Installation Guide
Strong authentication for Cisco ASA
5500 Clientless SSL VPN and Cisco
VPN Client Solutions with
One Time Password Server
The complete installation guide for securing the authentication to your Cisco ASA
5500 solution with Nordic Edge One Time Password Server, delivering two-factor
authentication via SMS to your mobile phone. For both clientless SSL VPN and Cisco
VPN Client.
Strong Authentication for Cisco ASA 5500 Solutions with Nordic Edge™One Time Password Server Page 1of 49
Installation Guide
Content
1SUMMARY ...................................................................................................................................... 4
2PREREQUISITES ........................................................................................................................... 4
3IMPORTANT INFORMATION REGARDING COMMUNICATION................................................. 4
4GETTING STARTED....................................................................................................................... 5
4.1 1.1 Download the software ....................................................................................................... 5
4.2 Register and download the software....................................................................................... 6
5INSTALLATION .............................................................................................................................. 9
5.1 Start the installation .................................................................................................................. 9
5.2 Installing license...................................................................................................................... 11
6CONFIGURING THE ONE TIME PASSWORD SERVER ............................................................ 15
6.1 Start the OTP Configuration................................................................................................... 15
6.2 Server page .............................................................................................................................. 16
6.3 Plugin manager page .............................................................................................................. 17
6.3.1 Nordic Edge SMS Plugin................................................................................................... 18
6.4 Nordic Edge SMS Page ........................................................................................................... 19
6.5 Radius & Client page............................................................................................................... 20
6.5.1 Enable Radius ................................................................................................................... 21
6.6 Add client ................................................................................................................................. 22
6.7 Configure LDAP....................................................................................................................... 23
6.7.1 Test LDAP Connection...................................................................................................... 23
6.7.2 Selecting Search Base DN................................................................................................ 25
6.7.3 Select Search filter ............................................................................................................ 27
6.7.4 Test LDAP Authentication ................................................................................................. 29
7START THE ONE TIME PASSWORD SERVER.......................................................................... 31
8ADD MOBILE PHONE NUMBER WITH MICROSOFT MANAGEMENT CONSOLE.................. 32
9CONFIGURING ASA5500 FOR SSL VPN AUTHENTICATION WITH NORDIC EDGE ONE TIME
PASSWORD SERVER.......................................................................................................................... 33
9.1 Start ASA device manager...................................................................................................... 33
www.nordicedge.se Copyright, 2008, Nordic Edge AB Page 2of 49
Installation Guide
9.2 Browse to Configuration, Remote Access VPN, AAA/Local Users, AAA Server Groups
and click Add. ...................................................................................................................................... 33
9.3 Name Server Group OTPserver, choose protocol RADIUS ................................................ 34
9.4 Add new radius server to the RADIUS group ....................................................................... 35
9.5 Configure Radius Server : Interface name, IP address to OTPserver and the pre-shared
key between the One Time Password server and Cisco ASA5500. ............................................... 35
9.6 Create a ”test” connection profile (in case you want to test this for certain users only).
37
9.6.1 Browse to Configuration/Remote Access/Clientless SSL VPN Access/Connection Profiles
and click Add..................................................................................................................................... 37
9.6.2 Specify Connection Profile Name...................................................................................... 38
9.6.3 Specify AAA Server Group = OTPserver ......................................................................... 38
9.6.4 Edit Connection Profile Clientless SSL VPN Settings....................................................... 40
9.6.5 Add Alias if user should be able to select authentication method by drop-down-list ........ 40
9.6.6 Edit Connection Profile Clientless SSL VPN Settings....................................................... 41
9.6.7 Add Group URL if user should be able to select authentication by specifying URL ......... 41
9.6.8 If user should be allowed to select authentication method by drop-down-list,.................. 41
9.6.9 select this item................................................................................................................... 41
10 CONFIGURING ASA5500 FOR CISCO VPN CLIENT AUTHENTICATION WITH NORDIC
EDGE OTP SERVER ............................................................................................................................ 45
10.1 Add a new ( or Edit an existing) Cisco VPN Client Connection Profile to use the
OTPserver............................................................................................................................................. 45
10.2 At the Cisco VPN Client, create an entry with correct name and password ..................... 46
Name must match the connection profile name at previous slide......................................... 46
Password must match the pre-shared key in ASA5500. ......................................................... 46
(Note : This can be distributed via MSI installation)........................................................................ 46
11 START TESTING ...................................................................................................................... 47
11.1 Enter your Userid and password as usual............................................................................ 47
