NuTone ERV100HC Manuel utilisateur

Your Fresh Air Solution for Mild Humid Climates

Features

•Best airflow, sensible energy recovery

and latent energy recovery of its class

•Smart Defrost System

•Ease of service

ERV100HC

Product

•64 to 152 cfm (0.3 in. w.g.)

•60 to 142 cfm (0.4 in. w.g.)

•Offers solid ventilation performance

•The enthalpic core will slow the moisture transfer

between the outdoor and indoor environments*

•Durability, reliability and performance are the

features that you will find with Broan Energy

RecoveryVentilators (ERV)

*The ability to slowthe moisture transfer depends on

the outdoor humidity condition.

Ideal For

•Houses in moderate humid climates from

4,501 sq. ft. to 7,500 sq. ft.

•Contractors who want to offer added

value, quality and best performance

Benefits

•Enjoy the benefits of fresh air to dilute

contaminants without an energy penalty.

Our advanced enthalpic core transfersheat

from one airstream to the other, tempering

the air. This innovative technology reduces

moisture that entersthe houseduring the summer.

• Failure protection system prevents the unit from

allowing cold air to enter into the house.

•All parts removable in 5 minutes. Electrical

access on side panel.

Sensible Apparent Latent Recovery

SupplyNet Average Recovery Sensible Moisture

Temperature Airflow Power Efficiency Effectiveness Transfer

Heating C F L/s cfm Watts % %

0 32 29 60 56 71 79 0.52

032 47 100 80 64 73 0.41

0 32 65 137 126 60 68 0.36

-15 531 65 64 56 81 0.41

Total Recovery Efficiency

Cooling 35 95 28 59 52 45

Voltage: 120 V AC

Frequency: 60 Hz

Dimensions: 21.1" x 34.6" x 13.25"

Weight: 65 lbs

Shipping Weight: 75 lbs

Warranty: 2 years, parts

HVI Rated of air flow: 169 cfm

Power Consumed (max): 150 Watts

Supply air duct connections: 6" Diameter

Exhaust air duct connections: 6" Diameter

Filter: 30 ppi washable reticulated foam

Cabinet: 20 ga. Pre-painted steel

Mounting: Suspension by chains and springs

Wall control modes: N/A

Power: 147 Watts

Current: 1.4 Amps

ERV100HC Specifications

Ventilation Performance

External Static Net Supply Gross Airflow

Pressure Airflow Supply Exhaust

Pa In. W.g. L/s cfm L/s cfm L/s cfm

25 0.1 81 173 87 184 93 197

50 0.2 78 165 83 175 86 182

75 0.3 72 152 76 162 80 169

100 0.4 67 142 71 151 77 103

125 0.5 55 117 59 124 67 143

150 0.6 46 98 49 104 56 118

175 0.7 36 77 39 82 41 87

200 0.8 30 63 32 67 24 51

Note: Unit operating at maximum speed.

Distributed By

Installation

Options

Energy Performance

www.Broan.com

Broan-NuTone, LLC, 926 W. State Street, Hartford, WI 53027 • 800-558-1711

In Canada call 888-882-7626

Attic*

*Contactyour Broan sales representative for information on attic installation requirements.

Return-Return Connection

Return Connection — Extended Exhaust
