixtures and couplings are important for the safety of the appliance. These things must be recommended by
the manufacturer.
※ Unsuitable extension cords can be hazardous. It is only approved in such circumstances: 1-10 m(3.3ft-33ft)
: 1.5 m², 10-30 m(33ft-98ft) : 2.5 m²
※ Please ensure that 30cm(1ft) far away from the vehicle tyres when using the power washer for vehicle
cleaning, to avoid getting your tyres damage or explosion.
※ The operator must use the appliance correctly. When using the appliance, please consider the situations
around you, especially with kids around.
※ Children should be supervised to prevent them from playing with the appliance.
※ Do not spray directly at peoples.
Please read the manual carefully and pay attention to the signs before using.
[ Danger ] imminent danger which may result in serious injury or even
death, if not avoided.
[ Warning ] potential hazardous situation which may result in serious
injury or even death, if not avoided.
[ Caution ] possible hazardous situation which may result in minor injury
or property damage, if not avoided. It will be very dangerous if the high
pressure washer is not used correctly. Please never direct at persons,
animals, electric equipment or the appliance itself.
01 02 03 04 05 06 07
Front:
1.Power cord
2.ON/OFF switch
3.Garden hose adapter
4.Water inlet
5.Water outlet
6.High pressure hose
7.High pressure hose lock
8.Trigger gun
9.Trigger lock
10.Spray wand
11.Spray nozzles
Back:
1.Telescopic handle
2.Trigger gun holder
3.Spray wand holder
4.Detergent suction tube
5.Filter
6.Detergent tank
7.Wheels
Product Parts
English
34
2
1
5
6
7
8
10
11
9
2
1
4
6
5
3
7
01 02 03 04 05 06 07
Please check if the accessories are complete first. If something missing, please contact us.
Install accessories before start-up.
Connect the adapter we provide to the water inlet on the appliance, then install the garden hose.
The garden hose for water inlet connection is not included in the package box. Please make sure that the
size of your hose is G3/4 thread of British standard.
Note: Please check if there is a rubber seal and a filter in the adapter. If they fell out, or left in the
packing box, just put them back. Because no matter which one is missing, it will cause leaks. Besides, be
sure that both ends of the water inlet hose adapter must be screwed tightly. Especially note that there must
be no looseness between the black part and the aluminum part of the water inlet hose adapter, or it will
cause leak of water.
1.Water Inlet Garden Hose
Two Ways of Water Sucking
I.Water Tap
You can put the water inlet hose into a large container filled with water for self-priming, please use the
water inlet hose not exceeding 2M ( 6.5ft ).
II.Suck Water Automatically
Technical Specification
Installation Steps
English
Voltage: AC 100~120V (American Standard)
Working pressure: 1828psi
Working temperature: 5-50°C
Max. flow rate: 1.85GPM (420L/h)
Power: 1800W
Max. pressure: 3046psi
Water temperature: 0 ～40°C
Max. water inlet pressure: 0.4Mpa
01 02 03 04 05 06 07
English
1)Install the high pressure hose to the water outlet on the appliance.
2) Connect the other end of the high pressure hose to the spray gun [1], then lock the hose [2].
Note: When the trigger is not engaged, the appliance will shut off automatically and will maintain
pressure. Please close the trigger lock [3] and insert the spray gun into the trigger gun holder when not in
use (or stop washing), to avoid causing any injury.
2.Water Outlet High Pressure Hose
Insert the spray wand into the spray gun and fasten by rotating it through 90 degree.
3.Install The Spray Wand
3
4.Install The Spray Nozzle
0°
25°
25°
40°
Black soap
spray nozzle
01 02 03 04 05 06 07
Note: Be careful when using the red nozzle (0º) to avoid any injury. Only the black nozzle is a low-pres-
sure foam nozzle for spraying detergent, and the other nozzles are high-pressure nozzles that do not
generate foam.
Note: When filling the detergent, please remove the spray nozzle to keep the appliance at low pressure. It
's better to use liquid detergent. Do not put any solid cleaner into the detergent tank avoiding the filter
blockage. If you want to use the solid cleaner, please water down the solid cleaner thinning it first, then
pour it into the detergent tank. Besides, if you hope to clean the car, we recommend you choose the car
wash soap for better cleaning effect.
English
1) Plug-n-play
2) 5 different spray nozzles (0°, 15°, 25°, 40° and black soap spray nozzle) can tackle various cleaning
tasks. You can replace different nozzle as you needs.
