Norton BBC157 Manuel utilisateur

OWNERS MANUAL

COMPACT MASONRY SAW

MODELS

BBC157

BBC207

BBC307

BBC547

BBC507

FORM BBC157-207-307-547-507 rev 10-2009

ConstructionParts.com 888-634-4289

ConstructionParts.com

ConstructionParts.com 888-634-4289

V. PARTS LIST SECTION

Power Plant (BBC547-507) Gasoline

S1 S2

ConstructionParts.com 888-634-4289

ConstructionParts.com

ConstructionParts.com 888-634-4289

Power Plant (BBC547-507) Gasoline

Item No Description Part Number

1 Honda motor GX160 83715

2 Motor pulley 83716

3 Belt XPZ 562 LW 83717

4 Jackshaft pulley 83718

5 Right belt guard 83719

6 Guard for the jackshaft 83720

7 Bearing 70599

8 Jackshaft 83721

9 Motor fixation plate 83722

10 Jackshaft fixation plate 83723

11 Cutting head BBC 14” 83724

Cutting head BBC 20” 232192

12 Support plate for belt guard 14” BBC only 83725

13 Belt guard for 14” BBC only 83726

14 Jackshaft pulley 14” BBC Only 76102

15 Water pump pulley 75270

16 Blade shaft pulley 76098

17 Belt XPZ 1280 LW BBC 14” Only 70398

18 Eyebolt with Hardware (1) 76015

S1 Switch support 83746

S2 Emergency stop switch 83745

ConstructionParts.com 888-634-4289

ConstructionParts.com

ConstructionParts.com 888-634-4289

Power Plant (BBC157-207-307) Electric

Item No Description Part Number

M1 Motor Assembly w/Switch 1-1/2HP 115/230v/60/1

Motor Assembly w/Switch 2 HP 115/230v/60/1

Motor Assembly w/Switch 3HP 230v/60/1

232084

232085

232160

M2 Capacitor Box Large (Terminal Box) 232085A

M3 Voltage Change Switch 231085

M4 Switch Box Rear 231087

M5 Switch On/Off 231088

M6 Switch Box Cover 231089

M7 Capacitor Box Small 231091

-NA- Thermal Reset Button 1-1/2 HP TPMST24AB

NOTE: The Thermal Reset Button Is Located On The

Rear Of The Large Capacitor Housing

232129

-NA- Thermal Reset Button 2 HP

NOTE: The Thermal Reset Button Is Located On The

Rear Of The Large Capacitor Housing

-NA- Pulley 68mm OD 24mmB 1G 4” Electric Models Only

Key 8mm x 7mm x 24mm 83747

232198

-NA- Belt XPZ 1500 LW (1) 14” Electric Models Only

Belt XPZ 1850 LW (1) 20” Electric Models Only 72926

232191

ConstructionParts.com 888-634-4289

ConstructionParts.com

ConstructionParts.com 888-634-4289

Frame (Common All BBC157-207-307-547-507)

Electrical Water Pump

ConstructionParts.com 888-634-4289

ConstructionParts.com

ConstructionParts.com 888-634-4289

Frame (Common All BBC157-207-307-547-507)

Item No Description Part Number

18 Screws for water pump 75280

19 Frame 83727

20 Leg set of 4 75817

21 Wheel 82733

22 Wrench 19mm 70807

23 Wrench 22mm 72143

24 Drain plug 76095

25 Split bearing 83728

26 Water pump fixation spring 76097

27 Support post 83729

28 Water pump complete Mechanical Pump 72305

29 Drive end comp. For water pump Mechanical Pump 72297

30 Sheath for flexible shaft Mechanical Pump

(Not Available, Now part of 72307) -NA- Part of 72307

31 Flexible shaft complete for mech. water pump

L=35.8 inches (910mm) 72307

32 Body of the pump Mechanical Pump 72284

33 Propeller water pump Mechanical Pump 72862

34 Plastic sieve for pump Mechanical Pump 72186

34a Knob M10 X 20 1.5 for Legs (sold each) 72856

34b Nut M10 Square (sold each) 27065

35 Water Pump PE1 – Electric Powered Units Only 214169

35a Screen Water Pump PE1 155775

35b Impeller Water Pump PE1 155774

35c Volute Water Pump PE1 101375

36 Fitting Barb Hose ¼” FPT X ½ MALE BARB 9602010

ConstructionParts.com 888-634-4289

ConstructionParts.com

ConstructionParts.com 888-634-4289

Cutting Head (Common All BBC157-207-307-547-507)

ConstructionParts.com 888-634-4289

ConstructionParts.com

ConstructionParts.com 888-634-4289

Cutting Head (Common All BBC157-207-547)

Item No Description Part Number

35 Locking Handle for cutting head (was 73098

replaced by 82738) 82738

36 Spring 72567

37 Cutting head BBC 14” 83724

Cutting head BBC 20” 232192

38 Protection for Bearings and shaft 76111

39 Support for blade shaft bearing (set of 2) 76060

40 Bearing (set of 2) 73418

41 Blade shaft assembly 14” Models Only

Blade shaft assembly 20” Models Only 76035

76556

42 Loose collar 14” Models Only 73216

Loose collar 20” Models Only 73281

43 Screw for loose collar 73217

44 Handle grip 72097

45 Leveling support 76113

46 Bushings, bearing-Nylon (set of 2) 73220

47 Hose for water pump 72413

48 Splash guard 73221

49 Blade guard 14” 76037

Blade guard 20” 76126

50 Water tap 72357

51 Stay-level arm 73266

52 Kit stay-level arm pin 76039

53 Blade shaft vent cover 76109

54 Y distributor 72286

55 Spray nozzle (set of 2) 80568

ConstructionParts.com 888-634-4289

ConstructionParts.com

ConstructionParts.com 888-634-4289

Cutting Table (Common All BBC157-207-307-547-547)

ConstructionParts.com 888-634-4289

ConstructionParts.com

ConstructionParts.com 888-634-4289

Cutting Table (Common All BBC157-207-547)

Item No Description Part Number

56 Conveyor Cart (aka Cutting Table) Complete

With Wheels, Top, Back Stop, and Conveyor Cart

Stop

83754

57 Top For Cutting Table (Wood & Rubber)

w/Hardware 76742

Screw 4x 12mm DIN 7976 (sold each, 11

required) 30373

58 Conveyor Cart Frame Only (No Wheels, Top,

Backstop or Conveyor Cart Stop) -NA- Part of 83754

59 Wheel Kit, Conveyor Cart (Set Of 4) w/Hardware 75333

Carriage Bolt M10 x 30 DIN 603 (sold each, 3

required) 27282

Washer 10.5 DIN 9021 (sold each, 3 required) 27508

Wing Nut M10 DIN 315 (sold each, 3 required) 27040

60 Back Stop Plate 83752

61 Scale for Conveyor Cart w/rivets 83753

62 Stop Assembly for Conveyor Cart (Complete) 82856

Rubber Stop -NA- Part of 82856

Nut M6 DIN 439 27003

Washer M6 DIN 125 27539

Item No Description Part Number

-NA- Guide-A-Cut Assembly 83892
