Noxon iRadio 310 Manuel utilisateur
English
Internet Radio
NOXON iRadio 310
Quick Start Guide
Version 1 - 01/2014
11
10
NOXON iRadio 310
Important information!
Safety
• Read through the operating manual carefully and keep it in a safe place.
• Observe all warnings and follow the instructions to avoid damage.
• Use this device indoors only.
• Place the device on a level, dry surface to prevent re and electrical shock hazards
as well as possible damage to the player itself.
• Do not use the device close to water or other liquids.
• Keep the device away from direct sunlight, radiators, open ames and other sour-
ces of heat.
• Only use the accompanying power supply cable. If you are not going to use the
device for an extended period, disconnect it from the power supply. To avoid short-
circuits, never pull on the cable itself. In addition, be sure to unplug the device from
the AC outlet in the event of a thunderstorm.
• If the device has been exposed to extreme differences in temperature, allow it to
adjust to the room temperature for one hour before plugging it in. Condensation
may have formed inside the device, which impairs its functionality.
• Use a dry or slightly moistened, lint-free cloth to clean the NOXON. Do not use
cleaning products as they may damage the nish of the unit.
• To put it simply, just use the device sensibly. The warranty does not cover delibera-
te damage to the device, of course. Thank you.
Environment
• The product contains batteries that are subject to European Directive EC and must
not be disposed of in the normal household waste.
• This product fulls EC Directive EC and must not be disposed of in th normal
household waste.
• Please obtain information on correct disposal from your local authorities – this will
help protect the environment!
English
11
Scope of delivery
Start by making sure that the contents of the package are complete. The NOXON pa-
ckage should contain at least the following items:
•NOXON iRadio 310
•Power supply cable
•Remote control with battery inserted
•Quick Start Guide (DE, EN, FR, IT, ES, NL)
Quick Start Guide for pros
This Quick Start Guide shows you how to get started using your NOXON device. You
will nd detailed descriptions and special congurations in the advanced manual, which
you can download from our website (www.noxonradio.com).
Pretest
Like any network device, your NOXON needs to be connected to your network before
you can get started.
What do you need?
•A fast Internet connection (for example, DSL, ideally with a at rate).
•A router for Internet access; for wireless operation, what is called a WLAN
(Wireless LAN) router
•A network cable, if you do not want a wireless Internet connection for your device
•For WLAN integration: your network key (WEP, WPA or WPA2)
This key, just like any key, protects your network from unauthorised access and was
generated when your network was set up. To allow NOXON access to a key-protected
network, you will need to enter the network key into NOXON in a later step. If your
network does not have a key, the NOXON can connect to the Internet without a network
key.
Note: If you are not sure whether you are using a key of this type in your network, just
give it a try without entering anything! If this does not work, repeat the setup process
from the beginning. However, you will need to know your network key at this point.
Please ask the person who set up your network for assistance.
13
12
NOXON iRadio 310
Overview
1. Navigation dial with push function for
selection: Scroll through the menu by
turning the dial in the list view. To select a
menu item, press the dial once.
2. Back button:This takes you one step back
in the selection.
3. Display
1. Prest stations 1 - 5
2. Volume minus
3. Volume plus
4. Mode – change between internet radio
recepti on and musicplayer.
5. Menu/Info – receive more inforation about
the program
6. Standby On/Of
iRadio 310
English
13
1. Power switch Power on/off the internet radio
2. LAN port Ethernet connection
3. DC IN Power supply
4. Earphone jack 3.5mm jack for headphone or earphone
5. Line Out 3.5mm jack for speaker connection
Remote Controller
1. Standby On/Off
2. Mute / Sound off
3. Volume lauder
4. Volume quieter
5. Navigation enter with (ok)
6. Mode
7. Menu
8. Preset stations 1-10
9. Skip Back
10. Playback / Pause
11. Skip Forward
12. Sleep / Snooze
13. Stopp
14. Shufe / Repeat
15. Numeric keypad / preset stations
16. Equalizer (EQ)
17. Information
Setup
Once your iRadio has been activated initially, follow these steps to link it to your net-
work for the rst time:
You are greeted by the setup wizard, which asks politely if you want to start it up.
OK
MODE
SLEEP /
SNOOZE
ABC DEF
GHI JKLM NO
PQRS TUV WXYZ
SHUFFLE/
REPEAT
INFOEQ
MENU
9
10
11
12
13
14
15
16
17
15
14
NOXON iRadio 310
Use the navigation dial to select a language for
the menu and conrm – as in all other menus –
the selection by pressing the navigation dial.
Then, enter the time format (12/24-hour).
However, we recommend that you set the date and time immediately (Day, Month,
Year,Time), as well as the WLAN region you are located in.
Once you have done so, all that remains to be done is to connect to the network. Don‘t
worry, even this should not be complicated – the network wizard will give you all the
help you need.
We‘ll explain the ins and outs of this in the detailed manual later on. For now, we offer
just a brief overview (after all, you are still in the „Overview“ chapter), as we do not want
to bore anybody.
The setup wizard gives you the ability to choose between the cable connection and the
wireless WLAN port. If you prefer the cable version, select [Wired].
The setup wizard connects to your router automatically and that‘s it – you‘re in! Howe-
ver, if the iRadio is integrated via WLAN, please select your WLAN network on the
display. After selecting the desired network, you then have to enter the password to
connect to the WLAN.
SSID
Wi network of your neighbor
Your Wi-Netzwerk
English
15
Navigate through the selection in the usual way
using the navigation dial, push function and
Back button.
When you have nished entering the key, con-
rm with OK. You likewise reach this eld via
the navigation dial.
There, you‘re nished already! Just press the navigation dial again to go to the main
menu – and use your NOXON iRadio to plunge into the wonderful world of Internet
radio.
Note: We recommend checking the device‘s rmware from time to time to ensure that
you have the latest version and to update it if necessary – only in this way can you
access the latest functions of your device. We‘ll explain how to do so later on in this
manual. Listen and enjoy
After you have set the device up successfully, the (almost) innite variety of Internet
radio is at your ngertips.
Listen and enjoy
After you have set the device up successfully, the (almost) innite variety of Internet
radio is at your ngertips.
From the main menu, select „Internet Radio“ and conrm the selection.
Main Menu
Music Player
Sleep
Alarm
System settings >
>
>
Internet radio >
>
17
16
NOXON iRadio 310
In the submenu that follows, navigate to the
station of your choice according to your perso-
nal taste.
To accommodate the large number of stations
available from around the world, our database
is conveniently sorted into countries, genres,
popular stations etc. and is updated
on an ongoing basis.
To adjust the volume during playback, use the button on vol+ and vol- on the radio
/ or the keys on the remote control.
Have fun with your new NOXON iRadio!
Here‘s how to reach NOXON:
http://www.noxonradio.de/en/support
Support-Hotline: 02157 - 817914
NOTE: The structure and function of the software can be changed with a rmware
update!
Volume
15
51
50
NOXON iRadio 310
NOXON iRadio 310
