Nuvico CT-2M-P30FH Manuel utilisateur
CT-2M-P30FH
30x Full-HD PTZ DOME
HD-TVI CAMERA
Please read this guide thoroughly before use and keep it handy for future reference.
“Nuvico surveillance equipment is designed to be installed and served only by a
trained, state-licensed professional installer”.
2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO
NOT INSERT ANY METALLIC OBJECTS THROUGH THE
VENTILATION GRILLS OR OTHER OPENINGS ON THE
EQUIPMENT.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
3
FCC COMPLIANCE STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC INFORMATION: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme
NMB-003 du Canada.
CE COMPLIANCE STATEMENT
WARNING
This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
4
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong is provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. CAUTION –THESE SERVICING INSTRUCTIONS ARE FOR USE BY
QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF
ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING OTHER THAN
THAT CONTAINED IN THE OPERATING INSTRUCTIONS UNLESS YOU
ARE QUALIFIED TO DO SO.
16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed
Class 2 power source only.
5
Table of Contents
Chapter 1 —Introduction..................................................................................................6
1.1 Features...............................................................................................................................6
Chapter 2 —Installation and Configuration....................................................................7
2.1 Package Contents ...............................................................................................................7
2.2 Installation ...........................................................................................................................8
2.2.1 Installation –Wall Mount.............................................................................................. 9
2.2.2 Installation –Ceiling Mount........................................................................................ 10
2.2.3 Installation –PTZ Camera Remove for Maintenance................................................11
2.3 Basic Configuration of Dome Camera System................................................................ 12
2.4 Setting Dome Camera Address (ID) ................................................................................. 13
2.5 Setting Dome Camera Video Type, Termination & Coaxitron Protocol.......................... 13
2.6 Connections....................................................................................................................... 14
2.7 Getting Started................................................................................................................... 16
Chapter 3 —Program and Operation.............................................................................17
3.1 Dome Camera Selection.................................................................................................... 17
3.2 Accessing the On-Screen Menu Utility ............................................................................17
3.3 How to control the On-Screen Menu Utility..................................................................... 17
3.4 Auto Scan (Shortcut: SCAN) ............................................................................................18
3.5 Preset (Shortcut: PRST) ................................................................................................... 20
3.6 Shortcut of Preset Program.............................................................................................. 22
3.7 Tour (Shortcut: TOUR)...................................................................................................... 22
3.8 Pattern (Shortcut: PTRN).................................................................................................. 24
3.9 Privacy Zone......................................................................................................................25
3.10 Camera Menu...................................................................................................................26
3.11 Dome Communication..................................................................................................... 29
3.12 Alarm................................................................................................................................30
3.13 Dome Setup ..................................................................................................................... 31
Appendix A —Specifications.........................................................................................38
Appendix B —Troubleshooting.....................................................................................40
6
Chapter 1 —Introduction
1.1 Features
The PTZ dome camera and the keyboard controller make up the building blocks for any surveil-
lance/security system. Using multiple keyboard controllers and multiple dome cameras, no place is
too large for monitoring. Extensible and flexible architecture facilitates remote control functions for
a variety of external switching devices such as multiplexers and DVRs.
Built-in optical power zoom camera with True Night Shot function
240 Preset positions with the individual camera AE setup
8 Tours consist of Presets, Patterns, Auto Scans and other Tours can be programmed with over
300 functions and preset locations. While moving, each Preset scan can be watched in smooth
Vector Scan mode.
16 Auto Scans with the normal, the vector, and the random mode and the endless Auto-Pan with
13 speed steps
8 Patterns (up to 500 seconds) and 8 Privacy Zones
4 Alarm inputs, 2 Alarm outputs (5VTTL)
Variable speed from 0.1/sec. to 380/sec.
Three Variable speed (SLOW, NORMAL, TURBO)
Turbo speed is 380/sec. with Ctrl key pressed.
Pan/Tilt speed is inversely proportional to the zoom ratio with the option.
Maximum speed is 380/sec. when Preset command.
Auto Calibration from 0.1to 6(Tilt range is -10to 190)
Programmable user preferences (alarm, preset, title, etc.)
180Digital Flip
Up to 3999 selectable camera addresses
Function Run menu using DVR without function key (Pattern, Scan …)
Built-in RS-485 receiver driver
12VDC or 24VAC for Dome
24VAC for Heater & Fan
Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power source only.
7
Chapter 2 —Installation and Configuration
2.1 Package Contents
The PTZ dome camera is designed with compact, small size, hard dome camera housing.
The housing is constructed of aluminum, steel and plastic. The housing is designed to be mounted
on a wall or a ceiling. The housing meets the Protection Classification IP66 standards for dust and
moisture resistance.
