Doorphone
Installation
Guide
.
Norstar Doorphone Installation Guide
i
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations for the Canadian
Department of Communications.
FCC Regulations
Radio Frequency Interference
Warning: This equipment generates, uses, and can radiate radio frequency energy,
and if not installed and used in accordance with the instruction manual, may cause
interference to radio communications. It has been tested and found to comply with
the limits for a Class B computing device pursuant to Part 15 of the FCC Rules and
CSA specification C108.8, which are designed to provide reasonable protection
against such interference when operated in a commercial environment. Operation of
this equipment in a residential area is likely to cause interference in which case the
user will be required at his own expense to take whatever measures necessary to
correct the interference.
Note: When the Doorphone is powered by a Station Auxiliary Power Supply instead
of the KSU station port, the Doorphone does not exceed Class A limits for radio
noise emissions.
In the event of equipment malfunction, all repairs will be performed by
Northern Telecom or by one of its authorized dealers.
Address of repair facilities
USA: Canada:
NorthernTelecom NorthernTelecom
ProductService Center 30NorcelcoDrive
640Massman Drive Weston,Ontario
Nashville,Tennessee M9L2X6
37210 Attn: RepairsDepartment
Ph:1-800-466-7835 Ph:416-744-5201FAX: 416-744-5227
Norstar Doorphone Installation Guide
ii
Norstar Doorphone Installation Guide
1
About the Doorphone
What is the Doorphone?
The Doorphone connects to a digital Meridian Norstar™ telephone port to provide
call notification and handsfree communication from a premise entry location to other
stations on the system.
Door opening functionality can be achieved if installed with one of two optional
hardware devices. If an External Relay Module (ERM) is installed, the call will be
ended immediately after the door is opened. If a Door Opening Controller (DOC) is
installed, the call will continue until QUIT or
®
is pressed.
Before Installation
Check the following environment requirements:
For the Doorphone
Temperature -35°to 60°C (-31°to 140°F)
Relative humidity 5% to 95% non-condensing
Background noise up to 70 d BA
Package Check List
Make sure the package contains:
❏
the Doorphone unit with a surface
mount bracket
❏
documentation:
Doorphone Installation Guide
Doorphone User Card
❏
two gaskets Figure 1 – Package Contents
™
Meridian and Norstar are trademarks of Northern Telecom
Norstar Doorphone Installation Guide
2
Installation Overview
Doorphone Compatibility
The Doorphone is compatible with and supports the North American KSU platforms
for DR2, DR3, DR4, DR5, Modular ICS Release 1-T1, Centrex and greater, for 3X8,
Compact and Modular systems.
Installation Overview
The Doorphone will identify itself to the KSU as an M7208 Norstar telephone.
There are five steps to follow when installing a Doorphone:
1. Select a station port for the Doorphone and determine the Directory Number.
2. Program the Station Port Parameters.
3. Wire and Mount the Doorphone.
4. Program the Doorphone.
5. Test the Doorphone.
Ext. 23
Ext. 22
Ext. 21
Figure 2 – Installation Overview
Norstar Doorphone Installation Guide
3
Installation
Step 1: Determine the Doorphone Directory Number
Up to four Doorphones can be installed on a Norstar system. Each is assigned a
Directory Number (DN) by the KSU.
To determine the DN of the port to which the Doorphone will be connected, use the
Maintenance Port/DN Status facility (Modular systems only), or refer to the wiring
charts in the relevant Norstar Installer Guide, or:
1. Ensure Auto Set Relocation feature is turned off.
2. Connect a jack and Norstar telephone to the port.
3. Press
ƒ
•
‚
∆
and record the DN.
4. Disable voice calls by pressing
ƒ
°
°
.
5. Repeat steps 2 to 4 for each Doorphone Port.
Norstar Doorphone Installation Guide
4
Installation
Step 2: Program Station Ports
Norstar configuration must be performed before wiring the Doorphone. Startup
defaults can cause the Doorphone to automatically answer incoming calls which
were not intended to be heard over the Doorphone.
1. Enter Norstar Configuration programming from a Norstar M7310 or M7324
telephone. To do so,
• Press
ƒ••Ç؈ÏÈÌ
.
• Enter the configuration password.
• The default is
Ç؈ÏÈÌ
, or
¤flfl‹››
.
Norstar Doorphone Installation Guide
5
Installation
Step 2: Program Station Ports (cont’d)
2. Perform the following configuration assignments. Refer to the
Norstar Installer Guide for details.
A. Configuration
1.Trunk/Line Data
❏ensure the Doorphone is not the prime set for any line
2. Line Access
❏remove all line appearances and line ringing assigned to the Doorphone. If you
do not remove all line appearances, incoming calls will automatically be
answered by the Doorphone.
❏ensure no answer DNs are assigned to the Doorphone
❏remove all line pools assigned to the Doorphone
❏assign only one intercom button to the Doorphone
❏assign the intercom (I/C) as the Doorphone’s prime line
Note: Two intercom buttons is acceptable, if this is the minimum offered in
**CONFIG programming. Prime line “none” is acceptable if Intercom is not
offered. This is dependent on your system software release.
B. General admin
2. Names
❏assign a name to each Doorphone (e.g., Front, Gate, etc.)
Norstar Doorphone Installation Guide
6
Installation
Step 2: Program Station Ports (cont’d)
4. Direct Dial
❏ensure the Doorphone is not assigned as a Direct Dial telephone
5. Capabilities
❏enable Full Handsfree
❏disable Auto Handsfree
❏enable Paging
Note: The Doorphone may be used as a paging device by assigning a page
zone, but it should not be assigned the page zone used for its own door chimes.
❏disable the Auxiliary Ringer
❏ensure the Doorphone does not Call Forward on Busy
❏ensure the Doorphone does not Call Forward on No Answer
❏ensure the Do not disturb feature (DND) is turned off
❏ensure Hotline is assigned “None”
6. Service Modes
❏ensure the Doorphone is not a control set
❏ensure the Doorphone is not assigned as an extra-dial set
❏ensure the Doorphone is not assigned as a ringing set
Note: Configuration headings may not be exactly as shown, depending on the KSU
software version.
