NuWave Nutri-Master Guide rapide
Owner’s Manual & Complete Recipe Book
NuWave Nutri-Master™
Slow Juicer
2
TABLE OF CONTENTS
Owner’s Manual
Important Safeguards ............... 4
Save These Instructions ........... 5
Parts Description....................... 6
Assembly Instructions ............... 7
Spinning Brush Assembly ......... 8
Operating Instructions .......... 9-10
Precautions ........................ 11-13
Troubleshooting Guide ....... 13-15
Warranty ................................. 16
Healthy Juice Recipes
Juicer Tips
Apple Juice ............................. 19
Orange Juice........................... 19
Carrot Juice............................. 19
Grape Juice............................. 19
Cranberry Cravings ................. 20
Grape-Grapefruit Juice ........... 20
Cherry Surprise ....................... 21
Berry Juice .............................. 21
Pear Juice ............................... 22
Watermelon Juice ................... 22
Pineapple-Grape Juice ........... 22
Grapefruit-Orange Juice ......... 22
Simple Fruit Juice ................... 24
Blue Moon ............................... 24
Tomato Juice ........................... 23
Pomegranate Juice ................. 23
Carrot Cran-Apple Juice ......... 23
Detoxifying Juice ..................... 25
Cleansing Juice....................... 25
Apple Zinger............................ 26
Apple-Squash Juice ................ 26
Digestion Aid ........................... 27
Kiwi Apple Juice ...................... 27
Breathe Right Juice................. 27
Watermelon-Kale Juice ........... 27
Carrot-Broccoli Juice............... 28
Carrot and Kelp Juice ............. 28
Celery and Carrot Blend ......... 29
Peas and Carrots .................... 29
Pomegranate-Apple Juice....... 30
Cherry Pomegranate Juice ..... 30
Sweet and Spicy Watermelon
Juice........................................ 31
Grapefruit Medley ................... 31
Strawberry-Rhubarb Juice ...... 32
Peppy Parsley Apple Juice ..... 32
Red Dawn Juice ...................... 33
Veggie Chiller .......................... 33
Rising Star Juice ..................... 34
Tangy Tomato Juice ................ 34
Red Rider ................................ 35
Spinach Juice.......................... 35
Easy Green Juice.................... 36
Broccoli Cabbage Juice .......... 36
Cabbage Juice ........................ 37
Sweet Asparagus Juice........... 37
Smoothie Recipes
Banana Berry Smoothie .......... 39
Honey Banana Smoothie ........ 39
Spiced Orange Smoothie ........ 40
Pineapple Mango Smoothie .... 40
Green Apple Smoothie ............ 40
3
Pulp Recipes
Baking
Orange Carrot Pulp Mufns ...... 42
Apple Cinnamon Pulp Mufns .. 43
Fat-Free Sugar-Free Blueberry
Pulp Mufns .............................. 44
Berry Pulp Mufns .................... 45
Savory Pulp Mufns .................. 46
Orange Carrot Pulp Mufns ...... 47
Cookie Recipes
Baking
Apple Oatmeal Cookies ............ 49
Butter Berry Cookies................. 50
Banana Pulp ............................. 51
Papaya Salsa............................ 53
Corn Chili Salsa ........................ 53
Mango, Apple and Black Bean
Sauce........................................ 54
Heavenly Apple Sauce.............. 54
Red Pepper Dip ........................ 55
Avocado Cucumber Dip ............ 55
Raw Tomato-Basil Soup ........... 57
Raw Asparagus Soup ............... 58
Raw Creamy Carrot-Avocado
Soup ......................................... 58
Almond Milk .............................. 59
Cashew Milk ............................. 59
Manual del Usuario.............. 60-70
4
IMPORTANT SAFEGUARDS
All users of this appliance must read and understand these safety precautions
before operating to avoid personal injury or damage to the appliance.
Important Safeguards
WARNING
Hazards or unsafe practices that could result in appliance damage, serious
personal injury or death.
1. When using electrical appliances, basic safety precautions should always be
followed. Read all instructions before using the NuWave Nutri-Master™ Slow Juicer.
2. Close supervision is necessary when any appliance is used near children.
3. To protect against risk of electrical shock, do not put the main body (motor) in
water or any other liquid.
4. Avoid contact with moving parts.
5. Unplug from outlet when not in use, before assembling or taking off parts and
before cleaning.
6. To protect against electric shock, DO NOT immerse cord, plug or any part of the main
unit in water or any other liquids.
7. Do not operate any appliance with damaged cord or plus, or after the appliance
malfunctions, or is dropped or damaged in any manner. Return appliance to
NuWave, LLC for examination repair or electrical or mechanical adjustment.
8. Always make sure hopper is securely fastened in place before motor is tuned on.
Do not unfasten hopper while juicer is in operation.
9. Do not let cord hang over edge of table or counter.
10. Be sure to turn switch to off position after each use of your juicer. Make sure
the motor stops completely before disassembling.
11. Do not put your ngers or other objects into the juicer while it is operation. If food
becomes lodged in opening, use food pusher or another piece of fruit or vegetable to
push it down. When this method is not possible, turn the motor off and disassemble
juicer to remove the remaining food.
12. Do not place on or near a hot gas or electric burner or in a heated oven.
13. Do not use outdoors.
14. Do not use appliance for other than intended use.
15. Do not use chamber if it is cracked or chipped.
16. Do not use attachments not recommended or sold by the product manufacture.
17. Do not plug or unplug the product into/from the electrical outlet with a wet hand.
18. To disconnect from an electrical outlet, pull directly on the plug: do not pull on the
power cord.
