Learning Remote Control

User’s Guide

NV-LRC1

User’s Guide

Introduction

Installing Batteries

Your NV-LRC1 remote requires 2 AAA batteries (included).

Battery Use And Safety

- Use only fresh batteries of the required size and recommended type.

- Do not mix old and new batteries, different types of batteries (standard,

alkaline, or rechargeable), or rechargeable batteries of different capacities.

- If you do not plan to use the remote for an extended period, remove the

battery. It can leak chemicals that can destroy electronic parts.

WARNING: Dispose of old batteries promptly and properly. Do not burn or bury

them.

To Install Batteries

1. Open the battery compartment cover (located on the back of the remote).

2. Place the AAA battery in the compartment and match the + and - polarity

symbols inside.

3. Replace the cover.

NOTE: When the NV-LRC1 remote stops operating properly, replace the

batteries within 10 minutes (to protect the programming information).

The LRC1 universal learning remote control is the easy all-in-one solution for

controlling all of your audio source equipment. The LRC1, with over 1,000 built-

in manufacturer’s Infrared codes, can be easily setup for wireless control of up

to six audio components.

This setup guide is designed to allow you quick control of your entire NuVo

System.

A Quick Look At The Controls

Press this key... To...

Turn the selected device on or off.

Program sequences.

Raise or lower the sound level.

Press MUTE to turn the sound off or on.

Select the next or previous channel.

Select next or previous chapter on

some models of DVD players.

Move the cursor in the menu

screens.

Press SELECT to choose the

highlighted menu Option.

Skip backward, rewind, fast

forward, skip forward, stop, pause,

or play tracks on the current disc.

View the current channel and

program information.

Exit the selected device’s menu,

guide, or program without

making a menu selection.

Display the program guide for the

selected device.

Switch the device input to view TV

or video programs.

Press LAST to recall the last-viewed

channel.

The Source buttons 1-6 correspond to

the source inputs on the NuVo System

or preferred devices.

Display the menu for the selected

device.

123

456

GUIDE

INFO

EXIT

INPUT

NV-LRC1

User’s Guide

Introduction

Installing Batteries

Your NV-LRC1 remote requires 2 AAA batteries (included).

Battery Use And Safety

- Use only fresh batteries of the required size and recommended type.

- Do not mix old and new batteries, different types of batteries (standard,

alkaline, or rechargeable), or rechargeable batteries of different capacities.

- If you do not plan to use the remote for an extended period, remove the

battery. It can leak chemicals that can destroy electronic parts.

WARNING: Dispose of old batteries promptly and properly. Do not burn or bury

them.

To Install Batteries

1. Open the battery compartment cover (located on the back of the remote).

2. Place the AAA battery in the compartment and match the + and - polarity

symbols inside.

3. Replace the cover.

NOTE: When the NV-LRC1 remote stops operating properly, replace the

batteries within 10 minutes (to protect the programming information).

The LRC1 universal learning remote control is the easy all-in-one solution for

controlling all of your audio source equipment. The LRC1, with over 1,000 built-

in manufacturer’s Infrared codes, can be easily setup for wireless control of up

to six audio components.

This setup guide is designed to allow you quick control of your entire NuVo

System.

A Quick Look At The Controls

Press this key... To...

Turn the selected device on or off.

Program sequences.

Raise or lower the sound level.

Press MUTE to turn the sound off or on.

Select the next or previous channel.

Select next or previous chapter on

some models of DVD players.

Move the cursor in the menu

screens.

Press SELECT to choose the

highlighted menu Option.

Skip backward, rewind, fast

forward, skip forward, stop, pause,

or play tracks on the current disc.

View the current channel and

program information.

Exit the selected device’s menu,

guide, or program without

making a menu selection.

Display the program guide for the

selected device.

Switch the device input to view TV

or video programs.

Press LAST to recall the last-viewed

channel.

The Source buttons 1-6 correspond to

the source inputs on the NuVo System

or preferred devices.

Display the menu for the selected

device.

123

456

GUIDE

INFO

EXIT

INPUT

6. If the device responds, go to step 6. If the device does not respond,

press CH+. The remote will try the next code. Continue until the device

responds.

NOTE: Press CH- to try the previous code.

7. To set the code, press SETUP once. The LED blinks twice.

8. To search for other device codes, repeat steps 1 to 6.

Checking The Codes

If you have set up the remote using the procedure in “Searching For Your

Code”, you may need to find out which five-digit code is operating your

equipment.

For example, to find out which code is assigned to your TV:

1. Press SOURCE 1 once.

2. Press and hold SETUP until the red LED blinks twice, then release.

3. Enter 990. The LED blinks twice.

4. To view the code for the first digit, press numeric key 1. Count the LED

blinks (for example, three blinks = 3), and write down the number in

the appropriate code listing in step 8 under “Programming a Device”.

NOTE: If a code digit is 0, the LED does not blink.

5. Repeat step 4 for the four remaining digits, using 2for the second

digit, 3for the third digit, 4for the fourth digit, and 5for the fifth

digit.

6. To check for other device codes, repeat steps 1-5, substituting

Sources 2-6.

Changing Volume Lock

The NV-LRC1 comes preset to allow independent volume control of each

selected device (Global Volume Unlock). However, you may change the

Volume Lock setting to Global Volume Lock so that one source’s volume

will control volume in all other modes. After that, you can perform

Individual Volume Unlock on a selected source to set its volume control

for independent operation or Global Volume Unlock to remove all volume

locking.

