Noble CX3 Manuel utilisateur

WWW.NOBLE-BIKES.COM

SECTION 01 I WELCOME TO THE FAMILY............................................................3

SECTION 02 I TECHNICAL INFORMATION............................................................4

SECTION 03 I MAINTENANCE............................................................................4

SECTION 04 I EXPLODED VIEW..........................................................................5

SECTION 05 I CABLE ROUTING..........................................................................6

SECTION 06I TORQUE SPECIFICATIONS...............................................................8

SECTION 07I REGISTRATION.............................................................................9

SECTION 08I ASSEMBLY...................................................................................9

SECTION 09I WARRANTY.................................................................................9

WWW.NOBLE-BIKES.COM

CONGRATULATIONS ON YOUR PURCHASE OF A NOBLE BIKE. WEL-

COME TO THE FAMILY!

Thank you for purchasing a Noble, we are condent that you will be happy

with your new bike. At Noble we strive to deliver high quality, excellent

value performance bikes that are within reach of the everyday enthusiast.

By purchasing a Noble, you’re leng us know we’re doing something

right. Thank you.

Yes, we know you’re excited to get rolling on your new rig, but please take

a moment to read this manual before you saddle up.

OWNER’S MANUAL

In addion to this model specic manual, we also have a generic owner’s

manual. Please download and read the owner’s manual. Cycling can be a

dangerous acvity and the owner’s manual contains important safety,

performance and service informaon. Please read the manual before you

take your new ride for a spin and keep it for reference.

The manual contains many warnings and cauons intended to keep you

safe. Failure to follow these recommendaons can result in a potenally

dangerous situaon, which if not avoided can result in serious injury or

death.

COMPONENT MANUALS

All Noble Bikes come equipped with components from a variety of suppli-

ers. If you are missing any of the component manuals, please download

the appropriate manual from the manufacturer’s website.

SERVICE AND MAINTENANCE

It is crical for your safety that your bike is properly maintained and ser-

viced at all mes. Bicycle technology is advancing at an ever increasing

pace, making bicycle components more complex. In order to minimize the

chances of injury, it is crical that all work on your bike is performed by a

qualied mechanic.

WWW.NOBLE-BIKES.COM

FRAME TECHNICAL SPECIFICATIONS

Your new CX3 comes with high quality components, but even the best

components will eventually wear out. In order to make the replacement

process as easy as possible, reference the list below when it’s the me for

some new parts.

Technical informaon

Fork Length 400mm

Fork Oset 52mm

Headset Top 1.125”-ID 42mm, Boom 1.5”-ID 52.1mm

Boom Bracket PF BB86, ID 41mm

Front Brake Flat Mount 160

Rear Brake Flat Mount 160

Front Axle 122x12mm, M12x1.5 Pitch

Rear Axle 172x12mm, M12x1.5 Pitch

Seat Post Diameter 27.2mm

Seat Clamp 31.8mm

Maximum Chain Ring 44 Tooth

Maximum Tire Size 700x40C

Warranty 5 Year

SHEDULE

WEEKLY

MONTHLY

3 MONTHS

ANNUALLY

Clean and lube chain X

Check re pressure X

Clean bike of dirt and debris X

Check brake funcon X

Check bolts and ghten if necessary X

Check brake pads, replace if necessary X

Check res, replace if necessary X

Check spoke tension, ghten if necessary X

Check chain for wear, replace if necessary X

Complete tune-up by qualied mechanic X

OVERVIEW

Following these guidelines will help keep your CX3 in good running order

and prevent most problems from arising. It is important to remember that

these service intervals vary depending on climate condions, road/trail

condions and your riding frequency. If you are unsure about working on

your own bicycle, always consult a qualied mechanic for more infor-

maon on bicycle maintenance.

WWW.NOBLE-BIKES.COM

ITEM# PART# DESCRIPTION QTY

1YU913-0-XXX CX3 FRAME, ALUMINUM, CYCLOCROSS, 700X33C 1

2UCHK03-M12 CX3 FORK, CARBON CYCLOCROSS, 700X33C 1

312Q52M12503 FRONT AXLE 125x12mm, M12x1.5 PITCH 1

412Q52M17201 REAR AXLE 172x12mm, M12x1.5 PITCH 1

502B-26158 CX3 HANGER KIT, DERAILLEUR HANGER 1

602B-26158 CX3 HANGER KIT, FLOATING NUT 1

702B-26158 CX3 HANGER KIT, STEP SCREW, SHCS M4XL13 1

8022-12011 CX3 CABLE GUIDE KIT, CABLE GUIDE 1

9022-12011 CX3 CABLE GUIDE KIT, FHCS M3XL6 1

WWW.NOBLE‐BIKES.COM

REARDERAILLEURCABLEREPLACEMENT

TheCX3hasinternalcableroungandreplacingtherearderailleurcable

cangosmoothlywiththerighttoolsandbyfollowingthesesteps.It’sa

straighorwardjobthatshouldtakearound30minutes.

STEP01.Witha4mmallenkey,

removethederailleurcablenut.

STEP02.Pullcableandhousing

throughthechainstaytoremove.

STEP03.Witha2mmallenkey,re‐

movetheboombracketcable

guide.



STEP04.witha2mmallenkeyre‐

movethedowntubecableguide



STEP05.Removecablehousingand

foamprotectorfromdowntube.



STEP06.Unwrapgeltapefromhan‐

dlebar.Ifyoudothiscarefully,you

canre‐usethetape.



