Nuvico LP-17 Manuel utilisateur
3
WARNING: FOR CONTINUED SAFETY, REPLACE POWER ADAPTOR ONLY WITH
MANUFACTURER'S RECOMMENDED MODELS
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
NOTE : This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio or TV technician for help.
CAUTION :Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
CANADIAN NOTICE
AVIS CANADIEN
This Class A digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la Class A respecte toutes les exigences du
Règlement sur le matériel brouilleur du Canada.
European Union Notice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) issued by
the Commission of the European Community.
Compliance with these directives implies conformity to the following European Norms (in
brackets are the equivalent international standards):
•EN55022 (CISPR 22) - Electromagnetic Interference
•EN55024 - Immunity Test for ITE Product
•EN61000-3-2 (IEC555-2) - Power Line Harmonics
4
CONTENTS
CONTENTS
Introduction ............................................................................. 5
Product Features...................................................................... 6
Remote Control ........................................................................7
Setup ......................................................................................... 9
Operation & Adjustment .......................................................11
OSD Function .........................................................................14
Specifications.......................................................................... 24
Troubleshooting ..................................................................... 25
5
INTRODUCTION
INTRODUCTION
This manual explains how to correctly install, operate and get the
best performance from your monitor. Please read this Installation
Manual carefully before installing your monitor, then keep it near
your monitor for quick reference.
First, please check that the contents of the box corresponds with
the following checklist :
• TFT LCD Monitor
• Power Cord
• RCA Cable
• 15 Pin Signal Cable
• Installation Manual
• AC Adapter
• Remote Controller
If any item is missing or damaged, please contact your distributor
Please keep the box and packing materials so that you may
properly store or transport your monitor.
6
The convenient and user-friendly on-screen display allows for
easy and accurate adjustments of screen size, position and
screen color.
The monitor complies with the VESA Display Data Channel
(DDC) specification for Plug and Play compatibility.
Advanced microcircuitry makes setup and configuration fast
and effortless.
The monitor features Advanced Color Controls for fine-tuning
to meet your own personal tastes or application requirements.
Use the on-screen controls to adjust the color temperature,
RGB gain value for the best possible screen color and intensity.
Press the menu button and activate the Self-Diagnosis menu to
determine whether your monitor is functioning normally, not
receiving a signal or is receiving a signal that is out of scanning
range.
Activate the higher refresh rates of the monitor to stabilize the
screen and eliminate the annoying flicker that contributes to
eye-strain and headaches.
PRODUCT FEA
PRODUCT FEATURES
TURES
7
REMOTE CONTROL
REMOTE CONTROL
R1 POWER
·Turns the set on from stand-by or odd
to Stand-by mode.
R2 INPUT SOURCE
·Select the signal source from the
multiple input sources.
R3 MUTE
·Turns the sound on and off
R4 NUMBER Button
·Unavailable.
R5 LAST CH
·Unavailable.
R6 INFORMATION
·Information display.
R7 PICT Mode
·Recalls your preferred picture
settings.
R8 SLEEP
·Sets the sleep timer.
R9 MENU
·Display a main menu.
R10 EXIT
·Turns the OSD window off and moves
from sub Menu to top menu in the
OSD window.
R11 / R17 UP/DOWN / Button
·
Adjust the main or camera menu setting.
R12 / 14 LEFT/RIGHT / Button
·Adjust the main or camera menu setting.
8
Inserting batteries into the Remote Control unit
To load the batteries turn the remote control handset over and open the
battery compartment. Insert the batteries (2x 1.5v type R03 or AAA). Make
sure that the polarity matches with the (+) and (-) marks inside of the battery
compartment.
Note : To avoid damage from possible battery leakage, remove the batteries
if you do not plan to use the remote control handset for an extended
period of time.
R13 OK
·Select menu items.
R15 VOL +/-
·Adjust the sound level
R16 PR +/-
·Unavailable.
R18 PC
R19 S MODE
·Choose different preset sound
mode or your owncustomized
sound.
R20 AUTO
·Choose automatically the proper
horizontal Position andvertical
position & size of the screen
image.
R21
·Unavailable.
R22 POSITION
·Select the position of PIP display.
R23 ZOOM
·Select the ZOOM or FULL mode.
R24 SIZE
·Select the size of PIP display.
R25 SKIP
·Unavailable.
R26 PIP
·Activate or cancel the PIP function.
R27 S. SWAP
·Change the sound source of the
main or sub display.
R28 SOURCE
·Select the signal source of the sub
display.
R29 P. SWAP
·Change the picture of the main or
sub display.
R30, R31,R32,R33
·Unavailable.
9
SETUP
SETUP
CONNECTING THE 15 PIN SIGNAL CABLE AND POWER CORD
①Turn off the DVR and monitor.
②Connect the 15 pin signal cable to the appropriate VGA port located at the
back of your DVR and the security monitor panel.
③Connect the DVI cable to the appropriate DVI port located at the back of
your DVR and the security monitor panel. (Optional)
④Connect the audio cable to the audio output port located at the back of
your DVR. (Optional)
⑤Plug the DC jack into the DC in port located on the back of the monitor.
⑥Plug the power cord into the AC receptacle of the Adapter.
⑦Plug the other end of the power cord into the AC outlet.
10
Audio input for video source
Video source should be mached as below
Audio 1 : AV1, S-video, CAM IN
Audio 2 : AV2
DC input
Line in
Line out
DVI-D input
Analog signal input (15 pin)
Component input
AV input 1 (stereo), AV output 1 (Mono)
AV input 2 (stereo), AV output 2 (Mono)
S-Video input/output
Camera input
CONNECTING THE OTHERS
