SB·200
USER MANUAL

2
EN CONTENTS
Contents������������������������������������������������������������������������������������������������������������������������� 2
Box Contents ����������������������������������������������������������������������������������������������������������������� 3
Controls & functions����������������������������������������������������������������������������������������������������� 4
How to Connect������������������������������������������������������������������������������������������������������������� 7
Getting Started�������������������������������������������������������������������������������������������������������������� 8
Basic Operations����������������������������������������������������������������������������������������������������������� 9
Organising Channels & Stations�������������������������������������������������������������������������������� 11
USB/Multimedia & Recording������������������������������������������������������������������������������������ 12
Electronic Program Guide������������������������������������������������������������������������������������������ 15
Scanning & Rescanning ���������������������������������������������������������������������������������������������� 16
Audio Language & Format ����������������������������������������������������������������������������������������� 17
Audio-Visual Settings & Options ������������������������������������������������������������������������������� 18
Parent Controls & Auto-Power On���������������������������������������������������������������������������� 19
System Maintenance�������������������������������������������������������������������������������������������������� 20
Factory Reset & Software Update����������������������������������������������������������������������������� 21
Network Settings & Apps ������������������������������������������������������������������������������������������� 22
Troubleshooting���������������������������������������������������������������������������������������������������������� 23
Spec & Warranty ��������������������������������������������������������������������������������������������������������� 24
Safety Information������������������������������������������������������������������������������������������������������ 25
Register your product online for a FREE 3 year
extended warranty at: www�oakcastle�co�uk
3YEAR
WARRANTY

3
EN
BOX CONTENTS
WHAT’S IN THE BOX
A. Oakcastle SB200 HD Freesat Recorder
B. Instructions Guide
C. Remote Control (and 2 x AAA batteries)
A
B C

4
EN
REMOTE CONTROL
CONTROLS & FUNCTIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
16
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36

5
EN
CONTROLS & FUNCTIONS
1� Power on/o
2� PVR button (access PVR menu)
3� V-Format: change TV resolution
4� Exit: Exit to top menu
5� Fav: Add favourites
6� Rec: Start recording (Press Menu
to stop)
7� Repeat:
8� Rewind
9� Fast forward
10� Menu: Display/return to menu
11� Up
12� Left
13� OK/Select
14� Down
15� Back: Go back
16� Time Shift: pause live TV (requires
17� Volume +
18� Volume -
19� Media: press to access USB
content
20� Number keypad
21� Recall: Go to previous channel
22� Mute/Unmute
23� Schedule: Schedule recording
24� Aspect: Change aspect ratio
25� Audio: Change audio settings
26� Subt:
27� Pause/play
28� Stop
29� Skip forwards:
30� Skip backwards: Back to previous
31� Info: show programme info
32� Right
33� EPG: Electronic Program Guide
34� CH+: Next channel
35� CH-: Previous channel
36� TV/Radio: Switch modes

6
EN
CONTROL BUTTONS
CONTROLS & FUNCTIONS
37. USB Port
38. Standby Light
39. CH- (prev. channel)
40. CH+ (next channel)
41.
42. LNB IN
43. LNB OUT
44. HDMI port
45. Ethernet Port
46. Scart Connection
47. Power Supply
37 38 39 40 41
43 44 45 46 47
42

7
EN
HOW TO CONNECT
Connection
Refer to the diagram above for the connection of your Freesat box to your satellite
and TV using the HDMI slot.
Step 1: Connect your antenna lead to the TV LNB IN port (Ref.42).
Step 2: Choose an installation method (HDMI (Ref.44) or SCART (Ref.46)) and
follow the steps below.
HDMI - connect an HDMI cable between your TV and the device. HDMI
incprporates both audio and video so there is no requirement to make separate
connections for audio.
SCART - if your TV does not have an HDMI slot, you can connect using the SCART
connection (Ref.46).
HDMI Cable
Coaxial Cable
Rear view of the TV
Satellite

8
EN GETTING STARTED
Steps for getting started with your Freesat Box
Turn on your TV.
Plug the STB (Set Top Box) device into the mains.
Connect the STB to your TV using an HDMI cable or SCART cable (See page 7 for
details).
Select the correct source/video or AV input channel for the HDMI input. This can
be done by pressing the TV/AV or VIDEO button on your TV remote control. (Refer
to your TV user’s manual for instructions).
The welcome screen will appear, followed by a message asking if you would like to
automatically search for channels and stations.
To automatically search for available channels and stations, press OK on the
remote control (Ref.13). The auto search window will apear and searching begins.
If you want to search for channels and stations yourself, see ‘Manual Searching’ on
page 17 for instructions and follow the steps described.
Once the search is complete, the device will automatically begin playing one of the
TV channels found.

9
EN
Selecting a channel
Follow one of the methods below to switch channels.
Press up or down on the navigation controls (Ref.11/Ref.14) to move to the next or
previous channel.
If you already know the channel number, enter the number using the number
keypad (Ref.20) and then press OK (Ref.13) or wait for 2 seconds.
Press OK (Ref.13) on the remote control. This will display the channel/radio station
list.
Press up or down until the channel you want is highlighted, and then press OK
(Ref.13).
Press the EPG button (Ref.33), select the channel you want from the list, and press
EPG (Ref.33) again.
NOTE: Press the RECALL button (Ref.21) to return to the last channel or station
played.
Selecting a radio station
Press TV/RADIO (Ref.36) to enter radio mode, then enter the number. (For
example, 201 is the number for ABC Jazz).
Press OK (Ref.13) to display the station list. Press up or down until the channel you
want is highlighted, and then press OK (Ref.13).
NOTE: The STB uses the Logical Channel Numbering system (LCN) by default.
Secondary channels can be selected by pressing the primary number followed by
another number. (For example, pressing 2 gives you ABC1, and pressing 22 gives
you ABC2).
BASIC OPERATIONS

10
EN BASIC OPERATIONS
Adjusting the volume
Press up or down on the remote control (Ref.17/Ref.18) to increase or decrease
the volume.
Press the mute button (Ref.22) to mute or un-mute the sound.
Getting channel information
Press the info button (Ref.31) to view program information including the current
and next program. The banner will stay displayed for a few seconds. To hide it,
press exit (Ref.4) on the remote control.
Subtitles
To switch on subtitles, if they are available for the program you are watching,
press SUBT on the remote control (Ref.26), then select the desired language and
press OK (Ref.13).
Picture freeze/pause live TV
Press Timeshift (Ref.16) to pause live TV. Press again to resume. Note: this
function requires USB storage space of at least 1GB by default (you can change
storage size).
Favourites
To add a channel to your favourites list, press Menu on the remote control
(Ref.10) to bring up the main menu. From here, select the ‘Program’ section from
the main header. Then select ‘Program Edit’ by pressing down on the remote
control (Ref.14) and press OK (Ref.13). Insert the password (default password is
000000). Select the channel you want to save as a favourite, press the FAV button
(Ref.5) to bring up the favourites menu, then choose a favourite type to add it to
the list. Press EXIT (Ref.4) to exit the menu and save your changes.
To select favourites while watching TV, press FAV (Ref.5).
