Nortek Reznor 85 Manuel utilisateur

Oil Fired

Floorstanding Heaters

Two Stage, Low Nox Cabinet Heater

WARNINGS

Reznor equipment must be installed and maintained in accordance with the relevant provisions of the Gas Safety

(Installations and Use) Regulations 1998 for gas ﬁred products.

Due account should also be taken of any obligations arising from the Health and Safety at Works Act 1974 or

relevant codes of practice.

In addition the installation must be carried out in accordance with the current IEE wiring regulations (BS 7671),

BS 6896 (Industrial & Commercial) and any other relevant British Standards and Codes of Practice by a qualiﬁed

installer. All external wiring MUST comply with the current IEE wiring regulations.

Reznor® Is a registered trademark of Nortek Global HVAC, LLC.

INSTALLATION AND OPERATING MANUAL

ErP

2018 Part No˚ D301029 Issue C

Page 2

Any reference made to Laws, Standards, Directives, Codes of Practice or other recommendations governing

the application and installation of heating appliances and which may be referred to in Brochures, Specications,

Quotations, and Installation, Operation and Maintenance manuals is done so for information and guidance purposes

only and should only be considered valid at the time of the publication. The Manufacturer cannot be held responsible

from any matters arising from the revision to or introduction of new Laws, Standards, Directives, Codes of Practice or

other recommendations.

Bio fuel statement - All our oil red heater products are congured for use on both Class D light distillate fuel oil.

As a result of recent changes made to European legislation regarding the specication of class D heating oil to allow

for the inclusion of 7% FAME (Fatty Acid Methyl Ester) i.e. bio fuel and effective from early 2011, all oil red air heater

products and installations maybe affected.

From April 2011 all our oil red cabinet heaters will be tted with Riello burners which are bio fuel compatible for

blends up to 10%.

Please note that the use of bio fuels may give rise to a number of installation issues, to both new and existing plant

which could affect the warranty of the burner. We recommend that you familiarise yourself with current information

from both the burner manufacturer Riello and OFTEC.

Important notice to installers

Installers should satisfy themselves that the oil pipework installation is carried out in accordance with all

current legislation, Codes of Practice and recommendations .

