NuWaves NUPOWER L60T01 Manuel utilisateur



USERMANUAL

NUPOWER



L60T01

L‐BANDPOWERAMPLIFIER



PARTNUMBER:

NW‐PA ‐L60T01



NuWavesEngineering

132EdisonDrive

Middletown,Ohio45044

PH:513‐360‐0800

FAX:513‐539‐8782

www.nuwaves.com

product.sales@nuwaves.com

NuPower

L60T01UserManual 



Rev1.1

1



1NUPOWER

PRODUCT LINE OVERVIEW

TheNuPowerfamilyofsolid‐stateRFpoweramplifier(PA)modulesisdesignedtomeetthedemanding

needsoftheAerospace&Defense,Industrial,andCommercialmarkets.Basedonthelatestgallium

nitride(GaN)technology,NuPower’spowerefficiencyandminiatureformfactormakeitidealforsize,

weight,andpower‐constrainedRFtelemetryandtacticalcommunicationssystems.

1.1 NUPOWER

PRODUCT LINE HIGHLIGHTS



HighPerformance:Uniquecombinationofcoverage,miniatureformfactors,andhighefficiency.



Enclosures:TheNuPowerfamilyofpoweramplifiersishousedinanaluminumenclosurewith

mountingholesincorporatedintothechassis.



CompletelyCharacterized:TheNuPowerfamilyofsolid‐statepoweramplifiershasbeen

completelycharacterizedovertemperature,voltage,andfrequency.Thesehigh‐performance

modulesoffersignificantvaluefortheOEMuserortheSystemsIntegrator.



UserFriendly:Over‐Voltageprotectionandregulatorthermalshutdownprovidedefenses

againstuserinterfaceissues.



HighReliability:NuWaves’selectionofconservativelyratedcomponentsprovideshigh

reliability.EachNuPowerisinspectedtoIPC‐A‐610ClassIIqualitystandards.NuWaves’Quality

ManagementSystemisAS9100:2016RevDandISO9001:2015certified.



Applications:RFTelemetry•RFCommunicationSystems•ElectronicWarfare•Unmanned

AircraftSystems(UAS)•UnmannedGroundVehicles(UGV)•UnmannedSurfaceVehicles(USV)•

SoftwareDefinedRadios• TestLabs



AvailableOptions:



oFan‐cooledheatsinkwith28Voperatedfan

oLabeledinterfacecablewithbananajackplugs



NuPower

L60T01UserManual 



Rev1.1

2



2NUPOWER

L60T01 PA OVERVIEW

TheNuPower

TM

L60T01PAisahighlyefficient,solidstatepoweramplifierthatprovidesover50watts

(minimum)ofRFpoweracross960MHz–1390MHz.



Basedonthelatestgalliumnitride(GaN)technology,NuPowerL‐Bandpowerefficiencyand<10in

3



cubicinchformfactormakeitidealforsize,weight,andpower‐constrainedRFtelemetryandtactical

communicationsystems.



TheNuPower

L60T01ruggedizedchassisallowsthesystemintegratortoeasilyincorporatetheunit

intoaplatformoperatinginharshenvironmentswithlimitedspace,suchassmallUnmannedAircraft

Systems(UAS).

RF Output

50W min

960 - 1390 MHz

0dBm Nominal Input

RF Input

Gain = 48 dB

Bias 1 Bias 2 Bias 3 Bias 4

28VDC_SW 28VDC_SW28VDC_SW28VDC_SW

Limiter

Pin (dB)

Pout (dB)

Overvoltage

Protection

+28V Prime +28V SW

Enable

Figure 1: NuPower L60T01 Functional Diagram





NuPower

L60T01UserManual 



Rev1.1

3

2.1 NUPOWER L60T01 PA SPECIFICATIONS

ThesubsequenttablesinthissectionoutlinetheNuPowerL60T01’sperformancespecifications.