11.2 You will receive a one-time password to your mobile phone within a couple of seconds.
47
11.3 Enter your one time password and click on “OK”............................................................... 48
12 PURCHASE............................................................................................................................... 49
13 TECHNICAL QUESTIONS........................................................................................................ 49
www.nordicedge.se Copyright, 2008, Nordic Edge AB Page 3of 49
Installation Guide
1 Summary
This is the complete installation guide for securing the authentication to your Cisco ASA 5500 solution
with Nordic Edge One Time Password Server, delivering two-factor authentication via SMS to your
mobile phone. For both clientless SSL VPN and Cisco VPN Client. You will be able to test the product
with your existing Cisco ASA 500 and LDAP user database, without making any changes that affect
existing users. The guide will also allow you to make the complete installation effeciently, using a
maximum of 1 hour. Nordic Edge provides several methods for delivering one time passwords, like e-
mail, tokens, mobile clients, prefetch etc. - however in this test we are only going to use SMS.
This is a step-by-step guide that covers the entire installation from A to Z. It is based on the scenario
that you are running your Cisco 5500 solution against Active Directory, and that you install the One
Time Password Server on a Windows Server. The One Time Password Server is platform
independent and works with all other LDAP user databases, like eDirectory, Sun One, Open LDAP
etc. If you are not running Active Directory or Windows and if you have any questions regarding the
slight differences in the installation process, you are most welcome to contact us at
support@nordicedge.se and we will take you through the entire process.
2 Prerequisites
You will need to have a server available, for example a VMware virtual machine with Windows Server
2003 installed with Ethernet in bridge mode. The server needs to have an ip-address configured and
must also be able to reach your DNS-servers, your Cisco 5500 ASA solution and the Active Directory.
Since the software is quite small and easy to remove, you can also use any existing server in your
network.
3 Important information regarding communication
The One Time Password Server is a software that you can place on any server in your internal
network or DMZ.
- The One Time Password Server needs to be able to communicate (Outbound traffic) with your
LDAP or JDBC User Database. Default port for LDAP and Secure LDAP is TCP port 389 / 636.
- The Integration Module needs to be able to communicate (Outbound traffic) with the One Time
Password Server on TCP port 3100. Or Radius with UDP port 1812 or 1645 (Outbound traffic)
- If you want to use the Nordic Edge SMS Gateway, the One Time Password Server needs to be
able to communicate (Outbound traffic) with otp.nordicedge.net and otp.nordicedge.se with HTTPS on
TCP port 443.
In this test-scenario you will want to communicate with RADIUS port 1812 or 1645 and use
our Nordic Edge SMS Gateway.
www.nordicedge.se Copyright, 2008, Nordic Edge AB Page 4of 49
Installation Guide
4 Getting started
4.1 1.1 Download the software
Go to www.nordicedge.se and click on Download
www.nordicedge.se Copyright, 2008, Nordic Edge AB Page 5of 49
Installation Guide
4.2 Register and download the software
www.nordicedge.se Copyright, 2008, Nordic Edge AB Page 6of 49
Installation Guide
You will receive a link for downloading the software. A 30 days evaluation license will be sent via e-mail
when you download the software.
Download the version with JAVA included.
www.nordicedge.se Copyright, 2008, Nordic Edge AB Page 7of 49
Installation Guide
www.nordicedge.se Copyright, 2008, Nordic Edge AB Page 8of 49
Installation Guide
5 Installation
5.1 Start the installation
Start the installation on the server where you want to install the One Time Password Server
www.nordicedge.se Copyright, 2008, Nordic Edge AB Page 9of 49
Installation Guide
www.nordicedge.se Copyright, 2008, Nordic Edge AB Page 10 of 49
