GeForce FX/MX Series

VGA Card

User's Guide

Declaration of Conformity

According to 47 CFR, Parts 2 and 15 of the FCC Rules

The following designated product:

EQUIPMENT: VGA Card

is a Class B digital device that complies with 47 CFR Parts 2 and 15 of the FCC Rules. Operation

is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired operation.

Disclaimer

The information in this document is subject to change without notice and does not represent a

commitment on the part of the vendor. No warranty or representation, either expressed or implied, is

made with respect to the quality, accuracy or fitness for any particular purpose of this document. The

manufacturer reserves the right to make changes to the content of this document and/or the products

associated with it at any time without obligation to notify any person or organization of such changes.

In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential

damages arising out of the use or inability to use this product or documentation, even if advised of the

possibility of such damages. This document contains materials protected by copyright. All rights are

reserved. No part of this manual may be reproduced or transmitted in any form, by any means or for

any purpose without express written consent. Product names appearing in this document are

mentioned for identification purposes only. All trademarks, product names or brand names appearing in

this document are registered property of their respective owners.

Printed in Taiwan

FCC Compliance Statement

This equipment has been tested and found to comply with limits for a Class B digital device, pursuant

to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful

interference in residential installations. This equipment generates, uses, and can radiate radio frequency

energy, and if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause interference to radio or television equipment

reception, which can be determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Move the equipment away from the receiver.

-Plug the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-Consult the dealer or an experienced radio/television technician for additional

suggestions.

Only equipment certified to comply with Class B should be attached to this equipment, and must have

shielded interface cables. You are cautioned that any change or modifications to the equipment not

expressly approved by the party responsible for compliance could void your authority to operate such

equipment. This device complies with Part 15 of the FCC rule. Operation is subjected to the following

two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that may cause

undesired operation.

Oct 2003

OST-CONSUMER

RECYCLED PAPER

100%

CONTENTS

Chapter 1 Introduction ..............................................................1

Product Specifications...........................................................................................1

Package Contents ..................................................................................................2

System Requirements............................................................................................2

Chapter 2 Hardware Setup........................................................3

Installing the Hardware........................................................................................3

硬體的安裝.............................................................................................................3

Installation du matériel.........................................................................................3

하드웨어 설치.......................................................................................................4

Installation der Hardware....................................................................................4

Chapter 3 Driver Setup..............................................................5

Display Drivers Setup ...........................................................................................5

Display properties .................................................................................................5

Appendix....................................................................................6

WinCinema (Optional) .........................................................................................6

DirectX 9.0 (FX Series Only)................................................................................6

Video in Drivers (Optional)..................................................................................6

3Deep E-color (Optional)......................................................................................6

WinProducer3 (Optional).....................................................................................6

Chapter 1

User’s Guide 1

Chapter 1 Introduction

Product Specifications

Interface

-AGP 2x/4x/8x and AGP texturing support

Chipset

-NVIDIA GeForce FX / MX Series GPU

Memory Interface

-Supports 64 /128/256 MB DDR SDRAM

Features (For MX Series)

-64 / 128-bit memory interface

-256-bit graphics architecture

-350 MHz internal RAMDAC (Integrated dual DACs)

-NVIDIA nView Multi-Display Technology

-Cube environment mapping

-NVIDIA Shading Rasterizer technology

-Integrated hardware T & L

-MX Memory Crossbar (dual memory controllers)

-32-bit color with 32-bit Z-stencil

-Multibuffering (double, triple, quad) for smooth animation and video

playback

-Lightspeed Memory Architecture™ II technology

-Video Processing Engine (VPE)

-Unified Driver Architecture (UDA)

-Accuview ™ Antialiasing Engine

-NVIDIA Digital Vibrance Control technology

Features (For FX Series)

-350 / 400 MHz internal RAMDAC

-4 pixels per clock rendering engine

-16 texels per pixel with 8 textures applied per clock

-CineFX Shading Architecture

-128-bit studio-precision color

-High-performance, high-precision 3D rendering engine

-High-performance 2D rendering engine

-Advanced Display Pipeline with full nView Capabilities

-Digital Vibrance Control (DVC) 3.0

-NVIDIA nView multi-display technology

-Unified Driver Architecture (UDA)

