Nokia N85 Get started
© 2008 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nseries, N85, Navi, and Nokia Care are trademarks or registered trademarks of Nokia Corporation. Other product and
company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia
is prohibited.
9208550/Issue 1
Keys and parts (front and top)
1— Earpiece
2— Selection keys
3— Call key
4— Menu key
5— Numeric keypad
6— Microphone
7— Navi™ wheel; hereafter referred to as scroll key
8— Clear key C
9— End key
10 — Multimedia key
11 — Light sensor
12 — Secondary camera
1— Power key
2— Nokia AV Connector for compatible headsets,
headphones, and TV-out connectors
3— Micro USB connector for charger and to connect
to a compatible PC
3
Keys and parts (back and sides)
1 and 9 — Stereo speaker with 3-D sound effect
2— Volume/Zoom key
3— Key lock switch for locking and unlocking the
keys
4— 2-stage capture key for auto-focus, still image
capture, and video recording
5— Main camera for high resolution image capture
and video recording
6— Flash and video light
7— Hole for a wrist strap
8— Memory card slot for a compatible microSD card
4
Short Slide keys
Short slide keys enable multitasking. For example,
if you are viewing images, with the Music player on
the background, and you want to skip to the next
or the previous track, press the Play/Pause key to
make the forward and rewind keys available.
1— Forward
2— Play/Pause
3— Stop
4— Rewind
5 and 8 — Zoom keys (available when they are lit)
6 and 7 — Game keys (available in the landscape
mode)
5
Insert SIM card and battery
Always switch the device off and disconnect the
charger before removing the battery.
1. With the back of the
device facing you,
press and hold the
release button and
lift up the cover.
2. Insert the SIM card
into the card
holder. Ensure that
the bevelled corner
on the card is facing
right, and that the
contact area on the
card is facing down.
3. Insert the battery.
4. To replace the cover,
direct the top locking
catch toward its slot
first and then press
down until the cover
locks into place.
6
Switch the device on
1. Press and hold the power key.
2. If the device asks for a PIN
code or lock code, enter it,
and press the left
selection key. The factory
setting for the lock code is
12345. If you forget the
code and your device is
locked, your device will
require service and
additional charges may
apply. For more
information, contact a Nokia Care point or your
device dealer.
7
Antenna locations
Your device may have internal and external
antennas. As with any radio transmitting device,
avoid touching the antenna area unnecessarily
while the antenna is transmitting or receiving.
Contact with such an antenna affects the
communication quality and may cause the device to
operate at a higher power level than otherwise
needed and may reduce the battery life.
1— Bluetooth and wireless LAN antenna, and GPS
receiver
2— FM transmitter antenna
3— Cellular antenna
Note that the Bluetooth, WLAN, GPS, and FM
transmitter antennas are located in the back cover
of your device. If you change the back cover, check
that the new cover includes these antennas,
otherwise these connections stop working.
8
Memory card
Use only compatible microSD cards approved by
Nokia for use with this device. Nokia uses approved
industry standards for memory cards, but some
brands may not be fully compatible with this device.
Incompatible cards may damage the card and the
device and corrupt data stored on the card.
Insert the memory card
A memory card may be already inserted in the
device. If not, do the following:
1. Place your finger in the recess beside the cover
of the memory card slot, and lift the cover. Pull
the cover to the left to reveal the hinge, and
swing the cover to the side.
2. Insert a compatible memory card
in the slot. Ensure that the
contact area on the card is facing
down and towards the slot.
3. Push the card in.
You can hear a
click when the
card locks into
place.
4. Push the hinge
back in, and
close the cover. Ensure that the cover is properly
closed.
Remove the memory card
Important: Do not remove the memory card
in the middle of an operation when the card is being
accessed. Removing the card in the middle of an
operation may damage the memory card as well as
the device, and data stored on the card may be
corrupted.
1. Before you remove the card, press the power
key, and select Remove memory card. All
applications are closed.
9
2. When Removing memory card will close all
open applications. Remove anyway? is
displayed, select Yes.
3. When Remove
memory card and
press 'OK' is displayed,
open the cover of the
memory card slot.
4. Press the memory card
to release it from the
slot.
5. Pull out the memory
card. If the device is switched on, select OK.
10
