Northern HDDVR Series Manuel utilisateur

HDDVR Series

Models: HDDVR4, HDDVR8 & HDDVR16

Rev. 033018

3625 Cincinnati Avenue, Rocklin, CA 95765

♦

855-388-7422

♦

www.northernvideo.com

User Manual

HDDVR Series Digital Video Recorder User Manual

User Manual

About this Manual

This Manual is applicable to HD Digital Video Recorder (HDDVR4 / HDDVR8 / HDDVR16 models).

The Manual includes instructions for using and managing the product. Pictures, charts, images and

all other information hereinafter are for description and explanation only. The information

contained in the Manual is subject to change, without notice, due to firmware updates or other

reasons. Please find the latest version on the company website.

Please use this user manual under the guidance of professionals.

Legal Disclaimer

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY

AT YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL

OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER

ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, OUR COMPANY

WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR

JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS

THE APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS

USED WITH ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER

PREVAILS.

HDDVR Series Digital Video Recorder User Manual

Regulatory Information

FCC Information

Please take attention that changes or modification not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

FCC compliance: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the interference at his

own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and

comply therefore with the applicable harmonized European standards listed under the

EMC Directive 2014/30/EU, the LVD Directive 2014/35/EU, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as

unsorted municipal waste in the European Union. For proper recycling, return this

product to your local supplier upon the purchase of equivalent new equipment, or

dispose of it at designated collection points. For more information see: www.recyclethis.info

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of

as unsorted municipal waste in the European Union. See the product documentation for

specific battery information. The battery is marked with this symbol, which may include

lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the

battery to your supplier or to a designated collection point. For more information see:

www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

HDDVR Series Digital Video Recorder User Manual

Applicable Models

This manual is applicable to the following models: HDDVR4, HDDVR8, HDDVR16

Symbol Conventions

The symbols that may be found in this document are defined as follows.

Safety Instructions

Proper configuration of all passwords and other security settings is the responsibility of the

installer and/or end-user.

In the use of the product, you must be in strict compliance with the electrical safety

regulations of the nation and region. Please refer to technical specifications for detailed

information.

Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power

Source with 12 VDC according to the IEC60950-1 standard. Please refer to technical

specifications for detailed information.

Do not connect several devices to one power adapter as adapter overload may cause

over-heating or a fire hazard.

Please make sure that the plug is firmly connected to the power socket.

If smoke, odor or noise rise from the device, turn off the power at once and unplug the power

cable, and then please contact the service center.

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

Ensure unit is installed in a well-ventilated, dust-free environment.

Unit is designed for indoor use only.

Keep all liquids away from the device.

Symbol

Description

Provides additional information to emphasize or supplement important points of

the main text.

Indicates a potentially hazardous situation, which if not avoided, could result in

equipment damage, data loss, performance degradation, or unexpected results.

Indicates a hazard with a high level of risk, which if not avoided, will result in death

or serious injury.

HDDVR Series Digital Video Recorder User Manual

Ensure environmental conditions meet factory specifications.

Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of

dropping it may cause damage to the sensitive electronics within the unit.

Use the device in conjunction with an UPS if possible.

Power down the unit before connecting and disconnecting accessories and peripherals.

A factory recommended HDD should be used for this device.

Improper use or replacement of the battery may result in hazard of explosion. Replace with

the same or equivalent type only. Dispose of used batteries according to the instructions

provided by the battery manufacturer.

Ensure to use the attached power adaptor only and not to change the adaptor randomly.

The USB flash drive can only connect to mouse or keyboard.

Use only power supplies listed in the user instructions.

HDDVR Series Digital Video Recorder User Manual

Product Key Features

General

Connectable to TVI and standard 960H analog cameras.

Supports UTC (Coaxitron) protocol for connecting camera over coax for TVI/AHD formats and

most CVI formats.

Connectable to AHD cameras.

Connectable to HDCVI cameras.

Connectable to IP cameras.

The analog signal inputs including TVI, AHD, HDCVI, and CVBS can be automatically recognized

without configuration.

Each channel supports dual-stream. And sub-stream supports up to WD1 resolution.

Independent configuration for each channel, including resolution, frame rate, bit rate, image

quality, etc..

The minimum frame rate for main stream and sub-stream is 1 fps.

Encoding for both video stream and video & audio stream; audio and video synchronization

during composite stream encoding.

Supports enabling H.265+/H.264+ to ensure high video quality with lowered bit rate.

H.265+/H.265/H.264+/H.264 encoding for the main stream, and H.265/H.264 encoding for the

sub-stream of analog cameras.