* Dome Camera 1
* Instruction Manual (This Document) 1
* Accessory Kit & Connector 1
1) Torx wrench (1)
2) 2-Pin Terminal Block (1)
3) 3-Pin Terminal Block (2)
4) 4-Pin Terminal Block (1)
5) 5-Pin Terminal Block (1)
8
2.2 Installation
You need one optional mount kit of the wall mount and the ceiling mount to install.
The wall or ceiling mount must be attached to a structural object such as hard wood, concrete that
will support the weight of the mount and dome camera.
The use of a solid backboard is recommended when attaching to gypsum walls.
1. Remove the Protection pad and the tape from attached the dome camera.
2. Attach the mounting base to wall using the supplied M8 tapping screw and plastic bushing.
(Ceiling using the supplied M6 tapping screw and bushing)
3. Wind the both thread of the pipe end with Teflon tape about 20 times for sealing. Then use a
silicone rubber sealant to seal the area where the wall (ceiling) mount and the pipe meet.
4. Place a bead of silicone sealant around the wall and ceiling mount mounting flange, press it to
the surface and line up the flange hole with drilled holes.
CAUTION 1: A silicone rubber sealant must be applied to seal the housing to secure
waterproofing.
CAUTION 2: When installing, a bracket must be applied.
CAUTION 3: Please reset the camera after 30 ~ 60 minutes when installing it in situations
colder than -10°C.
9
2.2.1 Installation –Wall Mount
The wall mounting plate must be attached to a structural object such as concrete that will support
the weight of the mount and Dome Camera.
1. Select a suitable mounting location and verify there is sufficient cable to reach the middle of
the Wall Mount.
2. Mark and drill mounting holes in the surface using the Wall Mount Flange.
3. Pull out cables required to connect to the dome camera from the wall.
4. Set and fix wall mount bracket using plastic anchors and M8x35 screws.
5. Open the access plate and pull out cables through rectangular access hole of the wall mount
bracket.
6. Attach the 1.5 inch adapter to wall mount bracket and fix it using set screw.
7. Attach the camera’s safety wire to the wall mount bracket and organize cables.
8. Close the access plate of the wall mount bracket.
9. Push in and turn clockwise the camera into the adapter, and fix it using set screw of the
adapter.
10
2.2.2 Installation –Ceiling Mount
The ceiling mounting plate must be attached to a structural object such as concrete that will
support the weight of the mount and Dome Camera.
1. Select a suitable mounting location
and verify there is sufficient cable to
connect with cables from the
housing.
2. Mark and drill mounting holes on the
surface using the ceiling mount
bracket.
3. Pull out cables required to connect
to the dome camera from the ceiling.
4. Attach the ceiling mount bracket
using plastic anchors and screws.
5. Attach 1.5 inch adapter to the pipe
and fix it using set screw of the
adapter.
6. Pull out camera cables through the
pipe and attach the camera to
adapter and fix them using set screw
of the adapter.
7. After safety wire to the pipe to one
of M6x35 screws of the ceiling
mount bracket.
8. Join every connectors and organize
cables.
9. Lock hexagonal nut of the ceiling
mount bracket to fix camera
attached pipe and ceiling mount
bracket.
Table des matières
Autres manuels Nuvico Caméra de sécurité
Nuvico
Nuvico EasyView Lite CD-H21N Manuel utilisateur
Nuvico
Nuvico NC-2M-MPOV12 Manuel utilisateur
Nuvico
Nuvico Xcel NCT-4M-B31AF Manuel utilisateur
Nuvico
Nuvico EasyView CD-H266 Manuel utilisateur
Nuvico
Nuvico Xcel NCT-4M-E31AF Manuel utilisateur
Nuvico
Nuvico CD-H21P-LI Manuel utilisateur
Nuvico
Nuvico CF-ED2N Manuel utilisateur
Nuvico
Nuvico EasyView Lite CD-H2N-I Manuel utilisateur
Nuvico
Nuvico EasyView Manuel utilisateur
Nuvico
Nuvico Xcel NCT-5ML-OV2 Manuel utilisateur
Nuvico
Nuvico EasyTrak SC-P36N Manuel utilisateur
Nuvico
Nuvico Xcel NCT-5ML-E21AF Manuel utilisateur
Nuvico
Nuvico CF-S1N/P Manuel utilisateur
Nuvico
Nuvico Xcel NCT-5ML-B2 Manuel utilisateur
Nuvico
Nuvico EasyView 2 CD Series Manuel utilisateur
Nuvico
Nuvico CT-2M-D3 Manuel utilisateur
Nuvico
Nuvico CD-21N Manuel utilisateur
Nuvico
Nuvico Xcel NTCT-3M-IRPTZ20 Manuel utilisateur
Nuvico
Nuvico Zoom Matic Manuel utilisateur
Nuvico
Nuvico NC-5M-D21 Manuel utilisateur
