Nitho ADONIS CAMO MLT-ADOB-CMO Manuel utilisateur
adonis camo
QUICK START GUIDE
Model: MLT-ADOB-CMO
WIRELESS CONTROLLER
EN
THANK YOU FOR BUYING NITHO adonis.
WE WOULD LIKE TO INTRODUCE ITS
SPECIFICATIONS:
A、Full compatibility with PS4® console
B、 It’s equipped with the latest motion sensing technology
C、The built-in three-axis gyroscope and three-axis
accelerator can detect an omnidirectional dynamic
information including Roll, Pitch and Yaw
D、It’s also featured with a dual-point capacitive sensing
touchpad
E、3.5mm headset jack enables the audio chat
F、The frontal lightbar indicates the dierent players and
connection, glowing or lighting in dierent
colours
G、High performance analog triggers
SPECIFICATIONS
Micro-USB
Charging port
Stereo headset
3.5mm mini-Jack port
Built-in speaker
Ergonomic grip
1、Buttons List:
N (Home), Share, Option, ↑, ↓, ←, →, ×, ○, 口, △, L1,
L2, L3, R1, R2, R3, VRL, VRR, RESET.
2、Supports any version of PS4® Console
3、adonis keeps connected up to 10 meter`s distance from
the console
4、It’s equipped with a 6-axis sensor catching the
controller`s movements
5、RGB LED lightbar
5、It supports the dual-point capacitive sensing touchpad
6、Equipped with 3.5mm stereo headset jack that enables
the in-game chat
FEATURES
X-AXIS acceleration directions:
le→right, right→le
Y-AXIS acceleration directions:
front→back, back→front
Z-AXIS acceleration directions:
up→down, down→up
· PS4® CONTROLLER`S FUNCTIONS
· SIX-AXIS DETAILS
FUNCTION
- Sensor calibration is automatic
- adonis switches to Sleep mode if it fails to connect with
PS4® console or if it doesn’t receive any input for 30 minutes
- Charging mode (in use): Blue Light
- Charging mode (in stand-by): Orange Light
- Charging mode (not in use): Breathing Light
- Stand-by: Orange light
- Fully charged: Light o
- User`s connection mode:
Player 1: Blue light
Player 2: Red light
Player 3: Green light
Player 4: Pink light
- Lost connection mode: White light
· SENSOR CALIBRATION
· SLEEP MODE
· LIGHTBAR INDICATION
1. Connect the USB data cable to adonis and to the console
2. Press & Hold the “N” button, then the LED bar will light in
single color
· WIRELESS CONNECTION
Note:
- To establish the connection between adonis and the
console, it is required a USB to Micro-B data cable
- Aer the rst pairing, the data cable is no longer
needed for any further pairing
· ADONIS TEST MODE ON PC
Follow the below instructions for the testing keys in
Windows® 10
Connect
adonis
to your computer through the
Micro-B data cable, then follow the route:
PC →Start →Control Panel→Device and Printer
Then:
Double click on “Wireless Controller”
→
Properties
· BUTTONS LAYOUT PS4®-PC
CORRESPONDENCE
PS4® PC
1
× 2
O 3
4
L1 5
R1 6
L2 7
R2 8
SHARE 9
OPTION 10
L3 11
R3 12
PS 13
T-PAD 14
□
△
WWW.NITHO.COM NITHOGAMES NITHOGAMES
www.nitho.com
SERVICE & SUPPORT
For any question and support request, contact us on
www.nitho.com
NiTHO GmbH – Victoriastrasse 3b – 86150 Augsburg – Germany
