Niles SVC100R Instructions d'utilisation d'origine

INSTALLATION & OPERATION GUIDE

BLENDING HIGH FIDELITY AND ARCHITECTURE®

High-Power Sliding Volume Control

SVC100R

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 2

TABLE OF CONTENTS

Introduction 1

Features and

Benefits 2

Installation

Considerations 3

Installation 5

Operation 6

Specifications 8

Contents 9

SVC100R

HIGH-POWER SLIDING VOLUME CONTROL

INTRODUCTION

The SVC100R is a wall mount, stereo sliding volume control. It connects between the speak-

er-level output of an amplifier, speaker selector, or distribution hub and a pair of speakers.

A perfect application for the SVC100R is adjusting the volume of remotely located speakers.

The SVC100R adjusts the volume of speakers connected to it by attenuating the amplifier sig-

nal. To assure minimal dissipation of internal power with virtually no power wasted as heat,

Niles volume controls use autoformers instead of L-pads as the volume-controlling element.

The SVC100R is an impedance-magnifying (IM) volume control. Unlike other brands, it has

additional autoformer windings that magnify the impedance of connected speakers,

while allowing all 12 steps to adjust the volume of the sound. Switches on the PC board select

these windings.

With the volume control providing impedance protection for your amplifier, you can create

systems with no additional impedance-matching devices between the volume control and

the amplifier.

In a typical application of IM controls, a system has eight pairs of 8-ohm speakers throughout

the house and in adjacent outdoor locations. Connect each pair of speakers to an IM volume

control with its switch in the 8x position, eliminating the need for an external impedance-

matching device to protect the amplifier. Even when playing all eight speaker pairs at once, the

amplifier runs at normal operating temperatures.

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 3

FEATURES AND BENEFITS

The SVC100R offers a number of improvements over other

volume controls:

• A universal impedance-magnifying design enables the

SVC100R to act as both a stereo and an impedance magni-

fying volume control. You can magnify the speakers’ imped-

ance by a factor of two, four, or eight.

• Unlike other impedance-matching volume-control products,

Niles IM volume controls maintain a 12-position adjustment

regardless of how much impedance magnification you use,

with total attenuation >54dB.

• Pop-free switching between all steps.

• Redesigned autoformers provide superior sonic performance,

exceeding the audio quality of non-impedance magnifying

volume controls.

• Isolated left and right-channel grounds ensure safety with

any amplifier.

• May be used with 4-, 6-, or 8-ohm speaker systems.

• Ideal for home and commercial sound installations.

• UL rated to comply with all local building codes.

• Available colors: almond, black, bone, brown and white.

• Installation requires only a screwdriver and wire stripper.

• Mounting depth of only 2-9/16". Fits into standard 18-cubic-

inch one-gang junction boxes.

• Power handling: 100W/channel RMS.

• Frequency response: 20Hz to 20kHz ±2dB.

• Ten years parts and labor warranty.

HIGH-POWER SLIDING VOLUME CONTROL

Some speakers have selectable impedance.

Before you proceed, please confirm that any

selectable-impedance speakers in your system

are properly set for the system you are installing.

TECH TIP

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 4

INSTALLATION CONSIDERATIONS

Calculating the Impedance Magnification Setting

Use the following instructions and the accompanying charts to

select the correct switch setting for the number and type of

speakers in your system.

CAUTION! Every speaker pair in the system must be connect-

ed to an impedance-magnifying volume control and set to the

same magnification.

1. Count the number of pairs of 4-ohm speakers and the num-

ber of pairs of 8-ohm speakers you are connecting. Count

pairs of 6-ohm speakers as 4-ohm pairs.

2. Determine whether the amplifier should see a 4-ohm load or

an 8-ohm load. This information is typically found in the

owner’s manual of the amplifier.

3. Read the correct switch position from the charts on page 7.

See Figure 4 if your amplifier can drive a 4-ohm load. See

Figure 5 if your amplifier must have an 8-ohm speaker load.

4. Set the switches on all of the controls to the same

position (1x, 2x, 4x, or 8x). See Figure 1 on page 5.

Limitations in Volume with High

Magnification Settings

Using an 8x setting limits the

power to each speaker pair to one-

eighth of the amplifier’s output.

In a typical application of IM vol-

ume controls, a system has eight

pairs of 8-ohm speakers throughout

the house and in adjacent outdoor

locations. Each pair of speakers is

connected to an IM volume control

with its switches set for 8x.

With eight pairs of speakers, one-eighth of the amplifier’s

power is available to any pair. Therefore, an amplifier rated at

100W per channel RMS into 8 ohms will deliver up to 12.5W

to each of the eight pairs – whether you play all eight pairs or

just one pair. This translates into a drop in the maximum vol-

ume capability of about 9dB at the 8x setting.

USING SPEAKER SELECTORS WITH IM VOLUME

CONTROLS

Although IM controls provide volume and on/off at the volume-

control location, they do not give you central control of speak-

ers playing throughout the house.

