Nokia X2 Manuel utilisateur
Quick Guide
Nokia X2
Issue 1 EN RM-1014
Psst...
This guide isn't all there is...
There's a user guide in your phone – it's always
with you, available when needed. On the start
screen, swipe left, and tap .
For the online user guide, even more info, and
troubleshooting help, go to www.nokia.com/
support.
The instructions in this user guide are based on
the latest available software version. If your
device has not been updated to the latest
available software, there may be differences in
the availability and functionality of some
features.
For info about writing text on your phone, see the
user guide in your phone or the online user guide.
For info on Microsoft Mobile Service terms and
Privacy policy, go to www.nokia.com/privacy.
Contents
For your safety 3
Keys and parts 5
Insert the SIM card, battery, and memory
card 7
Charge the battery 9
2
Copy contacts from your old phone 10
Switch between views 11
Take better photos with Smart mode 12
Update your phone software 13
Find your model number and serial
number (IMEI) 14
Product and safety information 15
For your safety
Read these simple guidelines. Not following them may be dangerous
or illegal. For further info, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or
when it may cause interference or danger, for example, in
aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which
could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved
by Microsoft Mobile for use with this device. Do not connect
incompatible products.
3
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The device screen is made of glass. This glass can break if the
device is dropped on a hard surface or receives a substantial
impact. If the glass breaks, do not touch the glass parts of the device
or attempt to remove the broken glass from the device. Stop using
the device until the glass is replaced by qualified service personnel.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when holding
your device near your ear while the loudspeaker is in use.
SAR
This device meets RF exposure guidelines when used either in
the normal use position against the ear or when positioned at
least 1.5 centimetres (5/8 inch) away from the body. The specific
maximum SAR values can be found in the Certification Information
(SAR) section of this user guide. For more info, go to www.sar-
tick.com.
When a carry case, belt clip or other form of device holder is used for
body-worn operation, it should not contain metal and should provide
at least the above-stated separation distance from the body. Note
that mobile devices may be transmitting even if you are not making
a voice call.
4
Keys and parts
Explore the keys and parts of your new phone.
1Micro-USBconnector
2Earpiece
3 Audio connector (3.5 mm AHJ)
4Volumekeys
5 Lock/Power key
6Homekey
7 Back key
8Microphone
9Touchscreen
5
10 Camera flash
11 Antenna area
12 Loudspeaker
13 Camera lens. Before using the camera,
remove the protective tape from the lens.
Avoid touching the antenna area while the
antenna is in use. Contact with antennas affects
the communication quality and may reduce
battery life due to higher power level during
operation.
Do not connect products that create an output
signal, as this may damage the device. Do not
connect any voltage source to the audio
connector. If you connect an external device or
headset, other than those approved for use with
this device, to the audio connector, pay special
attention to volume levels.
Some of the accessories mentioned in this user
guide, such as charger, headset, or data cable,
may be sold separately.
Parts of the device are magnetic. Metallic
materials may be attracted to the device. Do not
place credit cards or other magnetic storage
media near the device, because info stored on
them may be erased.
Keep a safe distance when using the flash. Do not
use the flash on people or animals at close range.
Do not cover the flash while taking a photo.
6
Insert the SIM card, battery, and
memory card
Learn how to get your phone ready.
Important: Your device uses a micro-SIM
card, also known as a mini-UICC SIM card.
Use of incompatible SIM cards, or use of SIM
card adapters, may damage the card or the
device, and may corrupt data stored on the
card.
Use only compatible memory cards approved for
use with this device. Incompatible cards may
damage the card and the device and corrupt data
stored on the card.
Note: Switch the device off and disconnect
the charger and any other device before
removing any covers. Avoid touching
electronic components while changing any
covers. Always store and use the device with
any covers attached.
1. Hold your phone by the bottom corners in one
hand, and with the thumb of your other hand,
press the back cover, and remove it.
7
2. If the battery is in the phone, lift it out.
3. Push the SIM into the SIM1 slot, contact area
face down.
To remove the SIM, pull the card out.
4. Push the memory card into the memory card
slot with the contact area face down.
To remove the memory card, pull it out.
8
Important: Do not remove the memory card
when an app is using it. Doing so may
damage the memory card and the device
and corrupt data stored on the card.
5. Line up the battery contacts, and put the
battery in.
6. Replace the back cover.
7. To switch on, press and hold the power key.
Your device has a maximum charging voltage of
4.35V. Use only batteries designed for a 4.35V
charging voltage and approved by Microsoft
Mobile. You can confirm the proper battery
charging voltage from the battery label. Make
sure that the battery has a maximum charging
voltage of 4.35V, and/or a nominal charging
voltage of 3.8V.
Charge the battery
Your battery has been partially charged at the
factory, but you may need to recharge it before
you can use your phone.
1. Plug the charger into a wall outlet.
2. Connect the charger to the phone. When done,
unplug the charger from the phone, then from the
wall outlet.
9
If the battery is completely discharged, it may
take several minutes before the charging
indicator is displayed or before any calls can be
made.
Tip: You can use USB charging when a wall
outlet is not available. Data can be
transferred while charging the device. The
efficiency of USB charging power varies
significantly, and it may take a long time for
charging to start and the device to start
functioning.
Make sure your computer is switched on.
Copy contacts from your old phone
Easily get your contacts to your new phone.
To copy contacts from your old phone using your
SIM card, you must have copied them from your
old phone to the SIM and placed the SIM in your
new phone.
1. On the start screen, swipe left, and tap .
2. Swipe up from the bottom of the screen, and
tap Import/export > Import from SIM.
10