Locking Volume Control to One Mode (Global Volume Lock)

1. Press and hold SETUP until red LED blinks twice, then release.

2. Enter 993 and then press the mode key for the source you want to

control volume (for example, CD). The LED blinks twice. Now, when

you press VOL+, VOL- or Mute, the selected source (for example, CD)

will control the volume regardless of the current mode.

Unlocking All Volume Control (Restoring Global Unlock)

1. Press and hold SETUP until the red LED blinks twice, then release.

2. Enter 993 and then press VOL+. The LED blinks four times. Volume is

independently controlled for all programmed sources.

Unlocking a Single Source’s Volume Control

1. Press a source key (1-6).

2. Press and hold SETUP until the red LED blinks twice, then release.

3. Enter 993 and then press VOL-. The LED blinks four times. Volume is

independently controlled for the selected sources.

Programming Macros

A macro can be used to control a home theater operation, to set a

favorite channel, or for other multiple functions you would like to

control with one key press. You can use any key to activate a macro.

Moreover, each Macro Key can hold up to 32 key presses total.

You can program a macro that will operate regardless of what mode you

are in, or one that will only operate when you are in a specific mode.

NOTE: Programming a new macro over an existing one will erase the

original macro.

Programming a Mode-Independent Macro

1. Press and hold SETUP until the red LED blinks twice, then release.

2. Press 995. The LED blinks twice.

3. Press the key you want to use to activate your macro (POWER, any

unused key, etc.).

4. Enter the series of commands you want the macro to execute (up to 32

commands).

5.Press and hold SETUP until the red LED blinks twice, then release.

Now, when you press the Macro key, the remote will send the series of

commands you have entered, regardless of what mode you are in. For

example, you could program the Macro key to turn on both your TV and

cable box and select a particular channel.

To clear the macro, repeat steps 1 to 5 above, but do not enter a series of

commands at step 4.

Programming a Mode-Dependent Macro

1. Press a source key (1-6).

2. Press and hold SETUP until the red LED blinks twice.

3. Press 978. The LED blinks twice.

4. Press the key you want to use to activate your macro (POWER, any

unused key, etc.).

5. Enter the series of commands you want the macro to execute (up to 32

commands).

6. Press and hold SETUP until the red LED blinks twice, then release.

Directly enter channels

(For example, 09 or 31).

Press ENTER to send channel

number entries on some TV

models.

Macro device keys can be used to

dedicate multiple string macro

commands.

Whole-Home Control is dedicated

control of your NuVo System.

MUTE, VOL-, VOL+, ON/OFF

duplicate the NuVo zone keypad

functions.

Press this key... To...

Programming a Device

To control devices, 1-6, follow these steps.

Before proceeding, find the codes for the devices you want to program in

“Manufacturer’s Codes” in the following pages and write them down or

highlight them.

NOTE: Any device may be set up on any mode key.

Whole-Home Control

1. Turn on the device (for example, CD player) and, if needed, load

media (for example, a CD).

2. Press a device key (1-6).

3. Press and hold SETUP until the red LED blinks twice, then release.

4. Enter the first five-digit code for your device. The red LED blinks once

as each digit is entered. If the code is correct, the LED blinks twice.

NOTE: If the LED does not blink twice, repeat steps 2 to 4 and try entering

the code again.

5. Aim the remote at the device and press POWER. The device should

turn off. If it does not, repeat steps 3 to 5, trying each code for your

brand until you find one that works. If you cannot find a code that

works, see “Searching For Your Code”.

6. Repeat steps 1 to 5 for the other devices you want to control. For

Future reference, write down each working device code below:

Searching For Your Code

If your device does not respond to the remote after trying all codes

listed for your brand, or if your brand is not listed, try searching for your

code:

1. Press a device key once.

2. Press and hold SETUP until the red LED blinks twice, then release.

3. Enter 991. The LED blinks twice.

4. Enter the device group number:

5. Select a test function, such as POWER or PLAY. The remote sends IR

codes from its library to the selected device, starting with the most

popular code first.

SOURCE 1 Code:

Desc. _______

SOURCE 2 Code:

Desc. _______

SOURCE 3 Code:

Desc. _______

SOURCE 4 Code:

Desc. _______

SOURCE 5 Code:

Desc. _______

SOURCE 6 Code:

Desc. _______

TV (TVs)

VCR (VCRs, DVD players)

0Cable (Cable Converters, Video Accessories, Satellite

Receivers).

Audio (Audio Amplifiers, Audio Amp/Tuners, CD players)

Code Device Group

M2 M3 M4

M5 M6 M7 M8

MUTE VOL- VOL+ ON/OFF

6. If the device responds, go to step 6. If the device does not respond,

press CH+. The remote will try the next code. Continue until the device

responds.

NOTE: Press CH- to try the previous code.

7. To set the code, press SETUP once. The LED blinks twice.

8. To search for other device codes, repeat steps 1 to 6.

Checking The Codes

If you have set up the remote using the procedure in “Searching For Your

Code”, you may need to find out which five-digit code is operating your

equipment.

For example, to find out which code is assigned to your TV:

1. Press SOURCE 1 once.

2. Press and hold SETUP until the red LED blinks twice, then release.

3. Enter 990. The LED blinks twice.

4. To view the code for the first digit, press numeric key 1. Count the LED

blinks (for example, three blinks = 3), and write down the number in

the appropriate code listing in step 8 under “Programming a Device”.

