NISTA SD-30A Manuel utilisateur

Analog Door

Phones

Door Access Control with analog telephony interface

Installation and Programming Manual

Document Release: 1.15

Release 1.17_U4

April 2015

Analog Door Phone

Installation and Programming Manual

Door Access Control with Analog Telephony Interface

NOTICE

This document refers to the Nista Devices GmbH Door Access Control devices with analog telephony interface.

Additional copies of this manual may be obtained from Nista Devices GmbH. Reproduction of this manual or parts

thereof without written permission from Nista Devices GmbH is strictly prohibited.

Nista Devices GmbH reserves the right to modify the hardware and software described herein without prior notice.

However, changes made to the hardware or software described do not necessarily render this publication invalid.

Declaration of Conformity

Nista Devices GmbH. hereby declares that the Nista Devices GmbH Door Phone products SD-30X and SD-40X

series models complies with the essential requirements specified in the directive 1999/05/EC on radio equipment and

telecommunications terminal equipment and the mutual recognition of their conformity.

The technical documentation as required by the conformity Assessment procedure is kept at the following address:

Nista Devices GmbH, Pilatusstrasse 38, Lucerne, 6002, Switzerland , Tel: +41 55 508 5899

Table of Contents

1Cautions ....................................................................................................................................................................4

2Product Overview......................................................................................................................................................5

3The Door Phone kit content ......................................................................................................................................6

4The Door Phone Man Machine Interface (MMI)........................................................................................................7

5The Analog Door Phone Schematic setup................................................................................................................9

6Installation...............................................................................................................................................................10

6.1 Physical installation.........................................................................................................................................10

6.2 Electrical connections .....................................................................................................................................12

6.3 Internal / External Video Camera powering connector ...................................................................................14

7User’s Operations....................................................................................................................................................16

7.1 Access by using the ‘Door Access Code’ .......................................................................................................16

7.2 Door opening by using the Bypass Switch button...........................................................................................16

7.3 Call to the Day / Night Operator......................................................................................................................16

7.4 Direct Call to destination number....................................................................................................................17

7.5 Dialing by using Speed Dialing Memories ......................................................................................................17

7.6 Door opening from PBX Extension by using the Extension’s Door Opening Code ........................................18

7.7 The maximum conversation time....................................................................................................................19

7.8 Video Monitoring .............................................................................................................................................20

8Programming...........................................................................................................................................................21

8.1 Enter to programming mode ...........................................................................................................................21

8.2 To change the Day/Night operational mode: ..................................................................................................22

8.3 To reset the unit to factory default:..................................................................................................................22

8.4 Door Phone Programming codes....................................................................................................................23

8.5 Special DTMF Characters...............................................................................................................................25

9Technical specification............................................................................................................................................26

10 Appendixes..........................................................................................................................................................27

10.1 The Speed dialing memories table..................................................................................................................27

1 Cautions

Please read this User Manual carefully before using the product. Follow all instructions and recommendations

included in manual.

Any use of the product that is in contradiction with the instructions provided in manual may result in malfunction,

damage or destruction of the product.

The manufacturer shall not be responsible for any product damage incurred as a result of a use of the product other

than that included in manual and disobedience of the recommendations and warnings mentioned in manual.

Any use or connection of the product other than those included in manual shall be considered undue and the

manufacturer shall not be responsible for any consequences arisen as a result of such product usage.

Moreover, the manufacturer shall not be liable for any damage or destruction of the product incurred as a result of

incompetent installation and/or undue operation and use of the product in contradiction with instructions described in

manual.

The manufacturer assumes no responsibility for any malfunction, damage or destruction of the product caused by

incompetent replacement of parts or due to the use of reproduction parts or components.

The manufacturer shall not be liable and responsible for any loss or damage incurred because of a natural disaster or

any other unfavorable natural condition.

The manufacturer shall not be responsible for any damage of the product arising during the shipping thereof.

The manufacturer shall not make any warrant with regard to customer data loss or damage.

All applicable legal regulations concerning the product’s installation and use as well as provisions of technical

standards on electric installations have to be obeyed. The manufacturer shall not be liable and responsible for

damage or destruction of the product or damage incurred by the consumer in case the product is used and handled

contrary to the said regulations and provisions.

The consumer shall immediately change the default access password for the product after installation. The

manufacturer shall not be responsible for any damage incurred by the consumer in connection with the use of the

default product password.

The manufacturer also assumes no responsibility for additional costs incurred by the consumer as a result of making

calls using a public or another telephony line with an increased tariff.