Table 1: NuPower L60T01 Electrical Specifications

Parameter Specification

FrequencyRange960MHzto1390MHz

RFOutputPower60Watts(typ)

50Watts(min)

OutputPower@1dBCompression

41dBm@960MHz

43dBm@1175MHz

43dBm@1390MHz

RFGain48dB(typ)

InputVSWR1.9(typ),2.3(max)

OutputMismatch

(NoDamage)10:1

NominalInputDriveLevel0dBm

MaximumInputDriveLevel

(Nodamage)+15dBm

Harmonic

:≤‐8dBc

:≤‐17dBc

ThirdOrderInterceptPoint

(Twotonetestat1MHzspacing,

Pout=20dBm/tone)

48dBm@960MHz

49dBm@1175MHz

45dBm@1390MHz

SwitchingSpeed2µS

OperatingVoltage+27to+30VDC

OperatingCurrent4.5A@+28VDC(typ)

ModuleEfficiency42%

PowerAmplifierEnableGNDOn

Impedance50Ω

NuPower

L60T01UserManual 



Rev1.1

4



Table 2: NuPower L60T01 Environmental Specifications

Operating Conditions Specification

OperatingTemperature ‐40to+60

C(ambient)

‐40to+85

C(baseplate)

StorageTemperature‐55to+85

C



Table 3: NuPower L60T01 Mean Time Between Failure (MTBF)

Conditions Hours

GroundBenign(GB)292,657

AirborneInhabitedCargo(AIC)14,955

AirborneInhabitedFighter(AIF)11,976

AirborneUninhabitedCargo(AUC)4,994

AirborneUninhabitedFighter(AUF)4,108





NuPower

L60T01UserManual 



Rev1.1

5



2.2 NUPOWER L60T01 PA MECHANICAL SPECIFICATIONS

Figure 2: NuPower L60T01 Mechanical Outline



Table 4: NuPower L60T01 Mechanical Specifications

Parameter Specification

RFConnectorsSMA(female)

Control/PowerInterfaceConnector9PinMicro‐D(socket)

Dimensions(LxWxH)4.5”x3.5”x0.61”

Weight9oz.





NuPower

L60T01UserManual 



Rev1.1

6



2.3 HEAT SINKING

TheNuPowerL60T01isofferedasastand‐alonemoduleorwithanaccessorykit

(p/nNW‐PA‐ACC‐KT03),whichincludesa28VDCfan‐cooledheatsinkandrequisitepowercable.[Thekit

alsoincludesanupgradedmoduleinterfacecableassembly,labeledandterminatedwithbananaplugs.]



Figure 3: The NuPower PA Kit offers “out‐of‐the‐box” operation for the user. The 28 VDC fan‐cooled

heatsink is shown with the NuPower L60T01 mounted.



Caution:Theuseofexternalheat‐sinkingisrequiredespeciallyforthoseapplications

requiringhighdutycycleoperation(e.g.continuouswave)orforextendedon‐timetesting.

Operationwithoutaproperheatsinkundertheseconditionswillcausepermanentdamage

totheproductandwillvoidtheproductwarranty.



Themaxoperatingtemperatureis85˚C(baseplate).





NuPower

L60T01UserManual 



Rev1.1

7



3SETUP AND OPERATION

ThissectionprovidesspecificdetailsforproperoperationoftheNuPowerL60T01module.Following

theseguidelineswillpreventdamagetothepoweramplifierorexternalequipment.

3.1 POWER SUPPLY REQUIREMENTS

TooperatetheNuPowerL60T01,ensurethatthepowersupplyhasadequateoverheadtosourcethe

currentdemandoftheRFpoweramplifier.Thepowersupplysourcemustprovideatypicalvoltageof

+28VDCwithgreaterthan5ampscapability.

3.2 CONNECTING A PROPER LOAD TO THE ANTENNA TERMINAL

TopreventdamagetothePA,theantennaterminalmustbeterminatedintoa50Ωload.Examplesofa

properloadinclude:



Directlyconnectingtoanantennaspecifiedforthefrequencyrange(960MHzto1390MHz).

ConnectingtoaninappropriateantennamayresultindamagetothePAmodule.