NOTE: If a code digit is 0, the LED does not blink.

5. Repeat step 4 for the four remaining digits, using 2for the second

digit, 3for the third digit, 4for the fourth digit, and 5for the fifth

digit.

6. To check for other device codes, repeat steps 1-5, substituting

Sources 2-6.

Changing Volume Lock

The NV-LRC1 comes preset to allow independent volume control of each

selected device (Global Volume Unlock). However, you may change the

Volume Lock setting to Global Volume Lock so that one source’s volume

will control volume in all other modes. After that, you can perform

Individual Volume Unlock on a selected source to set its volume control

for independent operation or Global Volume Unlock to remove all volume

locking.

Locking Volume Control to One Mode (Global Volume Lock)

1. Press and hold SETUP until red LED blinks twice, then release.

2. Enter 993 and then press the mode key for the source you want to

control volume (for example, CD). The LED blinks twice. Now, when

you press VOL+, VOL- or Mute, the selected source (for example, CD)

will control the volume regardless of the current mode.

Unlocking All Volume Control (Restoring Global Unlock)

1. Press and hold SETUP until the red LED blinks twice, then release.

2. Enter 993 and then press VOL+. The LED blinks four times. Volume is

independently controlled for all programmed sources.

Unlocking a Single Source’s Volume Control

1. Press a source key (1-6).

2. Press and hold SETUP until the red LED blinks twice, then release.

3. Enter 993 and then press VOL-. The LED blinks four times. Volume is

independently controlled for the selected sources.

Programming Macros

A macro can be used to control a home theater operation, to set a

favorite channel, or for other multiple functions you would like to

control with one key press. You can use any key to activate a macro.

Moreover, each Macro Key can hold up to 32 key presses total.

You can program a macro that will operate regardless of what mode you

are in, or one that will only operate when you are in a specific mode.

NOTE: Programming a new macro over an existing one will erase the

original macro.

Programming a Mode-Independent Macro

1. Press and hold SETUP until the red LED blinks twice, then release.

2. Press 995. The LED blinks twice.

3. Press the key you want to use to activate your macro (POWER, any

unused key, etc.).

4. Enter the series of commands you want the macro to execute (up to 32

commands).

5.Press and hold SETUP until the red LED blinks twice, then release.

Now, when you press the Macro key, the remote will send the series of

commands you have entered, regardless of what mode you are in. For

example, you could program the Macro key to turn on both your TV and

cable box and select a particular channel.

To clear the macro, repeat steps 1 to 5 above, but do not enter a series of

commands at step 4.

Programming a Mode-Dependent Macro

1. Press a source key (1-6).

2. Press and hold SETUP until the red LED blinks twice.

3. Press 978. The LED blinks twice.

4. Press the key you want to use to activate your macro (POWER, any

unused key, etc.).

5. Enter the series of commands you want the macro to execute (up to 32

commands).

6. Press and hold SETUP until the red LED blinks twice, then release.

Directly enter channels

(For example, 09 or 31).

Press ENTER to send channel

number entries on some TV

models.

Macro device keys can be used to

dedicate multiple string macro

commands.

Whole-Home Control is dedicated

control of your NuVo System.

MUTE, VOL-, VOL+, ON/OFF

duplicate the NuVo zone keypad

functions.

Press this key... To...

Programming a Device

To control devices, 1-6, follow these steps.

Before proceeding, find the codes for the devices you want to program in

“Manufacturer’s Codes” in the following pages and write them down or

highlight them.

NOTE: Any device may be set up on any mode key.

Whole-Home Control

1. Turn on the device (for example, CD player) and, if needed, load

media (for example, a CD).

2. Press a device key (1-6).

3. Press and hold SETUP until the red LED blinks twice, then release.

4. Enter the first five-digit code for your device. The red LED blinks once

as each digit is entered. If the code is correct, the LED blinks twice.

NOTE: If the LED does not blink twice, repeat steps 2 to 4 and try entering

the code again.

5. Aim the remote at the device and press POWER. The device should

turn off. If it does not, repeat steps 3 to 5, trying each code for your

brand until you find one that works. If you cannot find a code that

works, see “Searching For Your Code”.

6. Repeat steps 1 to 5 for the other devices you want to control. For

Future reference, write down each working device code below:

Searching For Your Code

If your device does not respond to the remote after trying all codes

listed for your brand, or if your brand is not listed, try searching for your

code:

1. Press a device key once.

2. Press and hold SETUP until the red LED blinks twice, then release.

3. Enter 991. The LED blinks twice.

4. Enter the device group number:

5. Select a test function, such as POWER or PLAY. The remote sends IR

codes from its library to the selected device, starting with the most

popular code first.

SOURCE 1 Code:

Desc. _______

SOURCE 2 Code:

Desc. _______

SOURCE 3 Code:

Desc. _______

SOURCE 4 Code:

Desc. _______

SOURCE 5 Code:

Desc. _______

SOURCE 6 Code:

Desc. _______

TV (TVs)

VCR (VCRs, DVD players)

0Cable (Cable Converters, Video Accessories, Satellite

Receivers).

