COMPLY
● Do not touch the equipment with wet hands or dip into water or splash water over the equipment.
It may cause electrification or trouble.
● Do not overhaul or modify equipment.
It may cause electrification and trouble.
● Do not use the equipment in location where operating temperature exceeds its range (0-
where explosive gas or corrosive gas is generated.
It may cause the equipment trouble or fire ignition.
● Do not put anything into the openings.
It may cause the equipment trouble or fire.
● The installation work on AC power must be performed by a qualified person.
● Please ensure that the terminal cover of AC power supply is attached properly after completion of
work. Otherwise it may cause electric shock.
● Wire connection to each terminal should be properly carried out in accordance with specified rating
and polarity. Incorrect wiring may cause trouble or fire.
● Carry out sufficient
checking of operating condition of interlocking devices in case of test operation.
Improper operation may cause damages to the equipment or cause danger to personnel.
● The equipment is for indoor use only. Do not install it outside.
It may cause malfunction.
● Please make sure wiring to smoke detector as two-wire connecting arrangement. (Do not connect
end-of-line resistor to end of detector line.)
● Maximum number of smoke detectors to be connected is 20. (Only 0KB3 can be connected but old model
0IB cannot be connected.)
● Smoke detector connection terminals (L+ and C-) have polarity.
● Please use shield wire for wiring in electromagnetic disturbing environment
● This equipment cannot be connected to detectors in automatic fire alarm system.
● The Smoke Detector Control Panel is operated in normal monitoring mode [Normal] or in setting mode [AD Set
by confirming [Mode SW] condition at initial time (power supply switch on time or reset operation time).
set to normal monitoring mode [Normal] at monitoring time and setting completion time.
If initial operation (power supply switch on or reset operation) is carried out by setting mode [AD Set
cannot be detected since system operates by setting mode.
● Make sure to check the equipment by activating smoke detectors.
Connect
Otherwise it may cause electric shock during the use
equipment or in the event of electric leakage.