HIGH-POWER SLIDING VOLUME CONTROL

TOOLS REQUIRED

• 1/8" Standard

Slotted Screwdriver

• 1/4" Standard

Slotted Screwdriver

• Wire Stripper

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 5

Speaker-selection systems give you central control, but some

speaker selectors have non-defeatable impedance-protection

circuits. Combining IM controls with such a selector will

reduce your maximum volume substantially. To solve this

problem, specify a speaker selector with a defeatable protec-

tion circuit (Niles models HPS4, HPS6, SS-4, or SS-6). Keep the

protection circuit off at all times.

JUNCTION BOXES

The mounting depth of the SVC100R is 2-9/16". When

installed, the unit extends 2-1/16" behind the sheetrock wall

(assuming 1/2" sheetrock). For installation, use a standard 18-

cubic-inch (or larger) junction box. Suitable junction boxes are

available from your Niles dealer or local electrical-supply com-

pany.

TYPE OF SPEAKER WIRE

We recommend 16-gauge

stranded copper speaker

wire for most connections,

and 14-gauge wire for runs

longer than 80 feet. Don’t

use speaker wire larger

than 14 gauge, because

larger wire may not fit into

the connectors. Never use

solid-core, aluminum, or Romex wire with an IM volume con-

trol. For speaker-wire runs within walls, most U.S. states and

municipalities require a special type of speaker wire with a spe-

cific CL fire rating, such as CL-2 or CL-3. Consult your Niles

dealer, building contractor, or local building-inspection depart-

ment if you aren’t sure what kind of wire is best for your appli-

cation.

MOUNTING LOCATIONS

Some states or municipalities allow installation of devices such

as Niles speaker volume controls in the same junction box as

110V devices, with a low-voltage partition between the

devices. We do not recommend this, because speaker wires

can act as an antenna for electrical noise. Locating speaker

wires too close to a light switch or dimmer may cause the

speakers to emit a popping or buzzing sound. If you must

locate the volume control near electrical devices, install it in a

separate metal junction box, ground the box to the electrical-

system ground, and route the speaker wires several feet away

from the electrical wiring.

Convenient mounting locations include:

• Near doorways.

• Near a desk.

• At your bedside.

• Close to a telephone.

• Near other wall-mounted controls.

HIGH-POWER SLIDING VOLUME CONTROL

12 AWG

14 AWG

TECH TIP

Wire size is expressed by its

AWG (American Wire Gauge)

number. The lower the AWG

number, the larger the wire.

Thus, 12 AWG wire is physically

larger than 14 AWG.

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 6

DECORA®FACEPLATES

The SVC100R is designed to use Decora-

style faceplate mounting hardware. You

can combine multiple Decora-style mod-

ules (if all are low-voltage controls) within

one Decora faceplate (up to six-gang)

with color-matched plate screws. Decora

plates and screws are available from your

Niles dealer.

PREPARING FOR INSTALLATION

Before you install the SVC100R into an

existing wall, consider the possibility of

hidden obstructions inside the wall, such

as wood and metal studs; electrical, tele-

phone, or other wiring; plumbing; con-

duit; and old wall safes.

1. Install the junction box in the usual manner.

2. Run all necessary wiring to the volume control. Label the

wires for future reference.

INSTALLATION

1. Locate the connector plugs (and

remove them if they are

plugged in). See Figure 6 on

page 7.

2. Strip 1/4" of insulation from the

end of each wire. Tightly twist

the end of each wire until no

frayed ends remain.

3. Use a small flathead screwdriv-

er or your thumbnail to raise

the locking tabs, exposing the

holes on the removable con-

nector plug.

4. Insert each wire into the appro-

priate hole on the removable

connector plug, and snap the locking tab down.

NOTE: Maintain proper phasing. Connect the positive terminals

on the volume control to the positive terminals on the amplifi-

er and speakers, and connect the negative terminals on the vol-

ume control to the negative terminals on the amplifier and

speakers. See Figure 2. To help you avoid improper phasing,

the connector plug is keyed. Insert the smooth side of the con-

nector plug into the smooth side of the socket. Don’t force the

HIGH-POWER SLIDING VOLUME CONTROL

Figure 1

SVC100

From Amplifier

(Input)

To Speakers

(Output)

Speakers

Receiver

Figure 2

Wiring Diagram

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 7

scalloped side of the connector plug into the smooth side of the

socket. See Figure 6 on page 7.

5. Set the Impedance Magnification Switch (See Figure 1) as

determined by the IM charts (Figures 4 and 5 on page 7).

6. Plug the connectors into the volume control as shown in

Figure 6 on page 7. The inputs of the IM volume control are

the connector pins labeled AMPLIFIER. The outputs are the

connector pins labeled SPEAKERS.

NOTE: If you reverse these connections, the volume control

won’t function properly.

7. Secure the volume control to the junction box. Insert the

1-1/4" device screws into the oblong screw holes on the top

and bottom of the volume control. The oblong shape of the

screw holes helps you place the volume control in a vertical

position. Align the screws with the threaded holes

in the junction box. Tighten the screws using a Phillips

screwdriver. DO NOT OVERTIGHTEN. If necessary, loosen

these screws several turns so the volume control fits flush

with the faceplate.

