Nivona CafeRomatica 930 Manuel utilisateur

5 6 7 8910

Cafe Romatica

GB User manual

66 Control elements

CLARIS fresh water filter

Operating instructions

Warranty terms

Measuring spoon

2 Cleaning tablets

Test strips

(for measuring water hardness)

Connection tube for milk

WELCOME PACK

(included with machine)

2. CONTROL ELEMENTS

Frother

Type plate

(Remove drip tray)

Coffee grounds container

(inside)

Connection for milk tube

(in the drip tray)

Drip tray

Cover for coffee bean holder

Water tank with cover

On/off switch

Ground coffee shaft

Coffee bean holder

Display

Rotary dial

Height-adjustable

outlet with cover plate

(Frother behind)

Rear rollers (in back)

Cable compartment (in back)

Cup storage area

Service door with handle

(Brewing unit behind)

Connection for milk tube

(In the height-adjustable outlet)

3. Operation of the machine 7

Pressing

Turning

3. OPERATION OF THE MACHINE

3.1. Function switches

The NIVONA machine can be operated with the following switches:

3.2. Operation with the rotary dial

Turning

To select / navigate within the main menus Speciality Coffees, Settins and Maintenance,

and to change the setting options in the submenus and recipe menu.

Short press

To start / confirm the currently marked function.

In the Recipe menu, the first press selects the setting parameters and the next press

confirms the change.

A short press when the beverage is drawn cancels the procedure.

Long press

In the Speciality Coffees menu, a long press switches to the Recipe menu to change the

settings there.

Rotary dial

navigate / select / change /

confirm by turning

and pressing

Switch between the main

menus

exit

back / cancel / leave

8 Initial startup

3.3. Symbol functions

Currently marked symbol within

the menu is underlined. Symbol

description is displayed below the

Cancellation of a beverage draw or

deletion of a stored MY COFFEE

speciality in the menu Speciality

Coffees

Flashing rotary dial symbol re-

quires confirmation

Start of a beverage draw in the

menu Speciality Coffees

Process progress in the menu

Maintenance

Store changes

Even durin a coffee draw that has already started, various parameters can be changed by

turning the dial as lon as they are optically marked.

A beverage draw can be cancelled either with exit or with . If the draw is cancelled while

the parameters are still flashing, the symbol must be pressed 2x.

4. INITIAL STARTUP

4.1. Preparation

Remove the machine and other supplied parts from the packaging

Place the machine on a level, dry surface

(Ventilation slots must not be covered)

Connect the mains supply cable to a power socket which has been correctly installed

(Any unnecessary length of cable remains inside the cable compartment)

9Initial Startup 9

CAUTION

Insert filter straiht and do not overturn!

Screw filter

into water

tank

NOTE

If used with a filter, the ma-

chine does not need to be

descaled as often.

NOTE

Details on Operation of the Machine are

contained in Chapter 3, starting at page 7.

Milk tube – connected

to drip tray

Connect milk tube to the height-adjustable outlet and drip tray

Switch on machine

If the machine is switched on after the initial startup, it first heats up. If the automatic

switch-on rinse is activated, the display shows System rinsin and the rinse procedure starts

automatically. If the automatic switch-on rinse is deactivated, the display shows Please rinse

system, and the rinse procedure must be started by pressing the rotary dial.

4.2. Initial Start menu

The instructions on the display lead you through the Initial Start menu conveniently and

step-by-step.

Set language

Select the language with the rotary dial and confirm

Set filter

Select filter setting with the rotary dial

Operation without filter (factory setting)

Set the menu to No and confirm

with the rotary dial

When using the machine without a filter,

the water hardness must be entered in

the next step.

Operation with filter

Set the menu to Yes

Using the mounting aid at the end

of the measuring spoon, screw the

filter into the water tank and confirm

using the rotary dial.

10 Initial startup

Fill coffee

beans

Fill/rinse

system

Fill water tank

NOTE

At initial startup, the grind

chamber is still empty. After

the first grinding, it is possible

that Please fill coffee beans

is displayed and the machine

does not make coffee.