Page 3

1. Installation Requirements. 6

1.1 Compliance notices 6

1.2 Certicates of conformity 7

1.3 General product information 7

1.5 Delivery and pre-installation checks. 8

1.6 Warranty 8

1.7 Health and Safety 9

1.8 Location / Positioning 9

1.9 Fuel supply - general 10

1.9.1 Fuel 10

1.9.2 Storage tank 11

1.9.3 Single pipe system (gravity feed) 11

1.9.4 Two pipe system 11

1.9.5 Pressurised ring main system 12

1.9.6 Pipe work and ttings 12

1.10 Electrical supply 15

1.11 Air supply 15

1.11.1 Heaters installed within the heated space. 15

1.11.1.1 Natural Ventilation Openings to the Heated Space. 16

1.11.1.2 Mechanical Ventilation to the Heated Space. 16

1.11.2. Heaters Installed within a Plant Room or Enclosure. 16

1.11.2.1 Natural Ventilation Openings to Plant Rooms 17

1.11.2.2 Natural Ventilation Openings to Enclosures 17

1.11.2.3 Mechanical Ventilation to a Plant Room or Enclosure. 17

1.12 Air distribution system 18

1.13 Flue system. 18

1.14 Dimensions 22

1.15 Technical Details 26

2. Installation. 28

2.1 Packaging/siting 28

2.3 Minimum clearances 28

2.4 Assembly 28

2.5 Flue Installation 28

2.6 Oil Installation/connection 29

2.7 Electrical Installation/connection 29

2.8 Air Distribution Installation 29

2.9 Warm Air Registers 30

2.10 Heater Control Installation 30

3. Commissioning. 48

3.1 Commissioning - Pretest 48

3.2 Commissioning - Ignition 49

3.3 Commissioning - air delivery system 50

3.4 Commissioning - hand over 50

Contents Page

Page 4

4.0 Servicing. 51

4.1 Planned Servicing 51

4.2 Servicing Procedure - Major Component Parts 51

4.2.1 Flue 51

4.2.2 Main Fan Motor 52

4.2.3 Main Fan 52

4.2.4 Pulleys 52

4.2.5 Fan Belts 53

4.2.6 Heat Exchanger 53

4.2.7 Electrical Supply 53

4.2.8 Oil Supply 53

4.2.9 Burner 54

4.2.10 Air Delivery System 54

4.2.11 Report 54

4.3 Service Re-commissioning 54

5 Parts Lists 55

6. Fault Finding Guide 60

7. Replacement Parts. 63

7.1 Bur n er 63

7.2 Controller 63

7.3 Electrode Assembly 63

7. 4 N oz z le 64

7.5 Photocell 64

7.6 Oil Pump 64

7.7 Contactor/Overload 65

7.8 MCB 65

7.9 Fan/Limit Stat Assembly 65

7.10 Fan Belts 66

7.11 Blower Motor 66

7.12 Fan Blower 66

8. User Instructions 67

8.1 Commissioning and hand over 67

8.2 Servicing 67

8.3 Start Up Procedure 67

8.4 Stop procedure 67

8.5 Shut down procedure 68

8.6 Ventilation only 68

8.7 Lockout situations 68

Contents Page

Page 5

Introduction.

Welcome to the Oil Fired Cabinet Heater Range. Local regulations may vary in the country of use and it is the

installers responsibility to ensure that such regulations are satised

All installation, assembly, commissioning and service procedures must be carried out by suitable qualied competent

persons to the statutory regulations in the country of use.

When installing, commissioning and servicing is undertaken on these heaters due care and attention is required to

ensure that working at height regulations are adhered to at the mounting heights specied.

All Dimensions shown are in mm unless

PLEASE READ this document prior to installation and use. The safety of this heater is guaranteed only by the

correct usage in accordance with these instructions, therefore it is recommended that they are retained for

future reference.

The manufacturer reserves the right to alter specications without prior notice.

Page 6

1. Installation Requirements.

1.1 Compliance notices

The Oil Fired Cabinet Heater range detailed herewith are manufactured within a strictly controlled quality environment

within the parameters of ISO 9001.

These instructions are only valid if the following country code is on the appliance GB. IE. If this code is not present

on the appliance, it is necessary to refer to the technical instructions which will provide the necessary information

concerning the modication of then appliance to the conditions of use for the country.

The Oil Fired Cabinet Heater range have been tested and assessed for compliance with the following European

Directives.

• Machinery Directive: (2006/42/EC)

• Low Voltage Directive: (2006/95/EC)

• Electromagnetic Compatibility Directive: (2004/108/EC)

• Product Liability Directive: (85/374/EEC)

The manufacturer has taken reasonable and practical steps to ensure that all Oil Fired Cabinet Heaters are safe and

without risk when properly used. These heaters should therefore only be used in the manner and purpose for which

they were intended, and in accordance with the recommendations detailed herewith.

The Oil Fired Cabinet Heater range has been designed, manufactured, assembled, inspected, and tested, with safety

and quality in mind, there are certain basic precautions which the installer and user should be aware of, and they are

strongly advised to read the appropriate sections of the information pack accompanying the heater, prior to installation

or use.

The manufacturer supports all new products being supplied to their customers with a comprehensive information

pack; this clearly denes mandatory instructions for the safe installation, use, and maintenance, of the appliance(s).

Where proprietary items are incorporated into any Oil Fired Cabinet Heaters, detailed information and instructions are

also provided as part of the information pack.

It is the responsibility of the installer, owner, user, or hirer of Oil Fired Cabinet Heaters to ensure that they are familiar

with the appropriate information/manuals supplied by the manufacturer and the safety instructions. In addition,

operators must be suitably trained in the use of the appliance so as to ensure its continued safe and efcient use.

