Condensation dryer TK 7656

Operating Instructions

Dear customer,

Please read this User Information carefully and keep

it to refer to at a later date.

Pass this User Information on to any subsequent

owner of the appliance.

The following symbols are used in the

text:

1Safety instructions

Warning: Notes that concern your personal

safety.

Attention: Notes that show how to avoid

damage to the appliance.

3Useful tips and hints

2Environmental information

Contents

Instructions for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Environmental tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Description of machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Operating screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Before the first drying cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Sorting and preparing laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Overview of programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Switching machine on / switching light on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Opening loading door / filling laundry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Selecting the programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Selecting additional functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

INTENSITY (RESTFEUCHTE). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

AUDIBLE SIGNAL (SIGNAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

SPECIAL CARE (SCHON) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

SENSITIVE (SENSITIV). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Setting time delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Starting the programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Changing programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Putting in extra items or taking items out before end of programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Drying cycle complete / removing laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Cleaning fluff filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Cleaning the door seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Emptying the condensate tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Cleaning heat exchanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Cleaning the drum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Clean operating screen and housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Troubleshooting by yourself . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Changing bulb for inside light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Programming options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Consumption values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Installation and connection instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Installation safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Removing transport safety equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Changing door stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Special accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Customer Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Instructions for use

1Safety

Before first starting up

•Note the ”Installation and connection instruc-

tions”

•Before first starting up, check the machine for any

damage incurred during transport. Never connect

up a damaged machine. If parts are damaged,

contact your supplier.

Intended use

•The dryer is intended for drying standard laundry in

domestic applications.

•Conversions or modifications to the dryer are not

permitted.

•The laundry must not contain flammable solvents

(benzene, alcohol, stain remover, etc.) . Risk of fire

and/or explosion! Laundry which has come into

contact with such substances must be rinsed thor-

oughly by hand before drying.

•When using dry-cleaning sets: Only use those

products which are declared as suitable for the

dryer by the manufacturer.

•Do not place items of laundry in the dryer which

contain foam rubber or materials similar to rubber.

Risk of fire!

•Do not place heavily worn laundry items in the dry-

er. Risk of fire!

•Do not place laundry items with loose fillings (e.g.

cushions) in the dryer. Risk of fire!

•Parts with rigid components (e.g. door mats) may

cover the air slots. Risk of fire! Do not place such

items in the dryer.

•Do not overfill the dryer. Risk of fire! Observe max.

loading volume of 6 kg.

•Ensure that explosive objects (e.g. cigarette light-

ers, spray cans, etc.) do not enter the dryer with

the laundry. Risk of fire and/or explosion!

•Risk of fire: items that have been spotted or

soaked with vegetable or cooking oil constitute a

fire hazard and should not be placed in the tumble

dryer.

•If you have washed your laundry with stain remover

you must execute an extra rinse cycle before load-

ing your tumble dryer.

•Clean the micro-fine filter and fine strainer after

each drying cycle.

•Do not use the machine if there are no lint filters or

if these are damaged. Risk of fire!

•Clean the heat exchanger regularly.

•With stacked washer and dryer: Do not place ob-

jects on the dryer. These may fall off during opera-

tion.

•The covering bonnet of the bulb for the drum light

must be screwed down tightly.

Child safety

•Keep packaging away from children. Risk of suffo-

cation!

•Children can often not see the dangers associated

with electric machines. Never leave unsupervised

children near the dryer.

•Ensure that children and small animals cannot

climb into the dryer’s drum. Risk of death! Keep

the dryer door shut whenever it is not being used.

General safety

•Only specialists may undertake repairs on the dry-

er.

•Never start up the dryer if the mains cable is dam-

aged or if the operating screen, operating plate or

base area are damaged so that the inside of the

machine is open and accessible.

•Switch off the dryer before all cleaning, care or

maintenance work. Also disconnect the mains plug

from the socket or – with permanent connections –

switch off the LS switch in the fuse box and/or fully

unscrew the screwed-in fuse.

•Disconnect the machine from the power supply

during long pauses in operations.

•When removing from the socket, never pull the

mains plug by the cable, instead take a hold of the

plug.

•Manifold plugs, couplings and extension cables

must not be used. Risk of fire from overheating!

•Do not spray down the dryer with jets of water.

Risk of electric shock!

•Do not lean on the open door. The machine may tip

over.

•Once the drying cycle has been interrupted, the

laundry and drum may be hot. Risk of burns! Take

care when removing the laundry.