Press the rotary dial again

for an additional draw; the pro-

cess is then repeated

Test strips Deree of

hardness

Water hard-

ness display

≤

1 red point

1 - 7° DEGREE 1

2 red points 8 - 14° DEGREE 2

3 red points 15 -21° DEGREE 3

(Factory setting)

≥4 red points > 21° DEGREE 4

Set water hardness*

Immerse supplied test strip briefly in water, shake it off and read the test result after

about 1 minute

In the menu, use the rotary dial to select the water hardness read from the test strip

and confirm

Fill water tank (> 0.5l)

Remove the water tank and fill it with fresh, cold water without carbonation (no mineral

water), reinsert the tank, and confirm using the rotary dial

Do not fill any carbonated liquids or any other liquids, or the warranty is void!

Fill coffee bean holder

Fill the coffee bean holder with untreated, roasted coffee beans without foreign objects

or dirt and without sugar, then close the flavour protection cover well and confirm using

the rotary dial

Fill / rinse system, rinse filter

Place a large container (> 0.5 l) under the outlet and confirm using the rotary dial

For operation with filter, a second confirmation with the rotary dial is necessary to fill

the system and rinse the filter

Wait until no more water comes out of the outlet, then empty the container

* For operation without filter

11Menu navigation

Prepare Speciality Coffees

6.5.

Speciality

Coffees

Settings Maintenance

Speciality

Coffees

Connect milk source

Operation tutorial

At the end of initial startup, a short tutorial on the machine’s operation appears. All operating

functions that should be performed when they appear are shown on the display one after

another. As soon as an operating function has been performed, the next one appears. The

tutorial is ended with exit.

All settings that were determined during initial startup can be changed at any time in the

Settins menu.

5. MENU NAVIGATION

In the NIVONA machine, you can select the main menus Settins, Speciality Coffees, and

Maintenance. All available functions of the machine can be carried out within these main

menus.

Detailed information on navigation within and between the main menus is found in Chapter

3 starting at page 7.

6. PREPARE SPECIALITY COFFEES

6.1. Draw speciality coffee

Select the desired speciality coffee in the Speciality Coffees menu

For speciality coffees with milk, connect the milk-filled container (milk container, milk

refrigerator, Tetra Pack, or similar) to the lower end of the milk tube. The upper end

remains in the outlet

A short press on the desired speciality coffee begins the beverage draw

Switch

between the

main menus

exit

Back / cancel /

leave menu

12 Prepare Speciality Coffees

Recipe menu

Save Start beverage draw

in the Recipe menu

Frother rinsingConnect tube

After completion of the draw of a speciality coffee with milk, the display shows the

message / instruction to rinse the frother. The frother should then be rinsed as soon

as possible, but at the latest before switching off the machine. To do this, reconnect the

tube to the drip tray, and select and confirm the message / instruction on the display

using the rotary dial. Follow the instructions in the display up to the end of the program

and confirm each time with the rotary dial.

6.2. Recipe menu

The Recipe menu is a submenu in the individual speciality coffees. Here, the factory recipe

settings can be changed individually and stored permanently.

A long press of the rotary dial on the symbol of a speciality coffee leads to the Recipe

menu of the beverage

Adjustable parameters in the Recipe menu:

Bean strenth 1- or 2-cup function Quantity

(Coffee / milk foam /

water / milk, depending

on the speciality coffee)

Temperature Flavour profile

(DYNAMIC, CON-

STANT, INTENSE)

A short press on the activated Save symbol saves the beverage recipe with the changed

parameters

A short press on the activated Start symbol begins the beverage draw with the changed

parameters

13Prepare Speciality Coffees

First milk

1 cup 2 cups

DYNAMIC CONSTANT INTENSE

First

coffee

6.3. 2-cup function*

To fill two cups directly next to each other from the same beverage draw, a second cup must

be placed under the outlet and then either

Press the rotary dial briefly twice in succession to start beverage preparation (for the

current draw) or

Change the cup symbol in the Recipe menu of the speciality coffee (as permanent

recipe setting)

6.4. Cappuccino Connaisseur

By changing the sequence in the sequence symbol, cappuccino / caffè latte enthusiasts can

set in the Recipe menu whether the milk or the coffee goes into the cup first.