19. Children should be supervised to ensure that they do not play with the appliance.
5
Save These Instructions
IMPORTANT SAFEGUARDS (Continued)
SAVE THESE INSTRUCTIONS
CAUTION
Hazards or unsafe practices that could result in minor personal
injury or appliance damage.
1. Do not operate without locking the Hopper properly.
2. Do not attempt to juice hard materials such as large seeds (those that cannot
be swallowed or chewed), pits, or ice.
3. Do not attempt to move the base while operating.
4. Do not put any parts into the dishwasher or use abrasives to clean. Expose
to heat or abrasives can cause damage.
5. Do not operate the appliance while the Chamber is empty. Operating without
adding any ingredients will damage the Auger.
6. If food gets stuck in the feeding tube, do not use anything other than
provided pusher.
7. Do not use for more than 30 minutes continuously (for household use only).
8. If the appliance gives off an unpleasant smell or smoke or overheats,
stop using immediately and contact customer service. When using a new
appliance, it may give off a smell, which will disappear naturally over time.
9. Do not input fruit preserved in sugar, honey, alcohol, etc, as the hopper may
not open easily.
10. Always unplug the appliance after use.
11. Always place the product on a at, level, stable surface.
12. Keep the product out of reach of children and pets. This product is not
intended for use by children.
13. After using the Slow Juicer, user should clean the Auger with mild detergent
and cooking oils such as olive oil or canola to remove color from pigment
from the fruit.
20. Do not let the power cord come in contact with hot surfaces, including the stove.
21. Do not operate the appliance if the rotating sieve is damaged.
22. Only operate the appliance if the pulp container is in place.
23. Never insert ingredients by hand. Always use the provided food pusher.
24. Do not attempt to remove parts when locked in place. Always ensure that parts are
rotated to the open position before removing.
6
1
6d
2
5b
6a
4a
9
3
5a
8
10
76b
4b
Pusher
Model# 27121
Hopper
Model# 27133
Auger
Model# 27122
Fine Strainer
Model# 27123
Coarse Strainer
Model# 27124
Spinning Brush
Model# 27125
Silicone Brush
Model# 27126
Chamber
Model# 27127
Pulp Spout
Juice Spout
Juice Cap
Model# 27128
Cleaning Brush
Model# 27132
Base
Model# 27131
Pulp Container
Model# 27130
Juice Container
Model# 27129
1
2
3
4a
4b
5a
5b
6a
6b
6c
6d
7
8
9
10
PARTS DESCRIPTION
Parts Description
6c
7
ASSEMBLY INSTRUCTIONS
Place the Strainer (Fine or Coarse) inside the
Spinning Brush. Push the Strainer into the Spinning
Brush until the edges properly align and the Strainer
easily rotates within the Spinning Brush.
Lower the Spinning Brush with Strainer attachment
into the Chamber. Place the Spinning Brush inside
the Chamber so that the Red Dots are properly
aligned. Do not force the Spinning Brush downward
during assembly.
Place the Auger directly in the middle of the Strainer
attachment and carefully rotate the Auger clockwise
until it is properly secured and aligned.
Ensure that the Juicer power switch is set to the
OFF position. Place the Hopper on top the Chamber
with OPEN aligned with the arrow on the Chamber.
Rotate the Hopper clockwise until CLOSE is aligned
with the arrow on the Chamber and the Hopper is
locked into place.
Place the Chamber onto the
Base ensuring that the arrow on
the back of the Hopper is aligned
with the arrow on the base.
The Chamber must be properly
sealed and aligned on the Base
to function.
1
2
4
3
5
Assembly Instructions
Hopper
Base
Back of the Hopper
Strainer
Chamber
Both the Strainer
and Chamber
have Red Dots which
indicate proper alignment.
1
2
4
3
5
8
SPINNING BRUSH DISASSEMBLY
• Remove the Strainer from
the Spinning Brush.
• Locate the inner groves
on the Spinning Brush.
• Push the top of the Silicone
Brush down towards the
center opening.
• Pull the bottom of the
Silicone Brush up towards
the center opening.
Spinning Brush Disassembly
• Pull the center tab
of the Silicone Brush out.
• Pull the top tab out.
• Pull the bottom tab out.
Note: Use the Cleaning Brush to
clean the Spinning Brush, Silicone
Brush and Strainers.
2
4
3
5
6
• Reverse steps to assemble
1
9
OPERATING INSTRUCTIONS
• Ensure that the power switch
is set to OFF before operating.
• Set the power switch
to FORWARD to begin.
• Gently insert ingredients
into the Hopper to juice.
Only use the Pusher if
ingredients become lodged
in the Hopper.
• Once juicing is complete
and all pulp has been ejected,
set the power switch to OFF.
Operating Instructions
12
3
Pulp Spout
Juice Spout
10
WARNING
Ensure that the Auger has completely stopped moving before
setting the power switch to FORWARD or REVERSE.
Cleaning
Once you’re done juicing, ensure the power switch is set to OFF and
position the pulp spout over your sink or waste receptacle. Set the
power switch to REVERSE to easily and quickly remove excess pulp
from the chamber.
Are you unable to open the Hopper after juicing?
• After juice extraction, pour water into the hopper. The hopper will open
easily after simple cleaning.
• Press and hold the power switch on REVERSE for 3-4 seconds.
This releases pressure from the chamber and makes opening
the Hopper easier.
Continued
Operating Instructions
DO NOT
SUBMERGE
BASE UNDER
WATER.
Autres manuels pour Nutri-Master
1
Table des matières
Autres manuels NuWave presse-agrumes
