Instruction

Manual

For

Models:

D12 and D24 Digital Power Supply

D12R and D24R Digital Power Supply

INTRODUCTION

Thank you for purchasing a Norman Power Supply. Welcome to the Norman family of

interchangeable high-quality flash equipment. The utilization of larger high-duty-cycle flash

capacitors and related components enables this Power Supply to be utilized for demanding

commercial and portrait silver halide and digital applications.

FEATURES

oD12: 1200 watt-second capacity and D24: 2400 watt-second capacity. The D12 and

D24 is an honest 1200/2400 watt-seconds respectively.

o1/20-stop repeatability at full power. Holds this tolerance with line voltages from 105

to 125 volts.

o2 Independently controlled channels, symmetric or asymmetric operation.

o4-lamp head connectors (2 per channel) with individual on/off switches.

oMisfire alarm for each lamphead.

oFan Cooled

oDigital controls with LED display. Adjustable in 1/10-stop increments.

oAudio and visual ready indication (switchable).

oBuilt in photo-eye (switchable).

oModeling light full/ratio/trim modes.

oError condition diagnostic readouts via internal software, as displayed in the LED

arrays.

oAutomatic thermal protection.

oSlow recharge selection.

oInterchangeable with the entire Series 900 line. Over 80 lamphead and accessory

items support the D12 and D24 digital power supply.

oFull two year limited warranty, including parts and labor.

oOptional built in Pocket Wizard. D12R and D24R.

IMPORTANT SAFEGUARDS

In accordance with UL122 specifications for photographic equipment.

When using your photographic equipment, basic safety precautions should always be

followed, including the following:

1. Read and understand all instructions.

2. Care must be taken as burns could occur from touching the flashtube or modeling

lamp.

3. Do not operate the appliance with a damaged cord or if the appliance has been dropped

or damaged, until it has been examined by a qualified service technician.

4. If an extension cord is necessary, a cord with a suitable rating should be used. Cords

rated for less amperage than the appliance may overheat. Care should be taken to

arrange the cord so it will not be tripped over or pulled.

5. When practical, unplug the appliance from the electric outlet when not in use. Never

yank the cord to pull it from the outlet. Grasp the plug and pull to disconnect.

6. To avoid electrical shock hazard, do not disassemble this appliance, but take it to a

qualified service technician when service or repair work is required. Incorrect

reassembly could cause an electric shock hazard when the appliance is subsequently

used.

7. CAUTION – Designed for indoor use only. Do not operate outside in the rain or in

inclement weather or in the presence of standing water.

8. The use of an accessory attachment not recommended by the manufacturer may cause

a risk of fire, electric shock, or injury to persons.

9. Always connect this appliance to a grounded outlet.

10. Disconnect the unit from its source of supply before replacing the flashtube or

modeling lamp.

Warning: Changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. Operation of this equipment in residential area is likely

to cause harmful interference in which case the user will be required to correct the interference

at their own expense.

UNPACKING

Carefully unpack and remove all parts from the shipping carton(s). Do not discard or destroy

any packing materials until all parts of the equipment have been inspected, assembled, and

working properly.

Inspect all parts for damage due to shipping. If any damage is found, contact the delivery

carrier immediately. Claims should be made to the delivery carrier before destroying shipping

carton(s).

Flash Rate

This unit is designed to quickly recharge to full power in about 2.6 seconds. However,

continuous rapid flashing of the unit, without resting, may overheat and damage the

lampheads and internal components. At maximum power, the recommended continuous cycle

rate is 12 seconds between flashes. In addition, up to 4 minutes of rapid firing at a 4 second

flash rate is possible. By lowering the power and/or increasing the time between flashes you

can extend the duration of rapid flashing. Alternatively, the cycle rate may be increased by

lowering the power and/or decreasing the duration of rapid flashing.

14 2 1 7 5 15 11

3 9 13 6 10 8 4 16

CONTROL PANEL / OUTLETS / BASIC OPERATION

1. AC Power Inlet

Connects to the AC power cable. The AC input is 115 volts, 60 Hz. The unit is voltage

stabilized to provide 1/20-stop full power repeatability with AC line voltage fluctuations of 20

volts (105-125 volts).

2. Power Switch

Switches the AC power on/off. A memory circuit retains the output settings when the unit is

switched back on or when the AC power is interrupted.

3. Modeling Lamp

Depress the pushbutton switch to toggle between the three modeling lamp modes:

FULL - The modeling lamp is at full brightness regardless of the flash power setting.

