Nokia N76-1
Get started
9254304 Issue 2 EN
2
Keys and parts (cover and fold open)
Hereinafter referred to as Nokia N76.
1Right cover key
2Middle key
3Left cover key
4Secondary camera with lower resolution
5Light sensor
6Selection keys and
7Menu key to access the main menu
8Multimedia key to access the multimedia menu
9Call key
10 End key
11 Edit key to open a list of commands when you edit
text
12 Clear key
13 Navi™ scroll key , , , (hereinafter referred
to as the scroll key) and middle selection key
14 Numeric keypad
3
Keys and parts (top and back)
1Power key
2Mini USB connector to connect to a compatible PC
(under USB cover)
3Nokia AV connector for compatible headsets and
headphones
4Zoom/volume/scroll keys
5Mode key
6Capture key
7Main camera for high-resolution image capture and
video recording
8Camera flash
9Charger connector
10 Memory card slot for a compatible microSD card
4
Insert the USIM card and battery
A USIM card is an enhanced version of the SIM card and is
supported by UMTS mobile phones.
Keep all SIM cards out of the reach of small children.
Always switch the device off and disconnect the charger
before removing the battery.
For availability and information on using SIM card services,
contact your SIM card vendor. This may be the service
provider or other vendor.
During extended operation, such as an active video sharing
session or high-speed data connection, the device may feel
warm. In most cases, this condition is normal. If you
suspect the device is not working properly, take it to the
nearest authorized service facility.
1Remove the instructive
foil from the battery
cover.
2With the back of the
device facing you,
remove the cover by
sliding it downwards.
3To remove the SIM tray
from the SIM tray slot,
pull the foil or the SIM
tray handle out.
4Insert the USIM card
into the SIM tray. Make sure that
the contact area on the card is
facing upwards, and that the
bevelled corner on the card is facing the bevelled
corner on the tray.
Tip! You can remove the foil from the bottom of
the SIM tray.
5
5Slide the SIM tray all the
way into the SIM tray
slot. Make sure that the
contact area on the card
is facing upwards, and
that the bevelled corner
is facing towards the
slot.
Note that the upper flap of the
SIM tray fits against the SIM
tray slot.
6Insert the battery.
7Replace the back cover.
Switch the device on
1Press and hold .
2If the device asks for a UPIN code
or lock code, enter it, and press
. The factory setting for the
lock code is 12345.
When you switch your device on for
the first time, it may ask you to select
a country and city and set the time
and date. To find the country or city,
enter the first letters of the name.
Your device has internal antennas.
Note: As with
any radio
transmitting
device, avoid
touching an
antenna
unnecessarily
when the antenna
is in use. For
example, avoid
touching the cellular antenna during a phone call.
Contact with a transmitting or receiving antenna
affects the quality of the radio communication, may
6
cause the device to operate at a higher power level than
otherwise needed, and may reduce the battery life.
1Cellular antenna
2Bluetooth technology
Insert a memory card
Use only compatible microSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored on
the card.
1To insert the memory
card, pull the microSD
cover out.
2Swing the microSD
cover open.
3Insert the memory
card in the slot. With
the back of the device
facing you, make sure
that the contact area
of the card is facing
down and towards
the slot.
4Push the card in. You hear a click
when the card locks into place.
5Close the cover. You cannot use
the memory card if the cover is
open.
Eject the memory card
1Before you eject the memory
card, press , and select
Remove memory card. All applications are closed.
2When Removing memory card will close all open
applications. Remove anyway? is displayed, select
Yes.
7
3When Remove memory card
and press 'OK' is displayed, open
the door of the memory card slot.
4Press the memory card to release
it from the slot.
5Pull out the memory card. If the
device is switched on, select OK.
Important: Do not remove the memory card in the
middle of an operation when the card is being accessed.
Removing the card in the middle of an operation may
damage the memory card as well as the device, and data
stored on the card may be corrupted.
8
Play music
Do not connect products that create an output signal as
this may cause damage to the device. Do not connect any
voltage source to the Nokia AV connector.
When connecting any external device or any headset,
other than those approved by Nokia for use with this
device, to the Nokia AV connector, pay special attention to
volume levels.
To listen to music in digital format
with the Music Player, plug a
headset into the audio connector. The
Music Player has two views: Music
menu to select music and Now
playing to listen to music.
Play music with the fold closed
1In the standby mode, press
to enter Music menu.
2Select the music you want to play,
and press .
In Now playing, use the quick cover
keys to control playback:
•Press to play or pause a song.
When you pause a song, a list of the tracks you are
currently listening to is displayed.
•Press to rewind the track or to skip backwards.
•Press to fast forward the track or to skip forward.
•To switch between Now playing and Music menu,
press .
Use the camera
Your device has two cameras, a high-resolution camera on
the back of the device and a lower resolution secondary
camera on the inside of the fold. Both cameras can be used
to take still pictures and videos.
Take pictures with the main camera
1To start the camera, press and hold the capture key for
more than 1 second.
The viewfinder opens.
2To take a picture, press the
capture key again.
To record video, open the
fold and select Options >
Video mode.
To use the secondary camera,
open the fold and select
Options > Use secondary
camera.
9
Support
Help
The help function provides instructions when using the
device. To access it from an application, select Options >
Help.
User guide
Refer to the user guide for other important information
about your device.
Online
Check www.nseries.com/support or your local Nokia
website for the latest version of the user guide, additional
information, downloads, and services related to your Nokia
product.
© 2007 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nseries, N76, and Navi
are trademarks or registered trademarks of Nokia
Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of
their respective owners.
Reproduction, transfer, distribution, or storage of part or
all of the contents in this document in any form without
the prior written permission of Nokia is prohibited.
