NorthStar 6000I - REV A FOR VERSION 4.00 Fiche technique

SmartCraft

for the

Northstar

6000i

Operation and Installation Manual

for software version 4.00 and greater

SmartCraft

is a registered trade-

mark of BNT Mototron

Northstar

is a brand name of

Brunswick New Technologies

Marine Electronics (BNTME) GMSMCRFT Revision A 19JUN05

Warning:

Engine data and faults displayed by this device are for

the convenience of the user. Always consult your

dealer for definitive and accurate engine fault

diagnosis.

Contents

SmartCraft introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Displaying SmartCraft data . . . . . . . . . . . . . . . . . . . . . . .1

The primary screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Vessels with multiple 6000i control heads. . . . . . . . . .4

Configuring the screens. . . . . . . . . . . . . . . . . . . . . . . . . .5

Other SmartCraft options. . . . . . . . . . . . . . . . . . . . . . . . .6

Additional Info bars . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

SmartCraft alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

SmartCraft installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting the Gateway to the engine. . . . . . . . . . . .11

Connecting the gateway to the Northstar 6000i. . . .11

Configuring the 6000i for SmartCraft . . . . . . . . . . . . .12

Uninstalling SmartCraft . . . . . . . . . . . . . . . . . . . . . . . . .12

Setup and Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Tanks setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Vessel setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Save/Load SmartCraft . . . . . . . . . . . . . . . . . . . . . . . . . . .19

GMSMCRFT Rev A – 1 –

SmartCraft introduction

The SmartCraft system provides a wealth of real-time informa-

tion about the physical systems on your vessel, including

engines, tanks and trim settings. When properly installed and

calibrated, SmartCraft displays and manages data such as engine

RPM, oil pressure, and many other items.

Most readings are shown as traditional analog gauges that are

easy to read and interpret. Others, such as gear position, are

shown as pictorial representations.

Displaying SmartCraft data

Once SmartCraft is properly configured by your dealer, just press

the

STAR

key to display a full screen of data. Most data is

displayed as traditional analog gauges, in some cases with a small

digital readout at the bottom of the each gauge. Data can be

displayed in metric or English units, as determined by the

Distance/Speed units selection on the Display Options screen.

Three SmartCraft screens can be selected by pressing the menu

keys.

• Engine Screen — the primary display, showing the data you

need for normal use

• Docking Screen — displays information for docking and

maneuvering

• Tanks Screen — displays gauges indicating the levels of fuel,

water and waste tanks (if sensors are installed).

Select the desired screen by pressing the appropriate menu key

on the SmartCraft screen. The menu key for the selected screen

– 2 – GMSMCRFT Rev A

is displayed in red; others are blue. Other

STAR

key functions are

still available from additional presses of the

STAR

key.

If an engine is shut off, or if SmartCraft data is missing for any

other reason, the gauge needles disappear, digital readouts

display no data, and an alarm is raised.

The primary screens

Engine screen

See “Configuring the screens” on page 5 for choosing which

gauges are displayed on the engine screen.

Analog gauges

Most data is displayed on an analog gauges using a traditional

needle and a small digital readout at the bottom of the gauge.

The gauge is labelled with the data type, and the units of

measure are shown on the gauge.

Sync gauge

On a dual-engine system, the engine sync needle indicates the

RPM difference between the two engines. Adjust engine speed

until the needle is centered.

Trim gauge and popup

The trim gauge indicates the angle of the engine/propellor. Trim

may be displayed on the screen, or can be configured to appear

as a popup gauge whenever it changes by a designated amount.

The gauge dial displays the operating range of the trim setting as

readings from 0 to 10, covering 2/3 of the dial. The remaining

GMSMCRFT Rev A – 3 –

third of the dial indicates the trailer positions of the trim (read-

ings from 10 to 25).

Gear position

The gear position indicator shows whether the transmission is in

gear or in neutral, and, for some systems, whether in forward or

reverse gear.