Audio (Audio Amplifiers, Audio Amp/Tuners, CD players)

Code Device Group

M2 M3 M4

M5 M6 M7 M8

MUTE VOL- VOL+ ON/OFF

Troubleshooting

PROBLEM: LED does not blink when you press a key.

SOLUTION: Replace battery with one new 3.3 V 2032 Lithium battery.

PROBLEM: LED blinks when you press a key, but device does not respond.

SOLUTION: Make sure the remote is aimed at your device and is not more

than 15 feet away.

PROBLEM: LED blinks one long blink.

SOLUTION: An entry error has occurred (for example, wrong key). Try

entry sequence again.

PROBLEM: Remote does not control sources or commands are not working

properly.

SOLUTION: Try all listed codes for the device. Make sure the device

operates with an infrared remote control.

PROBLEM: CH+,CH-, and LAST do not work for your RCA TV.

SOLUTION: Due to RCA design from 1983 to 1987, only the original remote

control will operate these functions.

PROBLEM: No volume on a source.

SOLUTION: See “Changing Volume Lock”.

PROBLEM: Channels do not change properly.

SOLUTION: If the original remote control required you to press Enter to

change channels, press Enter on this remote after entering the channel

number.

Control for NuVo T2 Tuner

Move the cursor up and down to

scroll through T2 categories (as

setup in T2 configurator).

Move left and right to scroll through

T2 knob functions.

Press OK to make a selection.

Tune forward and backward, scan,

and seek forward and backward.

Press INFO to access WX.

Press EXIT to access AM.

Press GUIDE to access FM.

Press MENU to access AUX.

GUIDE

INFO

EXIT

Now, when you press the Macro key, the remote will send the series of

commands you have entered, but only if you are in the mode you

selected in step 1. For example, you could program the Macro key to turn

on your T2 tuner and select a particular channel, but only if you are in

tuner mode. If you are in DVD mode, this key will do nothing.

Clearing a Mode-Dependent Macro

1. Press and hold SETUP until the red LED blinks twice, then release.

2. Press 978.

3. Press the source key where you programmed the macro (Source 1-6).

4. Press the macro’s activation key (POWER, any unused key, etc.).

5. Press and hold SETUP until the red LED blinks twice, then release.

Using Learning

The NV-LRC1 includes a Learning feature so you can add functions that

are unique to your home entertainment devices (e.g., CD skip forward or

backward). However, there are some considerations:

Learning Precautions

- Your original remote controls must be in working order for learning to

work properly.

- Learning keys are mode specific, so each one can store a unique

function for each mode.

- Learned keys can be used in macros (See Using Macros).

- Do not use the following keys for learning: Source Keys, SETUP, BACK,

REPEAT, FAV SCAN, SLEEP, or Record ( ) Key.

- Learning capacity is approximately 16 to 25 keys, depending on the

code being learned.

- Certain device codes are not learnable including multi-frequency

types, some high frequency ones, and other unusual formats.

- For optimum learning: avoid high levels of ambient light such as

natural sunlight or energy-efficient fluorescent lights.

NOTE: Please have your original remote controls handy before

programming learning.

Programming a Learned Key

NOTE: If more than 10 seconds pass between key presses, the remote

exits programming.

1. Press and hold SETUP until LED flashes twice.

2. Press 975.

3. Press a source key once (1-6) to assign a mode for learning.

4. Place the NV-LRC1 head-to-head (about 2” apart) from your original

remote control. Also locate the key (on your original remote control)

that will serve as the teaching function.

5. On the NV-LRC1, press a key where the learned function will be stored.

6. On the original remote, press and hold the key to be learned. The

LRC1’s LED will turn off. Continue holding the key on the original

remote until the LRC1’s LED blinks twice.

NOTE: If the LED displays one long blink, a learning error has occurred.

Try repeating this step again until a successful capture occurs. If the

function is still not captured, press and hold SETUP to exit programming

and review the “Learning Precautions” above. If needed, also see

“Troubleshooting”. After review, start programming again at step1.

7. Repeat steps 2 to 6 for another key or press and

hold SETUP to exit programming.

Deleting a Single Learning Key

1. Press and hold SETUP until the LED flashes twice.

NOTE: If more than 10 seconds pass between key presses, the remote

exits programming.

2. Press SETUP, then 976 to delete a learned function.

3. Press a source key once (1-6).

4. Press the key containing the learned function to be deleted. The

remote blinks twice.

5. Repeat steps 2 to 4 for another key or press and hold SETUP to

exit programming.

Deleting All Learned Keys in a Specific Mode

1. Press and hold SETUP until the LED blinks twice.

NOTE: If more than 10 seconds pass between key presses, the remote

exits programming.

2. Press 976.

3. Press a source key twice (1-6) to clear all the learned keys for that

Mode. The LED blinks twice.

4. Repeat step 3 for another key or press and hold SETUP to exit

Programming.

123

456

OL-

N/O OFF

V +

Troubleshooting

PROBLEM: LED does not blink when you press a key.

SOLUTION: Replace battery with one new 3.3 V 2032 Lithium battery.

PROBLEM: LED blinks when you press a key, but device does not respond.

SOLUTION: Make sure the remote is aimed at your device and is not more

than 15 feet away.

PROBLEM: LED blinks one long blink.

SOLUTION: An entry error has occurred (for example, wrong key). Try

entry sequence again.

PROBLEM: Remote does not control sources or commands are not working

properly.

SOLUTION: Try all listed codes for the device. Make sure the device

operates with an infrared remote control.

