O.S. engine MAX-46FX-Hring Series Guide de configuration
It is of vital importance, before attempting to
operate your engine, to read the general
'SAFETY INSTRUCTIONS AND WARNINGS'
section on pages 2-5 of this booklet and to strictly
adhere to the advice contained therein.
●Also, please study the entire contents of this
instruction manual, so as to familiarize yourself
with the controls and other features of the
engine.
Keep these instructions in a safe place so that
you may readily refer to them whenever
necessary.
It is suggested that any instructions supplied
with the model, radio control equipment, etc.,
are accessible for checking at the same time.
●
●
CONTENTS
SAFETY INSTRUCTIONSAND WARNINGS
ABOUT YOUR O.S. ENGINE
INTRODUCTION,
BASIC ENGINE PARTS
INSTALLATION
INSTALLATION OF COOLING FAN,
BEFORE STARTING
FACTS ABOUT GLOW PLUGS,
FUEL
CARBURETOR CONTROLS
STARTING
RUNNING-IN
ADJUSTMENT
SUBSEQUENT READJUSTMENTS
CARBURETTOR CLEANLINESS
ADJUSTING CHART
INSTALLATION OF THROTTLE SERVO
CARE AND MAINTENANCE
ENGINE EXPLODED VIEW &
PARTS LIST
CARBURETOR EXPLODED
VIEW & PARTS LIST
THREE VIEW DRAWING
O.S. GENUINE PARTS & ACCESSORIES
2
~
5
6
7
8
~
10
10
~
11
12
13
~
14
18
21
22
~
25
26
27
14
19
28
15
~
17
20
1
Remember that your engine is not a "toy", but a highly efficient internal-
combustion machine whose power is capable of harming you, or others, if it is
misused.
As owner, you, alone, are responsible for the safe operation of your engine, so act
with discretion and care at all times.
If at some future date, your O.S. engine is acquired by another person, we would
respectfully request that these instructions are also passed on to its new owner.
SAFETY INSTRUCTIONS AND WARNINGS ABOUT YOUR O.S. ENGINE
The advice which follows is grouped under two headings according to the
degree of damage or danger which might arise through misuse or neglect.
WARNINGS NOTES
These cover events which
might involve serious (in
extreme circumstances, even
fatal) injury.
These cover the many other
possibilities, generally less obvious
sources of danger, but which, under
certain circumstances, may also
cause damage or injury.
2
WARNINGS
••
•
•
•
Never touch, or allow any
object to come into contact
with, the rotating parts.
Model engine fuel is poison-
ous. Do not allow it to come
into contact with the eyes or
mouth. Always store it in a
clearly marked container and
out of the reach of children.
Model engine fuel is also
highly flammable. Keep it
away from open flame,
excessive heat, sources of
sparks,oranythingelsewhich
might ignite it. Do not smoke
orallowanyoneelsetosmoke,
near to it.
Model engines generate
considerable heat. Do not
touch any part of your
engine until it has cooled.
Contact with the muffler
(silencer), cylinder head or
exhaust header pipe, in
particular, may result in a
serious burn.
Never operate your engine in an en-
closed space. Model engines, like auto-
mobile engines, exhaust deadly carbon-
monoxide. Run your engine only in an
open area.
3
NOTES
•
•
•
•
•
These engine were designed for model
helicopters. Do not attempt to use it for any
other purpose.
Mount the engine in your model securely, fol-
lowing the manufacturers' recommendations,
using appropriate screws and locknuts.
Install an effective silencer (muffler). Frequent
close exposure to a noisy exhaust (especially
in the case of the more powerful high-speed
engines) may eventually impair your hearing
and such noise is also likely to cause
annoyance to others over a wide area.
Check the linkage to the throttle arm before
each flight.
Avoid sudden high r.p.m. immediately after the
engine is started, as the clutch will engage and
you may be struck by the rotor.
•
•
After starting the engine, carry out any needle-
valve readjustments after stopping the rotor by
closing the throttle to the lowest r.p.m..
Stop the engine before attempting to make
other adjustments to the carburetor.
Use an electric starter. The wearing of safety
glasses is also strongly recommended.
Press the rotor head down securely.
Take care that the glow plug clip or battery
leads do not come into contact with rotating
parts.
Adjust the throttle linkage so that the engine
stops when the throttle stick and trim lever on
the transmitter are fully retarded. Alternatively,
the engine may be stopped by cutting off the
fuel supply. Never try to stop the engine
physically.
•
•
4
NOTES
•
•
•
Take care that loose clothing (ties, shirt sleeves,
scarves etc.) do not come into contact with the
rotor. Do not carry loose objects (such as pen-
cils, screwdrivers, etc.) in a shirt pocket from
where they could fall through the rotor disc.
For their safety, keep all onlookers (especially
small children) well back (at least 20 feet or 6
metres) when preparing your model for flight. If
you have to carry the model to the take-off point
with the engine running, be especially cautious.
Hold the rotor securely and keep well clear of
spectators.
Warning! lmmediately after a glowplug-ignition
engine has been run and is still warm,
conditions sometimes exist whereby it is just
possible for the engine to restart when turned
over WITHOUT the glowplug battery being
reconnected. Remember this if you wish to
avoid the risk of accidents.
5
Because of initial tightness, a standard
electric starter may have difficulty in
rotating the engine when cold, before it has
been adequately run-in. In this case, use a
high-torque type starter. DO NOT, however,
confuse tightness with the symptoms of
hydraulic lock caused by an excess of fuel
within the cylinder - often the result of over-
priming. Attempting to force the engine to
turn over in this condition may cause
internal damage. Instead, remove the
glowplug, invert the engine and eject
surplus fuel from the combustion-chamber.