RATIO - The modeling lamp will automatically ratio (track) with the flash power

setting.

OFF - The modeling lamp is off (indicated by both the Full and Ratio LED’s off).

TRIM- The Modeling lamps can be trimmed without losing ratio if they are too bright

or too dim in their default setting.

4. TEST Button/Ready Light

The unit can be flashed by depressing the TEST button. When changing power levels, power

can be discharged through the flashtube instantly with this button instead of waiting for the

power to be bled through the discharge resistor of the internal circuitry. The switch

illuminates when the Power Supply has recharged to full power.

5. SYNC Outlets

The camera connects to this outlet via the R4158 Sync Extension Cord (included).

Note: Proper polarity is important with cameras that utilize grounded shutter switch circuits

(cameras that utilize PC cords). If the unit does not flash on initial set-up the polarity may be

reversed. To achieve the correct polarity – Reverse the camera sync cord at the point where it

joins the Sync Extension Cord. This establishes a common ground between the camera body

and the flash unit. If the polarity is incorrect the unit could self-flash or flash intermittently.

6. Photo Eye (Slave)

Permits remote triggering from other flash units. The Photo Eye can be enabled/ disabled by

pushing the photo eye button. (When the button is illuminated the photo-eye is enabled).

7. RESET 15 Amp Circuit Breaker

Automatically protects the flash circuit against excessive overloads. When activated, it will

pop out about ¼” and the unit will become inoperative. To reset, wait at least 30 seconds and

depress the RESET button. If the circuit breaker continues to activate, consult the factory or

your authorized Norman service center.

8. Power Trim Knob

Adjusts the flash output from full to –5 f-stops in 1/10 increment settings. In combine mode

either power trim knob will change the output level of the entire pack.

9. Flash Verification

Visual- Flash verification will visually indicate when the unit has flashed. The

modeling lamp will cycle on and off, then return to its previous state.

Audible- The unit will beep twice when the unit has flashed and returned to full

power.

This function can be enabled / disabled by toggling the Flash Verification audible / visual

pushbutton switch.

10. Combine- When the pack is in combine mode; all of the power in the power pack is

distributed evenly to all lampheads that are enabled.

11. Lamphead Enable- Enables a Lamphead to be turned off without unplugging the

Lamphead. When “on” the Lamphead enable button illuminates and the lamphead display

shows the output level the lamp is set for. Upon a misfire, the Lamphead enable button will

blink on the head or heads that misfired. If enabled and there is no Lamphead plugged in, a

misfire will be recorded upon each flash.

12. Cooling fan- The D12 and D24 utilizes a cooling fan to remove excess heat from the

unit. Care should be taken to prevent blocking the vents on the sides of the unit. (Not shown

located on side panel of unit).

13. Slow Recharge- When enabled, the units recycle time is increased. This feature is useful

when operating at a location that has sub-par wiring.

14. Led Displays- Indicate the exact power setting, in watt-seconds, for each lamphead. The

displays also show error codes.

15. Computer Control Modular Jack- Used to hook up power pack to a computer via serial

port; contact factory sales about use and computer software.

16. Optional Pocket Wizard antenna-

For Norman D12R and D24R

Digital Power Supplys Supplied with

the PocketWizard™ Receiver

The D12R and D24R Incorporate

a built-in PocketWizard™ receiver which is internally wired for simple operation.

No Batteries are required.

Operation

The PocketWizard™ enabled D12R and D24R “listens” for wireless data transmissions from a

PocketWizard™ transmitter upon power up for the first 30 seconds of operation. The D12R

and D24R automatically scans continuously through the channels and if it detects continuous

valid trigger signals for 4 seconds on a particular channel it will set itself to operate on that

channel. To do this, press and hold the “test” button on your transmitter. If no valid trigger

data is found within the first 30 seconds from power up, the unit will set itself to operate on

the last channel used prior to the previous power down.

When you apply power to the D12R or D24R, the radio receiver will not respond for the first

30 seconds, unless you “teach” it a new channel (by pressing and holding the “test” button on

your transmitter). After learning, the unit will flash to indicate it is ready on the new channel.

Power Option Examples

Note: All listed examples are for the D24, 2400 watt-second digital power supply.

(Divide the power in half for D12, 1200 watt-second digital power supply.)