TOOLSNEEDED

‐4mmAllenKey   ‐2mmAllenKey

‐CableandHousingCuer ‐AdjustablePliers

‐SideCuers‐HookandPickTools



‐OponalParktoolInternalRoungKit

‐Foropmalperformance,werecommendusinghighqualityshiercables

andhousingsuchasJagwire,SRAMorShimano.



NOTE;Feedingthenewcablethroughthechainstayisbestdonewiththe

bikeupsidedown.Gravitywillhelptoguidethecabletothecableentryon

topofthechainstay.TheParktoolInternalRoungKitcanalsobevery

usefulforfeedingnewhousingandcablethroughtheframe.

6

WWW.NOBLE‐BIKES.COM

STEP11.Install,cableguideand

foamprotectorovercablehousing.



STEP12.Feedcable,housingand

protectorthroughdowntube.Exit

housingatBoomBracket.

STEP13.Feedhousingthrough

boombracketcableguide.



STEP15.Tapederailleurhousing

andbrakelinetohandlebar.3M

strappingtapeworksreallywell.

STEP16.Rewrapthehandlebar,

payingaenontomirrortheoppo‐

siteside.



STEP07.Completelyremovethe

shierhousingfromthehandlebar.

STEP08.Withtheshierinthebig‐

gestgear,pushthecableunlit

comesoutoftheshierandremove

thecable

STEP09.Insertthenewcableand

pushunlitcomesoutoftheside

oftheshier.



STEP14.Installdowntubecable

guideandghtenwith2mmallen

key.



STEP10.Cutanewpieceofcable

housingtocorrectlengthandin‐

stalloverthederailleurcable



7

WWW.NOBLE‐BIKES.COM

STEP17.Usinga2mmallenkey,

removethechainstaycableguide.

STEP18.Feedthecablethroughthe

chainstay.Thisisbestdonewiththe

bikeupsidedown.(Gravityisyour

friend)

STEP19.Usinga2mmallenkey

installtheboombracketcable

guide.Itisbesttodothisaerthe

housingisfedthroughthechain

stay.

STEP20.Usinga2mmallenkey,

installthechainstaycableguide.



STEP21.Installderailleurhousing

andghtenthecablenutwitha

4mmallenkey.

FASTENERTORQUESPECIFICATIONS.

Correctghteningtorqueofthreadedfastenersisveryimportanttoyoursafety.

Alwaysghtenfastenerstothecorrecttorque.Incaseofaconﬂictbetweenthe

instruconsinthismanualandinformaonprovidedbyacomponentmanufacturer,

consultwithaqualiﬁedmechanicorthemanufacturer’scustomerservicerepre‐

sentaveforclariﬁcaon.

Alwaysuseacorrectlycalibratedtorquewrenchtoghtencricalfastenersonyour

bike.Carefullyfollowthetorquewrenchmanufacturer’sinstruconsonthecorrect

waytosetandusethetorquewrenchforaccurateresults.

8

STEP22.Withthecableinstalled,

adjustthederailleuraccordingto

themanufacturer’sspeciﬁcaons

andinstallanendcaptoprevent

frayingofthecable.

COMPONENT TORQUE

Derailleurhangerscrews 1‐2N.m,unlessotherwisespeciﬁed

RoadStemsteererclampscrews 5‐6N.m,unlessotherwisespeciﬁed

Stemhandlebarclampscrews 5‐6N.m,unlessotherwisespeciﬁed

Seatpostclampscrew 4‐5N.m,unlessotherwisespeciﬁed

Seatpostsaddleclampscrews 9‐10N.m,unlessotherwisespeciﬁed

Throughaxlefront 10‐11N.m,unlessotherwisespeciﬁed

Throughaxlerear 10‐11N.m,unlessotherwisespeciﬁed

Brandedcomponents Followmanufacturerstorquespeciﬁcaons

WWW.NOBLE-BIKES.COM

HERE’S WHAT YOU NEED TO KNOW ABOUT OUR WARRANTY.

All Noble Bikes are manufactured to high quality standards. We stand behind our

products, and we cover our bikes against manufacturing or material defects. Every

product has a useful life cycle and this will vary depending on the materials used and

the type of use the bike is subjected to. For this reason, we oer bike specic war-

ranty terms. The warranty applies to the original owner from the date of the retail

purchase and is not transferable. At the me of a claim, you must be able to present

proof of purchase.

The length of the warranty period for your bike is determined by the category of

use. Our bikes are separated in two categories. We oer a 3-Year, or a 5-Year war-

ranty to the original owner.

3-YEAR WARRANTY

Mountainbikes

5-YEAR WARRANTY

Gravel bikes and Cyclocross bikes

NOBLE BIKES

15641 19th Ave. SW

Burien, WA 98166

P: (206) 607-7764

PLEASE REGISTER YOUR NOBLE.

Registering your bike enables us to provide full warranty support and help us stay in

touch with you. In addion, it provides a record of your serial number, should your

bike ever get lost or stolen. To register your Noble Bike, you must create a Noble

account, or sign in to your account using the link at the top of any page on the Noble

website. When signed in, go to the “Register you Noble” secon and complete the

registraon.

ASSEMBLY INSTRUCTION VIDEOS.

All Noble Bikes require assembly. Our bikes come 85% assembled and the remaining

assembly can be performed by anyone with reasonable bicycle assembly skills. We

have created assembly videos that document the steps required to complete the

assembly of your bike. These videos are extremely helpful, especially if you have

never fully assembled a bike before.

To assure your safety, please take your bike to a qualied mechanic if you nd your-

self unsure about how to perform any of the steps required to assemble your bike.

Visit the support secon on the Noble website for the latest assembly videos.