Disposal

2Packaging material

The packaging materials are environmentally

friendly and can be recycled. The plastic com-

ponents are identified by markings, e.g. >PE<,

>PS<, etc. Please dispose of the packaging

materials in the appropriate container at the

community waste disposal facilities.

2Old appliance

The symbol Won the product or on its pack-

aging indicates that this product may not be

treated as household waste. Instead it shall be

handed over to the applicable collection point

for the recycling of electrical and electronic

equipment. By ensuring this product is dis-

posed of correctly, you will help prevent po-

tential negative consequences for the

environment and human health, which could

otherwise be caused by inappropriate waste

handling of this product. For more detailed in-

formation about recycling of this product,

please contact your local city office, your

household waste disposal service or the shop

where you purchased the product.

1Warning! Remove mains plug from socket

when you have no further use for the machine.

Cut off mains cable and dispose of together

with plug.

Destroy loading door lock. Children cannot

then lock themselves in the machine and put

their lives at risk.

2Environmental tips

•In the dryer, laundry becomes fluffy and soft. Fab-

ric softeners are not therefore needed when wash-

ing.

•Your dryer will function most economically if you:

–always keep the ventilation slots on the base of

the dryer unobstructed;

–use the loading volumes specified in the pro-

gramme overview;

–ensure you have good ventilation in the installa-

tion room;

–clean the micro-fine filter and fine strainer after

each drying cycle;

–spin the laundry well before drying. Example:

Consumption data – depending on spinning

speed – for 6kg of laundry, dried using the COT-

TONS STORAGE DRY (BAUMWOLLE

SCHRANKTROCKEN) programme.

Pre-draining Drying cycle

Revolutions

per minute

Residual dampness

in litres

Residual dampness

as a %

Energy

in kWh

800 4.2 70 3,84

1000 3,6 60 3,36

1200 3.2 53 3,10

1400 3.0 50 3,00

1800 2.5 42 2,60

Description of machine

Operating screen

Drawer containing

condensate tank

Screwed feet

(with height

adjustment)

Loading door

(interchangeable stop)

Operating screen

Large mesh filter

(lint filter)

Air slots

Lamp for inside light

Type plate

Base door

upstream of

heat exchanger

icro-fine filter

(

lint filter)

Fine strainer

(lint filter)

Display showing level

of dryness

Programme progress display

Programme selector

Maintenance displays

–HEAT EXCHANGER (WÄRMETAUSCHER - clean!)

–EMPTY WATER (BEHÄLTER - empty!)

–CLEAN FILTER (SIEB - clean lint filter!)

Block of buttons and displays

Multi-display

DELAY TIMER

button

INTENSITY button

Before the first drying cycle

In order to remove any residue which may have been

produced during production, wipe the dryer drum

with a damp cloth or undertake a brief drying cycle

(30 MIN) with damp cloths.

Sorting and preparing laundry

Sorting laundry

•Sort by fabric type:

–Cotton/linen for programmes in COTTONS

(BAUMWOLLE) programme group.

–Mixtures and synthetics for programmes in EASY

CARES (MISCHGEWEBE) programme group.

•Sorting by care label. The care labels mean:

•Do not dry new, coloured textiles together with

light-coloured laundry items. Textile colours may

bleed.

•Do not dry tricot or knitted items with the EXTRA

DRY (EXTRA TROCKEN) programme. Items may

become stuck!

•Do not dry wool in the dryer. May become entan-

gled! After air-drying, wool may be dried with the

WOOL CARE (WOLLPFLEGE) programme.

Preparing laundry

•To avoid laundry becoming tangled: Close zips,

button up coverings and tie loose bands or ribbons

(e.g. of aprons).

•Empty pockets. Remove metallic items (paper-

clips, safety pins etc).

•Turn items with double-layered fabrics inside out

(e.g. with cotton-lined anoraks, the cotton layer

should be outermost). These fabrics will then dry

better.

nm l k

Basic drying in tumble

dryer possible

Drying at

normal

temperature

Drying at

reduced temperature

(press SPECIAL CARE (SCHON)

button!)

Drying in tumble

dryer not

possible

Overview of programmes

Programme

max. loading volume

(weight when dry)

Additional

functions

Application/properties Care

symbols

AUDIBLE SIGNAL (SIGNAL)

SPECIAL CARE (SCHON) 1)

1) SPECIAL CARE (SCHON) and SENSITIVE (SENSITIV) cannot both be selected at the same time.