1200 W-S 1200 W-S 600 W-S 600 W-S 1200 W-S

Full Power, Isolate mode, 2 lampheads Full Power, Isolate mode, 3 lampheads

2400 W-S 800 W-S 800 W-S 800 W-S

Full power, combine mode, 1 lamphead Full power, combine mode, 3 lampheads

ADVANCED OPERATION

Alarm System

In the event of a misfire the alarm system is reset automatically by flashing the unit or by

pressing any button on the control panel.

Thermal Protection

The D12 and D24 are protected with an internal overtemp cutout. In the event of an overtemp,

the Power pack will be disabled; The Power Pack will automatically reset itself after it has

cooled down.

SERVICE

Should not be attempted by user. Consult an authorized Norman Service Center.

Modeling lamp or flashtube replacement. Always unplug unit and discharge stored energy

by pressing the Test button. Wait 10 minutes for any residual charge on the main capacitors to

drain and let the flashtube and modeling lamp cool before handling. Always handle modeling

lamp with clean gloves or cloth to avoid transfer of body oils to lamp dome. Carefully remove

old flashtube and/or modeling lamp and replace with new.

Never place metal object or fingers into modeling lamp or flashtube sockets.

DIAGNOSTIC TROUBLESHOOTING / ERROR CODES

This information can assist the operator in determining the source of a malfunction and it can

assist an authorized Norman Service Center in servicing a Norman Power Pack. These codes

flash on the LED Display, signifying the following:

Over Temp- Indicates the unit has exceeded normal operating temperatures. In the first

stage, the unit goes into slow recycle mode; this is indicted by the slow recycle mode switch

blinking. The second stage the unit is disabled and will not function until a safe operating

temperature is reached; this is indicated by the unit blinking “hot” on the displays.

GENERAL TROUBLESHOOTING

Unit will not flash:

•Flashtube is not installed properly.

•Sync cord polarity not correct (see ‘SYNC Outlet’ page 5)

Constant misfires:

•Lamphead not plugged in.

•Flash tube not installed properly

•Bad flashtube

Unit does not turn on:

•Check power cord

•Check circuit breaker

Photo Eye does not flash unit:

•Photo-eye switch is off

•Trigger flash is out of range

Modeling light will not turn on.

•Modeling lamp is not installed properly

•Modeling lamp is broken

•Modeling lamp is turned off. Check the control panel switches (see page 5)

Note: If you are still experiencing trouble after checking the above general troubleshooting

guidelines contact Photo Control Customer Service or your Norman Service Center.

SPECIFICATIONS

Power: D12: 1200 W-S / D24: 2400 W-S

Recycle Time: D12: 2.0 sec / D24: 2.6 sec.

Power Control: Full to -5 F-Stops

Modeling Lamp Control: Off, Ratio, Full, Trim

Trigger: Built-in Photo-eye, ¼” Sync Jack, Test Button

PocketWizard built-in models D12R and D24R

Supply Voltage: 105-125 VAC, 60Hz, 15A

Consumption: 15A

Voltage Stabilization: +/- 1%

Overload Protection: 15A Circuit Breaker

Weight: D12: 12.26 pounds / D24: 18.18 pounds

Sync Voltage: 6 VDC

Manufactured by Photo Control Corporation

www.photo-control.com

Email: [email protected]

4800 Quebec Avenue North, Minneapolis, MN 55428

(763) 537-3601 Voice, (763) 537-2852 Fax

(Pub. No. 332-035A)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Norman Alimentation

Norman

Norman P24/24 Manuel utilisateur

Norman

Norman BP320 Manuel utilisateur

Manuels Alimentation populaires d'autres marques

Monacor

Monacor PS-12CCD Manuel utilisateur

VOLTIMA

VOLTIMA MagicBox 15 Manuel utilisateur

Agilent Technologies

Agilent Technologies 6032A Manuel utilisateur

Miller

Miller Auto Deltaweld 452 Manuel utilisateur

BCP

BCP PUOUBK Feuille d'instructions

HC 2210 Manuel utilisateur

Puls

Puls CT5.241 Manuel utilisateur

OCZ

OCZ ZX1250W Manuel utilisateur

iseg

iseg ECH 238 Manuel utilisateur

Power

Power XXL A Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 6631B Manuel utilisateur

Renogy

Renogy PHOENIX 300 Manuel utilisateur

HP 6200B Manuel de service

Epson

Epson Stylus Scan 2500 Manuel d'utilisation

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manuel utilisateur

Puls

Puls MiniLine ML50.100 Manuel utilisateur

Puls

Puls AS-Interface SLA4.100 Manuel utilisateur

Kenwood

Kenwood PS-60 Manuel utilisateur