The manufacturer has a commitment to continuous improvement and therefore reserve the right to amend or

change the specication of Cabinet Heaters subject to compliance with the appropriate European, national and local

regulations

Contained within the text of the manual, the words ‘Caution’ and ‘Warning’ are used to highlight certain points.

CAUTION

Caution is used when failure to follow or implement the instruction(s) can lead to premature failure or damage

to the heater or its component parts.

WARNING

Warning is used when failure to heed or implement the instruction(s) can lead to not only component damage,

but also to a hazardous situation being created where there is a risk of personal injury.

Page 7

The Oil Fired Cabinet Heater range conform to the following harmonised standards:

BS EN 292-1

Safety of Machinery - Basic Concepts, General Principles for Design Basic terminology, methodology BS EN 292-2

BS EN 292-2

Safety of Machinery - Basic Concepts, General Principles for Design Technical Principles and Specications

BS EN 60204-1

Safety of Machinery - Electrical Equipment for Machines Specication for General Requirements

BS EN 60335-1

Safety of Household and Similar Electrical Appliances General Requirements

BS EN 55014

Limits and methods of measurement of radio disturbance characteristics of electrical motor-operated and thermal

appliances for household and similar purposes, electrical tools and similar electric apparatus

BS EN 50165

Electrical Equipment of non-electric heating appliances for household and similar purposes, safety requirements

1.2 Certicates of conformity

Certicates of conformity are available from the manufacturer, address details are shown on the back page.

1.3 General product information

The Oil Fired Cabinet Heater models have an output range from approximately 32.0 kW to 381kW, and are available

in a conguration that will allow for down ow, horizontal, or oor mounting.

The units can suit either ducted applications, or be used as free blowing units, but each heater must be connected to

its own individual open ue.

Each heater is tted with a forced draught burner which has been test red and pre-set prior to despatch. The safety

functions of the burner are by way of a fully sequential control box tted to the burner.

Neither asbestos nor soft soldered joints are used in the construction or manufacture of The Oil Fired Cabinet

Heater range. The materials selected for use can withstand the mechanical, chemical, and thermal stresses

which they will be subject to during foreseen normal use when installed in accordance with the manufacturers

recommendations.

1.4 General requirements

CAUTION

Ensure the fuel supply is in accordance with the manufacturer’s recommendations and is as stated on the

appliance data plate.

CAUTION

Installation, commissioning, and servicing must only be carried out by appropriately qualied and competent

persons.

WARNING

Unauthorised modications to the appliance, or departure from the manufacturers guidance on intended use,

or, installation contrary to the manufacturers recommendations may constitute a hazard.

To ignore the warning and caution notices, and to ignore the advice from the manufacturer on installation,

commissioning, servicing, or use, will jeopardise any applicable warranty, moreover, such a situation could

also compromise the safe and efcient running of the appliance itself, and thereby constitute a hazard.

Page 8

The installation of the appliance must meet all the relevant European, national, and local criteria.

Prior to installation the following points should be considered;

• The position of the heater for the optimum efcient distribution and circulation of warm air.

• The position of the heater relative to the route of the ue

• The position of the heater relative to the supply of fuel

• The position of the heater relative to the electrical services, and if appropriate, any additional controls.

• The position of the heater relative to the supply of fresh air

• The height if applicable at which the heater is to be mounted and potential stratication /circulation problems.

• The position of the heater relative to service and maintenance requirements

CAUTION

The heater must not be installed within an area where the conditions are unsuitable, e.g. where the atmosphere

is highly corrosive, has a high degree of salinity, or where high wind velocities may affect burner operation.

Suitable protection should be provided for the appliance when it is located in a position where it may be

susceptible to external mechanical damage from; for example, fork lift trucks, overhead cranes etc.

1.5 Delivery and pre-installation checks.

The heater is supplied wrapped in heavy duty protective polythene. On receipt of the heater, the following checks

should be carried out;

• The model is as per order.

