INFLATION
INFLATION
1. Clean an area, where the tent should be placed. Mainly sharp objects and chemicals have to be removed. Use of protecধon
blanket is recommended.
2. Remove tent from the bag, place it to its future posiধon.
3. Check posiধon and funcধon of all four valves. Due to an order of one way central inaধon system, the black inaধon valve
must be installed on posiধon signed with black arrow. A base part of black valve must be properly ধghted (check a valve seal
before use), small black cap must stay open. Red overpressure valves must be installed on other 3 posiধons, well ধghted to
prevent air leak. In a case tent was not used for longer ধme period, it is recommended to check funcধoning of all overpressure
valves by pushing the spring with a nger or blowing through the valve.Paralelly, seats of all valves shall be checked to avoid
sand grains or dirt to block closing the valve.
red overpressure valves black inaধon valve black arrow posiধon
4. Check correct placement of small roof over the central assembly
5. Connect a hose of pump to the black valve and start inaধon.
6. By the gradual acধon of springs in central inaধon system, legs of AXION tent are inated gradually.The rst inated leg is
one with installed black (inaধon) valve.In the second phase leđand right leg are inated.In the third phase a tranverse leg is
inated. In this step it is important to „help“ a leg to erect (see picture).
7. Connue an inaon within whole structure gets rigid, ideally ll the moment when one of overpressure valves would open
automacally. Overpressure valves are calibrated to the maximum allowable pressure, do not overpressure your tent more as
necessary. Do not disable overpressure valves, it may cause a bladder rupture!
8. Aer releasing an inaon hose, close and ght the small black cap of inaon valve .
9. Side walls and visors can be zipped on the tent all the me, but we rather suggest to install it to already inated tent. Each wall
or visor ts to each side of the tent. An artwork side of the wall may be faced to outside or inside of the tent. Check span of
legs before zipping the wall on the roof. Span of legs bigger as width of side wall can cause damage of zipper during zipping on
the wall. Try to minimaze a stress of zipper by fair handling. Secure end of zipper with velcro aer zipping on the side wall.
DEFLATION
1. Zip oall side walls and visors, pack each separately.
2. Open a valve on one leg, ideally on the leg which was last inated (diagonally to the inaon leg).Once some air is released and
internal pressure in the leg decrease, pull the leg to the transverse one. Aer whole tent will lay down, open rest 3 valves.
3. Once most of air is released, put legs to the paralell order, see picture below.
4, Rolling the tent in a direcon from small roof towards to valves. In this way you will release the rest of air out of the structure.
Unroll it and roll again to get a compact package, ng into the trolley bag. A last step before pung the package into the bag
is to screw all valves back into their posion.
5. Steel spikes must be packed in an extra pouch, which is included in a delivery.Put a pouch into separate pocket in a trolley bag.
Put spare parts and a repair kit into another separate pocket in a trolley bag. When all parts including side walls etc are in a trol-
ley bag, zip it on smoothly. If the volume is too big, use support tapes with trident buckles to bing the bag, decrease a volume
and help the zipper to prevent its damage.
