Norcold DE-461 Manuel utilisateur

PARTS LIST

PART NO.619748

NORCOLD 10/20/2002

EV461

DE461

EV461

DE461/EV461 PARTS LIST - PAGE 2

DOOR - UPPER (FREEZER) - DE461/DE461T/EV461

NO. PART # DESCRIPTION DE461 EV461

1 61567830 DOOR GASKET-UPPER/GRAY X X

2 61631330 HINGE PLATE-BLACK/RH TOP/LH BOTTOM/PLASTIC X X

3 61689938 DOOR LINER ASSY-FOAMED/UPPER/BLACK/WHITE X X

NS 61592930 PANEL HOLDER-BLACK/UPPER DOOR (NOT SHOWN) X X

4 61743638 DOOR HANDLE ASSY-UPPER/BLACK X X

5 61593830 END CAP-BLACK/STOP CATCH X X

6 61743622 DOOR HANDLE WITH DECAL-UPPER X X

7 61593730 END CAP-BLACK/SPRING CATCH X X

NS 61558822 SPRING-DOOR HANDLE (NOT SHOWN) X X

8 61631430 HINGE PLATE-BLACK/LH TOP/RH BOTTOM/PLASTIC X X

9 61580525 JUICE RACK-WHITE XX

10 61564025 BIN-DOOR SHELF/WHITE XX

DE461/EV461 PARTS LIST - PAGE 3

DOOR - LOWER (FRESH FOOD) - DE461/DE461T/EV461

NO. PART # DESCRIPTION DE461 EV461

1 61567930 DOOR GASKET-LOWER/GRAY X X

2 61631330 HINGE PLATE-BLACK/RH TOP/LH BOTTOM/PLASTIC X X

3 61690038 DOOR LINER ASSY-FOAMED/LOWER X X

NS 61593030 PANEL HOLDER-BLACK/LOWER DOOR (NOT SHOWN) X X

4 61743738 DOOR HANDLE ASSY-LOWER/BLACK X X

5 61593830 END CAP-BLACK/STOP CATCH X X

6 61743722 DOOR HANDLE WITH DECAL-LOWER X X

7 61593730 END CAP-BLACK/SPRING CATCH X X

NS 61558822 SPRING-DOOR HANDLE (NOT SHOWN) X X

8 61631430 HINGE PLATE-BLACK/LH TOP/RH BOTTOM/PLASTIC X X

9 61579425 BIN-MILK/WHITE (2 PER DOOR) 2 2

10 61564025 BIN-DOOR SHELF/WHITE (5 PER DOOR) 5 5

DE461/EV461 PARTS LIST - PAGE 4

CABINET ASSEMBLY - FRONT VIEW - DE461/DE461T/EV461

DE461/EV461 PARTS LIST - PAGE 5

CABINET ASSEMBLY - FRONT VIEW - DE461/DE461T/EV461

NO. PART # DESCRIPTION DE461 EV461

1 61578522 DOOR LATCH XX

2 61630422 ICE CUBE TRAY-PLASTIC (2 PER REFRIGERATOR) 2 2

3 61580830 HINGE BRACKET-RH TOP/LH BTM/BLACK X X

4 61578130 HINGE PIN-BLACK/MALE XX

NS 61580630 HINGE PIN-BLACK/TOP/BOTTOM HINGE/FEM ALE (NOT SHOWN) X X

5 61566730 HINGE PIN SHAFT-BLACK/AT CENTER HINGE X X

6 61580722 HINGE BUSHING-AT CENTER HINGE X X

7 61566530 HINGE BRACKET-BLACK/CENTER HINGE X X

8 618056 SHELF-WIRE/WHITE/FLIPPER X X

NS 618065 CAP-CLEAR/FOR FLIPPER SHELF (NOT SHOWN) X X

9 618052 SHELF-WIRE/MIDDLE XX

10 618055 SHELF-WIRE/CUT OUT XX

NS 61580222 RETAINER-WIRE SHELF (NOT SHOWN) X X

11 61564122 CRISPER COVER-GLASS SHELF X X

NS 61580322 RETAINER-GLASS SHELF (NOT SHOWN) X X

12 61571325 CRISPER-WHITE XX

13 61580930 HINGE BRACKET-LH TOP/RH BTM/BLACK X X

14 61622130 FRONT COVER-BLACK/REPLACEABLE BOTTOM TRIM X X

15 620377 THERMOSTAT-160114410 XX

160206700 KNOB-THERMOSTAT/61729422 X X

16 620502 COVER PLATE-THERMOSTAT X X

17 61686722 COVER PLATE-FRONT/BLACK X X

18 61772122 BOTTOM PAN-SUPPORT ASSY X X

19 61691310 DRIP TRAY XX

NS 61706522 HOLE PLUG-FOR DRIP TRAY (NOT SHOWN) X X

NS 61693622 RETAINING CLIP-DRIP TRAY (NOT SHOWN) X X

NS 61579730 CAP-SNAP ON/BLACK/INSTALLATION HOLES (NOT SHOWN) X X

DE461/EV461 PARTS LIST - PAGE 6

CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DE461/DE461T/EV461

NO. PART # DESCRIPTION DE461 EV461

1 620541 POWER SUPPLY-DE461/160115500 X

620544 POWER SUPPLY-EV461/160115510 X

NS 160928900 FAN ONLY-50 CYCLE/40 WATT (NOT SHOWN) X X

NS 160929310 FAN ONLY-50 CYCLE/LARGE (NOT SHOWN) X X

2 61691522 PANEL COVER-UPPER BACK X X

3 61691938 FOAM PLUG ASSY XX

4 617844 COOLING UNIT-DE461/EV561/161008410 X X

161008430 COOLING UNIT-DE461T T

NS 620648 THERMISTER-DE461/EV461/605505440 (NOT SHOWN) X X

NS 190264730 CORD ASSY-COMPRESSOR CORD (NOT SHOWN) X X

NS 191238400 CORD ASSY-THERMOSTAT TO POWER SUPPLY/600 MM (NOT SHOWN) X X

NS 192116605 CORD WITH TERMINAL-GROUND CORD (NOT SHOWN) X X

NS 601058020 COUPLER ASSY-FANS TO POWER SUPPLY (NOT SHOWN) X X
