Nokia N95-3 Fiche technique

Get started

Nokia N95-3

Issue 1

Keys and parts (work mode)

Model number: Nokia N95-3.

Hereinafter referred to as Nokia N95.

1Power key

2Selection keys and to select commands and access

Options

Tip! To lock or unlock the keypad, press , then .

3Menu key to access the main menu

4Call key

5Edit key to open a list of commands when you edit text

6Scroll key to move around the menus ( , , , ) and

to select items ( ).

7Numeric keypad

8Clear key

9End key

10 Multimedia key to access the multimedia menu and

open the music player

11 Light sensor

12 Secondary camera with lower resolution

Keys and parts (back)

1Charger connector

2Mini USB connector to connect to a compatible PC

3Stereo speakers with 3D sound effect

4Main camera for high resolution image capture and video

recording

5Camera flash

6Nokia AV connector 3.5 mm for compatible headsets,

headphones, and Video Connectivity cable

7Infrared (IR) window

8Memory card slot for a compatible microSD card

Keys and parts (media mode)

1Media keys under the 2-way slide

•Next key

•Play/pause key

•Stop key

•Previous key

2Zoom/volume key

3Review key to view the last stored image or video

clip

42-stage capture key for auto-focus, still image

capture, and video recording

When you open the media keys under the 2-way slide, the media

mode is activated and the display is shown in landscape

orientation.

Use the media keys to control music and video players.

To access the multimedia menu, press , or open the media

keys under the 2-way slide when the device is in the standby

mode.

To activate the main camera, press and hold the capture key. To

lock the focus on an object, press the capture key halfway down.

To take a picture, press the capture key down.

To activate the video mode, select in the active toolbar. To

shoot video, press the capture key down.

To deactivate the main camera, select Exit.

Shortcuts

•To switch between open applications, press

and hold .

Leaving applications running in the

background increases the demand on battery

power and reduces the battery life.

•To open the music player, press and hold .

•To start the camera press and hold the capture

key.

•To open Gallery, press twice.

•To call your voice mailbox (network service),

press and hold .

•To open the multimedia menu, press , or in the standby

mode, open the media keys under the 2-way slide.

•To change the profile, press , and select a profile.

•To switch between Normal and Silent profiles, press and

hold . If you have two phone lines (network service), this

action switches between the two lines.

•To open the last dialed numbers list, press .

•To use voice commands, press and hold .

•To start the Web browser (network service), press and

hold .

Keypad lock (keyguard)

When the keys are locked, is displayed.

To lock the keys, press , then .

To unlock the keys, open the 2-way slide, or press , then .

To have the keypad lock activated automatically after a time-out

or when the 2-way slide is closed, press , and select Tools >

Settings > General > Security > Phone and SIM card.

When the keypad lock is on, calls may be possible to the official

emergency number programmed into your device.

Insert the (U)SIM card and battery

A USIM card is an enhanced version of the SIM card and is

supported by UMTS mobile phones.

Keep all SIM cards out of the reach of small children.

Always switch the device off and disconnect the charger before removing

the battery.

For availability and information on using SIM card services, contact your

SIM card vendor. This may be the service provider or other vendor.

1With the back of the device facing you, press the release

button, slide the cover, and lift it up.

2To release the (U)SIM card holder, lift the holder up from the

handle.

3Insert the (U)SIM card. Make sure that the contact area on

the card is facing the connectors on the device and the

bevelled corner on the card is facing the base of the device.

4Close the holder, and lock it into place.

5Insert the battery.

6Replace the cover so that the locking catches are directed

towards their slots, and slide the cover into place.

Switch the device on

1Press and hold .

2If the device asks for a (U)PIN code or

lock code, enter it, and press . The

factory setting for the lock code is

12345.

Your device has internal antennas.

Note: As with any radio transmitting

device, avoid touching an antenna unnecessarily when the

antenna is in use. For example, avoid touching the cellular

antenna during a phone call. Contact with a transmitting or

receiving antenna affects the quality of the radio

communication, may cause the device to operate at a higher

power level than otherwise needed, and may reduce the battery

life.

1Cellular antenna

2Bluetooth technology/

wireless LAN antenna

3GPS receiver

Charge the battery

1Connect a compatible charger

to a wall outlet.

2Connect the power cord to the

device. If the battery is

completely discharged, it may

take a while before the

charging indicator starts

scrolling.

3When the battery is fully

charged, the charging indicator

stops scrolling. Disconnect the charger from the device, then

from the wall outlet.

Support

Help

The help function provides instructions when using the device.

To access it from an application, select Options > Help.

User guide

Refer to the user guide for other important information about

your device.

Online

Check www.nokia.com.au/N95850/support or your local Nokia

web site for the latest version of the user guide, additional

information, downloads, and services related to your Nokia

product.

Nokia, Nokia Connecting People, Nseries, and N95 are trademarks or

registered trademarks of Nokia Corporation. Other product and company

names mentioned herein may be trademarks or tradenames of their

respective owners.

Reproduction, transfer, distribution, or storage of part or all of the

contents in this document in any form without the prior written

permission of Nokia is prohibited.