8. Use the shorter plate screws to fasten the Decora faceplate

to the volume control.

9. Align all the screws in the same direction for a clean,

finished look.

OPERATION

1. Make sure the amplifier or receiver

power is OFF and set the volume to

minimum.

2. Set the volume on the volume control

to maximum.

3. If you are using a Niles speaker-

selection system, locate the ON/OFF

button that corresponds to the speak-

er pair you wish to play. Set it to the ON position. Make sure

the defeatable protection circuit is not enabled. See Using

Speaker Selectors with IM Volume Controls, on page 3.

4. Turn ON the amplifier or receiver and select a source, such

as the tuner or CD player.

5. Slowly turn up the amplifier or receiver volume and set it to

a comfortable – not maximum – listening level. Don’t over-

drive or "clip" your amplifier. If the sound becomes muddy or

distorted, you have reached the limit of your amplifier’s vol-

ume capability. Reduce the volume at once to avoid damag-

ing your speakers.

6. Use the volume control to adjust the volume of the speakers

to the desired listening level. If all the speaker pairs in your

system are equipped with Niles volume controls, you can set

the amplifier or receiver volume at one position and use the

Niles controls exclusively. 6

HIGH-POWER SLIDING VOLUME CONTROL

Figure 3

Loosening the Screws

for a Flush Fit

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 8

HIGH-POWER SLIDING VOLUME CONTROL

Figure 6

4x 8x

MPLIFIER’S MINIMUM SPEAKER LOAD IS 8 OHMS

8 OHM Speaker Pairs

4 OHM

Speaker

Pairs

012345678

1x 2x

AMPLIFIER’SMINIMUM SPEAKER LOAD IS4 OHMS

2x4x

01234567891011121314 15 16

8 OHM Speaker Pairs

4 OHM

Speaker

Pairs

Figure 5

Figure 4

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 9

7. To turn OFF the speakers, turn the knob on the volume con-

trol fully counter-clockwise, or press the ON/OFF button on

your speaker selector.

MAINTENANCE

Niles volume controls do not require any regular maintenance

other than occasional cleaning. Use a damp soft cloth and sim-

ply wipe the knob and wallplate clean. Do not use an abrasive

cleanser as this might scratch the surface of the wallplate.

SPECIFICATIONS

Audio Power Handling

100W/channel RMS

200W/channel peak music power

Mounting

In-wall, fits into most 18-cubic-inch single-gang junction boxes

at least 2-3/4" deep

Wiring Requirements

14-16 gauge, two individual runs of two-conductor speaker

wire, or one run of four-conductor speaker wire.

Unit Dimensions

1-5/8" wide x 2-5/8" high

Faceplate Dimensions

Faceplate: 2-3/4" wide x 4-1/2" high

Depth Behind Faceplate

2-9/16"

HIGH-POWER SLIDING VOLUME CONTROL

When using a receiver, set all of your IM volume

controls at maximum volume. Then turn up the

master volume on the receiver until you reach the

maximum listening level. Finally, turn down the

volume controls.

TECH TIP

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 10

HIGH-POWER SLIDING VOLUME CONTROL

CONTENTS

SVC100R

• SVC100 volume control

• Snap-on Decora color insert

• Decora wallplate

• Slider insert

• Device mounting screws X2

• Faceplate screws X2

• Removable speaker connector X2

DS00411ACN-SVC100R.qxp 5/5/05 5:38 PM Page 11

Autres manuels pour SVC100R

Table des matières

Autres manuels Niles Télécommande

Niles

Niles VCS-2D Instructions d'utilisation d'origine

Niles

Niles TVC-1 Instructions d'utilisation d'origine

Niles

Niles RCA-HT Manuel utilisateur

Niles

Niles R-6L Instructions d'utilisation d'origine

Niles

Niles REMOTE CONTROL ANYWHERE! RCA-TT2 Manuel utilisateur

Niles

Niles ZR-6 Instructions d'utilisation d'origine

Niles

Niles RCA-SM Manuel utilisateur

Niles

Niles iREMOTE TS Manuel utilisateur

Niles

Niles RCA-HT2 Manuel utilisateur

Niles

Niles MVC100IR Instructions d'utilisation d'origine

Niles

Niles RCA3 Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

Niles

Niles R-6L Manuel utilisateur

Niles

Niles iREMOTE TS Manuel utilisateur

Niles

Niles HR200 Manuel utilisateur

Niles

Niles INTELLIPAD CI Manuel utilisateur

Niles

Niles RCA-SM2 Manuel utilisateur

Niles

Niles RCA-TT Manuel utilisateur

Niles

Niles HDL-4 Instructions d'utilisation d'origine

Niles

Niles VCS-2S Manuel utilisateur

Niles

Niles RCA2 Instructions d'utilisation d'origine

Niles

Niles iREMOTE Manuel utilisateur

Niles

Niles VCS100 Instructions d'utilisation d'origine

Niles

Niles RCA-TT Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation

Invacare

Invacare G91S Manuel utilisateur
