Nokia 500 Auto Navigation

Getting Started Guide

Issue 1 EN

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that this PD-14 product is in compliance

with the essential requirements and other relevant provisions of Directive 1999/

5/EC.

The product is in conformity with the limits defined in Directive 2004/104/EC

(amending Directive 72/245/EEC), Annex I, paragraph 6.5, 6.6, 6.8 and 6.9.

A copy of the Declaration of Conformity can be found at http://www.nokia.com/

phones/declaration_of_conformity/.

At the time of production of this document, the FM transmitter part of this

product is intended for use in the following countries: Belgium, Czech Republic,

Denmark, Estonia, Finland, Germany, Iceland, Liechtenstein, Luxembourg,

Norway, Portugal, Spain, Switzerland, Sweden, Turkey, United Kingdom. For the

latest information, refer to http://www.nokia.com.

Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other

product and company names mentioned herein may be trademarks or tradenames of their

respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document

in any form without the prior written permission of Nokia is prohibited.

Issue 1 EN

■Introduction

You can use the Nokia 500 Auto Navigation device for GPS navigation in

a car and outdoors. You can also make calls, view photos, watch videos,

and listen to music.

This guide briefly describes the setup and basic features of the

navigation device. Before using the device, carefully read the user guide

on the DVD that is supplied with the device. The user guide provides

important safety and maintenance information.

■Keys and parts

1. Cover of connector for an optional external GPS antenna

2. Power key

3. Cover of stereo audio-out connector

4. Indicator light

5. Touch screen

6. Volume down key

7. Menu key

8. Volume up key

9. Memory card with adapter

10.Memory card slot

11.Main power switch

12.Mini USB port/charger connector

13.Reset key

678

11 12 13

■First use

1. To switch on the device, slide the main power switch to the right.

In daily use, use the standby mode instead of switching the device

off. This way the device starts up faster. To set the device to (or to

exit) the standby mode, press and hold the power key for about 3

seconds.

2. When you are asked to calibrate the screen, tap and briefly press the

displayed crosshair with your finger. Repeat this as the crosshair

moves around the screen.

3. When you are asked to select the language, tap the desired language

and . The language is used for display texts and spoken navigation

instructions.

4. Carefully read and accept the displayed safety notice, and tap the

right arrow. The Navigator application starts and the map view is

displayed. Now you can start to use the device.

5. To set the date and time (including time zone and daylight saving),

press the menu key, and tap Setup.

■Set up Bluetooth connection

1. Switch on the navigation device and your compatible mobile phone.

2. Activate the Bluetooth feature on your phone. See the user guide of

your phone for instructions.

3. On the navigation device, press the menu key, and tap Phone.

4. When the device asks you to start pairing from your phone, set your

phone to search for Bluetooth devices, and select the navigation

device (Nokia PND) from the list of found devices on your phone.

5. Enter the passcode 0000 on your phone to pair and connect the

navigation device to it.

In some phones you may need to make the connection separately

after pairing. See the user guide of your phone for details.

6. When you are asked to download the contacts from your phone to

the navigation device, tap Yes if you want to use the contacts saved

in your phone with the navigation device.

■Install the device in a car

Attach the mobile holder to the mounting device using the supplied

screw (1), and snap the protection plate into place. To attach the

mounting device to the windscreen, carefully push the locking lever

toward the cup (2). Insert the navigation device into the mobile holder

(3), and press the device backwards so that the two arms of the holder

lock the device in place (4). (To release the device, push the arms.) To

adjust the vertical or horizontal position, use the screws (5) and (6).

To charge the internal battery, connect the supplied charger to the mini

USB port on the navigation device, and insert the charger plug into the

12 V cigarette lighter socket of your car.

To use the TMC (traffic message channel) service with the device, keep

the charger connected to the device as the charger includes the TMC

antenna.

■Basic operation

Touch screen

To use most features of the device, tap the screen with your finger.

Important: Avoid scratching the touch screen. Never use a pen

or pencil or other sharp objects to write on the touch screen.

Open applications from map screen

When you switch on the device, the map screen is displayed. This screen

shows the map view of the Navigator application.

To show or hide the application menu, press the menu key. To open an

application from the menu, tap its icon. The device includes the

following applications:

•Navigator ( ) for GPS navigation

•Phone ( ) to make and answer calls using the mobile phone

connected to the device

•Music ( ) to play songs saved on the memory card

•Gallery ( ) to view photos and watch video clips saved on the

memory card

•Setup ( ) to adjust settings and view information about the device

To return to Navigator from other applications, press the menu key.

To return to the previous screen in any application, tap .

To adjust the volume for the current application, press (or press and

hold) the volume up (+) or down (-) key.

The status indicators displayed in the upper right corner of the map

screen show the status of the GPS, Bluetooth, and TMC connection, and

the charge level of the internal battery.

■Navigator

Map

When the device has a GPS connection, Navigator shows your current

location on a map.

Tracking mode

When you are not navigating to a destination, Navigator is in the

tracking mode. In this mode, the map shows, for example, your GPS

position and the number of GPS satellites to which the device is

connected.

To browse the map, tap it to go to the browsing mode.

Navigation mode

When you are navigating to a destination, Navigator is in the navigation

mode. In this mode, the map shows, for example, the route to the

destination, current street, next street (and distance to it), speed,

estimated time of arrival, distance to the destination, and average speed

(if this function is set to on).

To browse the map, tap it to go to the browsing mode. To stop the

navigation, tap . To access the functions available during navigation,

tap .

Browsing mode

In the browsing mode, the bottom of the screen is orange, and north is

always on the top.

To select a location, zoom the map in or out if necessary, and move the

map with your finger until the cursor points to the desired location. Tap

and the desired option.

