OPERATOR’S MANUAL

TORQUE WRENCH CALIBRATOR (TWC)

TWC 400 & TWC 1500 - Manual

Part Number 34446 | Issue 2 | Original Instructions (English)

NORBAR TORQUE TOOLS LTD

Wildmere Road, Banbury,

Oxfordshire, OX16 3JU

UNITED KINGDOM

Tel + 44 (0)1295 270333

Email enquiry@norbar.com

NORBAR TORQUE TOOLS

45–47 Raglan Avenue, Edwardstown,

SA 5039

AUSTRALIA

Tel + 61 (0)8 8292 9777

Email enquiry@norbar.com.au

NORBAR TORQUE TOOLS INC

36400 Biltmore Place, Willoughby,

Ohio, 44094

USA

Tel + 1 866 667 2279

Email inquiry@norbar.us

NORBAR TORQUE TOOLS PTE LTD

194 Pandan Loop

#07-20 Pantech Business Hub

SINGAPORE 128383

Tel + 65 6841 1371

Email enquires@norbar.sg

NORBAR TORQUE TOOLS (SHANGHAI) LTD

91 Building-7F, No.1122 North Qinzhou Rd,

Xuhui District, Shanghai

CHINA 201103

Tel + 86 21 6145 0368

Email sales@norbar.com.cn

NORBAR TORQUE TOOLS INDIA PVT. LTD

Plot No A-168, Khairne Industrial Area,

Thane Belapur Road, Mahape,

Navi Mumbai – 400 709

INDIA

Tel + 91 22 2778 8480

Email enquiry@norbar.in

www.norbar.com

CONTENTS

Safety 1

Introduction 2

Parts Included 2

Accessories 2

Features and Functions 3

Specifications 4

Installation 5

Location 5

Counter Balance Reaction Post Installation 5

Operating Instructions 8

Locating a Torque Wrench 8

Gearbox and Drive Wheels 10

Handle Use 10

Maintenance 11

Greasing Procedure 11

Accessory Instructions 13

Static Transducer Support Kit – 60318 13

Square Drive Adaptors – 29214, 29215, 29216, 29217 13

Short Length Reaction Plate – 60319 14

Hexagon Adaptor Kit – 60324 15

FMT 25 Adaptor Kit – 60327 15

FMT Quick Release Kit – 60322 16

Pro-Test and Static Torque Block Adaptor Kit – 60323 16

TWC Angle Offset Plate Kit – 60330 16

SAFETY

• The TWC is heavy. Take care when installing.

• Ensure the operating area is capable of taking the weight of the TWC.

• Trapping hazard - Keep hands and loose clothing away from the torque wrench during use.

• To avoid damage to the torque wrench under test do not exceed the wrenches set torque value.

• To avoid damage to the transducer do not exceed the maximum capacity.

• Never exceed the maximum torque capacity of the TWC.

• Do not operate without a torque measurement system connected and working.

• The TWC is designed for testing torque tools, do not use for other purposes.

INTRODUCTION

This manual covers items 60331 & 60332 only.

Parts Included

Part Number

Quantity

TWC 400 / 1500

60331 / 60332

TWC Counter Balance Reaction Post Assembly

62330

Operators Manual

34446

Maintenance Grease Kit

60325

Accessories

Accessories Available

Part Number

Norbar torque measurement system

Consult Norbar

Static Transducer Support Kit

60318

Short Length Reaction Plate

60319

FMT Quick Release Kit

60322

FMT 25 Adaptor Kit

60327

Pro-Test / Static Torque Block Adaptor Kit

60323

Hexagon Adaptor Kit

60324

TWC Angle Offset Plate Kit

60330

Square Drive adaptor 1” M to ¾” F

29214

Square Drive adaptor 1” M to ½” F

29215

Square Drive adaptor 1” M to ⅜” F

29216

Square Drive adaptor 1” M to ¼” F

29217

Maintenance Grease Kit

60325

FEATURES AND FUNCTIONS

• Can produce certification to ISO 6789-2:2017 when used with T-Box XL™ software version 3.0.0.X and

TDMS version 4.0.X.

• Counter balance reaction is designed to support the weight of the wrench so that the weight does not

become a parasitic force within the calibration system. The floating nature of the support means that the

wrench is able to find its own natural level rather than being constrained as in many other loading

devices. Any such constraint will be a parasitic force within the system. Patents apply.

• Two speed gearbox designed for a sufficient balance of speed and control by allowing for both fast

loading of the torque wrench and a slower more precise loading.

• Lightweight alloy construction ensures the TWC is easily transported, making it suited for mobile

laboratory applications.

• Rotating transducer design ensures that the load is applied 90° to the torque wrench handle. The benefit

of this precise alignment is that forces are applied squarely to the load point of the handle.

• Compatible transducers include Flange Mounted Transducers, Static Transducers (when using part

number: 60318) and Pro-Test (when using part number: 60323)

FIGURE 1 – Features

Twin speed gearbox drive wheel

Guide Rail

Counter Balance Reaction

Post Assembly

Transducer

mounting platform

SPECIFICATIONS

Specification

TWC 400

TWC 1500

Maximum Torque:

400 N·m / 295 lbf·ft

1500 N∙m / 1100 lbf∙ft

Wrench Length

(Torque Radius):

Minimum

135mm

Maximum

750mm

1500mm

Wrench Orientation:

Horizontal

Calibration Direction:

Clockwise and Anti-Clockwise

Operating Temperature:

0°C - 50°C

Dimensions (Maximum):

620

330

395

487

1010

1760

Weight:

35 kg

40 kg

INSTALLATION

WARNING: THE TWC WEIGHS UP TO 40KG. ALWAYS USE TWO PEOPLE WHEN

LIFTING THE TWC.

Location

FIGURE 2 – Locating the TWC

1) Ensure location can cope with weight of loader.

2) Locate the TWC on a level surface at a comfortable working height.

3) Secure the feet to the bench.

Counter Balance Reaction Post Installation

Your TWC has been delivered with the reaction counter balance wheel assembly unattached to the reaction

assembly. This has been done to prevent damage to this assembly during transit.

FIGURE 3 – Disassembled Counter Balance Reaction Post Assembly

Place the counter balance wheel onto the top plate of the reaction assembly.

FIGURE 4 – Lining up the Counter Balance Reaction Wheel

Attach the counter balance wheel assembly with the two M4 socket cap screws from the underside of the top

plate of the reaction assembly. Tighten to 1 N·m.

FIGURE 5 – Attaching the Counter Balance Reaction Wheel

Assemble the weight carriage over the balance wheel.

FIGURE 6 – Counter Balance Reaction Assembly

Slide the “Counter Balance Reaction Post Assembly” on to the reaction rail.

FIGURE 7 – Sliding the Counter Balance Reaction Assembly onto the Reaction Rail

Set the locking lever to engage positively when applied. This is done by pulling the lever towards you whilst

at the same time winding in the screw with an appropriate screwdriver. When at top dead centre, the lever

should start to engage to lock the reaction post’s position. Turn the lever to the right and you should start to

feel some resistance as the lock is engaged. Before continuing check the reaction post assembly is securely

fixed in position.

FIGURE 8 – Adjusting and Setting the Locking Lever

OPERATING INSTRUCTIONS

Locating a Torque Wrench

Select the correct capacity transducer and secure to the platform with socket cap screws.

FIGURE 9 – Attaching a Transducer

Ensure the transducer has been fitted with the correct adaptor and place the torque wrench drive into the

transducer. Ensure that the torque wrench drive is fully engaged (see figure 10).

FIGURE 10 – Attaching a Torque Wrench

Set the reaction post position on the reaction arm so it is in the middle of the torque wrench handle (see figure 11).

FIGURE 11 – Locating a Torque Wrench
