5.7.3 MUTE function
When the receiver enter into MUTE status, it means the receiver will give out visual
LED flashing without sound.
5.7.3.1 Normal status to MUTE status
5.7.3.2 MUTE status to normal status
When the receiver is MUTE status, press receiver function button 1 time, LED4 will flash 1
time along with 1 beep, it enters into normal status(see Fig 14),then the LED3 of the
receiver flashes every 10 seconds to indicate the receiver is in working status (see Fig
9-4).
5.7.4 Low battery alarm
DI
LED2
short press
DI
LED4
short press
LED2 LED3 LED4
LED3LED1 LED2 LED4 LED5LED3LED1 LED2 LED4 LED5 LED3LED1 LED2 LED4 LED5
Fig15-2 Fig 15-3
Fig 13-1 Fig 13-2 Fig 14
Fig15-1
Short press function button 1 time, LED2 will flash 1 time along with 1 beep, it
enters into Mute status, then LED2, LED3, LED4 will flash every 10 seconds to
indicate the receiver is now MUTE status(see Fig 13-1/2).
When the transmitter battery is lower than 7V, it will send out signal to the receiver
every 30 seconds, when the receiver receive the transmitter low battery signal, the
receiver will turn on all the 5 LEDS at the same time, and then turn out from left to
right one by one to indicate that the transmittet buttery is low (see Fig15-1/2/3).