Note:
The MAX-46FX-H RING is a high-
performance engine that has been
developed expressly for "medium-sized"
radio-controlled helicopters.
INTRODUCTION BASIC ENGINE PARTS
Heatsink Head
Carburettor
Typr 40E
Crankshaft
Propeller nut
Crankcase
Drive Hub
Glowplug
Beam Mount
Cover Plate
MAX-46FX-H RING
6
INSTALLING THE GLOWPLUG
Install the washer on the
glowplug and screw
carefully into cylinder-
head, making sure that it
is not cross-threaded
before tightening firmly. Glow plug
Washer
INSTALLATION OF THE ENGINE
The under-surfaces of all O.S. engine beam
mounting lugs are precision machined flat and
exactyly parallel to the engine's horizontal axis. It is
essential that the engine mounts in the model are
also accurately made and aligned. If they are not,
they will cause stress and distortion within the engine
itself, probably resulting in loss of performance and
internal damage.
The recommended screws for securing the engine to
the engine mounts in the model are 3mm or 4-40
steel Allen type. It is also advisable to use lock
washers or LOCTITE to prevent nuts from loosening.
Front view
CORRECT
Side view
Top surfaces are in the same plane.
Re-align the surfaces as necessary
INCORRECT
Top surfaces are not
in the same plane. Top surfaces are not in the
same plane.
Engine does not rest firmly.
Make sure that only the under-surfaces
of the engine’s mounting lugs are in
contact with the engine mount.
If the crankcase body touches the
mount, chamfer the edges of the mount.
7
BEFORE STARTING
Tools, accessories, etc.
The following items are necessary for operating the
engine.
1 Fuel
Model glowplug engine fuel of good quality, preferably
containing a small percentage of nitromethane.
INSTALLATION OF COOLING FAN
As supplied the MAX-46FX-H is equipped with a
conventional drive hub, keyed to flats on each side of
the crankshaft. However, some helicopters require
this to be replaced by a taper collet for cooling fan
installation. Fit this as follows. Rotate crankshaft to
TDC. Remove drive hub and thrust washer. Slide
taper collet onto 3/8-in. dia. front journal with its slot
uppermost-i.e.along the full diameter of the journal
NOT passing over the gap formed either side of the
flats. It is not necessary to replace the thrust washer.
Open slot in taper collet
Flats each side of
crankshaft front journal
for drive hub.
Front Journal
Split Taper Collet
3 Glowplug battery
The power source for heating the glowplug may be
either a large heavy-duty 1.5volt dry cell, or preferably,
a 2-volt rechargeable lead-acid cell .
1.5 volt heavy-duty
dry battery or 2 volt rechargeable
lead-acid cell (at least 5Ah)
If a 2-volt cell is employed,
use a resistance wire, as
shown, to reduce applied
voltage, otherwise element
will overheat and burn out.
2 Glowplug
O.S. No.8 glowplug is installed in the engine.
8
Resistance coil
(nichrome wire)
Adjust applied voltage by changing the position of clip on
resistance coil until glowplug element is glowing bright red.
Battery leads
Raise
voltage to
increase
brightness.
Lower voltage to
reduce brightness.
Warning (Very hot)
Never touch the
nichrome wire
while the battery
is connected.
4 Plug wrench
Used for tightening glowplug. The
O.S. long plug wrench is available
as an optional accessory.
5 Battery leads
These are used to conduct current
from the battery to the glowplug.
Basically, two leads, with clips, are
required, but, for greater conve-
nience, twin leads with special
glowplug connectors, as shown on
theright,arecommerciallyavailable.
6 Fuel bottle or pump
For filling the fuel tank, a simple,
polyethylene"squeeze"bottle,with
a suitable spout,is all that is
required. Alternatively, one of the
purpose-made manual or electric
fuelpumpsmaybeusedto transfer
fuel directly from your fuel
container to the fuel tank.
For tightening
glowplug
Fuel bulb
Battery leads
Manual Electric
Fuel pumps
Fuel Can Filter
7 Fuel container filter
Install a filter on the outlet tube
of your refuelling container to
prevent entry of foreign matter
into the fuel tank
8 Silicone tubing
This is required for the
connection between the fuel
tank and engine.
Silicone tube
9
Table des matières
Autres manuels O.S. engine Moteur
O.S. engine
O.S. engine FSA-81 Guide de configuration
O.S. engine
O.S. engine GT15HZ600 Guide de configuration
O.S. engine
O.S. engine max-12TZ series Guide de configuration
O.S. engine
O.S. engine MAX-91SX-HRING C Spec PS VIPER Guide de configuration
O.S. engine
O.S. engine FS-120S-E Guide de configuration
O.S. engine
O.S. engine MAX-12CV Series Guide de configuration
O.S. engine
O.S. engine MAX-12TR Series Guide de configuration
O.S. engine
O.S. engine MAX-61SX-H RING WC Series Guide de configuration
O.S. engine
O.S. engine MAX-10LA Manuel utilisateur
O.S. engine
O.S. engine GT120THU Manuel utilisateur
O.S. engine
O.S. engine MAX-21TM Manuel utilisateur
O.S. engine
O.S. engine MAX-91HZ Manuel utilisateur
O.S. engine
O.S. engine MAX-55HZ HYPER Guide de configuration
O.S. engine
O.S. engine Max-50SX-H Ring Guide de configuration
O.S. engine
O.S. engine MAX-15 Guide de configuration
O.S. engine
O.S. engine GT15 Guide de configuration
O.S. engine
O.S. engine MAX-70SZ-Hring Guide de configuration
O.S. engine
O.S. engine FS-70S Manuel utilisateur
O.S. engine
O.S. engine Max-BGX-1 Ring Guide de configuration
O.S. engine
O.S. engine MAX-15CV-R Series Guide de configuration