High quality video playback

-Dual, 350 / 400 MHz internal RAMDACs for display resolutions up to

2048*1536* 32 bpp @75/85Hz

-Integrated NTSC/PAL TV encoder support resolutions up to 1024*768

without the need for panning with built-in Macrovision copy protection

-DVD and HDTV-ready MPEG-2 decoding up to 1920*1080i resolutions

-Support for dual-link DVI for compatibility with next generation flat panel

displays with resolutions greater than 1600*1200 without the need for

Chapter 1

User’s Guide

reduced blanking

-Single-Link external TMDS (DVI 1.0), max resolution over digital port:

1600*1200*60Hz (VESA STD) (MX series only)

Full Software Support

-Microsoft DirectX optimizations and support

-Full OpenGL 1.3/1.4 and lower support

-Complete support DirectX 8.x/9.0 and lower

-WHQL-certified Windows 9x / ME / 2000 / XP

Other Features

-TV-out

-VIVO (Optional)

-DVI-I (Optional)

Package Contents

1. GeForce FX/MX series VGA card

2. User's Guide

3. Driver Pack

- Windows 9x/ME/2000/XP drivers

- Adobe Photoshop Album 1.0 (Optional)

- WinCinema (Optional)

- WinProducer 3.0 (Optional)

4. S-Video cable (Optional)

System Requirements

-Intel Pentium®II or newer compatible CPU (Intel Pentium®III or AMD

Athlon®or newer CPU’s recommended)

-Support AGP 1X / 2X / 4X / 8X universal slot. (FX series only)

-VGA/Super VGA monitor, supporting minimum 640x480 resolution.

-64MB RAM or higher.

-15MB HDD space.

-CD-ROM or DVD-ROM Driver.

-DirectX 8.x/ 9.0 or lower.

-Windows 9x / ME / 2000 / XP operation system

Chapter 2

User’s Guide 3

Chapter 2 Hardware Setup

Installing the Hardware

1. Turn off the computer's power and make sure the system is properly

grounded (leave the power cord connected). Then disconnect the monitor

signal cable.

2. Remove the computer chassis cover. Be sure to discharge your body's static

electricity by touching the metal area of the computer each time before

touching both the old and new VGA cards.

3. Remove the old card, if it exists.

4. Grasp the edge or bracket of the card, align your card with an empty AGP

expansion slot and slide it into place.

5. Replace the screw to fasten the card onto the chassis, and replace the

computer chassis cover.

6. Plug the monitor cable into your card, and then turn on the computer and the

monitor.

硬體的安裝

1. 關掉電腦的電源，並且確定拔掉電源線，然後拔除螢幕的訊號線。

2. 移開電腦的外殼蓋。在每次安裝新的和舊的顯示卡前，請觸摸電腦的金屬

部位，以確保排出身體中之多餘靜電。

3. 假如你有舊的顯示卡請先移除。

4. 握緊你的顯示卡，小心地將顯示卡插入空的 AGP 插槽中。

5. 用螺絲將顯示卡固定於機殼中，並且將電腦的外殼蓋放回原處，並用螺絲

栓緊。

6. 連接螢幕的排線於顯示卡上，並且打開電腦和螢幕的電源開關。

Installation du matériel

1. Eteignez votre ordinateur et déconnecté votre écran.

2. Enlevez le couvercle ou les panneaux de côté de votre ordinateur (consultez le

manuel d’instructions de votre ordinateur pour les instructions de montage et

de démontage).

3. Enlevez la carte graphique AGP présente -o u – enlevez la languette de métal

qui recouvre l’emplacement du connecteur AGP.

4. Alignez le côté de votre carte où se trouvent les connecteurs avec

l’emplacement du connecteur AGP et appuyez fermement jusqu’à ce qu’elle

soit complètement mise ne place (ne SURTOUT PAS forcer la carte dans son

emplacement – appliquez une poussée uniforme de chaque côté de la carte).

Chapter 2

User’s Guide

5. Visez la carte au châssis, et remonté le couvercle du boîtier.

6. Branchez le cordon VGA à la carte graphique et reconnectez votre moniteur

ainsi que le reste des câbles.

하드웨어 설치

1. 먼저 컴퓨터의 전원을 차단하고 전원이 완전히 차단되었는지 확인한

후에 모니터 시그널 케이블을 분리해 주십시오.