To return to the tracking mode or the navigation screen, tap .

Search for and navigate to a destination

You can search for a destination, for example, to navigate to it, to show

it on the map, or to save it for later use. To return to the previous screen,

tap .

To navigate to a destination, press the menu key, and tap Navigator >

Destination and one of the following:

•Address — you can enter the address of the destination. See

“Navigate to an address,” p. 8.

•POI search — you can search for the desired point of interest. See

“Navigate to a point of interest,” p. 9.

You can also navigate to a recently visited location (Recent), a

previously saved location (Favourites), or an address saved with a name

in your phonebook if it contains addresses (Contacts).

After you have set up the destination, tap and Navigate. The device

calculates the route to the destination and enters the navigation mode.

Navigate to an address

To search for an address to which you want to navigate, press the menu

key, and tap Navigator > Destination > Address. To select the country,

city (or postal code), street, and house number (optional), tap the fields

one by one, and enter the information in this order using the displayed

keypad.

Enter characters until you have narrowed down the search to only one

result, or tap and the desired address on the list. To scroll through

the list, tap the up or down arrow.

When you have found the address, tap in the Find address screen,

and tap the desired option. You can navigate to the address, add it to a

route (Via), save it as a bookmark, or view it on the map.

Navigate to a point of interest

You can search for a point of interest located near the desired location.

To navigate to a point of interest, press the menu key, and tap

Navigator > Destination > POI search. The starting point (usually your

current location) of the search is shown at the top of the screen. To

change the starting point, tap Where? and then Address to enter the

address, Favourites to select a previously saved address, or GPS position

to set your current location as the starting point.

Tap the category and subcategory for the point of interest. Alternatively,

tap , enter the name of the point of interest, and tap .

A list of found points of interest is displayed. The list is sorted by the

distance to the starting point. Tap the desired point of interest and the

option that you want to use.

Plan a route

You can plan your route in advance, also without GPS connection.

To plan a route, press the menu key, and tap Navigator > Destination.

Select the start point for the route in the same way as a destination, and

add it to the route (Via). When you tap Via, Destination list is displayed.

To add a waypoint to the route, tap +, and select the location in the

same way as a destination. To delete a stopover from the trip, tap the

stopover on the list and .

After you have set up the route, tap and Routing. After the route has

been calculated, a route summary is displayed. To view a detailed

waylist, tap the right arrow. To view the waypoints on the map, tap the

right arrow again. To move to the previous or next waypoint, tap the

arrow at the left or right side of the waypoint name. To return to the

previous screen, tap the left arrow.

Navigation settings

Press the menu key, and tap Navigator > Settings and one of the

following:

•General settings — You can select, for example, a voice for

navigation instructions (VoiceSkin), the distance unit, and how the

device reacts to TMC messages (Automatic, Manual, or Off).

•Map settings — You can select, for example, the 2D or 3D view and

toggle between the night and day modes.

•Route settings — You can select, for example, the desired mode of

transportation and define the routing settings, such as allow or avoid

motorways.

■Call handling

To connect the device to your phone using Bluetooth wireless

technology, press the menu key, and tap Phone > .

Call a saved contact

To call a contact that you have downloaded from your mobile phone,

press the menu key, and tap Phone > Contacts.

Enter the desired name using the displayed keypad. Tap or the name

list. To view the phone numbers saved with a name, tap the name. To call

a phone number, tap it.

To change the way contacts are sorted, or to download contacts from

the currently connected mobile phone, press the menu key, and tap

Phone > Settings > Sort order of contacts or Contacts download.

Other calling methods

To make a call, you can also use other dialling methods. Press the menu

key, tap Phone, and proceed in one of the following ways:

• To enter the phone number, tap Dial pad, and key in the number. To

call the number, tap . To end the call, tap .

• To call the last dialled number, tap Dial pad > , or tap Call

• If your phone supports voice dialling with the navigation device, tap

Voice dial to call a phone number saved in your phone using voice

dialling.

Autres manuels pour 500

Table des matières

Autres manuels Nokia Téléphone portable

Nokia

Nokia C5-06 Manuel utilisateur

Nokia

Nokia RM-598 Manuel utilisateur

Nokia

Nokia E72 Manuel utilisateur

Nokia

Nokia INTRIGUE 7205 Manuel utilisateur

Nokia

Nokia 7360 Intelligent Services Access Manager FX... Manuel utilisateur

Nokia

Nokia C3 Manuel utilisateur

Nokia

Nokia 6233 Manuel utilisateur

Nokia

Nokia 5320 XpressMusic Manuel utilisateur

Nokia

Nokia C5 Manuel utilisateur

Nokia

Nokia 8210 Manuel

Nokia

Nokia NPL-4 Series Manuel utilisateur

Nokia

Nokia 9500 - Communicator Smartphone 80 MB Instructions d'installation et d'entretien

Nokia

Nokia 150 Manuel utilisateur

Nokia

Nokia TA-1189 Manuel utilisateur

Nokia

Nokia 6175i Manuel utilisateur

Nokia

Nokia E55-1 Manuel utilisateur

Nokia

Nokia PRISM 7070 Manuel utilisateur

Nokia

Nokia 2610 - Cell Phone 3 MB Manuel utilisateur

Nokia

Nokia 2110 Instructions d'installation et d'utilisation

Nokia

Nokia Lumia 820 Manuel utilisateur

Nokia

Nokia 6235 Mode d’emploi

Nokia

Nokia 6600 slide Manuel utilisateur

Nokia

Nokia 6015i - Cell Phone - CDMA Manuel utilisateur

Nokia

Nokia 6300b RM-222 Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur

LG Thrive Manuel utilisateur