• That it is undamaged.

• That it is suitable for the fuel supply.

• That it is suitable for the electrical supply

If any of these points are not satised then contact should be made with the suppliers sales ofce as soon as possible

by telephoning the number shown on the rear page. In the case of claims for damage, this must be signed for as

damaged and reported in writing within 24 hours of delivery, in order to comply with insurance criteria.

1.6 Warranty

The heater is supplied with a 1 year parts and labour warranty and a further year on all parts excluding consumables.

In addition to this there is a 10 year time related warranty on the combustion chamber.

The warranty commences from the date of dispatch from the manufacturer, and is subject to the terms detailed within

the Manufactures ‘conditions of business’.

Note (i) The warranty may be invalidated if …

• The installation is not in accordance with the general requirements of this manual.

• The ue arrangement and air supply for the heater are not in accordance with the manufacturers recommendations, codes of practice, or

similar standards.

• Air ow through the heater is not in accordance with the manufacturers technical specications.

• Internal wiring on the heater has been tampered with or unauthorised service or repairs undertaken.

• The main electrical supply input to the heater has been interrupted during the heating mode.

• The heater has been subject to and affected by the ingress of water in any form.

• The heater is not operated at the rating(s) laid down in the manufacturers technical specications.

• The heater has not been operated or used within the normal scope of its intended application.

• The manufacturer’s recommended minimum service requirements have not been complied with

Page 9

Note (ii) All warranty claims must contain the following info to enable processing to take place

• Heater model

• Heater serial number

• Order reference/date of order, together with full installation details (name and address)

• Details or symptoms of fault

• Installers name and address.

Faulty parts must be returned to the supplier, the address of which is provided at the rear of this manual.

Any such parts will undergo inspection to verify the claim. Replacement parts supplied prior to this may be charged,

and a credit supplied upon subsequent validation of the warranty claim.

Consumable items are specically not included within the scope of the warranty.

Note (iii) Notication is required immediately a fault is suspected.

The manufacturer will not accept responsibility for any additional damage that has been caused, expense incurred, or

consequential loss resulting from any failure of the heater(s).

1.7 Health and Safety

WARNING

The Oil Fired Cabinet Heater range must be installed in accordance with the current OFTEC regulations for oil

red products Due account should also be taken of any obligations arising from the Health and Safety at Works

Act 1974 or relevant codes of practice. In addition the installation must be carried out in accordance with the

current IEE wiring regulations (BS 7671), BS 6896: (Industrial & Commercial) and any other relevant British

Standards and Codes of Practice by a qualied installer. Isolate all electrical supplies to the heater & controller

before proceeding.

For your own safety we recommend the use of safety boots and leather faced gloves when handling sharp or heavy

items. The use of protective eye wear is also recommended.

CAUTION Before using this appliance:

• Check that the voltage indicated on the type plate corresponds to the mains supply voltage.

• Ensure that the heater has been securely fastened in its nal mountain position.

WARNING

UNDER NO CIRCUMSTANCES should any item be placed on or above any part of the heater, whether the heater

is being used or not. This appliance must be earthed.

1.8 Location / Positioning

WARNING

All of the basic criteria must be satised prior to commencing installation and commissioning, additionally, the

Oil Fired Cabinet Heater must be positioned and installed so as to comply with all the relevant standards and

guide lines (see section 1.1), as well as meeting national and local re regulations and insurance criteria,

especially if it is proposed that the heater is to be installed within a special risk area (e.g. proximity to where

petrol engined vehicles are stored or parked, where cellulose spraying takes place, where woodworking

machinery is operated, etc,).

Indirect heaters must not be located in hazardous areas, however, it is permissible for the heater to supply air to such

areas.

The heater must not be installed within an environment where there is a high concentration of chlorides, uorides,

salts, or other aggressive or volatile chemicals/compounds. Nor should the heater be positioned where the burner

could be adversely affected by high winds or draughts.

