9125A Knee Walker

Instruction Manual

Thank you for choosing OasisSpace.

PRODUCT INTRODUCTION

The OasisSpace Knee Walker with Basket is a sturdy, dur

able,and comfortable 4-wheel mobility aid that offers patients

suffering from a foot or ankle injury a smooth-

rolling alternative to crutches during their recovery

Features

•

Sleek, compact design

Detachable features foreasy installation,

carrying, and storage

Adjustable handlebar height

Ad justable knee pad height

Foldable steering column

Attachable basket for personal storage

Front steering wheels

Easily controllable dual back wheel brak

Washable, plush knee pad cover

•

Product Components

•

Padded Contoured Knee Pad

Handlebar with Anti-Slide Grips and Hand Brak

es Height Adjustable Steering Column, 33"- 41'

Height Adjustable Knee Pad Column, 19"- 23"

Front and Back Wheels, 7.8" Diameter

Dual Back Wheel Brakes

Sturdy Dual Bar Frame

Attachable Basket

Washable Knee Pad Cover

•

Height Adjustable

Steering Column

33" to 41"Basket

Anti Slip Grips

Attached

Basket

Height

Adjustable

Seat 19" to23"

Double

Back Brakes

7.8"

Wheels

Sturdy

Dual Bar Frame

Product Specifications

•

Knee Pad Adjustable Height : 19"-

Handlebar Adjustable Height: 33"-

Max. Weight Capacity: 300 lb. [136 kg)

24" [48.8 cm- 61.3 cm)

42" [84 cm- 106.8 cm)

•

INSTALLATION

To assemble the knee walker, the following components

are required:

Front frame with Front Wheels

Rear Frame with Back Wheels

Handlebar Attachment

Padded Contour Knee Pad Attachment

5.Attachable Basket with Mounting Hardware

[Two Screws, Mounting Bar ,and Allen Wrench]

Washable Knee Pad Cover

Three [3] Knobs and Pins

。

Frame Assembly

Insert the dual rods of the front frame into the dual rods of the

rear frame.

Ensure the spring pin on the bottom rod of the front frame

locks into the matching hole in the bottom rod of the rear

frame.

Then attach one of the three knobs with a pin into the

available hole through the top rods.

Tighten the knob to secure.

Knee Pad Assembly and Height Adjustment

Insert the knee pad into the knee pad column.

Select the height, then attach the second of the three knobs

with a pin into the correct hole, locking the height in plac

Tighten the knob to secure .

Steering Column Assembly and Disassem

bly

1. From

the

folded

position,

straighten the steering

column vertically

Lock it in place by tightening the lever down at the base of

the column

3 To fold the steering column,release the lever, and push the column downwa

rd.

Insert the handlebar into the steering column.

Adjust to the correct height,

then attach the final knob with a pin into the correct hole,

locking the height in place.

3.Tighten the knob in secure.

Handlebar Assembly and Height Adjustment

Basket Attachment

install the basket, align the holes in the front anchor

plate located on the steering column with the holes in

the anchorsection of the basket

Tighten until the basket is secure.

Brakes Test

Grip the hand brake levers on the handlebars tightly, and test

to ensure the brakes are working on the back wheels.

Setting The Parking Brake

To set the parking brake, locate the spring pins on each

hand brake lever

Grip

then

each hand brake to activate the back-wheel brakes

push the spring pins down to lock the brakes in place

To release the parking brake , grip each handbrake again

causing the spring pins to

position .

How To Use

Before use, set the

parking brake

Place your hands on the

handlebars.

Position the knee of your

injured foot or ankle on

the center of the knee pa

d.Your lower leg will rest

the rear portion

of the pad .