Red /0 degrees - areas that are high and hard to reach; clean crevices in sidewalks or driveways.
Yellow / 15 degrees - use on concrete, brick and other hard surfaces with stubborn stains.
Green/ 25 degrees - use on painted surfaces, wood siding, fences and lawn mowers.
White / 40 degrees - use on windows and screens.
Black / Soap - low pressure foam nozzle for spraying detergent.
1)Pull out the tank and remove the cap.
2)Fill with the detergent, and cover the cap.
3)Put the tank back into the appliance .
5.Fill & Install The Detergent Tank
Detergent
01 02 03 04 05 06 07
Note: Dry run lasting more than 2 minutes will lead to damage to the high pressure pump. If the
appliance does not build up pressure within 2 minutes, switch it off and proceed as instructed in the
Chapter Troubleshooting.
Operation Cautions
Maintenance
English
When the first time using the pressure washer, there may exist some air in the spray gun and the high
pressure hose, so the pressure would not be on right away, it is normal. We recommend,
please long press the spray gun trigger for about 15 to 30 seconds after starting up the machine, to squeeze
out the air until the water is coming out, then install the spray wand. (To better protect the machine, this
step should also be done when the cleaning job is finished.)
I.Before Use :
Please note to release the pressure inside the machine after each use. The purpose for doing this is to drain
out of extra air and water inside, reset the overflow valve exactly, and make the disassembly easier.
Especially in the winter, if the pressure is not to be released timely after use, the pressure washer will
freeze, and fail to work. ( This steps is also required when there is no water coming out after starting the
machine. But if no water comes out after 2 minutes of starting the machine, please turn off the power
switch, to avoid any damage to the motor. )
※ Before maintenance, please make sure the device is off and the power plug is pulled out.
※ Remove the water inlet adapter, and pull out the filter and rinse with water.
※ Disassemble the high pressure hose, spray gun and spray wand.
※ Store the power cord, high pressure hose, spray wand with gun and other accessories.
※ Please properly store the pressure washer, and do not put it outdoors during the winter if there is some
residual moisture water in the device has not been drained out.
※ Please pull out the filter and rinse with water before or after a long-term storage. Use needle to clean
the residue if necessary.
II.After Use :
1)Connect the water inlet hose, and turn on the water tap;
2)Turn on the power switch of the machine;
3)Unlock the spray gun trigger;
4)Long press the spray gun trigger for seconds, to squeeze out the air until the water is coming out, then
install the spray wand.
Specific steps are as follows :
1)Shut off the water tap, and disconnect the water inlet hose;
2) Unlock the spray gun trigger and press the trigger to squeeze out the air inside and drain out the
residual moisture water in the device; Otherwise, disassembly will become difficult.
3) Turn off the power switch of the machine;
4) Pull out the mains plug, then store the pressure washer properly.
Specific steps are as follows :
01 02 03 04 05 06 07
Troubleshooting
English
Trouble Cause Remedies
The appliance fails to start up
Pump stops working
Fluctuating pressure
The appliance does not reach
the operating pressure
The appliance often starts or
stops to work by itself (Stop at
low pressure)
Trigger gun is unusable
1.Poor contact with the plug
2.Socket issue
3.Extension power cord issue
4.Incorrect voltage
5.The power switch is off
6.Fuse falls off (If it's used)
High temperature of the pump
due to lack of water
1.Spray wand blocked
2.Pump body is sucking air
3.Impurities inside the pump
1.Spray wand blocked or worn
2.Inadequate supply of water
3.Inlet hose kinked
4.Filter blocked
5.Inlet hose blocked
1.Spring of the decompression
valve worn out
2.Water leakage of pump,
high-pressure hose, gun, etc
Trigger gun is locked
1.Connect to the plug
2.Try another socket
3.Try another extension cord
4.Check the voltage if it is correct
5.Turn on the switch
6.Replace fuse
Check the water inflow - put the
tube into the container with 10
litre water (per Minute)
1.Clean the spray head with
needle
2.Check if the high-pressure tube
connection is tight
3.Please consult after-sales service
1.Clean or replace spray wand
2.Check the inlet water flow-rate
3.Straighten out the hose
4.Clean the filter
5.Check the hose for leaks or
blockages
Please contact us
Unlock the gun
01 02 03 04 05 06 07
After Sales Services
Two year warranty period.
If you have any questions during use, please contact us via the following email, we will provide you with
the most satisfactory solutions and services
US: support-us@oasser.net
CA: support-ca@oasser.net