2. 컴퓨터 케이스의 덮개를 열고 VGA 카드를 장착하기에 앞서

컴퓨터를 전자기로부터 보호하기 위해 전자기로부터 안전한 복장 및

도구를 착용하거나 이용해 주십시오.

3. 만약 구형카드가 시스템에 장착되어 있다면 먼저 구형카드를

시스템에서 분리해 주십시오.

4. 케이스 뒷면 브라켓 장착 부분과 AGP 확장 슬롯에 수직이 되도록

하여 카드를 조심스럽게 AGP 확장 슬롯에 장착해 주십시오.

5. VGA 카드를 장착한 후 컴퓨터 케이스 덮개를 씌워 주십시오.

6. VGA 카드에 모니터 케이블을 연결한 후 컴퓨터 본체와 모니터의

전원을 켜주십시오.

Installation der Hardware

1. Schalten Sie den Computer aus, und stellen Sie sicher, dass das Gerät richtig

geerdet ist (lassen Sie das Netzkabel sowohl am PC als auch an der

Netzsteckdose angeschlossen). Trennen Sie jetzt das Signalkabel des

Monitors vom VGA-Anschluß.

2. Entfernen Sie die Abdeckung des PC-Gehäuses. Stellen Sie sicher, dass Sie

sich jedes mal durch Berührung des Metallgehäuses von statischer Elektrizität

befreien, bevor Sie die alte oder neue VGA-Karte anfassen!

3. Remove the old card, if it exists.

4. Grasp the edge or bracket of the card, align your card with an empty AGP

expansion slot and slide it into place.

5. Replace the screw to fasten the card onto the chassis, and replace the

computer chassis cover.

6. Plug the monitor cable into your card, and then turn on the computer and the

monitor.

Chapter 4

User’s Guide 5

Chapter 3 Driver Setup

Display Drivers Setup

For Driver setup in Win98se/ME/2000/XP mode, please follow the steps below.

1. Insert VGA Driver Package CD into CD-ROM driver.

2. Please click on [Display Drivers] to begin driver installations.

3. Please click [Yes] to continue.

4. Please select [Yes] to restart computer now or [No] for restart later, then click

[Finish] to complete the installation.

Display properties

Select from [Start] -> [Settings] -> [Control Panel] ->[Display Properties]. Click

[Advanced] to enter the advanced setup for your display card.

a) nView Display Setup:

Select from [Start] ->[Settings] -> [Control Panel] -> [Display Properties] to

open the submenu. Click on nView Display Mode to setup the various nView

options.

Note: When your monitor display became unclear after it had been plugged

into the DVI port of VGA card. Please follow the steps below to resolve:

1. Please select Display to [Digital Display].

2. Please click [Device Setting >>], and then select [Screen Adjustment].

3. Please select [Use Display Adapter Scaling].

b) Performance and Quality Settings:

This option allows users to adjust Direct 3D Settings, Refresh Rate Override, and

OpenGL Settings.

c) Overlay Controls:

Use these controls to adjust the Brightness, Contrast, Hue and Saturation to

achieve optimal image quality during video or DVD movie playback.

d) Desktop Utilities:

Users can enable/disable Display Media Center icon, Enable NVIDIA Desktop

Manager and Desktop Manager Configuration on the desktop.

e) NVRotate:

The NVRotate feature lets you view your Windows desktop in Landscape or

Portrait mode. You can rotate desktop by 90, 180 and 270 degrees.

Appendix

User’s Guide

Appendix

WinCinema (Optional)

Installations of WinDVD, WinDVD Creator Setup and WinRip 2.1 Setup are

included.

1. Click [WinCinema] to begin WinCinema installations.

2. Please click [I have] and enter personal information on boxes below.

3. Choose [Select All] to select all the products. Click [Next >] to proceed.

DirectX 9.0 (FX Series Only)

1. If the system has an older version of DirectX, please click [DIRECTX 9.0] to

upgrade to the latest version.

2. After reading the license agreement, please click [Next >].

3. Please click [Next >] to continue.

4. Please click [Finish] to complete the setup process.

Video in Drivers (Optional)

1. Click on [Video In Drivers] to begin the installations.

2. Please click [Next >] to begin the setup process.

3. Please select [Yes] for restarting computer now or [No] for restart later, then

click on [Finish] to complete installation.