The location chosen for the heater must allow for the tting of an effective ue system.

Page 10

The location must also allow for adequate clearance for the air supply, return air circulation, oil supply and electrical

supply, whilst also providing good and safe working access. The heater must be installed on a at and level surface

made from non-combustible material, which is sufciently robust to withstand the weight of the heater and any

ancillary equipment. Any combustible material adjacent to the heater or ue system must be so placed or shielded so

that its surface temperature does not exceed 65°C.

In areas where it is proposed that more than one heater is to be installed, a general scheme of circulation should be

drawn up and maintained, thereby offering the best heat distribution

All Oil Fired Cabinet Heaters are tted with a pressure relief facility, this is incorporated into the design of the ue gas

exit duct.

Care should therefore be taken in siting service connections and controls well away from the pressure relief vent.

WARNING

Under no circumstances must the pressure relief be restricted, blocked, or have the free exit of exhaust gas

impaired or re-directed.

1.9 Fuel supply - general

The Oil Fired Cabinet Heater range are all manufactured and pre-set for use with 35 second gas oil delivered to the

burner via a suitable piped system from the oil storage tank.

WARNING

Galvanised or plastic pipe work and ttings must not be used. (See BS 5410 Part 1 1997)

The constraints of the application will, to a large extent, determine whether it is preferable to use a single pipe gravity

feed system, or whether the two pipe pumped system is more appropriate.

Where more than one appliance is to share a common supply it will be necessary to use a pressurised ring main

system.

All pipe work must be constructed and installed so that it does not permit the ingress of air.

The construction, size, and position of the oil storage tank must take account of the current regulations, as well as

suiting the requirements of the installation.

Please refer to pages 9 and 10 for additional information.

CAUTION

On pumped systems always check that the pump is correctly set up prior to running, and always ensure that

valves are open allowing a free ow of oil through the system.

1.9.1 Fuel

In order to promote trouble free operating it is necessary that the oil within the storage tank and oil line does not fall

below the cold lter plugging point (cfpp), in this country and with class D fuel (also referred to as gas oil). The critical

temperature is -4°C for this summer grade.

The cfpp critical temperature for the winter grade is -12°C. If summer grade fuel is stored for winter use in areas prone

to severe frosts and low temperatures it will be necessary to insulate or even heat the supply tank and pipe work.

The fuel supplier should be contacted prior to installation so that any requirements concerning delivery,

transport, storage and use can be addressed before work commences.

The inlet pump pressure must not exceed a maximum of 0.4 bar, this is because beyond this point gas is liberated

from the oil.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Nortek Chauffage

Nortek

Nortek C8QV Series Manuel utilisateur

Nortek

Nortek H9HK Series Manuel utilisateur

Nortek

Nortek Reznor UDSA-4 Manuel utilisateur

Nortek

Nortek REZNOR GUARDIAN GB Series Manuel utilisateur

Nortek

Nortek C84QA Series Manuel utilisateur

Nortek

Nortek REZNOR UDSBD 015-3 Mode d’emploi

Nortek

Nortek C84DA Series Manuel utilisateur

Nortek

Nortek C8QA Series Manuel utilisateur

Nortek

Nortek Reznor GUARDIAN GB Manuel utilisateur

Nortek

Nortek NRV24M Manuel utilisateur

Nortek

Nortek RENZOR GUARDIAN GB Manuel utilisateur

Nortek

Nortek Reznor RHC DJL 8000 Mode d’emploi

Nortek

Nortek Reznor FSE Series Mode d’emploi

Nortek

Nortek Ambirad Vision VSX Guide d'installation

Nortek

Nortek Reznor RHC21 8000 Guide de l'utilisateur

Nortek

Nortek C6B-T Manuel utilisateur

Nortek

Nortek AIRBLOC ACM900SE6 Manuel utilisateur

Nortek

Nortek Reznor 30 Guide de l'utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
