North Edge Watch Product Manual
Range 5
Touchable built-in GPS Multi-functional Sports Watch
Dear customers,
Thank you so much for buying and using the North Edge
RANGE 5 watch.
The model is a rechargeable sports watch with built-in GPS,
and can be operated by touchable screen and three buttons
on the right, both operating ways can control the watch and
make the functions working separately.
The RANGE 5 screen is visible in outdoor sunlight, it has
1.2-inch semi-penetrating reflective color screen that would
not be full dark when standby. It will be even clearer and
brighter in strong sunlight. With its low power consumption,
it is truly a good choice for outdoor activities.
1.Content:
One watch
One charging clip
One instruction manual
- 1 -
2.Product features:
1.Bright screen
2.Full Touch operation
3.Dynamic heart rate
4.Built-in multi-satellite positioning reception system
5.Instant altitude
6.Instantaneous air pressure
7.Ambient temperature
8.Compass
9.real-time diving depth
10.50M waterproof
11.Instant latitude and longitude
12.Abdominal rhythm
13.Mobile messaging Data
14.Analysis of multiple motion modes
15.Outdoor track record
16.Low power consumption
3.Key operation:
1.Top Right “START” button: Start/enter
2.Middle “DOWN” button: page DOWN
3.Right Bottom “BACK” button: exit/return/power
- 2 -
4.When the watch is off, press the BACK button for 3 seconds,
and the screen turns on and enters the standby user interface
5.On standby status, press the BACK button for 3 seconds and
the screen turns off
6.When the watch appears abnormal or out of control, long
BACK button for 10 seconds can force the watch to restore original
settings.
4.Touch screen controls:
1.Scroll up and down, flip the page
2.Swipe left: start/enter
3.Swipe right: back
5.Charging instructions:
1.Press the charging clip lightly so that the contacts of the clip are
aligned with the charging port above the bottom of the watch.
In order to make full contact, the step under the clamp contact
must be wedged into the notch of the watch metal contact.
2.Once you have the clip in place, connect it to your computer or
phone’s power adapter using a USB charging cable.
3.The watch shows a red charging screen and when it is turned
on, it indicates that the watch has started being charged.
- 3 -
4.The little arrow on the battery icon on the dial disappears and
shows full battery with green, then the watch was fully charged,
the clip can be removed.
6.Waterproof instructions:
1.Please do not press the buttons under water. For diving mode,
Please use the buttons above water when start/end diving.
2.When wearing the watch, we can wash hands, face or swim or
dive under normal conditions.
3.In order to prevent watch rusting, after using in the sea or
corrosive liquid, please be sure to wipe the watch clean, do not
affect the normal service life of the watch.
4.It is not suitable using the watch in high temperature and high
humidity (such as: Hot Springs, sauna steam room, Hot Bath)
environment, nor place the watch in a humid and steam
environment for a long time.
5.In any waterproof grade, watches should not be used in warm
water/hot spring to avoid high temperature vapor seeping into
the waterproof parts of the watch and affecting the normal service
life of the watch.
- 4 -
7.HPlusFit download installation:
You can search for “HPlusFit” in any of the major application
markets or scan the following QR code to download an application
that matches your watch.
Before pairing your phone with Bluetooth, make sure it meets the
following requirements:
1.IOS must be 12.0 or above.
2.Android 5.0 or above and support Bluetooth 5.1 transport
protocol.
8.Pairing:
1.Run HPlusFit application.
2.Click on Me-my device, and searching for devices, there will be
a watch device called the NORTH EDGE_XXXX. The XXXX number
corresponds to the watch’s “Settings”-version SN number.
- 5 -
3.Click on the watch model to match.
4.The Bluetooth pairing takes only one time, and the watch will be
automatically connected to the phone once pairing successfully.
The iPhone pops up a notification whether to pair with the watch
and whether to allow the watch to receive notifications from the
phone.
5.If a watch cannot automatically connect to the phone after a
successful match, try unbinding the watch in the APP and ignoring
the watch in the Bluetooth settings of the phone; then reenter the
APP to bound watch.
6.If the above operations cannot solve problem for bounding,
long press the BACK button for 10 seconds to reset the watch,
and then enter HPlusFit APP binding watch again.