3Deep E-color (Optional)

1. Please click [Next >] to continue.

2. After reading the license agreement, please click [Yes] to continue.

3. Please click [Next >] to continue.

4. Please click [OK] to allow the 3Deep E-color to tune up your display.

5. Choose your screen between CRT and FLAT PANEL and then press [Next >]

to continue.

WinProducer3 (Optional)

1. Please click [Next >] to continue installing WinProducer3.

2. Please click [Yes] to continue installing WinProducer3.

3. Enter personal information on spaces below to register the product.

4. Please select a folder where the program will be installed and click [Next >].

5. Please select one folder from existing list of folders and click [Next >].

6. Please click [Next>] to continue installing WinProducer 3.

7. Please click [Finish] to complete the WinProducer 3 installation program.

Autres manuels pour GeForce FX Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Nvidia Carte vidéo

Nvidia

Nvidia Quadro FX 3700 Instructions d'utilisation

Nvidia

Nvidia Geforce RTX 2080 Manuel utilisateur

Nvidia

Nvidia Quadro K6000 Manuel utilisateur

Nvidia

Nvidia Video-PX9000 series Manuel utilisateur

Nvidia

Nvidia FX 1500 Instructions d'utilisation

Nvidia

Nvidia NVS 810 Manuel utilisateur

Nvidia

Nvidia geforce gtx 1080 Manuel utilisateur

Nvidia

Nvidia Quadro FX 3700 Manuel utilisateur

Nvidia

Nvidia NVIDIA GEFORCE 7800 GT Instructions d'utilisation

Nvidia

Nvidia GeForce 6 series Manuel utilisateur

Nvidia

Nvidia QUADRO G-SYNC II Manuel utilisateur

Nvidia

Nvidia Quadro K5000 Manuel utilisateur

Nvidia

Nvidia 5700 - ASUS V9570 Series GeForce FX AGP 256MB S-VId DVI VGA Video... Manuel utilisateur

Nvidia

Nvidia Titan RTX Manuel utilisateur

Nvidia

Nvidia NVIDIA Quadro FX 1300 Instructions d'utilisation

Nvidia

Nvidia Quadro 6000 Manuel utilisateur

Nvidia

Nvidia GV-N430-2GI Manuel utilisateur

Nvidia

Nvidia GeForce FX Series Manuel utilisateur

Nvidia

Nvidia GeForce GTX 650 Ti Manuel utilisateur

Nvidia

Nvidia GEFORCE GT 240 Manuel utilisateur

Nvidia

Nvidia D870 - X8 INTERFACE CARD Manuel utilisateur

Nvidia

Nvidia 4000 - e-GeForce MX 128MB DDR PCI Graphics... Manuel utilisateur

Nvidia

Nvidia GeForce GTX 980 Manuel utilisateur

Nvidia

Nvidia FX4500 - Apple MAC Pro QUADRO FX 4500 Video Card... Manuel utilisateur

Manuels Carte vidéo populaires d'autres marques

Gainward

Gainward GeForce GTX 690 4GB Manuel utilisateur

ATI Technologies

ATI Technologies RADEON 137-40225-20 Manuel utilisateur

MSI

MSI N220GT series Manuel utilisateur

ATI Technologies

ATI Technologies RADEON 7000 MAC EDITION Manuel utilisateur

SIIG

SIIG aurora Manuel utilisateur

ClearSpeed

ClearSpeed ClearSpeed Advance e720 Manuel utilisateur

MSI

MSI R7850 series Manuel utilisateur

DVS

DVS Atomix HDMI Manuel utilisateur

Aztech

Aztech VGS3D-AGP Manuel utilisateur

Advoli

Advoli TB4 Standard Manuel utilisateur

ELSA

ELSA ERAZOR III LT Manuel utilisateur

Gigabyte

Gigabyte GV-R7500L Manuel utilisateur

Themis

Themis TGA-7000 PMC Manuel utilisateur

EMS

EMS XtremeRGB-Ex1 Manuel utilisateur

Pioneer

Pioneer PDA-5003 Manuel utilisateur

QDI

QDI N2 Manuel utilisateur

NEC

NEC N8116-48 Manuel utilisateur

MSI

MSI R7770 PoweR Edition Manuel utilisateur