SENSITIVE (SENSITIV) 1)

INTENSITY (RESTFEUCHTE)

COTTONS (BAUMWOLLE)

EXTRA DRY

(EXTRA-

TROCKEN)

6kg • • • •

Drying thick or multi-layered textiles,

e.g. terry towelling items, bathing cos-

tumes.

INTENSIVE

DRY

(STARK-

TROCKEN)

6kg • • • • Drying thick textiles, e.g. terry towelling

items, towels.

STORAGE

DRY

(SCHRANK-

TROCKEN)

6kg • • • •

Drying textiles of even thicknesses, e.g.

terry towelling items, knitted items,

towels.

DAMP

(LEICHT-

TROCKEN)

6kg • • • • For thin textiles which are still to be

ironed, e.g. knitted items, cotton shirts.

HAND

IRON

(BÜGEL-

TROCKEN)

6kg • • • • For normal thickness cotton or linen

laundry, e.g. bedding, table linen.

MACHINE

DRY

(MANGEL-

TROCKEN)

6kg • • • •

For cotton or linen laundry which are

still to be put through a machine, e.g.

bedding, table linen.

EASY CARES (MISCHGEWEBE)

EXTRA DRY

(EXTRA-

TROCKEN)

3kg • • • • Drying thick or multi-layered textiles,

e.g. pullovers, bedding, table linen.

ml2) n

2) Press the SPECIAL CARE (SCHON) button!

STORAGE

DRY

(SCHRANK-

TROCKEN)

3kg • • • •

For thin textiles which are not ironed,

e.g. easy care shirts, table linen, baby’s

clothes, socks, corsetry.

ml2)

DAMP

(LEICHT-

TROCKEN)

3kg • • • • For thin textiles which are still to be

ironed, e.g. knitted items, cotton shirts.

ml2)

Programme

max. loading volume

(weight when dry)

Additional

functions

Application/properties Care

symbols

AUDIBLE SIGNAL (SIGNAL)

SPECIAL CARE (SCHON) 1)

1) SPECIAL CARE (SCHON) and SENSITIVE (SENSITIV) cannot both be selected at the same time.

SENSITIVE (SENSITIV) 1)

INTENSITY (RESTFEUCHTE)

30 MIN 1kg • • - - For drying individual items of laundry or for

small volumes of less than 1kg.

ml2)

2) Press the SPECIAL CARE (SCHON) button!

LEISURE

(FREIZEIT) 6kg • • • •

Special programme for leisure clothing, such

as jeans, sweat-shirts, etc., of different mate-

rial thicknesses (e.g. at the cuffs and seams).

EASY IRON

(LEICHT-

BÜGELN)

1kg • • - -

Special programme with anti-crease mecha-

nism for easy care textiles such shirts and

blouses; for minimum ironing effort. The re-

sult depends on the type and quality of tex-

tiles. (The loading volume corresponds to

approx. 5 to 7 shirts.)

Recommendation: Place textiles in the dryer

straight after spinning. Once dried, immedi-

ately remove textiles and place on clothes

hanger.

ml2) n

WOOL CARE

(WOLL-

PFLEGE)

1kg • • - -

Special programme for briefly treating wool-

lens with warm air after they have been dried

naturally, worn or stored for long periods.

Wool fibres are aligned and the wool be-

comes soft and snugly.

Recommendation: Remove textiles immedi-

ately after drying.

REFRESH

(AUF-

FRISCHEN)

1kg • • - -

Special programme, lasting around 35 min-

utes, for refreshing or gently cleaning textiles

with commercially available dry cleaning

sets.

(Only use those products which are declared

as suitable for the drier by the manufacturer;

please observe the manufacturer’s instruc-

tions for use.)

Drying

Switching machine on /

switching light on

Turn the programme selector to any programme or

turn it to LIGHT (BELEUCHTUNG). The machine has

been switched on. When the loading door is opened,

the drum is illuminated.

Opening loading door / fill-

ing laundry

1. Open loading door:

–Either use force to push against the loading door

(push point )

–or if the machine is switched on: Press the DOOR

(TÜR) button.

2. Load your laundry (do not force it in).

1Caution! Do not jam laundry in between the

loading door and rubber seal.

3. Close loading door securely. Lock must audibly

lock.

Selecting the programme

Use the programme selector to set the programme

you require.

The probable programme run time is displayed (in

minutes) on the multi-display.

Table des matières

Autres manuels Novamatic Séchoir

Novamatic

Novamatic TK 660 E Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