Trim popup gauge

Gear position

– 4 – GMSMCRFT Rev A

Docking screen

See “Configuring the screens” on page 5 for choosing which

gauges are displayed on the docking screen.

The docking screen is designed to show information needed for

docking and other close maneuvering. Depending on the installa-

tion and engine type, the docking screen can display RPM, gear

position, steering angle, depth, SOG, pitot speed, paddle wheel

speed, and a video window.

Tanks screen

See “Configuring the screens” on page 5 for choosing which

gauges are displayed on the tanks screen.

The tanks screen shows the fluid level of fuel, oil, water, and/or

waste tanks. Level may be shown in gallons, liters, or percentage,

depending on the configuration (only percentage readings are

available if a tank has not been calibrated).

Tanks levels should be calibrated during system installation, as

described later.

Vessels with multiple

6000i

control heads

If your

6000i

system has more than one control head installed,

you should be aware of the following:

The SmartCraft system is interfaced to one particular

6000i

your network. That

6000i

must be turned on to broadcast the

data to the other control heads. If it’s not on, a message will be

displayed on other heads when you try to display the unavail-

able SmartCraft data. Just turn the interfaced head on, and data

will soon be available.

GMSMCRFT Rev A – 5 –

Conﬁguring the screens

The SmartCraft system automatically configures itself appropri-

ately for the types of engines on your vessel. You can change the

content of each gauge or remove gauges from the screens, to

meet your needs.

Conﬁguring the gauge data for a SmartCraft screen:

1. Display the screen to be conﬁgured by pressing

STAR

followed by

the menu key for the desired screen.

2. Press

Conﬁg

One gauge on the screen blinks to show that it is selected for conﬁgura-

tion.

3. Press the cursor pad to highlight the gauge you want to change

and press

Gauge setup

A list of available data for that gauge is displayed.

Configuring the screen

– 6 – GMSMCRFT Rev A

4. Press the cursor pad up or down to select the desired data for that

gauge. To remove a gauge from the screen, select “

– None –

”

from the list.

5. Press

ENTER

Continue for each gauge you want to change.

If you are conﬁguring a gauge for data that applies to two engines, con-

ﬁgure it for one side and the same gauge data will be shown on the

opposite side of the screen.

6. When ﬁnished, press

Return

To set the color of the background:

1. Display any SmartCraft screen as described above.

2. Press

Background

repeatedly until the desired color is displayed.

Selecting day mode or night mode:

1. Display any SmartCraft screen as described above.

2. Press

Conﬁg

3. Press

Day mode

Night mode

, as appropriate.

Other SmartCraft options

Other, less used, SmartCraft options are accessed by pressing the

STAR

key several times to display the

Setup / Options

screen.

You can read more details about these functions in the Setup

and Calibration section of this manual. A summary is given

below.

On this screen, press

SmartCraft options...

to display the Smart-

Craft options screen. With this screen, you can turn the main

SmartCraft display on or off and access engine faults and Smart-

Craft setup functions. The following menu keys are displayed:

GMSMCRFT Rev A – 7 –

•

SmartCraft screen On/Off

— turn the SmartCraft display on or off

•

Engine

— set number of engines, and display engine faults

•

Tanks setup

— conﬁgure tanks

•

Vessel setup

—calibrate the steering angle, trim and speed sensors

•

Save/Load

—save or restore a SmartCraft conﬁguration

•

Return

— go back to the previous page

SmartCraft screen

Press to turn the main SmartCraft screen on or off.

If turned on, the SmartCraft screen is displayed as the first

press of the

STAR

key on this control head.

Tanks setup

With this screen, you can specify the function of system tanks,

set their capacities, and calibrate the sensors. See “Tanks setup”

on page 14.

Engine

This screen shows options for entering the number of engines on

the vessel, and displaying any active engine faults and the fault

history.

The Active Faults screen displays any faults that are currently

present. If there are more than 11 faults, press the cursor pad to

scroll the list to see more.

The criticality of each fault is displayed at the left, as Critical

(red), Severe (orange), Warn (yellow), Caution (black), and Info

(blue).
