Nokia N95 8GB Fiche technique
Get Started
Nokia N95 8GB
Copyright © 2007 Nokia. All rights reserved.
Copyright © 2007 Nokia. All rights reserved.
Copyright © 2007 Nokia. All rights reserved.
contents
Support 1
Keys and parts 2
Basic Phone Set-up 5
Insert the (U)SIM card and battery 5
Switch the device on 6
Charge the battery 7
Keypad lock (keyguard) 7
Transfer content from another Device 7
Headset 8
Shortcuts 9
Personalisation 9
Mobile Broadband 10
HSDPA (High-Speed Downlink Packet Access) 10
Wireless LAN 10
8GB of Entertainment 11
Nokia Video Center 11
Music Experience 12
Store more photos and videos 13
•
•
•
•
•
•
•
•
•
•
•
•
•
Copyright © 2007 Nokia. All rights reserved.
1
support
Model number: Nokia N95-2.
Hereinafter referred to as Nokia N95 8GB.
Help
The help function provides instructions when using the device. To access it from an application, select Options > Help.
User guide
Refer to the user guide for other important information about your device.
Online
Check www.nokia-asia.com/N958GB/support or your local Nokia web site for the latest version of the user guide, additional
information, downloads, and services related to your Nokia product.
Copyright © 2007 Nokia. All rights reserved. 2
Working mode
keys and parts
Selection keys to select
commands and access Options
Menu key
Caution: Leaving applications running
in background increases battery
consumption and reduces battery life.
Send key
Edit key
Scroll key
Internet key
Charger connector
Power
Secondary camera with
352 x 288 resolution
Light sensor
Multimedia key
End Key
Clear key
Alphanumeric keypad
Mini USB connector
Copyright © 2007 Nokia. All rights reserved.
3
keys and parts
Media mode
Media keys to control music and videos
Next key
Play/pause key
Stop key
Previous key
Infrared (IR) port
Nokia 3.5mm AV
connector
Stereo speakers
with 3D sound effects
Copyright © 2007 Nokia. All rights reserved. 4
keys and parts
Closed mode (Back)
Camera flash
Review key
To view the last stored
image / video
Tip: Press twice to open Gallery.
2-stage capture key
for auto-focus, still image
capture and video recording
5 megapixel camera
with Carl Zeiss
Optics
for image and video
capture
Zoom / volume key
Stereo speakers
with 3D sound
effects
Copyright © 2007 Nokia. All rights reserved.
5
Insert the (U)SIM card and
battery
A (U)SIM card is an enhanced version of the SIM card and is
supported by UMTS mobile devices.
Important: Keep all SIM cards out of reach of children. Switch
off device and/or disconnect charger before removing the
battery. For availability and information on using SIM card
services, contact your local mobile operator or service provider.
basic phone set-up
1With the back of the device facing
you, press the release button,
slide the cover, and lift it up.
2To release the (U)SIM card holder,
lift the holder up from the handle.
3Insert the (U)SIM card. Make sure
that the contact area on the card
is facing the connectors on the
device and the bevelled corner on
the card is facing the base of the
device.
4Close the holder, and lock it into
place.
5Insert the battery.
6Replace the cover so that the
locking catches are directed
towards their slots, and slide the
cover into place.
Copyright © 2007 Nokia. All rights reserved. 6
basic phone set-up
Switch the device on
1Press and hold .
2If the device asks for a
(U)PIN code or lock code,
enter it, and press . The
factory setting for the lock
code is 12345.
Your device has internal
antennas.
Note: As with any radio transmitting device, avoid touching an
antenna unnecessarily when the antenna is in use. For example,
avoid touching the cellular antenna during a phone call. Contact
with a transmitting or receiving antenna affects the quality of
the radio communication, may cause the device to operate at a
higher power level than otherwise needed, and may reduce the
battery life.
Cellular antenna
Bluetooth
technology/
Wireless LAN
antenna GPS
receiver
Copyright © 2007 Nokia. All rights reserved.
7
basic phone set-up
Tip: Disconnect the charger from the wall outlet when the
charger is not in use. A charger that is connected to the outlet
consumes power even when it is not connected to the device.
Charge the battery
1Connect a compatible charger to
a wall outlet.
2Connect the power cord to
the device. If the battery is
completely discharged, it may
take a while before the charging
indicator starts scrolling.
3When the battery is fully
charged, the charging indicator
stops scrolling. Disconnect the
charger from the device, then
from the wall outlet.
Keypad lock (keyguard)
When the keys are locked, is displayed.
To lock the keys, press , then .
To unlock the keys, open the 2-way slide, or press , then .
To have the keypad lock activated automatically after a time-
out or when the 2-way slide is closed, press , and select
Tools > Settings > General > Security > Phone and SIM
card.
Tip: If you want to close the 2-way slide without activating the
keypad lock, press any key after you close the slide.
When the keypad lock is on, calls may be possible to the
official emergency number programmed into your device.
Transfer content from another
Device
With the Transfer application, you can transfer content, such
as contacts, between two compatible Nokia devices using
Bluetooth connectivity or infrared. To transfer data, press ,
and select Tools > Utilities > Switch.