9.Sync with your phone:
The movement data of the watch will be transmitted to HPlusFit
via Bluetooth. The following points should be noted when
transmitting the data to HPlusFit:
1.Before uploading the motion data, you need to pair the watch
with the phone successfully.
2.Make sure the phone’s Bluetooth is enabled before uploading
the motion data.
3.By reading the watch’s data from your phone and running an
- 6 -
HPlusFit application, you can sync the data by pulling down and
refreshing it on the “Today” page.
4.The accuracy of pedometer data can be effectively improved by
faithfully filling in user configuration.
5.HPlusFit-Me-My information, editable user information.
6.Sex, age, height, and weight make differences in walking data
and calorie consumption data.
7.Sitting for a long time is harmful to health. The function of the
long-sitting reminder can monitor the long-sitting time and give
vibration reminder. The switch : HPlusFit-Me-My device-more-
Sedentary reminder.
10.Heart rate measurements indicate:
One, heart rate measurement in healthy mode
1.The optical heart rate sensor is located on the back of the watch
2.Clean and dry your wrists of sweat or sunscreen.
3.Wear your watch close to the wrist bone, make sure it is snug
against the bone and does not move when you move.
4.Go to watch health-heart rate measurement page.
5.Place it for 10-15 seconds to measure your heart rate, indicating
your current heart rate.
6.Heart rate measurements in the healthy mode show changes in
heart rate over 12 hours period as well as current measured heart
- 7 -
rate values. The measurements will be displayed in the HPlusFit-
today’s heart rate section when synchronized.
7.Heart rate unit of measure: beats per minute (BMP).
Two, heart rate measurement in Exercise Mode
1.The optical heart rate sensor is located on the back of the watch.
2.Clean and dry your wrists of sweat or sunscreen.
3.Wear your watch close to the wrist bone, make sure it is snug
against the bone and does not move when you move.
4.Once you’re in motion mode, select the type of motion, swipe
left or click OK to start motion/ GPS positioning and measure your
heart rate.
5.Place for 10-15 seconds to measure your heart rate, indicating
your current heart rate.
6.Complete GPS positioning and heart rate measurement, swipe
right/press the BACK button to continue/stop/discard the exercise
data and heart rate data.
7.The heart rate data measured in the exercise mode can be
viewed in the watch’s exercise history data, or through the
HPlusFit-exercise record when synchronized with phone.
8.Heart rate unit of measure: beats per minute.
Three, if the heart rate data is abnormal or not displayed,
try the following actions.
- 8 -
1.Clean and dry your wrists of sweat or sunscreen.
2.Please check the optical heart rate sensor on the back of the
watch for scratches or flashes.
3.Try wearing it on your other wrist and measure your heart rate
again.
11.Backlight:
1.In the dark environment, if you need to enhance the brightness
of screen, press any key can open the backlight, continue to swipe
the screen to keep backlight on.
2.In the “Settings” of watch or the APP, there are options for
automatically turning on the backlight by rotating arm during
6:00pm to 12:00pm. In original setting, it is off. If you need this
function, you can turn it on.
3.The backlight dwell time after the stop operation can be set in
Me-My device-more- screen saver time in HPlusFit.
4.Excessive use of backlight will affect standby time.
12.Vibration:
The watch’s vibrating reminder can be turned on or off in “settings”.
- 9 -
13.Dials
1.Time setting: the watch connects to the
phone to get the instant date time.
2.In pursuit of maximum standby time,
the dial with seconds is only displayed for
five seconds when activated.
3.The pedometer/distance/calorie count
displayed on the dials will be reset to zero
the next day. Historical data can be viewed
in the “Today” section of HPLUSFIT under
pedometer/sleep/heart rate.
4.In the dial interface, side-to-side swipe
can switch dial.
- 10 -
14.My Day
1.Pick pedometer data , exercise distance,
exercise calories today in this section. Goal
12,000 steps can be set in HPlusFit-Me-My
device-more-My goal. The watch alerts
you when you’ve achieved the goal.
2.Pedometer/distance/calorie count for
today will be reset to zero the next day.
Historical data can be viewed in the “Today”