Connectingtoaproperantennathrougha50Ωtransmissionlineorcoaxialcable.Avoidusing

damagedcablesorcorrodedconnectorswhileattachingtheunittoanantenna.

Terminatingtheantennaterminalintoa50Ωpowerattenuatorwithminimum20dB

attenuation.

ConnectingtoaloadcapableofdissipatingtheRFpowerfromthePAmodule.Loadscapableof

handling50Watts(min)arerecommended.

3.3 POWERING‐UP THE NUPOWER L60T01

TheNuPowerL60T01mustbeterminatedtoaproperloadbeforepowerisapplied.RefertoSection3.2

forthespecificationsoftheproperload.AfterthePAisproperlyterminated,theinterfacecablecanbe

connectedtotheunitandpowercanbeapplied.ThePAisnowreadyforoperation.

3.4 TRANSMIT TURN‐ON TIME



Caution:DonotapplytransmitdatauntilthePAmoduleisatfullpower.Thiswillprevent

lossofdataatthebeginningofamessage.



TheNuPowerL60T01isatfullpowerapproximately1µSaftertheRFEnablelinegoeslow(ground).

Therefore,transmitdatacanbeappliedtotheinputafter1µSwithoutlossofdata.

3.5 RF OUTPUT POWER VS. SUPPLY VOLTAGE

TheNuPowerL60T01wasdesignedfor+28VDCoperation.



NuPower

L60T01UserManual 



Rev1.1

8

4HARDWARE INTERFACE

TheRFInputconnectorisSMA(female).

TheRFOutputconnectorisSMA(female).

Thepin‐outdefinitionsforthe9pinMicro‐DsocketconnectorareprovidedinTable5.Ina

typicalinstallation,thePAmoduleismatedtoahostcontrollerboardviaacableharness.



TheRFOutSMAconnectoristheantennaconnection.Thisconnectionshould

alwaysbeloadedinto50Ω,otherwisethePAcouldbedamaged.

4.1 INTERFACE CABLE HARNESS

Thecableharnessthatconnectsthehostcontrollertothe9pinMicro‐DconnectoroftheNuPower

L60T01ismadeupof9wires.

Table 5: NuPower L60T01 Interface Pin‐Out Definitions

Pin No. Pin Name I/0 Description

3,4,5VSupplyIPrimaryPower(+28VDC)

1,2,6,8GNDISignalandPowerGround

7TempFlag0Over‐tempIndicator

(Low=temperaturefault)

9RFEnableITransmitControl



Figure 4: Micro‐D Socket Locations

4.2 DC POWER

ThenominalsupplyvoltagefortheNuPowerL60T01is+28VDC;Theacceptablesupplyvoltagerangeis

+27to+30VDC.



NuPower

L60T01UserManual 



Rev1.1

9



4.3 GROUND

ThesignalandpowergroundsaretiedtogetherinthePAmodule.

4.4 RF ENABLE

Thissignalisthelogiccontrolinputthatdesignateswhethertheunitisintransmitorstandbymode.The

RFEnablelineispulledhighinternallyplacingthePAmoduleinstandbymode.Ifthepinisleftfloating

(i.e.notconnected),theunitwilldefaulttostandbymode.

Groundingthepin(i.e.avoltagebelow+0.2VDC)placestheunitintransmitmode.Theusercaneither

connecttheRFEnablelinetopins1,2,6&8ontheCTRL/PWRinterfaceconnector,oranopendrain

logiclinecapableofsinking500µAtoplacetheunitintransmitmode.

4.5 TEMP FLAG

Thissignalisanoutputtoindicateanover‐temperatureconditionintheNuPowerL60T01.Alogichigh

(+5VDC)indicatesnormaloperation,whilealogiclow(0VDC)indicatesanover‐temperaturecondition.

TheNuPowerL60T01incorporatesinternallogiccircuitrythatturnsofftheDCbiastotheRFtransistors.



Caution:Theamplifiershouldbeshutdownandallowedtocooloffwhentheover‐

temperatureflagissetlowtoavoiddamagetothemodule.