Connectable to H.265 and H.264 IP cameras.

Watermark technology.

Local Monitoring

HDMI output at up to 4K (3840 × 2160) resolution (16Ch Model only)

1 / 4 / 6 / 8 / 9 / 16 screen live view is supported, and the display sequence of screens is

adjustable.

Live view screen can be switched in group and manual switch and automatic cycle live view are

also provided, the interval of automatic cycle can be adjusted.

CVBS output only serves as the aux output or live view output.

Quick setting menu is provided for live view.

The selected live view channel can be shielded.

Motion detection, video-tampering detection, video exception alarm, video loss alarm and

VCA alarm functions.

DVR series supports up to 4-ch line crossing detection and intrusion detection if enhanced VCA

mode is enabled and DVR also supports 1-ch sudden scene change detection. For the analog

channels, line crossing detection and intrusion detection can conflict with other VCA detection

HDDVR Series Digital Video Recorder User Manual

such as sudden scene change detection, face detection and vehicle detection. You can only

enable one function.

Privacy mask.

Several PTZ protocols (including Omnicast VMS of Genetec) supported; PTZ preset, patrol and

pattern.

Zooming in/out by clicking the mouse and PTZ tracing by dragging mouse.

HDD Management

Each disk with a maximum of 8 TB storage capacity.

8 network disks (8 NAS disks, 8 IP SAN disks or n NAS disks + m IP SAN disks (n+m ≤8)) can be

connected.

Remaining recording time of the HDD can be viewed.

Supports cloud storage (OneDrive, GoogleDrive, Dropbox).

S.M.A.R.T. and bad sector detection.

HDD sleeping function.

HDD property: redundancy, read-only, read/write (R/W). Redundancy only available for on

16Ch model with 2x storage drives installed.

HDD group management.

HDD quota management; different capacity can be assigned to different channels.

Recording, Capture and Playback

Holiday recording schedule configuration.

Cycle and non-cycle recording modes.

Normal and event video encoding parameters.

Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm

and event.

The device will note that the exported AVI video may have problems if the frame rates of the

continuous and event recording are different.

8 recording time periods with separated recording types.

Supports Channel-Zero encoding.

Main stream and sub-stream configurable for simultaneous recording.

Pre-record and post-record for motion detection triggered recording, and pre-record time for

schedule and manual recording.

Searching record files by events (alarm input/motion detection).

Customization of tags, searching and playing back by tags.

Locking and unlocking of record files.

Local redundant recording. Redundancy only available for models that can support 2x

storage drives with 2x storage drives installed.

HDDVR Series Digital Video Recorder User Manual

When TVI, AHD, or HDCVI input is connected, the information including the resolution and

frame rate will be overlaid on the bottom right corner of the live view for 5 seconds. When

CVBS input is connected, the information such as NTSC or PAL will be overlaid on the bottom

right corner of the live view for 5 seconds.

Searching and playing back record files by camera number, recording type, start time, end

time, etc..

Smart playback to go through less effective information.

Main stream and sub-stream selectable for local/remote playback.

Zooming in for any area when playback.

Multi-channel reverse playback.

Supports pause, fast forward, slow forward, skip forward, and skip backward when playback,

locating by dragging the mouse on the progress bar.

4 / 8 / 16-ch synchronous playback.

Backup

Exports data by a USB, and SATA device.

Exports video clips when playback.

Video and Log, Video and Player, and Player are selectable to export for backup.

Management and maintenance of backup devices.

Alarm and Exception

Configurable arming time of alarm input/output.

Alarms for video loss, motion detection, video tampering, illegal login, network disconnected,

IP confliction, record/capture exception, HDD error, and HDD full, etc..

Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email

and alarm output.

One-key disarms the linkage actions of the alarm input.

PTZ linking for the VCA alarm.

VCA detection alarm is supported.

System will automatically reboot when a problem is detected in an attempt to restore normal

functionality.

Other Local Functions

Manual and automatic video quality diagnostics.

Operable by mouse and remote control.

Three-level user management; admin user can create many operating account and define their

operating permission, which includes the permission to access any channel.

Completeness of operation, alarm, exceptions and log writing and searching.

Manually triggering and clearing alarms.

HDDVR Series Digital Video Recorder User Manual

Importing and exporting of configuration file of device.

Getting cameras type information automatically.

Unlock pattern for device login for the admin.

Clear-text password available.

GUID file can be exported for password resetting.

Network Functions

Self-adaptive 100M or 1000M network interface.

IPv6 is supported.

TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™ and HTTPS are

supported.

Supports access by Guarding Vision. If you enable Guarding Vision, the device will remind you

the internet access risk and ask you to confirm the “Terms of Service”and “Privacy

Statement”before enabling the service. You should create a verification code to connect to

the Guarding Vision.

TCP, UDP and RTP for unicast.

Auto/Manual port mapping by UPnP™.

Remote search, playback, download, locking and unlocking the record files, and downloading

files broken transfer resume.

Remote parameters setup; remote import/export of device parameters.

Remote viewing of the device status, system logs and alarm status.

Remote keyboard operation.

Remote HDD formatting.

Remote system restart and shutdown.

RS-485 transparent channel transmission.

Alarm and exception information can be sent to the remote host.

Remotely start/stop recording.

Remotely start/stop alarm output.

Remote PTZ control.

Two-way audio and voice broadcasting.

Output bandwidth limit configurable.

Embedded WEB server.

If DHCP is enabled, you can enable DNS DHCP or disable it and edit the Preferred DNS Server

and Alternate DNS Server.

HDDVR Series Digital Video Recorder User Manual

Table of Contents

Product Key Features ...............................................................................................................5

Chapter 1 Introduction...................................................................................................................14

1.1 Front Panel .......................................................................................................................14

1.2 IR Remote Control Operations .........................................................................................17

1.3 USB Mouse Operation......................................................................................................21

1.4 Input Method Description................................................................................................22

1.5 Rear Panel ........................................................................................................................23

Chapter 2 Getting Started ..............................................................................................................25

2.1 Starting Up and Shutting Down the DVR..........................................................................25

2.2 Activating the Device........................................................................................................26

2.3 Using the Unlock Pattern for Login ..................................................................................29

2.3.1 Configuring the Unlock Pattern...............................................................................29

2.3.2 Logging in via Unlock Pattern..................................................................................30

2.4 Basic Configuration in Startup Wizard .............................................................................32

2.5 Login and Logout..............................................................................................................37

2.5.1 User Login................................................................................................................37

2.5.2 User Logout .............................................................................................................37

2.6 Resetting Your Password ..................................................................................................38

2.7 Adding and Connecting the IP Cameras...........................................................................40

2.7.1 Activating the IP Camera.........................................................................................40

2.7.2 Adding the Online IP Camera ..................................................................................41

2.7.3 Editing the Connected IP Camera ...........................................................................45

Chapter 3 Live View .......................................................................................................................47

3.1 Introduction of Live View.................................................................................................47

3.2 Operations in Live View Mode.........................................................................................47

3.2.1 Using the Mouse in Live View .................................................................................48

3.2.2 Switching Main/Aux Output....................................................................................49

3.2.3 Quick Setting Toolbar in Live View Mode ...............................................................50

3.3 Channel-Zero Encoding ....................................................................................................53

3.4 Adjusting Live View Settings ............................................................................................53

3.5 Manual Video Quality Diagnostics...................................................................................55

Chapter 4 PTZ Controls .................................................................................................................57

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Northern DVR

Northern

Northern DVRN960 Series Manuel utilisateur

Northern

Northern TVIDVR4 Manuel utilisateur

Northern

Northern TVIDVR4 Manuel utilisateur

Northern

Northern DVRN960 Series Manuel utilisateur

Northern

Northern N2NVR Series Manuel utilisateur

Northern

Northern NVR4POE Manuel utilisateur

Manuels DVR populaires d'autres marques

FLIR

FLIR M3100E Series Manuel utilisateur

VTRACKPRO

VTRACKPRO FPRO300 Manuel utilisateur

Swann

Swann NVR-7085 models Manuel utilisateur

XtendLan

XtendLan DVR-1670C Manuel utilisateur

urmet domus

urmet domus 1093/004AHD Manuel utilisateur

Holux

Holux M1 Manuel utilisateur

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuel utilisateur

Whistler

Whistler D16VRS Manuel utilisateur

Defender Security

Defender Security 82-20235 Manuel utilisateur

MISUMI

MISUMI MP-WF100M Manuel utilisateur

Speco

Speco D8HU Manuel utilisateur

UST

UST DDR-E04AA Instructions d'utilisation

Consolidated

Consolidated Digital Video Recorder Manuel utilisateur

Mace

Mace DVR0404RW Guide de démarrage rapide

RCA

RCA RTD315W Manuel utilisateur

FSM

FSM Colibri Grande PRO Manuel utilisateur

Hauppauge

Hauppauge HD PVR 2 Manuel utilisateur

Identivision

Identivision ICR-PH161i PIONEER Manuel utilisateur