6.5. Flavour profiles

Changing the flavour profile (DYNAMIC | CONSTANT | INTENSE) in the Recipe menu

changes the brewing process and extraction from the beans and thus the taste of the coffee

(see also Chapter 7.3. Aroma Balance System on page 16).

6.6. MY COFFEE (for individual speciality coffees)

Up to 9 different beverages can be individually set, named, and stored with the NIVONA

machine.

To do this, in the Speciality Coffees menu select the menu option MY COFFEE

Select an existing beverage with a long press or add a new one with +

* Not for CAFFÈ AMERICANO, HOT WATER, MY COFFEE, ground coffee

MY COFFEE

14 Prepare Speciality Coffees

NOTE

If you accidentally open the ground coffee

shaft – or have not started a beverage draw

after adding ground coffee – the machine

is automatically rinsed about one minute

after the cover is closed again and is then

ready for use again.

CAUTION

The ground coffee shaft is not a storage

container. Therefore, never add more than

one portion to the shaft and use only fresh

or vacuum-packed ground coffee from

coffee beans.

Water-soluble instant coffee must not be

used!

Select a base recipe (speciality coffee), assign a name (if necessary, delete the MY

COFFEE presetting and save the name with OK), set the recipe individually and save it

A stored MY COFFEE recipe can be changed or edited with a long press of the rotary

dial on the corresponding symbol and also removed through confirmation of deletion

6.7. Prepare round coffee

Open the cover of the ground coffee shaft (underneath the cover on the upper right of

the machine)

The display shows Fill round coffee and close shaft lid

Add a level measuring spoon of ground coffee

Close cover and flap

The display shows when the ground coffee is ready

Place a cup in the middle below the coffee outlet

Select the beverage in the Speciality Coffees menu

Start preparation

Fill ground coffee

Save Confirm

deletion

Table des matières

Autres manuels Nivona Cafetière

Nivona

Nivona CafeRomantica NICR7 series Mode d’emploi

Nivona

Nivona CafeRomatica NICR626 Instructions de montage

Nivona

Nivona CafeRomatica 960 Manuel utilisateur

Nivona

Nivona CafeRomatica 830 Mode d'emploi

Nivona

Nivona CafeRomatica NICR9 Series Manuel utilisateur

Nivona

Nivona CafeRomatica NICR7 Manuel utilisateur

Nivona

Nivona CAFEROMATICA 710 Manuel utilisateur

Nivona

Nivona CafeRomatica 7 Manuel utilisateur

Nivona

Nivona CAFEROMATICA 610 Manuel utilisateur

Nivona

Nivona caferomatica NICR8 series Manuel utilisateur

Nivona

Nivona NICR646 Instructions de montage

Nivona

Nivona caferomatica NICR8 series Mode d'emploi

Nivona

Nivona NICR7 Series Mode d'emploi

Nivona

Nivona CafeRomatica 626 Manuel utilisateur

Nivona

Nivona cafefresco 410 Manuel utilisateur

Nivona

Nivona CafeRomatica 605 Mode d'emploi

Nivona

Nivona CafeRomatica NICR 520 Manuel utilisateur

Nivona

Nivona Cafe Romatica Manuel utilisateur

Nivona

Nivona CafeRomatica NICR7 Manuel utilisateur

Nivona

Nivona CafeRomatica 630 Mode d'emploi

Nivona

Nivona NICR646 Manuel utilisateur

Nivona

Nivona CafeRomatica 720 Mode d'emploi

Nivona

Nivona caferomatica NICR6 series Mode d'emploi

Nivona

Nivona CafeRomatica NICR10 Series Mode d’emploi

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

DeLonghi

DeLonghi DC300 Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

DeLonghi

DeLonghi ECI341 Manuel utilisateur

Krups

Krups KT406511 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur
