Welcome

This guide tells you how to operate the Nokia

A032 Wireless LAN Access Point, and provides

information about configuration options,

management and performance tuning.

How to use this guide

You should first have read and followed the

instructions in the

Getting Started

guide.

The material in this guide is for more advanced

users and system managers who want to

customize and fine-tune the Nokia A032’s

performance.

•

Using the Web manager

– This describes the

web browser-based interface for

configuring and monitoring the Nokia

A032.

•

Command line interface

– This describes

other ways of configuring the Nokia A032.

•

NID naming and security

– How to use MAC

addresses to control network access.

•

Using TFTP

– How to upload and download

configuration files and firmware updates.

•

SNMP manager

– Explains the capabilities

of the Nokia A032 SNMP agent.

•

Appendices

– These provide more detailed

material, such as WEP security measures,

using wireless repeaters and bridges,

upgrading instructions and troubleshooting

tips.

A032-Adv.book Page iii Monday, November 13, 2000 10:47 AM

Nokia A032 Advanced User Guide

Conventions used in this guide

Internet gateway information

Information relating to use of the Nokia A032

as an Internet access device, either by dial-up

or NAT, is shown with a bar on the right-hand

side of the page:

Such information includes Internet settings and

NAT addressing and firewalls.

Notes

You’ll find tips or other useful facts in side

notes throughout the manual.

Pay particular attention to notes that start with

Note

WARNING

Text conventions

The following conventions are used throughout

this manual:

•

courier

is used for file names, or to

denote text that appears on your screen.

•

courier bold

is used to denote text that

you should type in.

• new terms are shown in

italic

text the first

time they appear.

•

bold

text denotes the name of a physical

button or LED on the

Nokia A032

unit (e.g.

the

alert

LED) or a button on screen that you

need to click (e.g. “click

Restart

”).

Internet Gateway

Your Nokia A032 can

transfer information

between a wired LAN

and a wireless LAN.

A032-Adv.book Page iv Monday, November 13, 2000 10:47 AM

Contents

Table of contents

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii

Using the Web manager 1

Displaying the Access Point home page . . . . . . . . . . . . . . . . 2

Status monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Web-based setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Command line interface 67

Accessing the command line manager (CLM) . . . . . . . . . . . 67

Using the CLM ‘set’ command . . . . . . . . . . . . . . . . . . . . . . 70

CLM commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

NID naming and security 97

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Using NID names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Using TFTP 103

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Sending and fetching files . . . . . . . . . . . . . . . . . . . . . . . . 105

TFTP-accessible data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

SNMP manager 117

MIB Summary – RFC1213 – MIB II (1.3.6.1.2…) . . . . . . . . 118

SNMP configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Appendix A – Data encryption and

security 127

General security overview . . . . . . . . . . . . . . . . . . . . . . . . 127

WEP security overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

A032-Adv.book Page v Monday, November 13, 2000 10:47 AM

Nokia A032 Advanced User Guide

Appendix B – Wireless bridges and

repeaters 145

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Configuring for wireless bridge/repeater operation . . . . . 151

Associated CLM commands . . . . . . . . . . . . . . . . . . . . . . . 156

Setting up bridges using WEPGen . . . . . . . . . . . . . . . . . . 156

Appendix C – Factory defaults 157

Appendix D – Utilities CD-ROM 161

Installing the Nokia A032 utilities . . . . . . . . . . . . . . . . . . 161

Appendix E – Using the WEPGen utility 163

Installing the WEPGen utility . . . . . . . . . . . . . . . . . . . . . . 163

Running the WEPGen utility . . . . . . . . . . . . . . . . . . . . . . 164

Appendix F – Troubleshooting 175

Renewing client IP information . . . . . . . . . . . . . . . . . . . . 175

Startup problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Troubleshooting dial-up connections . . . . . . . . . . . . . . . . 185

Resetting factory defaults . . . . . . . . . . . . . . . . . . . . . . . . . 190

Appendix G – Upgrading 191

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Upgrading the Nokia A032 . . . . . . . . . . . . . . . . . . . . . . . . 193

Appendix H – NAT setup 197

Setting the NAT port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

Setting NAT holes – providing external access . . . . . . . . 201

Index 203

A032-Adv.book Page vi Monday, November 13, 2000 10:47 AM

Using the Web manager

1. Using the Web manager

The

Getting Started

guide explained how to

perform initial configuration by putting the

Nokia A032 into Learn mode.

Now you can access

all

of the Nokia A032’s

setup pages from any station (wired or

wireless), using a standard browser interface,

while the Nokia A032 is in Normal mode.

This is the easiest way of configuring your

Nokia A032. The other methods available are

described in

Command line interface

page 67,

Using TFTP

on page 103 and

Appendix G – Upgrading

The browser interface also provides

comprehensive status monitoring capabilities.

•

Displaying the Access Point home page

below, explains how to access the browser-

based setup and configuration pages.

•

Status monitoring

on page 5 explains how

to monitor wireless link statistics, modem

and LAN activity, for example, using the

browser interface.

•

Web-based setup

on page 32 gives a

detailed description of every parameter

available for customizing the A032.

In some cases, you can

only configure the

Nokia A032 from a

nominated station.

See Management

security options on

page 45.

A032-Adv.book Page 1 Monday, November 13, 2000 10:47 AM

Nokia A032 Advanced User Guide

Displaying the Access Point home page

To display the Access Point home page:

If necessary, start up the Nokia A032 in

Normal mode.

From any wired or wireless LAN station,

start a web browser (such as Internet

Explorer).

Point the browser to the IP address of the

Access Point. For example:

http://192.168.0.1

You’ll see the Nokia A032 home page:

From here, you can access all of the Nokia

A032’s Status and Setup pages, as described

below.

You can return to this home page at any time

during status monitoring or configuration by

clicking

Home

in the lefthand frame.

A032-Adv.book Page 2 Monday, November 13, 2000 10:47 AM

Using the Web manager

Home page features

The Home page gives a graphical indication of

the status of the Nokia A032 and allows quick

navigation to other status screens. The

components shown here will depend on your

setup.

Menu bar

Down the lefthand side of the Home page

there’s a menu bar with the following links:

•

Home

– Displays the Home page.

•

Status

– Displays a brief summary of the

A032’s current status (see

Main status

screen

on page 8).

•

Setup

– Allows you to enter the web-based

configuration manager (see

Displaying

Setup pages

on page 32 for more

information).

Graphical cues and links

The image of the A032 on the Home page gives

you a quick idea of the status of the various

interfaces. You can click different parts of the

image to view certain status pages.

See

Status summary and graphical links

page 6 for more details.

A032-Adv.book Page 3 Monday, November 13, 2000 10:47 AM

Nokia A032 Advanced User Guide

Internet link action buttons

When dial-up Internet access is enabled, three

buttons on the Home page give you manual

control over dialing the modem:

•

Connect

– If the Internet link is down, click

this to make a connection.

•

Disconnect (Abort)

–

If the Internet link is up,

click here to disconnect immediately. While

the unit is dialing or in the process of

connecting the button will display

Abort

but

the result is the same.

•

Disable (Enable)

–

Sometimes you need to

prevent the unit from attempting to make

automatic connections to the Internet. You

can disable automatic dialing by entering

the management password and clicking

Disable

. After the Internet connection has

been disabled the unit will no longer

attempt to dial out when users try to access

the Internet. However, it will still be

possible to force a connection by clicking

Connect

While automatic dialing is disabled the

button text reads

Enable

; enter the password

and click here to reenable.

Internet Gateway

A032-Adv.book Page 4 Monday, November 13, 2000 10:47 AM