2 Product Overview

This manual provides installation and programming instructions for the following products models:

Analog Door phone with the Touch or Piezo 16-buttons Keypads: SD-40A ,SD-40P, SD-40AC, SD-40PC

Analog Door phone with the Touch or Piezo Single Button: SD-41AC, SD-41PC

Analog Door phone with the Touch Single Button Mini housing edition: SD-30A, SD-30P

Model

Front Panel Description

SD-30A

Plastic Panel with Touch Sensitive Single Button

SD-30P

Aluminum Panel with Piezo Single Button

SD-40A

Plastic Panel with Touch Sensitive Keypad

SD-40P

Aluminum Panel with Piezo Keypad

SD-40AC

Plastic Panel with Touch Sensitive Keypad+Video

SD-40PC

Aluminum Panel with Piezo Keypad+Video

SD-41AC

Plastic Panel with Touch Sensitive Single Button+Video

SD-41PC

Aluminum Panel with Piezo Single Button+Video

Basic Features

PBX extension (SLT) analog line interface

Full telephony Keypad and Single Button configuration

Piezo outdoor and Touch indoor keypad housing

The Single button mini housing edition

Door Access Code protection

Day and Night calling to different pre-defined operators

Speed dialing memories

Direct call to a local and remote destinations

Door opening from remote extension during conversation

Telephony connection control:

oBusy tone detection

oTelephony line Loop disconnection detection

oContinuous tone detection and disconnection

High quality video control

Local and Remote maintenance

Administrator Login password protection

Digital volume control

The electrical door lock powering support

Anti-vandal housing

Reliable and stylish design

Indoor unit backlit keypad

Easy to install and support

3 The Door Phone kit content

The contents of the analog door phone are as follows:

The Door phone unit

External ~12V AC / 1.6 A power supply

Installation bracket

Installation kit which includes wall installation dowels and screws

Installation drill template

Enclosure opening secret screw with a key

Note:

1. Device is optionally available for orders with the internal color video camera.

The door phone unit with the installed internal video camera must be purchased separately.

2. Device with MINI housing supports the external video camera only

4 The Door Phone Man Machine Interface

(MMI)

The Door Phone front panel contains a built-in speaker, a microphone, Piezo or Touch-keypad and internal video

camera window (optional)

Figure 4-1 The Analog Door Phone Front Panel (Touch and Piezo Keypads editions)

The Analog Door Phone can be supplied in KEYPAD or SINGLE BUTTON editions.

The Analog Door phone Keypad edition equipped with the Touch or Piezo keypad 4x4: 16 buttons, where 12

buttons are standard telephone keypad: 0~9, * and # and additional row of 4 buttons are special functional buttons:

M1,M2 and M3: banks of speed dial memories

‘Ring’ button which shown on the keypad as ‘Bell’ icon purposed for the dialing and call cancellation

operations

Figure 4-2 Analog Door phone Keypad edition

The Analog Door phone Single Button edition equipped with the Single button keypad with button marked with the

‘Bell’ icon. This button is purposed for the call initialization and cancellation.

The Analog Door phone Single Button edition available in regular and mini housing. The unit’s physical dimensions

see in Chapter 9.

Figure 4-3 Analog Door Phone Single button edition with regular and mini housing

5 The Analog Door Phone Schematic setup

The Door Analog unit can be integrated with the office PBX (PABX) as simple analog extension/telephone

(SLT).

The unit powers the door lock, provided it is powered by an external supply

The unit powers the door lock, provided it is powered by its internal relay’s pins ( See Figure 6-4)

The unit dials to predefined ‘Day’ and ‘Night’ operators via PBX

The unit dials directly to local PBX extensions or external destination numbers via PBX

The unit dials to pre-programmed Speed Dial destination numbers via PBX

The unit opens doors by using the Bypass Switch button

The unit provides analog video stream directly to video monitor

Figure 5-1 details the unit schematic setup.

Figure 5-1 The Analog Door Phone schematic setup

6 Installation

6.1 Physical installation

The Door phone can be mounted on the installation bracket provided with the unit.

To install the Door Phone Touch keypad on the wall:

Open the Door Phone case by rotating the secret screw on the bottom of the unit.

Figure 6-1 Door Phone wall installation

To install wall bracket:

1. Measure and mark the location of the holes on the wall, where holes will be drilled.

2. Drill the holes and insert the wall dowels into the holes.

3. Attach rubber mat on the wall and then metal installation wall bracket using the provided wall screws. ( See

Figure 6-1 ). The rubber mat shall be directed to a wall with the rugged side.

4. Connect all required wired connections

5. Put the Door Phone’s front panel into the latch, then close the case and lock the secret screw