PROBLEM: CH+,CH-, and LAST do not work for your RCA TV.

SOLUTION: Due to RCA design from 1983 to 1987, only the original remote

control will operate these functions.

PROBLEM: No volume on a source.

SOLUTION: See “Changing Volume Lock”.

PROBLEM: Channels do not change properly.

SOLUTION: If the original remote control required you to press Enter to

change channels, press Enter on this remote after entering the channel

number.

Control for NuVo T2 Tuner

Move the cursor up and down to

scroll through T2 categories (as

setup in T2 configurator).

Move left and right to scroll through

T2 knob functions.

Press OK to make a selection.

Tune forward and backward, scan,

and seek forward and backward.

Press INFO to access WX.

Press EXIT to access AM.

Press GUIDE to access FM.

Press MENU to access AUX.

GUIDE

INFO

EXIT

Now, when you press the Macro key, the remote will send the series of

commands you have entered, but only if you are in the mode you

selected in step 1. For example, you could program the Macro key to turn

on your T2 tuner and select a particular channel, but only if you are in

tuner mode. If you are in DVD mode, this key will do nothing.

Clearing a Mode-Dependent Macro

1. Press and hold SETUP until the red LED blinks twice, then release.

2. Press 978.

3. Press the source key where you programmed the macro (Source 1-6).

4. Press the macro’s activation key (POWER, any unused key, etc.).

5. Press and hold SETUP until the red LED blinks twice, then release.

Using Learning

The NV-LRC1 includes a Learning feature so you can add functions that

are unique to your home entertainment devices (e.g., CD skip forward or

backward). However, there are some considerations:

Learning Precautions

- Your original remote controls must be in working order for learning to

work properly.

- Learning keys are mode specific, so each one can store a unique

function for each mode.

- Learned keys can be used in macros (See Using Macros).

- Do not use the following keys for learning: Source Keys, SETUP, BACK,

REPEAT, FAV SCAN, SLEEP, or Record ( ) Key.

- Learning capacity is approximately 16 to 25 keys, depending on the

code being learned.

- Certain device codes are not learnable including multi-frequency

types, some high frequency ones, and other unusual formats.

- For optimum learning: avoid high levels of ambient light such as

natural sunlight or energy-efficient fluorescent lights.

NOTE: Please have your original remote controls handy before

programming learning.

Programming a Learned Key

NOTE: If more than 10 seconds pass between key presses, the remote

exits programming.

1. Press and hold SETUP until LED flashes twice.

2. Press 975.

3. Press a source key once (1-6) to assign a mode for learning.

4. Place the NV-LRC1 head-to-head (about 2” apart) from your original

remote control. Also locate the key (on your original remote control)

that will serve as the teaching function.

5. On the NV-LRC1, press a key where the learned function will be stored.

6. On the original remote, press and hold the key to be learned. The

LRC1’s LED will turn off. Continue holding the key on the original

remote until the LRC1’s LED blinks twice.

NOTE: If the LED displays one long blink, a learning error has occurred.

Try repeating this step again until a successful capture occurs. If the

function is still not captured, press and hold SETUP to exit programming

and review the “Learning Precautions” above. If needed, also see

“Troubleshooting”. After review, start programming again at step1.

7. Repeat steps 2 to 6 for another key or press and

hold SETUP to exit programming.

Deleting a Single Learning Key

1. Press and hold SETUP until the LED flashes twice.

NOTE: If more than 10 seconds pass between key presses, the remote

exits programming.

2. Press SETUP, then 976 to delete a learned function.

3. Press a source key once (1-6).

4. Press the key containing the learned function to be deleted. The

remote blinks twice.

5. Repeat steps 2 to 4 for another key or press and hold SETUP to

exit programming.

Deleting All Learned Keys in a Specific Mode

1. Press and hold SETUP until the LED blinks twice.

NOTE: If more than 10 seconds pass between key presses, the remote

exits programming.

2. Press 976.

3. Press a source key twice (1-6) to clear all the learned keys for that

Mode. The LED blinks twice.

4. Repeat step 3 for another key or press and hold SETUP to exit

Programming.

123

456

OL-V

ON/OFF

VOL+

MANUFACTURER’S CODES

Setup Codes for Audio Amplifiers

Setup Codes for Audio Amp/Tuners

GE 31379

Glory Horse 31263

Go Video 31532

Goldstar 30281

GPX 31299

Hafler 30146

Harman/Kardon 30110, 30189, 30891

Hewlett Packard 31181

Hitachi 31801, 31273

Initial 31426

Inkel 30027, 30062, 30502, 30491

Integra 30135, 31298

JBL 30110, 31306, 30281

JVC 30074, 31282, 31263, 31495, 31374

Kansai 30440

Kenwood 31313, 31570, 31569, 30027, 31051, 30077,

30313, 31027, 30042, 30239, 30569, 31052,

30186, 30314

KLH 31412, 31390, 31428

Koss 30424, 30255, 31366

Lasonic 31798, 31510

Lenoxx 31437

Lexicon 31076

Linn 30189

Liquid Video 31497

Lloyd’s 30195

LXI 30181

Magnavox 31189, 31269, 30189, 30128, 30391, 30195,

31089, 31514, 30531

Marantz 31189, 31269, 30039, 30189, 31089, 31289,

30200, 30128

MCS 30039, 30346

Memorex 31596

Mitsubishi 31393

Modulaire 30195

Musicmagic 31089

NAD 30320

Nakamichi 30347, 30097, 31555

NEC 30235

Norcent 31389

NuVo 32000, 32001

Onkyo 30135, 31298, 30842, 30380, 31531

Optimus 31023, 30801, 31074, 30080, 30186, 30531,

30797, 30042, 30181, 30440, 30738, 30849,

30177, 30219, 30670

Oritron 31497, 31366

Panasonic 31518, 30039, 31548, 31764, 30518, 31350,

31763, 30367, 31316, 31509, 31633, 30309,

31288, 31363

Penney 30195

Philco 31390

Philips 31189, 31269, 30189, 31365, 31089, 31266,

31283, 30891, 31368, 30391, 31120, 31268

Pioneer 31023, 30150, 30630, 31184, 30080, 30531,

31084, 31384, 30244,31343

Polaroid 31508

Polk Audio 30189, 31289

Proscan 31254

Qisheng 31609, 31390

Quasar 30039

RadioShack 31263

RCA 31023, 31609, 31254, 30346, 30531, 31154,

31511, 30080, 30530, 31074, 31390, 30054,

30360

Realistic 30195, 30181, 30163

Regent 31437

Rio 31869, 31383

Saba 31519

Samsung 31500, 31295

Sansui 30189, 30346, 30193, 31089

Sanyo 30801, 30360, 31469, 30219, 31251

Scott 30163, 30322

Sharp 31286, 30186, 31386, 31361

Sharper Image 31545, 31556, 30797, 31409, 31416, 31549,

31385, 31411, 31546, 31723, 31263, 31410

Sherwood 30491, 31423, 30062, 31077, 30502, 31653

Shinco 31390

Shinsonic 31426

Silsonic 30176, 31426

Sonic 30281

Sonic Blue 31383, 31869, 31532

Sony 31058, 31441, 31258, 31759, 30158, 31442,

31529, 31758, 31371, 31503, 31042, 31658,

31158, 31858, 31367, 31406, 31458, 30168,

31558, 31131, 31349, 31382

Soundesign 30670

Stereophonics 31023

Sunfire 31313, 30314, 30313, 31052

Tae Kwang 30440

Teac 30163, 31267, 31074, 31528, 30463, 31390

Technics 31308, 31518, 30039, 30518, 30309, 31309,

30208

Techwood 30281

Accuphase 30382

Acurus 30765

Adcom 31100, 30577

Aiwa 30406

AudioSource 30011

Bel Canto Design 31583

Bose 30674

Carver 30269

Classe 31461, 31462

Curtis Mathes 30300

Denon 30160

Durabrand 31561

GE 30078

Harman/Kardon 30892

JVC 30331

Kenwood 30356

Korsun 31483

Left Coast 30892

Lenoxx 31561

Linn 30269

Logitech 31408

Luxman 30165

Magnavox 30269

Marantz 30892,30321, 30269

Mark Levinson 31483

Nakamichi 30321

NEC 30264

Optimus 30395, 30300

Panasonic 30521, 30308

Parasound 30246

Philips 30892, 30269

Pioneer 30013, 30300

Polk Audio 30892, 30269

PS Audio 31523

RCA 30300

Realistic 30395

Sansui 30321

Shure 30264

Sony 30689,30220, 30815

Soundesign 30078, 30211

Technics 30521, 30308

Victor 30331

Wards 30078, 30211, 30013

Yamaha 30354, 30143, 30133, 30504

YBA 31502

ADC 30531

Adcom 31616, 30616, 31617

Aiwa 31405, 30158, 30189, 31243, 31089, 31388,

30121, 30405, 31321, 31641, 31347

Akai 30224, 30076, 31512, 31255

Alco 31390

Amphion Media Works 31615, 31563

AMW 31563, 31615

Anam 31609, 31074, 30281

Apex Digital 31430, 31257

Arcam 31120

Audiophase 31387

Audiotronic 31189

Audiovox 31390, 31627

AVLight 30158

Bel Canto Design 31584

Bose 31229, 31253, 30639

Brix 31602

Cambridge Soundworks 31477, 31370

Capetronic 30531

Carver 31189, 30189, 30042, 31089, 30008, 30360

Casio 30195

Clarinette 30195

Classic 31352

Coby 31513, 31389, 31263

Compaq 31136

Criterion 31420

Curtis 31596

Curtis Mathes 30080

Daewoo 31250

Dell 31383

Denon 31360, 30004, 31104, 30771, 31311, 30273,

31142, 30301

Dynamic Bass 30360

Emerson 30424, 30255

Fisher 31409, 30360, 30219, 31801, 30042

Fonmix 31360

Fosgate 31487

Garrard 30424, 30281, 30463, 30146, 30440

Gateway 31517, 31567

MANUFACTURER’S CODES

Setup Codes for Audio Amplifiers

Setup Codes for Audio Amp/Tuners

GE 31379

Glory Horse 31263

Go Video 31532

Goldstar 30281

GPX 31299

Hafler 30146

Harman/Kardon 30110, 30189, 30891

Hewlett Packard 31181

Hitachi 31801, 31273

Initial 31426

Inkel 30027, 30062, 30502, 30491

Integra 30135, 31298

JBL 30110, 31306, 30281

JVC 30074, 31282, 31263, 31495, 31374

Kansai 30440

Kenwood 31313, 31570, 31569, 30027, 31051, 30077,

30313, 31027, 30042, 30239, 30569, 31052,

30186, 30314

KLH 31412, 31390, 31428

Koss 30424, 30255, 31366

Lasonic 31798, 31510

Lenoxx 31437

Lexicon 31076

Linn 30189

Liquid Video 31497

Lloyd’s 30195

LXI 30181

Magnavox 31189, 31269, 30189, 30128, 30391, 30195,

31089, 31514, 30531

Marantz 31189, 31269, 30039, 30189, 31089, 31289,

30200, 30128

MCS 30039, 30346

Memorex 31596

Mitsubishi 31393

Modulaire 30195

Musicmagic 31089

NAD 30320

Nakamichi 30347, 30097, 31555

NEC 30235

Norcent 31389

NuVo 32000, 32001

Onkyo 30135, 31298, 30842, 30380, 31531

Optimus 31023, 30801, 31074, 30080, 30186, 30531,

30797, 30042, 30181, 30440, 30738, 30849,

30177, 30219, 30670

Oritron 31497, 31366

Panasonic 31518, 30039, 31548, 31764, 30518, 31350,

31763, 30367, 31316, 31509, 31633, 30309,

31288, 31363

Penney 30195

Philco 31390

Philips 31189, 31269, 30189, 31365, 31089, 31266,

31283, 30891, 31368, 30391, 31120, 31268

Pioneer 31023, 30150, 30630, 31184, 30080, 30531,

31084, 31384, 30244,31343

Polaroid 31508

Polk Audio 30189, 31289

Proscan 31254

Qisheng 31609, 31390

Quasar 30039

RadioShack 31263

RCA 31023, 31609, 31254, 30346, 30531, 31154,

31511, 30080, 30530, 31074, 31390, 30054,

30360

Realistic 30195, 30181, 30163

Regent 31437

Rio 31869, 31383

Saba 31519

Samsung 31500, 31295

Sansui 30189, 30346, 30193, 31089

Sanyo 30801, 30360, 31469, 30219, 31251

Scott 30163, 30322

Sharp 31286, 30186, 31386, 31361

Sharper Image 31545, 31556, 30797, 31409, 31416, 31549,

31385, 31411, 31546, 31723, 31263, 31410

Sherwood 30491, 31423, 30062, 31077, 30502, 31653

Shinco 31390

Shinsonic 31426

Silsonic 30176, 31426

Sonic 30281

Sonic Blue 31383, 31869, 31532

Sony 31058, 31441, 31258, 31759, 30158, 31442,

31529, 31758, 31371, 31503, 31042, 31658,

31158, 31858, 31367, 31406, 31458, 30168,

31558, 31131, 31349, 31382

Soundesign 30670

Stereophonics 31023

Sunfire 31313, 30314, 30313, 31052

Tae Kwang 30440

Teac 30163, 31267, 31074, 31528, 30463, 31390

Technics 31308, 31518, 30039, 30518, 30309, 31309,

30208

Techwood 30281

Accuphase 30382

Acurus 30765

Adcom 31100, 30577

Aiwa 30406

AudioSource 30011

Bel Canto Design 31583

Bose 30674

Carver 30269

Classe 31461, 31462

Curtis Mathes 30300

Denon 30160

Durabrand 31561

GE 30078

Harman/Kardon 30892

JVC 30331

Kenwood 30356

Korsun 31483

Left Coast 30892

Lenoxx 31561

Linn 30269

Logitech 31408

Luxman 30165

Magnavox 30269

Marantz 30892,30321, 30269

Mark Levinson 31483

Nakamichi 30321

NEC 30264

Optimus 30395, 30300

Panasonic 30521, 30308

Parasound 30246

Philips 30892, 30269

Pioneer 30013, 30300

Polk Audio 30892, 30269

PS Audio 31523

RCA 30300

Realistic 30395

Sansui 30321

Shure 30264

Sony 30689,30220, 30815

Soundesign 30078, 30211

Technics 30521, 30308

Victor 30331

Wards 30078, 30211, 30013

Yamaha 30354, 30143, 30133, 30504

YBA 31502

ADC 30531

Adcom 31616, 30616, 31617

Aiwa 31405, 30158, 30189, 31243, 31089, 31388,

30121, 30405, 31321, 31641, 31347

Akai 30224, 30076, 31512, 31255

Alco 31390

Amphion Media Works 31615, 31563

AMW 31563, 31615

Anam 31609, 31074, 30281

Apex Digital 31430, 31257

Arcam 31120

Audiophase 31387

Audiotronic 31189

Audiovox 31390, 31627

AVLight 30158

Bel Canto Design 31584

Bose 31229, 31253, 30639

Brix 31602

Cambridge Soundworks 31477, 31370

Capetronic 30531

Carver 31189, 30189, 30042, 31089, 30008, 30360

Casio 30195

Clarinette 30195

Classic 31352

Coby 31513, 31389, 31263

Compaq 31136

Criterion 31420

Curtis 31596

Curtis Mathes 30080

Daewoo 31250

Dell 31383

Denon 31360, 30004, 31104, 30771, 31311, 30273,

31142, 30301

Dynamic Bass 30360

Emerson 30424, 30255

Fisher 31409, 30360, 30219, 31801, 30042

Fonmix 31360

Fosgate 31487

Garrard 30424, 30281, 30463, 30146, 30440

Gateway 31517, 31567

Setup Codes for CD Players

Setup Codes for Cable Converters

Thorens 31189

Venturer 31390, 30849

Victor 30074

Wards 30158, 30189, 30080, 30054

Yamaha 30176, 30081, 31176, 31375, 30186, 31331,

31276

Yorx 30195

Zenith 31293, 30857, 30281, 31869

ABC 00003, 00008, 00014, 00001, 00007, 00013,

00011, 00017

Allegro 00315, 00153

Americast 00899

Antronix 00207, 00022

Archer 00797, 00207, 00153, 00022

Belcor 00056

Bell & Howell 00014

Bell South 00899

Cable Star 00056

Cabletenna 00022

Cableview 00022

Century 00153

Citizen 00315, 00153

Clearmaster 00883

ClearMax 00883

Colour Voice 00025, 00031

Comtronics 00040

Contec 00019

Coolmax 00883

Daeryung 01877, 00877, 00477, 00008

Digi 00637

Director 00476

Dumont 00637

Eastern 00002

Emerson 00797

Everquest 00040, 00015

Focus 00400

Funai 00019

Garrard 00153

GC Electronics 00207, 00056

Gehua 00476

Gemini 00797, 00015

General Instrument 00476, 00810, 00276, 00003, 00014, 00011,

00015

Global 01327

GMI 00015, 00797

GoldStar 00144, 00040

Goodmind 00797

Hamlin 00009, 00273, 00034, 00020, 00259

Hitachi 00014, 00011

Hytex 00007

Jasco 00015, 00315, 00153

Jebsee 00400

Jerrold 00476, 00810, 00276, 00003, 00012, 00014,

00011, 00015

Leon 00015

LG 00144, 00040

Linsay 00440

Magnavox 00027

Memorex 00000

Motorola 00476, 00810, 00276, 01254, 01106, 01376

Movie Time 00156, 00063

MS 00015

MultiVision 00012

Novaplex 00618

NSC 00063, 00156

Oak 00019, 00007

Optimus 00021

Pace 01877, 00237

Panasonic 00000, 00008, 00107, 00040, 00021

Panther 00637

Paragon 00000

Philips 00317, 00027, 00025, 00153, 00013, 00031,

01305

Pioneer 01877, 00877, 00144, 00533, 01021

Popular Mechanics 00400

Pulsar 00000

Quasar 00000

RadioShack 00015, 00883, 00797, 00315

RCA 00021

Realistic 00207

Recoton 00400

Regal 00279, 00273, 00259, 00020

Regency 00002

Rembrandt 00011

Runco 00000

Samsung 00000, 00144, 00040

Scientific Atlanta 01877, 00877, 00477, 00008, 00017

Seam 00510

Signal 00040, 00015

Signature 00011

SL Marx 00040

Sony 01006

Sprucer 00021

Starcom 00003, 00014, 00015

Stargate 00015, 00797, 00040

Starquest 00015

Supercable 00276

Supermax 00883

Sylvania 00001

Tandy 00258

Teleview 00040

Texscan 00001

TFC 00310

Timless 00040

Tocom 00012, 00013

Torx 00003

Toshiba 00000

Trans PX 00276, 00153, 00315

Tristar 00883

TS 00003

Tusa 00015

TV86 00063

Unika 00207, 00153, 00022

United Artists 00007

Universal 00153, 00056, 00207, 00022, 00191

V2 00883

Viewmaster 00883

Viewstar 00063, 00027, 00258

Vision 00883

Vortex View 00883

Zenith 00000, 00525, 00899

Zentek 00400

ADC 30018

Adcom 30155, 30234

Aiwa 30157, 30124, 30012

Akai 30156

Audio Alchemy 30194

Audio-Technica 30170

BSR 30245, 30194

Burmester 30420

California Audio Labs 30029, 30303

Carrera 30194

Carver 30157, 30437, 30179

Classic 31297

Crown 30122

DAK 30245

DBX 30254

Denon 30873, 30003

DKK 30000

DMX Electronics 30157

Dynamic Bass 30179

Emerson 30305, 30164, 30155, 30469

Fisher 30179, 30174, 31325, 30088, 30342

Garrard 30245, 30420, 30393, 30280, 30425

GE 30009

Gemini 30625

Genexxa 30032, 30305, 30164

GoldStar 30417

GPX 31296

Harman/Kardon 30157, 30173, 31202, 30426

Hitachi 30032, 30155

Inkel 30196, 30180, 30437

Integra 30101

JVC 30072, 31294, 30655

Kenwood 30681, 30826, 30626, 30028, 30037,

30036, 30190

KLH 31318

Kodak 30287

Korsun 31484

Koss 31317

Krell 30157

Kyocera 30018

LG 31208

Linn 30157

Luxman 30093

LXI 30305

Magnavox 30157, 30305

Marantz 30626, 30029, 30157, 30180

Mark Levinson 31484

McIntosh 30287

MCS 30029, 30043

Miro 30000

Mission 30157

MTC 30420, 30625

Nakamichi 30147

NEC 30043, 30234

Nikko 30174, 30170, 30164, 30625

NSM 30157

Onkyo 30868, 30101

Autres manuels pour NV-LRC1

Table des matières

Autres manuels Nuvo Télécommande

Nuvo

Nuvo NV-WCPS Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
